Debugging techniques in Elixir - ElixirConf 2016

Ae362648af17ad86dbc65c56deed2192?s=47 Erich Kist
September 01, 2016

Debugging techniques in Elixir - ElixirConf 2016

Show some results in the standard output is the first experience in how to debug your code. What is the next step? Probably, the first answer that you found was: start the observer. After some minutes with an awesome feeling, you asked yourself: What I should look here?
In this talk, you will meet some tools, learn how to debug and profile your system, check crash dump and how to find and deal with the most common cause of failure. More than that, you will understand the concepts behind the reports and the observer tool.

Ae362648af17ad86dbc65c56deed2192?s=128

Erich Kist

September 01, 2016
Tweet

Transcript

  1. None
  2. Debugging techniques in Elixir

  3. debug |dēˈbəɡ| the process of identifying and removing errors from

    computer hardware or software.
  4. https://twitter.com/cerealvelocity/status/575826348414885888

  5. "Elixir leverages the Erlang VM" Erlang |> Elixir

  6. Erlang/OTP has applications to debug and maintain your application

  7. What I learned in my journey… • Tools used to

    debug applications. • When I can use each tool. • How I can analyze the system information. • How I connect to different nodes.
  8. @erichkist

  9. Sao Paulo - Brazil https://flic.kr/p/fyybDP

  10. Organize the tour to catch pokémons and back all of

    us with life
  11. consulting and software engineering Elixir coaching Elixir design review Custom

    development
  12. None
  13. http://elixir-lang.org/getting-started/introduction.html

  14. http://elixir-lang.org/getting-started/introduction.html

  15. IO.puts/2

  16. None
  17. iex(1)> IO.puts 1 1 :ok

  18. iex(1)> IO.puts {:a, :b} ** (Protocol.UndefinedError) protocol String.Chars not implemented

    for {:a, :b} (elixir) lib/string/chars.ex:3: String.Chars.impl_for!/1 (elixir) lib/string/chars.ex:17: String.Chars.to_string/ 1 (elixir) lib/io.ex:500: IO.puts/2
  19. IO.inspect/2

  20. iex(1)> IO.inspect {:a, :b} {:a, :b} {:a, :b} Win! \o/

  21. None
  22. IO.puts vs IO.inspect

  23. IO.puts: Chardata strings or lists of characters and strings

  24. IO.inspect: Inspect protocol transform any data structure into a readable

    textual representation
  25. http://elixir-lang.org/getting-started/protocols.html

  26. “From now on I'll only use inspect"

  27. |> Pipeability

  28. 1..10 |> Enum.take_random(3) |> Enum.map(&(&1 * 2))

  29. list = Enum.take_random(1..10, 3) IO.inspect list list |> Enum.map(&(&1 *

    2))
  30. 1..10 |> Enum.take_random(3) |> IO.inspect |> Enum.map(&(&1 * 2)) Awesome!!!

  31. 1..10 |> Enum.take_random(3) |> IO.inspect |> Enum.map(&(&1 * 2)) |>

    IO.inspect |> … |> IO.inspect |> … Awesome!!!
  32. Inspect.Opts

  33. 1..10 |> Enum.take_random(3) |> IO.inspect(label: "list") |> Enum.map(&(&1 * 2))

    list: [10, 2, 3] [20, 4, 6] Label
  34. 1..10 |> Enum.take_random(3) |> IO.inspect(label: “list") |> Enum.map(&(&1 * 2))

    |> IO.inspect(label: “after multiply") |> … |> IO.inspect(label: “after foo") |> … Label
  35. https://github.com/elixir-lang/elixir/commit/d6513a7 Label whatyouhide michalmuskala Thank you guys <3 Released?

  36. IO.inspect conn Limit

  37. %Plug.Conn{adapter: {Plug.Adapters.Cowboy.Conn, :...}, assigns: %{}, before_send: [#Function<0.7834419/1 in Plug.CSRFProtection.call/2>, #Function<4.100417920/1

