1. Reconciliation Testing Aspects of
   Trading Systems Software Failures
   Anna-Maria Kriger, Kostroma State Technological University
   Alyona Pochukalina, Obninsk Institute for Nuclear Power Engineering
   Vladislav Isaev, Yuri Gagarin State Technical University of Saratov
   Exactpro Systems
   ANALYSIS OF IMAGES, SOCIAL NETWORKS, AND TEXTS
   April, 10-12th, Yekaterinburg


   View Slide

2. Introduction
   • Our team is performing functional and non functional testing for
   electronic trading and post trade platforms
   • We are collecting information available about software outages
   and problems into our knowledge base to improve our test
   coverage and design more efficient ways to do our work
   • This paper describes the concept of reconciliation testing
   • We studied two major software disasters in financial services
   that led to substantial losses – Knight Capital and Facebook IPO
   • This paper focuses only on reconciliation controls and testing
   procedures relevant to these events
   • We plan to proceed with researching data reconciliation tools
   applicability in software testing and developing a reference
   implementation of a scalable real-time tool for reconciliation
   testing based on the proprietary market surveillance platform


   View Slide

3. Data Reconciliation
   Reconciliation is a process of finding discrepancies in
   data obtained from different sources.
   In accounting, reconciliation refers to the process of
   ensuring that two sets of records, usually account
   balances, match each other.
   In the financial markets, data reconciliation systems help
   asset managers to reconcile trades, cash and security
   flows, balances and positions between different systems,
   e.g. internal data stored by the trading participant vs.
   external data received from counterparties, brokers,
   clearers, custodians, etc.


   View Slide

4. Reconciliation Testing
   Reconciliation testing is a process of using data
   reconciliation tools to validate the system in parallel with
   other activities


   View Slide

5. Data Reconciliation Tools
   The main aspects of data reconciliation tools are:
   •Passive test tools
   •Serve as test oracles
   •Can be used with HiVAT methods
   •Should be used during negative test cycles
   •Require extra resources


   View Slide

6. Knight Capital Events
   • 1 August 2012, USA
   • Knight Capital – one of the most successful HFT firms
   • Implemented changes related to Retail Liquidity
   Program at NYSE
   • SMARS – an ultra-fast order router
   • Source code responsible for legacy functionality
   PowerPeg
   • 212 parent orders, millions child orders
   • Accumulated loss – $460m or $170k/sec
   • Incorrectly configured risk systems
   • Deployment on 7 servers instead of 8…


   View Slide

7. Knight Capital Events


   View Slide

8. Knight Capital Events


   View Slide

9. Knight Capital Stock Chart


   View Slide

10. Regulated Exchange


    View Slide

11. Facebook IPO on NASDAQ
    • 18 May 2012, NASDAQ, One of the largest IPOs in history
    • Secondary trading is preceded by a designate Display Only Period
    (DOP)
    • Multi-component architecture that included Matching Engine, IPO
    Cross Application and Execution Application
    • At the end of the DOP, NASDAQ’s “IPO Cross Application”
    analyzes all of the buy and sell orders to determine the price at
    which the largest number of shares will trade; then NASDAQ’s
    matching engine matches the buy and sell orders at that price.
    Usually takes 1-2 ms
    • NASDAQ allowed orders to be cancelled at any time up until the
    end of the DOP, including the very brief interval during which the
    IPO cross price is calculated. After calculation was completed, the
    system performed orders validation check between ME and “IPO
    Cross Application”. If any of the orders were cancelled after the
    start of the cross, the system would have to repeat the calculation


    View Slide

12. Facebook IPO on NASDAQ
    • Over 496k orders participated in the cross, and its duration
    exceeded 20ms
    • Order cancellation arrived during this period, and the application
    had to repeat the calculation. Two more cancellations arrived
    during the second iteration, and four more - during the third one
    • IPO Cross Application went into infinite loop at 11:05
    • The NASDAQ team switched off validation check on the
    secondary system and performed failover 25 minutes after the
    start of the loop
    • Unknown at that moment, 38k orders submitted between 11:11
    and 11:30 were stuck and did not participate in the uncross. It
    created another discrepancy, this time with Execution App and
    Members who were not able to receive confirmation for orders
    executed in the cross until 13:50


    View Slide

13. Failover Proposal


    View Slide

14. Failover Proposal


    View Slide

15. Facebook IPO Stock Chart


    View Slide

16. Comparison
    • Both Knight and NASDAQ had a set of reconciliation controls
    • In both cases they were not properly covered by testing:
    – Knight – reconciliation check stopped working years ago
    – NASDAQ – control was working, but operational procedure
    applicable to the case when it fails has not been tested
    • In both cases, monitoring systems notified operational team about
    a problem, however information provided was not enough to
    identify the source of the problem and react appropriately
    • In neither case a good balance between automatic and manual
    processing existed:
    – Some of Knight controls were not automatically connected to
    block real-time processing and prevent sending erroneous
    orders
    – On the opposite, the NASDAQ ones automatically halted
    processing, but the option to unblock the control wasn’t tested


    View Slide

17. Market Surveillance System


    View Slide

18. Market Surveillance System
    It is possible and beneficial to use market surveillance system as a
    reconciliation testing tool for the following reasons:
    •all required data is collected from the system and available both
    real-time and in the database;
    •most of surveillance systems are configured as a downstream
    component and do not affect the main transactional path;
    •rules engine allows creating data reconciliation checks and raise
    alerts when they fail;
    •order book replay allows studying the exact source of the
    discrepancy.


    View Slide

19. Questions and Answers
    Thank you!
