[ConFoo 2015] PHP: Under The Hood

Performance issues can be caused by many things, from database interactions, i/o and, less frequently, the code itself.

This talk will take that profiling a step further and look under the hood of PHP, at the C internals of how things tick.

This talk covers what every PHP developer should know about their tools — like what's really going on when you use double quotes vs single quotes.

Transcript

1. PHP: Under the Hood
2. Proprietary and Confidential •Community Engineer at Engine Yard •Author of Zend PHP 5 Certification Study Guide, Sitepoints PHP Anthology: 101 Essential Tips, Tricks & Hacks & PHP Master: Write Cutting Edge Code •A contributor to Zend Framework 1 & 2, phpdoc, & PHP internals • Original creator of PHAR/ PHP_Archive • Lead for PHPWomen US •@dshafik Davey Shafik
3. Let’s start a conversation about mental health in tech mhprompt.org
4. How I Got Here
5. Profiling
6. Proprietary and Confidential • Profiling Records Relative Speed + Memory Usage + # of calls per function + Call graph • The act of profiling affects the speed (the outcome) of the code (just like quantum physics!) • Benchmarking Tests Actual Speed • What your users actually see Benchmarking Vs Profiling
7. The Performance Loop
8. Proprietary and Confidential The Performance Loop
9. When Should I Profile My Code?
10. Do I Have a Problem?
11. Proprietary and Confidential • The #1 issue with performance tuning, is assuming you even have a problem. • Premature Optimization is a waste of time. • Determine desired performance (e.g. 100 concurrent users with less than 1s response times). Benchmark on production hardware. Do you even have a problem? How big? Do I Have a Problem?
12. Common Causes of Slowdowns
13. Proprietary and Confidential • Datastore • Doesn’t matter if it’s PostgreSQL, MySQL, Oracle, MongoDB, CouchDB, or MSSQL • External Resources • APIs, Filesystems, Network Sockets, External Processes • Bad Code • The only great code, is code that never has to run. Everything else, is just good code. Common Causes of Slowdowns
14. Agenda There is no Magic Bullet You’re In Trouble
15. Agenda Internals 101
16. Agenda Execution Life Cycle
17. Proprietary and Confidential Execution Life Cycle of PHP
18. Proprietary and Confidential Execution Lifecycle with an OpCode Cache
19. Proprietary and Confidential Execution Life Cycle of PHP
20. Tokenizing
21. Proprietary and Confidential The Worst “Hello World”, Ever <?php class Greeting { public function sayHello($to) { echo "Hello $to"; } } $greeter = new Greeting(); $greeter->sayHello("World"); ?>
22. Token Name Value T_OPEN_TAG <?php T_CLASS class T_WHITESPACE T_STRING Greeting T_WHITESPACE { T_WHITESPACE T_PUBLIC public T_WHITESPACE T_FUNCTION function T_WHITESPACE T_STRING sayHello ( T_VARIABLE $to ) T_WHITESPACE { T_WHITESPACE T_ECHO echo T_WHITESPACE " T_ENCAPSED_AND_WHITESP ACE Hello T_VARIABLE $to " ; Token Name Value T_WHITESPACE } T_WHITESPACE } T_WHITESPACE T_VARIABLE $greeter T_WHITESPACE = T_WHITESPACE T_NEW new T_WHITESPACE T_STRING Greeting ( ) ; T_WHITESPACE T_VARIABLE $greeter T_OBJECT_OPERATOR -> T_STRING sayHello ( T_CONSTANT_ENCAPSED_STR ING "World" ) ; T_WHITESPACE T_CLOSE_TAG ?>
23. Proprietary and Confidential • Note the difference between interpolated and non-interpolated strings. • They are both double quoted strings! • Interpolated: 4 Tokens • Non-interpolated: 1 Token • Start to see why this matters for performance: but don’t get caught up by micro-optimizations. Tokenization " T_ENCAPSED_AND_WHITESPACE Hello T_VARIABLE $to " T_CONSTANT_ENCAPSED _STRING "World"
24. Defining a String
25. echo "bar"; T_ECHO echo T_CONSTANT_ENCAPSED_STRING "bar" T_ECHO echo " T_VARIABLE $a T_ENCAPSED_AND_WHITESPACE bar " T_ECHO echo " T_CURLY_OPEN { T_VARIABLE $a } T_ENCAPSED_AND_WHITESPACE bar " echo 'bar'; echo "$a bar"; echo "{$a} bar"; T_ECHO echo T_CONSTANT_ENCAPSED_STRING 'bar'