    in Phoenix.Controller.fetch_flash/2>, #Function<0.82590416/1 in Plug.Session.before_send/2>, #Function<1.75806487/1 in Plug.Logger.call/2>, #Function<0.96656268/1 in Phoenix.LiveReloader.before_send_inject_reloader/1>], body_params: %{}, cookies: %{}, halted: false, host: "localhost", method: "GET", owner: #PID<0.381.0>, params: %{}, path_info: [], peer: {{127, 0, 0, 1}, 63732}, port: 4000, private: %{Chat.Router => {[], %{}}, :phoenix_action => :index, :phoenix_controller => Chat.PageController, :phoenix_endpoint => Chat.Endpoint, :phoenix_flash => %{}, :phoenix_format => "html", :phoenix_layout => {Chat.LayoutView, :app}, :phoenix_pipelines => [:browser], :phoenix_route => #Function<1.12450572/1 in Chat.Router.match_route/4>, :phoenix_router => Chat.Router, :phoenix_view => Chat.PageView, :plug_session => %{}, :plug_session_fetch => :done}, query_params: %{}, query_string: "", remote_ip: {127, 0, 0, 1}, req_cookies: %{}, req_headers: [{"host", "localhost:4000"}, {"connection", "keep-alive"}, {"cache-control", "max-age=0"}, {"upgrade-insecure-requests", "1"}, {"user-agent", "Mozilla/5.0 (Macintosh; Intel Mac OS X 10_11_5) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/52.0.2743.116 Safari/537.36"}, {"accept", "text/html,application/xhtml+xml,application/xml;q=0.9,image/webp,*/*;q=0.8"}, {"accept-encoding", "gzip, deflate, sdch"}, Limit
  38. IO.inspect conn, limit: 5 %Plug.Conn{adapter: {Plug.Adapters.Cowboy.Conn, :...}, assigns: %{}, before_send:

    [#Function<0.7834419/1 in Plug.CSRFProtection.call/2>, #Function<4.100417920/1 in Phoenix.Controller.fetch_flash/ 2>, ...], body_params: %{}, cookies: %{}, ...} Limit
  39. http://elixir-lang.org/docs/stable/elixir/Inspect.Opts.html

  40. “From now on I’m SURE I'll only use inspect"

  41. Code debuging

  42. IEx.pry/0 Inspect the state of a particular process

  43. defmodule Example do def double(list) do list |> Enum.map(&(&1 *

    2)) end end
  44. require IEx + IEx.pry

  45. require IEx defmodule Example do def double(list) do IEx.pry list

    |> Enum.map(&(&1 * 2)) end end
  46. Things to keep in mind: 1) lexical scope (its bindings

    and process info) 2) after allowed the pry, shell will be reset 3) a new shell will be started after respawn
  47. None
  48. IEx.pry with Phoenix

  49. chrismccord/phoenix_chat_example

  50. None
  51. defmodule Chat.RoomChannel do ... require IEx def handle_in("new:msg", msg, socket)

    do IEx.pry broadcast! socket, "new:msg", %{user: msg["user"], body: msg["body"]} {:reply, {:ok, %{msg: msg["body"]}}, assign(socket, :user, msg["user"])} end end web/channels/room_channel.ex
  52. fail $ mix phoenix.server Cannot pry #PID<0.336.0> at web/channels/ room_channel.ex:44.

    Is an IEx shell running?
  53. $ iex -S mix phoenix.server success

  54. IEx.pry with tests

  55. $ mix test Cannot pry #PID<0.244.0> at test/ chat_test.exs:7. Is

    an IEx shell running? fail
  56. $ iex -S mix test success

  57. It blocks the process Don’t use it in production

  58. IEx.pry isn’t a tradicional debugger

  59. :debugger Erlang Debugger for debugging and testing

  60. iex(1)> :debugger.start() {:ok, #PID<0.87.0>}

  61. You can set almost anything in the graphical tool

  62. iex(2)> :int.ni(Chat.RoomChannel) {:module, Chat.RoomChannel}

  63. None
  64. None
  65. None
  66. It blocks the process Don’t use in production environment

  67. Unlike some debuggers, you can’t change all the values of

    the bound variables…
  68. pid, reference, binary, or port values cannot be changed

  69. development & production mode

  70. Code & Behavior debugging

  71. https://flic.kr/p/8k9JhZ

  72. Erlang VM

  73. Multicore, Schedulers and Reductions

  74. Symmetric Multi-Processing SMP takes full advantage of multiple CPU architectures

  75. For every core, the BEAM virtual machine starts a thread

    that runs a scheduler
  76. https://hamidreza-s.github.io/erlang/scheduling/real-time/preemptive/migration/2016/02/09/erlang-scheduler- details.html

  77. Preemptive and reduction count

  78. Scheduler working Queue Scheduler Done

  79. Process done Queue Scheduler Done

  80. Scheduler runs new process Queue Scheduler Done

  81. Scheduler will run the process Process reduction count: 0 Scheduler

    reduction limit: 500 Scheduler fake values
  82. process is running Process reduction count: 123 Scheduler reduction limit:

    500 Scheduler fake values
  83. process is running Process reduction count: 123 Scheduler reduction limit:

    500 Scheduler cheap function fake values
  84. process is running Process reduction count: 999 Scheduler reduction limit:

