1. Messaging apps David Liman
2. Many out there.. Whatsapp, LINE, Facebook Messenger, iMessage, Skype, BBM, WeChat, Viber, Telegram..
3. Purpose To compare tech stack / architectural decisions: message transport, routing, storage Key goal: to learn from other people’s experience in building messaging systems
4. LINE
5. LINE Message transport • Adopting SPDY (Part1, Part2) ◦ not possible to send multiple requests in parallel ◦ redundant header fields like “User-Agent” ◦ long-polling drains device’s battery ◦ SPDY request multiplexing and response out of order ◦ header compression. not for all devices ◦ started with unsecured. need TLS ▪ prepackaged TLS per client installs Spoke to Mubarak (Layer HQ) at Erlang Factory as to why SPDY. In short answer: because we can. we control the clients and server (server push, rate limiting)
6. LINE Message protocol Apache thrift for RPC calls. No boilerplate code to serialize and transport objects Reversed engineered protocol https://github.com/cslinmiso/LINE-instant-messenger-protocol/
8. LINE Storage system • Redis (back in 2011) ◦ 3 nodes sharded on client side (with zookeeper) ◦ 1 million registered users. 1 billion rows per month in Jun 11. 5-10 billion rows per month in Mar. 12 • Evaluating: HBase, Cassandra, MongoDB ◦ HBase win How they choose?
9. LINE (Data Scalability) (n: # of Users) (t: Lifetime of LINE System) O(1) Messages in delivery queue Asynchronous jobs in job queue O(n) User Profile Contacts / Groups These data originally increase with O(n^2), but there are limitations on the number of links between users. (= O (n * CONSTANT_SIZE)) O(n*t) Messages in Inbox Change-sets of User Profile / Groups / Contacts
10. LINE (Data Requirement) O(1) Availability Workload: very fast reads and writes O(n) Availability, Scalability Workload: fast random reads O(n*t) Scalability, Massive volume Billions of small rows per day, but mostly cold data Workload: fast sequential writes (append-only) and fast reads of the latest data
11. LINE Global infrastructure • PoP (point of presence) ◦ network latency, keep the distance short between user and server. • CDN ◦ stickers, video upload speed
12. Telegram • Russian. Founder of VK social network • TCP/ IP • Custom message protocol (define how many bits header, auth, length, message body) • $300k security bounty • Open source clients: https://telegram.org/apps#source-code
13. Whatsapp Slack • Websocket • PHP • King of messaging • Patches to erlang BEAM http://highscalability.com/blog/2014/2/26/the-whatsapp-architecture- facebook-bought-for-19-billion.html
14. Links LINE Storing billion of rows in sharded redis and hbase • http://developers.linecorp.com/blog/?p=1420 LINE Server development and release process (in japanese) • http://developers.linecorp.com/blog/?p=2745 LINE Adopting SPDY • http://developers.linecorp.com/blog/?p=2381 • http://developers.linecorp.com/blog/?p=2729 Layer HQ - The art of powering the internet’s next messaging system • http://www.erlang-factory.com/static/upload/media/1427794729386661erlangfactory2015talklayer.pdf Whatsapp architecture http://highscalability.com/blog/2014/2/26/the-whatsapp-architecture-facebook-bought-for-19-billion.html