26. OpCodes
27. Agenda Vulcan Logic Dumper VLD
28. Proprietary and Confidential • An extension to dump the compiled opcodes • Installed via PECL
 $ pecl install vld-beta • Add the following to php.ini:
 extension=vld.so • Use via command line:

 $ php -dvld.active=1 -dvld.execute=0 <file> VLD - Vulcan Logic Dumper
29. Proprietary and Confidential • Outputs, in order: • global code (main script) • global functions • class functions VLD — Vulcan Logic Dumper
30. Proprietary and Confidential Header Understanding VLD Dumps Class Greeting: Function sayhello: filename: ./Greeting.php function name: sayHello compiled vars: !0 = $to number of ops: 8
31. Proprietary and Confidential Understanding VLD Output (Cont.) • line: The line number in the source file • #: The opcode number • *: entry (left aligned) and exit points (right aligned), indicated by greater than symbols (>) • op: The opcode name • fetch: Details on global variable fetches (super globals, or the use of the global keyword) • ext: Extra data associated with the opcode, for example the opcode to which it should JMP • return: The location where return data from the operation is stored • operands: the operands used by the opcode (e.g. two variables to concat) line # * op fetch ext return operands ----------------------------------------------------------------
32. Proprietary and Confidential VLD — Variables • Four types of variables Exclamation point (!) are compiled variables (CVs) — these are pointers to userland variables Tilde (~) are temporary variables used for temporary storage (TMP_VARs) of in-process operations Dollar ($) are another type of temporary variables (VARs) which are tied to userland variables like CVs and therefore require things like refcounting. Colon (:) are temporary variables used for the storage of the result of lookups in the class hashtable
33. Proprietary and Confidential class Greeting -> sayHello Class Greeting: Function sayhello: number of ops: 5 compiled vars: !0 = $to line # * op fetch ext return operands --------------------------------------------------------------- 3 0 > RECV !0 4 1 ADD_STRING ~0 'Hello+' 2 ADD_VAR ~0 ~0, !0 3 ECHO ~0 5 4 > RETURN null class Greeting { public function sayHello($to) { echo "Hello $to"; } }
34. Proprietary and Confidential class Greeting -> sayHello • RECV: The function receives a value which is assigned to !0 (which represents $to) • ADD_STRING: Next we create a temporary variable identified by a ~, ~0 and assign the static string,’Hello+', where the + represents a space • ADD_VAR: After this, we concat the contents our variable, !0 to our temporary variable, ~0 • ECHO: Then we echo that temporary variable • RETURN: Finally we return null as the function ends
35. Proprietary and Confidential Main Script number of ops: 9 compiled vars: !0 = $greeter line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > NOP 8 1 FETCH_CLASS 4 :1 'Greeting' 2 NEW $2 :1 3 DO_FCALL_BY_NAME 0 4 ASSIGN !0, $2 9 5 INIT_METHOD_CALL !0, 'sayHello' 6 SEND_VAL 'World' 7 DO_FCALL_BY_NAME 1 10 8 > RETURN 1 $greeter = new Greeting(); $greeter->sayHello("World");
36. Proprietary and Confidential Main Script • FETCH_CLASS: First we lookup the class, Greeting; we store this reference in :1 • NEW: Then we instantiate an instance of the class (:1) and assign it to a VAR, $2, and • DO_FCALL_BY_NAME: call the constructor • ASSIGN: Next we assign the resulting object (in VAR $2) to our CV (!0) • INIT_METHOD_CALL: We start calling the sayHello method, and • SEND_VAL: pass in 'World' to the method, and • DO_FCALL_BY_NAME: Actually execute the method • RETURN: The script ends successfully with an implicit return of 1.