    500 Scheduler expensive function fake values
  85. Process is preempted Queue Scheduler Done

  86. Scheduler working Queue Scheduler Done

  87. Scheduler working Queue Scheduler Done

  88. :observer Tracing and investigation of distributed systems

  89. iex(1)> :observer.start() :ok

  90. Common errors

  91. CPU bottleneck

  92. None
  93. None
  94. CPU is very hard to profile

  95. The VM does a lot of work unrelated to processes

    when it comes to scheduling
  96. To avoid going to sleep when work is low, the

    threads that control the Erlang schedulers will do busy looping
  97. None
  98. High reduction count usually means a high amount of CPU

    usage
  99. None
  100. None
  101. None
  102. None
  103. None
  104. Memory leak

  105. None
  106. Memory types

  107. 3 mistakes to avoid

  108. ETS tables are never garbage collected Only removing records manually

    will reclaim memory
  109. Don’t use dynamic atoms Atoms go in a global table

    and are cached forever!
  110. Message queue the most common cause of failure

  111. http://learnyousomeerlang.com/the-hitchhikers-guide-to-concurrency

  112. None
  113. Identifying errors

  114. Crash Dump Travel machine!

  115. erl_crash.dump

  116. :observer > File > Examine Crashdump

  117. None
  118. Tracing

  119. :et, :dbg, :ttb (:observer) Some tracing modules in the Erlang

  120. None
  121. None
  122. None
  123. None
  124. None
  125. None
  126. None
  127. None
  128. None
  129. andytill/erlyberly

  130. None
  131. Connect to a remote node

  132. It isn’t hard! but… you may find troubles.

  133. module :observer can be not available Releases are self contained

    packages without unnecessary applications
  134. iex(node@remote)1> :observer.start ** (UndefinedFunctionError) undefined function :observer.start/0 (module :observer is

    not available) :observer.start()
  135. :runtime_tools low footprint tracing/debugging tools in a production system

  136. def application do [mod: {Chat, []}, applications: [:runtime_tools, …]] end

    mix.exs
  137. server without graphical interface

  138. Name your remote node

  139. ## Name of the node -sname my_app ## Cookie for

    distributed erlang -setcookie my_cookie running-config/vm.args
  140. Erlang Port Mapper Daemon daemon acts as a name server

    on all hosts involved in distributed Erlang computations
  141. EPMD Port: 4369

  142. $ iex --sname my_app@localhost --cookie my_cookie -S mix phoenix.server

  143. EPMD Port: 4369 Port: 64722 my_app

  144. $ epmd -names epmd: up and running on port 4369

    with data: name my_app at port 64722
  145. Run :observer in a standalone node to minimize the impact

    of the system being observed
  146. $ iex --sname observer@localhost --cookie my_cookie --hidden -e ":observer.start"

  147. EPMD Port: 4369 my_app Port: 64722 :observer Port: 64749

  148. $ epmd -names epmd: up and running on port 4369

    with data: name observer at port 64749 name my_app at port 64722
  149. None
  150. SSH Port forwarding local EPMD port -> remote EPMD port

  151. http://blog.plataformatec.com.br/2016/05/ tracing-and-observing-your-remote-node/

  152. SASL System Architecture Support Libraries

  153. Redirects supervisor, crash and progress reports to Logger

  154. 09:27:51.872 [info] Child Logger.ErrorHandler of Supervisor Logger.Supervisor started Pid: #PID<0.78.0>

    Start Call: Logger.Watcher.watcher(:error_logger, Logger.ErrorHandler, {true, true, 500}, :link) Restart: :permanent Shutdown: 5000 Type: :worker 09:27:51.884 [info] Application logger started at :nonode@nohost 09:27:52.174 [info] Child Mix.State of Supervisor Mix.Supervisor started Pid: #PID<0.86.0> Start Call: Mix.State.start_link() Restart: :permanent Shutdown: 5000 Type: :worker
  155. $ iex --logger-sasl-reports true -S mix

  156. def application do [mod: {Chat, []}, applications: [:sasl, …]] end

    mix.exs
  157. Recap!

  158. Some tools we can use only for development..

  159. System information is different…

  160. crash dump is your friend

  161. You can run observer (and others tools) locally connected in

    your remote nodes!
  162. Next steps

  163. http://erlang.org/doc/applications.html

  164. None
  165. h4cc/awesome-elixir

  166. None
  167. "Measuring your Elixir Application” Talk by Renan Ranelli - Track

    2 - 3:30PM
  168. https://www.youtube.com/watch?v=4u6c2FNauYE

  169. https://www.youtube.com/watch?v=mrKwM9g6baQ

  170. https://www.erlang-in-anger.com/

  171. Thank you! @erichkist https://speakerdeck.com/erichkist
