What even is a table? A quick look at Accessibility APIs

Edd Sowden 
Senior Developer  
Government Digital Service 
@edds

View Slide

Accessibility and how to get the
most from your screenreader
!
What even is a table? A quick look
at Accessibility APIs
GDS
@edds

View Slide

*
I’m from the
Government
GDS
@edds

View Slide

We’re a team at the heart of
government building digital
public services
GDS
@edds

View Slide

*
We started
by building
GOV.UK
GDS
@edds

View Slide

*
The best
place to ﬁnd
government
services and
information
GDS
@edds

View Slide

GDS
@edds

View Slide

GOV.UK should work for
everyone
GDS
@edds

View Slide

I wrote a blog
post

View Slide

dimensions = ga:browser,ga:hour,ga:dayOfWeek
metrics = ga:users
filters = ga:browser==Internet Explorer
Which would get you something like: (view with your own data in the Query
Explorer)
Then using the TSV export button in the Query Explorer, found at the
bottom of the page, I can import the results into a Google Sheets and
produce a quick graph of the data.
For another example if we had a page which used a query string to let
users filter by a date field. You could get back all the different dates people
filtered by:
Browser Hour Day of Week Users
Internet Explorer 00 0 5895
… … … …
GDS
@edds

View Slide

GDS
@edds

View Slide

table {
display: block;
overflow-x: scroll;
}
GDS
@edds

View Slide

GDS
@edds

View Slide

What does this do to
accessibility software?
GDS
@edds

View Slide

Listen to your
websites

View Slide

How many of you use
Apple products regularly?
GDS
@edds

View Slide

GDS
@edds
How many of you test your
websites in a screenreader?

View Slide

Voiceover comes with
OS X and iOS
GDS
@edds

View Slide

The Voiceover Training is really good
GDS
@edds

View Slide

Let’s listen to it before I
made the change
GDS
@edds

View Slide

GDS
@edds

View Slide

And once I had added the
extra CSS…
GDS
@edds

View Slide

GDS
@edds

View Slide

The CSS display property
affects how accessibility
tech interprets the element
GDS
@edds

View Slide

…

GDS
@edds

View Slide

I had lunch

View Slide

“Can’t you just set an aria
role of table?”
@jaffathecake
GDS
@edds

View Slide

GDS
@edds

View Slide

Cell

GDS
@edds
Minimum viable table:

View Slide

GDS
@edds

View Slide

GDS
@edds
chrome://ﬂags/#enable-devtools-experiments

View Slide

GDS
@edds

View Slide

So our minimum viable
table isn’t a table?
GDS
@edds

View Slide

Let’s have a quick recap
on Accessibility APIs
GDS
@edds

View Slide

GDS
@edds

View Slide

Accessibility APIs!
!
Windows 7: MSAA/IAccessible
OSX: NSAccessibility
iOS: UI Accessibility
Android: Accessibility Framework
GDS
@edds

View Slide

role
name
state
children
GDS
@edds

View Slide

GDS
@edds
HTML to Platform Accessibility APIs Implementation Guide
W3C Working Draft 01 October 2013
This version:
http://www.w3.org/TR/2013/WD-html-aapi-20131001/
Latest published version:
http://www.w3.org/TR/html-aapi/
Latest editor's draft:
http://rawgithub.com/w3c/html-api-map/master/index.html
Previous version:
http://www.w3.org/TR/2012/WD-html-aapi-20130901/
Editors:
Steve Faulkner, The Paciello Group, [email protected]
Cynthia Shelly, Microsoft, [email protected]
Jason Kiss, New Zealand Government, [email protected]
Alexander Surkov, Mozilla Foundation, [email protected]
Copyright © 2011-2013 W3C® (MIT, ERCIM, Keio, Beihang), All Rights Reserved. W3C liability, trademark and document
use rules apply.
Select text and
ﬁle a bug

View Slide

GDS
@edds
svg
table
table
HTML4 Yes
HTML5 Yes
WAI-ARIA none
MSAA + UIA
Express
Role: ROLE_SYSTEM_TABLE
Use MSAA or UIA guidance
MSAA +
IAccessible2
Role: ROLE_SYSTEM_TABLE
Relations: IA2_RELATION_LABELLED_BY by child caption if any
Interface: IAccessibleTable2
UIA Control Type
and Other
Features
Control Type: Data Grid
Control Pattern: Table
AT-SPI Role: ROLE_TABLE
Relations: RELATION_LABELLED_BY by child caption if any
Interface: Table
AX AXRole: AXTable
AXSubrole: (nil)
AXRoleDescription: table
tbody
td