37. Variables
38. Agenda Zend Value zval
39. Proprietary and Confidential • C data structure • Used to store all PHP variable ($foo) data • Probably the most important thing in PHP typedef struct _zval_struct { zvalue_value value; zend_uint refcount__gc; zend_uchar type; zend_uchar is_ref__gc; } zval; zval
40. Proprietary and Confidential zval member name value Stores the actual data refcount__gc Number of references to the zval type Stores the data type is_ref__gc Whether the variable is a reference
41. Proprietary and Confidential • C Union • Stores only one piece of data • Memory is as large as it’s largest member • Stores the actual data • Strongly Typed zval value typedef union _zvalue_value { long lval; double dval; struct { char *val; int len; } str; HashTable *ht; zend_object_value obj; } zvalue_value;
42. Strongly Typed
43. Proprietary and Confidential • At the C-level, values are strongly typed • PHP coerces the data automatically for things like comparisons • PHP never changes the zvals actual type Strongly Typed Data Type ZVAL type Value Storage Location NULL IS_NULL none Integer IS_LONG lval Float IS_DOUBLE dval String IS_STRING str.*val, str.len Array IS_ARRAY *ht Object IS_OBJECT obj Boolean IS_BOOL lval Resource IS_RESOURCE lval
44. References & Copy-on-Write
45. Proprietary and Confidential • To avoid copying values, PHP utilizes reference counting. • When one variable is assigned to another, it is always as a reference until the data is changed. • This is different from PHP references using & • Easier to show with examples References & Copy-on-Write
46. Proprietary and Confidential Refcounting $a = 1; // $a = zval#1(value=1, refcount=1) $b = $a; // $a = $b = zval#1(value=1, refcount=2) $c = $b; // $a = $b = $c = zval#1(value=1, refcount=3) $a++; // $b = $c = zval#1(value=1, refcount=2) // $a = zval#2(value=2, refcount=1) unset($b); // $c = zval#1(value=1, refcount=1) // $a = zval#2(value=2, refcount=1) unset($c); // zval#1 is destroyed, because refcount=0 // $a = zval#2(value=2, refcount=1)
47. Proprietary and Confidential Refcounting & PHP References $a = 1; // $a = zval#1(value=1, refcount=1, is_ref=0) $b =& $a; // $a = $b = zval#1(value=1, refcount=2, is_ref=1) $b++; // $a = $b = zval#1(value=2, refcount=2, is_ref=1) // Due to the is_ref=1 PHP directly changes the zval // rather than making a copy
48. Proprietary and Confidential Refcounting & PHP References $a = 1; // $a = zval#1(value=1, refcount=1, is_ref=0) $b = $a; // $a = $b = zval#1(value=1, refcount=2, is_ref=0) $c = $b // $a = $b = $c = zval#1(value=1, refcount=3, is_ref=0) $d =& $c; // $a = $b = zval#1(value=1, refcount=2, is_ref=0) // $c = $d = zval#2(value=1, refcount=2, is_ref=1) // $d is a reference of $c, but *not* of $a and $b, so // the zval needs to be copied here. Now we have the // same zval once with is_ref=0 and once with is_ref=1. $d++; // $a = $b = zval#1(value=1, refcount=2, is_ref=0) // $c = $d = zval#2(value=2, refcount=2, is_ref=1) // Because there are two separate zvals $d++ does // not modify $a and $b (as expected).