View Slide

Browsers use the DOM and CSS
to generate an accessibility tree.
This is then passed onto
accessibility APIs
GDS
@edds

View Slide

So what does it look like for
a “real” table?
GDS
@edds

View Slide

GDS
@edds

View Slide

What do other browsers
think of our minimum
viable table?
GDS
@edds

View Slide

GDS
@edds

View Slide

JAWS
GDS
@edds

View Slide

JAWS advances to the
next table with the ’t’
shortcut
GDS
@edds

View Slide

GDS
@edds

View Slide

GDS
@edds

Cell

View Slide

Browsers have heuristics
to protect us from table
based layouts
GDS
@edds

View Slide

……

……

GDS
@edds

View Slide

GDS
@edds

……

……

View Slide

……

……

[ … 18 more rows … ]

GDS
@edds

View Slide

GDS
@edds

……

……

[ … 18 more rows … ]

View Slide

Green

GDS
@edds

View Slide

GDS
@edds

Green

View Slide

……

……

GDS
@edds

View Slide

GDS
@edds

……

……

View Slide

table { display: block; }
!

……

……

GDS
@edds

View Slide

GDS
@edds
table { display: block; }
!

……

……

View Slide

td { border-bottom: 1px solid; }
!

……

……

GDS
@edds

View Slide

GDS
@edds
td { border-bottom: 1px solid; }
!

……

……

View Slide

td { background: grey; }
!

……

……

GDS
@edds

View Slide

GDS
@edds
!

……

……

View Slide

table { border-collapse: collapse; }
!

……

……

GDS
@edds

View Slide

GDS
@edds
table { border-collapse: collapse; }
!

……

……

View Slide

Let’s have a quick look
under the hood in Chrome
GDS
@edds

View Slide

GDS
@edds
102. bool AXTable::isDataTable() const
103. {
104. if (!m_layoutObject || !node())
105. return false;
106.
107. // Do not consider it a data table if it has an ARIA role.
108. if (hasARIARole())
109. return false;
110.
111. // When a section of the document is contentEditable, all tables should be
112. // treated as data tables, otherwise users may not be able to work with rich
113. // text editors that allow creating and editing tables.
114. if (node() && node()->hasEditableStyle())
115. return true;
116.
117. // This employs a heuristic to determine if this table should appear.
118. // Only "data" tables should be exposed as tables.
119. // Unfortunately, there is no good way to determine the difference
120. // between a "layout" table and a "data" table.
121.
122. LayoutTable* table = toLayoutTable(m_layoutObject);
123. Node* tableNode = table->node();
124. if (!isHTMLTableElement(tableNode))
125. return false;
126.
127. // Do not consider it a data table if any of its descendants have an ARIA role.
128. HTMLTableElement* tableElement = toHTMLTableElement(tableNode);
129. if (elementHasAriaRole(tableElement->tHead()))
130. return false;
131. if (elementHasAriaRole(tableElement->tFoot()))
132. return false;
133.
134. RefPtrWillBeRawPtr bodies = tableElement->tBodies();
135. for (unsigned bodyIndex = 0; bodyIndex < bodies->length(); ++bodyIndex) {
136. Element* bodyElement = bodies->item(bodyIndex);

View Slide

GDS
@edds
103. {
105. return false;
106.
109. return false;
110.
115. return true;
116.
121.
125. return false;
126.
130. return false;
132. return false;
133.
103. {
105. return false;
106.
109. return false;
110.
115. return true;
116.
121.
125. return false;
126.
130. return false;
132. return false;
133.

View Slide

GDS
@edds
167. // cells have borders, or use attributes like headers, abbr, scope or axis
168. table->recalcSectionsIfNeeded();
169. LayoutTableSection* firstBody = table->firstBody();
170. if (!firstBody)
171. return false;
172.
173. int numCols = firstBody->numColumns();
174. int numRows = firstBody->numRows();
175.
176. // If there's only one cell, it's not a good AXTable candidate.
177. if (numRows == 1 && numCols == 1)
178. return false;
179.
180. // If there are at least 20 rows, we'll call it a data table.
181. if (numRows >= 20)
182. return true;
183.
184. // Store the background color of the table to check against cell's background colors.
185. const ComputedStyle* tableStyle = table->style();
186. if (!tableStyle)
187. return false;
188. Color tableBGColor = tableStyle->visitedDependentColor(CSSPropertyBackgroundColor);
189.
190. // check enough of the cells to find if the table matches our criteria
191. // Criteria:
192. // 1) must have at least one valid cell (and)
193. // 2) at least half of cells have borders (or)
194. // 3) at least half of cells have different bg colors than the table, and there is cell spacing
195. unsigned validCellCount = 0;
196. unsigned borderedCellCount = 0;
197. unsigned backgroundDifferenceCellCount = 0;
198. unsigned cellsWithTopBorder = 0;
199. unsigned cellsWithBottomBorder = 0;
200. unsigned cellsWithLeftBorder = 0;
201. unsigned cellsWithRightBorder = 0;
167. // cells have borders, or use attributes like headers, abbr, scope or axis
168. table->recalcSectionsIfNeeded();
169. LayoutTableSection* firstBody = table->firstBody();
170. if (!firstBody)
171. return false;
172.
173. int numCols = firstBody->numColumns();
174. int numRows = firstBody->numRows();
175.
176. // If there's only one cell, it's not a good AXTable candidate.
177. if (numRows == 1 && numCols == 1)
178. return false;
179.
180. // If there are at least 20 rows, we'll call it a data table.
181. if (numRows >= 20)
182. return true;
183.
184. // Store the background color of the table to check against cell's background colors.
185. const ComputedStyle* tableStyle = table->style();
186. if (!tableStyle)
187. return false;
188. Color tableBGColor = tableStyle->visitedDependentColor(CSSPropertyBackgroundColor);
189.
190. // check enough of the cells to find if the table matches our criteria
191. // Criteria:
192. // 1) must have at least one valid cell (and)
193. // 2) at least half of cells have borders (or)
194. // 3) at least half of cells have different bg colors than the table, and there is cell spacing
195. unsigned validCellCount = 0;
196. unsigned borderedCellCount = 0;
197. unsigned backgroundDifferenceCellCount = 0;
198. unsigned cellsWithTopBorder = 0;
199. unsigned cellsWithBottomBorder = 0;
200. unsigned cellsWithLeftBorder = 0;
201. unsigned cellsWithRightBorder = 0;

View Slide

GDS
@edds
294. return true;
295.
296. // if there is less than two valid cells, it's not a data table
297. if (validCellCount <= 1)
298. return false;
299.
300. // half of the cells had borders, it's a data table
301. unsigned neededCellCount = validCellCount / 2;
302. if (borderedCellCount >= neededCellCount
303. || cellsWithTopBorder >= neededCellCount
304. || cellsWithBottomBorder >= neededCellCount
305. || cellsWithLeftBorder >= neededCellCount
306. || cellsWithRightBorder >= neededCellCount)
307. return true;
308.
309. // half had different background colors, it's a data table
310. if (backgroundDifferenceCellCount >= neededCellCount)
311. return true;
312.
313. // Check if there is an alternating row background color indicating a zebra striped style pattern.
314. if (alternatingRowColorCount > 2) {
315. Color firstColor = alternatingRowColors[0];
316. for (int k = 1; k < alternatingRowColorCount; k++) {
317. // If an odd row was the same color as the first row, its not alternating.
318. if (k % 2 == 1 && alternatingRowColors[k] == firstColor)
319. return false;
320. // If an even row is not the same as the first row, its not alternating.
321. if (!(k % 2) && alternatingRowColors[k] != firstColor)
322. return false;
323. }
324. return true;
325. }
326.
327. return false;
328. }
294. return true;
295.
296. // if there is less than two valid cells, it's not a data table
297. if (validCellCount <= 1)
298. return false;
299.
300. // half of the cells had borders, it's a data table
301. unsigned neededCellCount = validCellCount / 2;
302. if (borderedCellCount >= neededCellCount
303. || cellsWithTopBorder >= neededCellCount
304. || cellsWithBottomBorder >= neededCellCount
305. || cellsWithLeftBorder >= neededCellCount
306. || cellsWithRightBorder >= neededCellCount)
307. return true;
308.
309. // half had different background colors, it's a data table
310. if (backgroundDifferenceCellCount >= neededCellCount)
311. return true;
312.
313. // Check if there is an alternating row background color indicating a zebra striped style pattern.
314. if (alternatingRowColorCount > 2) {
315. Color firstColor = alternatingRowColors[0];
316. for (int k = 1; k < alternatingRowColorCount; k++) {
317. // If an odd row was the same color as the first row, its not alternating.
318. if (k % 2 == 1 && alternatingRowColors[k] == firstColor)
319. return false;
320. // If an even row is not the same as the first row, its not alternating.
321. if (!(k % 2) && alternatingRowColors[k] != firstColor)
322. return false;
323. }
324. return true;
325. }
326.
327. return false;
328. }