49. More OpCodes
50. Agenda More than one way to do it… Incrementing By One
51. Proprietary and Confidential Incrementing By One: Post-Increment number of ops: 4 compiled vars: !0 = $i line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > ASSIGN !0, 1 4 1 POST_INC ~1 !0 2 FREE ~1 3 > RETURN 1 $i = 1; $i++;
52. Proprietary and Confidential • ASSIGN: We assign the value (1) to the CV !0 • POST_INC: We increment the CV !0 and store it in the temporary variable, ~1. • FREE: Free the temporary variable (~1) Incrementing By One: Post Increment
53. Proprietary and Confidential Incrementing By One: Pre-Increment number of ops: 5 compiled vars: !0 = $i line # * op fetch ext return operands ----------------------------------------------------------------- 2 0 > ASSIGN !0, 1 4 1 PRE_INC !0 5 2 > RETURN 1 $i = 1; ++$i;
54. Proprietary and Confidential • ASSIGN: We assign the value (1) to the CV !0 • PRE_INC: We increment the CV !0 Incrementing By One: Pre-Increment
55. Proprietary and Confidential Incrementing By One: Re-assignment number of ops: 6 compiled vars: !0 = $i line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > ASSIGN !0, 1 4 1 ADD ~1 !0, 1 2 ASSIGN !0, ~1 5 3 > RETURN 1 $i = 1; $i = $i + 1;
56. Proprietary and Confidential • ASSIGN: We assign the value (1) to the CV !0 • ADD: We add the CV (!0) to 1 and assign it to a temporary variable ~1 • ASSIGN: We assign the temporary variable ~1 to the CV (!0) Incrementing By One: Re-Assignment
57. Proprietary and Confidential Incrementing By One: Assign-Add number of ops: 5 compiled vars: !0 = $i line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > ASSIGN !0, 1 4 1 ASSIGN_ADD 0 !0, 1 5 2 > RETURN 1 $i = 1; $i += 1;
58. Proprietary and Confidential • ASSIGN: We assign the value (1) to the CV !0 • ASSIGN_ADD: We add 1 to the CV (!0) Incrementing By One: Assign-Add
59. Agenda Quoting Strings
60. Proprietary and Confidential Quoting Strings: Single Quotes number of ops: 2 compiled vars: none line # * op etch ext return operands ---------------------------------------------------------- 2 0 ECHO 'bar' 3 1 > RETURN 1 echo 'bar';
61. Proprietary and Confidential Quoting Strings: Double Quotes echo "bar"; number of ops: 2 compiled vars: none line # * op etch ext return operands ---------------------------------------------------------- 2 0 ECHO 'bar' 3 1 > RETURN 1
62. Proprietary and Confidential Quoting Strings: Simple Interpolation number of ops: 5 compiled vars: !0 = $a line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 ASSIGN !0, 'foo' 3 1 ADD_VAR ~1 !0 2 ADD_STRING ~1 ~1, '+bar' 3 ECHO ~1 4 4 > RETURN 1 $a = 'foo'; echo "$a bar";
63. Proprietary and Confidential • ASSIGN: We assign the value ('foo') to the CV !0 • ADD_VAR: We create a temporary variable (~1) to hold our interpolate string, and assign the CV !0 to it • ADD_STRING: We append the string '+bar' to the temporary variable ~1 and assign it back to ~1 • ECHO: We output the string in our temporary variable ~1 Quoting Strings: Simple Interpolation
64. Proprietary and Confidential Quoting Strings: Complex Interpolation $a = 'foo'; echo "{$a} bar"; number of ops: 5 compiled vars: !0 = $a line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 ASSIGN !0, 'foo' 3 1 ADD_VAR ~1 !0 2 ADD_STRING ~1 ~1, '+bar' 3 ECHO ~1 4 4 > RETURN 1
65. Agenda Concatenation
66. Proprietary and Confidential number of ops: 4 compiled vars: !0 = $a line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > ASSIGN !0, 'foo' 4 1 CONCAT ~1 !0, '+bar' 2 ASSIGN !0, ~1 5 3 > RETURN 1 Simple Concatenation $a = "foo"; $a = $a . " bar";