View Slide

What about the massive
fox in the room?
GDS
@edds

View Slide

GDS
@edds

View Slide

Firefox seems to be
different depending on
which screen reader
you’re using
GDS
@edds

View Slide

GDS
@edds
922 // performance problems only. Note, currently 'aAllowEmpty' flag is used for
923 // caption element only. On another hand we create accessible object for
924 // the first entry of caption element (see
925 // HTMLTableAccessible::CacheChildren).
926 return !!elements->Item(1);
927 }
928
929 bool
930 HTMLTableAccessible::IsProbablyLayoutTable()
931 {
932 // Implement a heuristic to determine if table is most likely used for layout
933 // XXX do we want to look for rowspan or colspan, especialy that span all but a couple cells
934 // at the beginning or end of a row/col, and especially when they occur at the edge of a table?
935 // XXX expose this info via object attributes to AT-SPI
936
937 // XXX For now debugging descriptions are always on via SHOW_LAYOUT_HEURISTIC
938 // This will allow release trunk builds to be used by testers to refine the algorithm
939 // Change to |#define SHOW_LAYOUT_HEURISTIC DEBUG| before final release
940 #ifdef SHOW_LAYOUT_HEURISTIC
941 #define RETURN_LAYOUT_ANSWER(isLayout, heuristic) \
942 { \
943 mLayoutHeuristic = isLayout ? \
944 NS_LITERAL_STRING("layout table: " heuristic) : \
945 NS_LITERAL_STRING("data table: " heuristic); \
946 return isLayout; \
947 }
948 #else
949 #define RETURN_LAYOUT_ANSWER(isLayout, heuristic) { return isLayout; }
950 #endif
951
952 DocAccessible* docAccessible = Document();
953 if (docAccessible) {
954 uint64_t docState = docAccessible->State();
955 if (docState & states::EDITABLE) { // Need to see all elements while document is being edited
956 RETURN_LAYOUT_ANSWER(false, "In editable document");
957 }
958 }
959
960 // Check to see if an ARIA role overrides the role from native markup,
961 // but for which we still expose table semantics (treegrid, for example).
962 if (Role() != roles::TABLE)
963 RETURN_LAYOUT_ANSWER(false, "Has role attribute");
964
965 if (mContent->HasAttr(kNameSpaceID_None, nsGkAtoms::role)) {
966 // Role attribute is present, but overridden roles have already been dealt with.
967 // Only landmarks and other roles that don't override the role from native
968 // markup are left to deal with here.
969 RETURN_LAYOUT_ANSWER(false, "Has role attribute, weak role, and role is table");

View Slide

GDS
@edds
927 }
928
929 bool
931 {
936
942 { \
947 }
948 #else
950 #endif
951
957 }
958 }
959
964
927 }
928
929 bool
931 {
936
942 { \
947 }
948 #else
950 #endif
951
957 }
958 }
959
964