67. Proprietary and Confidential • ASSIGN: We assign the value ('foo') to the CV !0 • CONCAT: We concatenate '+bar' to the compiled variable !0 and assign it to a temporary variable, ~1 • ASSIGN: We assign the complete string back to the compiled variable !0 Simple Concatenation
68. Proprietary and Confidential number of ops: 5 compiled vars: !0 = $a line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > ASSIGN !0, 'foo' 1 ASSIGN_CONCAT 0 !0, '+bar' 5 2 > RETURN 1 Assign-Concat $a = "foo"; $a .= " bar";
69. Proprietary and Confidential • ASSIGN: We assign the value ('foo') to the CV !0 • ASSIGN_CONCAT: We concat the value "+bar" to the CV !0 Assign-Concat
70. Function/Method Calls
71. Proprietary and Confidential number of ops: 2 compiled vars: none line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > DO_FCALL 0 'phpinfo' 3 1 > RETURN 1 Simple Function Call phpinfo()
72. Proprietary and Confidential number of ops: 4 compiled vars: none line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > SEND_VAL 1 1 SEND_VAL 3 2 DO_FCALL 2 'bcadd' 3 3 > RETURN 1 Function Call with Arguments bcadd(1, 3)
73. Proprietary and Confidential • SEND_VAL: Queue up two arguments to send to the function • DO_FCALL: Call the function Function Call with Arguments
74. Proprietary and Confidential number of ops: 5 compiled vars: none line # * op fetch ext return operands ------------------------------------------------------------------ 2 0 > NOP 7 1 SEND_VAL 1 2 SEND_VAL 3 3 DO_FCALL 2 'add' 8 4 > RETURN 1 Userland Function function add($a, $b) { $c = $a + $b; return $c; } add(1, 3);
75. Proprietary and Confidential Function add: number of ops: 6 compiled vars: !0 = $a, !1 = $b, !2 = $c line # * op fetch ext return operands --------------------------------------------------------------- 2 0 > RECV !0 1 RECV !1 3 2 ADD ~0 !0, !1 3 ASSIGN !2, ~0 4 4 > RETURN !2 5 5* > RETURN null Userland Function (cont.)
76. Proprietary and Confidential • RECV: Receive two arguments, assign them to compiled variables !0, !1 • ADD: Add the two variables, and assign to a temporary variable, ~0 • ASSIGN: Assign the result to a third compiled variables, !2 • RETURN: Return the third compiled variable Userland Function (cont.)
77. Proprietary and Confidential line # * op fetch ext return operands -------------------------------------------------------------------- 2 0 > NOP 7 1 FETCH_CLASS 4 :1 'foo' 2 NEW $2 :1 3 DO_FCALL_BY_NAME 0 4 ASSIGN !0, $2 8 5 INIT_METHOD_CALL !0, 'bar' 6 DO_FCALL_BY_NAME 0 9 7 INIT_METHOD_CALL !0, 'bat' 8 DO_FCALL_BY_NAME 0 10 9 > RETURN 1 Method Overloading (__call) class foo { public function bar() {} public function __call($a, $b) {} } $foo = new foo; $foo->bar(); $foo->bat();
78. Proprietary and Confidential • FETCH_CLASS: We do a class lookup and store the value in a temporary variable, :1 • NEW: We instantiate the class, assigning the object to temporary variable $2 (which requires refcounting) • DO_FCALL_BY_NAME: We call the constructor • ASSIGN: We assign the instantiated object in $2, to CV !0 • INIT_METHOD_CALL: We start calling the method • DO_FCALL_BY_NAME: We call the 'bar' method • INIT_METHOD_CALL: We start calling the method • DO_FCALL_BY_NAME: We call the 'bat' method Method Overloading (__call)
79. Proprietary and Confidential Feedback & Questions:
 Twitter: @dshafik Email: davey@engineyard.com Slides: http://daveyshafik.com/slides