View Slide

GDS
@edds
1089
1090 if (childIdx > 0 && prevRowColor != rowColor)
1091 RETURN_LAYOUT_ANSWER(false, "2 styles of row background color, non-bordered");
1092 }
1093 }
1094
1095 // Check for many rows
1096 const uint32_t kMaxLayoutRows = 20;
1097 if (rowCount > kMaxLayoutRows) { // A ton of rows, this is probably for data
1098 RETURN_LAYOUT_ANSWER(false, ">= kMaxLayoutRows (20) and non-bordered");
1099 }
1100
1101 // Check for very wide table.
1102 nsIFrame* documentFrame = Document()->GetFrame();
1103 nsSize documentSize = documentFrame->GetSize();
1104 if (documentSize.width > 0) {
1105 nsSize tableSize = GetFrame()->GetSize();
1106 int32_t percentageOfDocWidth = (100 * tableSize.width) / documentSize.width;
1107 if (percentageOfDocWidth > 95) {
1108 // 3-4 columns, no borders, not a lot of rows, and 95% of the doc's width
1109 // Probably for layout
1110 RETURN_LAYOUT_ANSWER(true,
1111 "<= 4 columns, table width is 95% of document width");
1112 }
1113 }
1114
1115 // Two column rules
1116 if (rowCount * colCount <= 10) {
1117 RETURN_LAYOUT_ANSWER(true, "2-4 columns, 10 cells or less, non-bordered");
1118 }
1119
1120 if (HasDescendant(NS_LITERAL_STRING("embed")) ||
1121 HasDescendant(NS_LITERAL_STRING("object")) ||
1122 HasDescendant(NS_LITERAL_STRING("applet")) ||
1123 HasDescendant(NS_LITERAL_STRING("iframe"))) {
1124 RETURN_LAYOUT_ANSWER(true, "Has no borders, and has iframe, object, applet or iframe, typical of advertisements");
1125 }
1126
1127 RETURN_LAYOUT_ANSWER(false, "no layout factor strong enough, so will guess data");
1128 }
1129
1130
1131 ////////////////////////////////////////////////////////////////////////////////
1132 // HTMLCaptionAccessible
1133 ////////////////////////////////////////////////////////////////////////////////
1134
1135 Relation
1136 HTMLCaptionAccessible::RelationByType(RelationType aType)
1137 {
1089
1090 if (childIdx > 0 && prevRowColor != rowColor)
1091 RETURN_LAYOUT_ANSWER(false, "2 styles of row background color, non-bordered");
1092 }
1093 }
1094
1095 // Check for many rows
1096 const uint32_t kMaxLayoutRows = 20;
1097 if (rowCount > kMaxLayoutRows) { // A ton of rows, this is probably for data
1099 }
1100
1112 }
1113 }
1114
1118 }
1119
1125 }
1126
1128 }
1129
1130
1131 ////////////////////////////////////////////////////////////////////////////////
1133 ////////////////////////////////////////////////////////////////////////////////
1134
1135 Relation
1137 {

View Slide

GDS
@edds
1099 }
1100
1112 }
1113 }
1114
1118 }
1119
1125 }
1126
1128 }
1129
1130
1131 ////////////////////////////////////////////////////////////////////////////////
1133 ////////////////////////////////////////////////////////////////////////////////
1134
1135 Relation
1137 {
1138 Relation rel = HyperTextAccessible::RelationByType(aType);
1139 if (aType == RelationType::LABEL_FOR)
1140 rel.AppendTarget(Parent());
1141
1142 return rel;
1143 }
1144
1145 role
1146 HTMLCaptionAccessible::NativeRole()
1099 }
1100
1112 }
1113 }
1114
1118 }
1119
1125 }
1126
1128 }
1129
1130
1131 ////////////////////////////////////////////////////////////////////////////////
1133 ////////////////////////////////////////////////////////////////////////////////
1134
1135 Relation
1137 {
1138 Relation rel = HyperTextAccessible::RelationByType(aType);
1139 if (aType == RelationType::LABEL_FOR)
1140 rel.AppendTarget(Parent());
1141
1142 return rel;
1143 }
1144
1145 role
1146 HTMLCaptionAccessible::NativeRole()

View Slide

So what does this all
mean?
GDS
@edds

View Slide

Accessibility
is more than
just markup

View Slide

Listen to your
websites

View Slide

…

GDS
@edds

View Slide

Thank you!!
!
!
Special thanks to:
Alice Bartlet, Robin Whittleton, Tom Byers,
Alex Muller, Léonie Watson, David Singleton,
Gemma Leigh and Jake Archibald
GDS
@edds

View Slide

Edd Sowden 
Senior Developer  
Government Digital Service 
@edds

View Slide

What even is a table? A quick look at Accessibility APIs

What even is a table? A quick look at Accessibility APIs

Edd S

More Decks by Edd S

Other Decks in Technology

Featured

Transcript
