Swift Optimizing at Compiler World

@NSSpain 2020 Remote Edition

Transcript

1. Swift Optimizing at Compiler World
   NSSpain 2020: Remote Edition, November 20th 2020
   Yuki Aki from LINE Fukuoka


   View Slide

2. About Me
   Yuki Aki (freddi)
   iOS Engineer at LINE Fukuoka


   View Slide

3. Activity & Community
   Developing LINE Creators Studio at LINE Fukuoka


   View Slide

4. Activity & Community
   Writing Swift for 2 years
   Swift Compiler, XcodeGen etc …
   Contributed to OSS Projects
   As a Speaker at many conferences


   View Slide

5. About Me
   Yuki Aki (freddi)
   iOS Engineer at LINE Fukuoka


   View Slide

6. Swift Optimizing at Compiler World


   View Slide

7. Agenda
   Why need to learn Swift Compiler (Optimizer)?
   Basis of Swift Compiler
   Swift Intermediate Language (SIL)
   SIL Optimizer


   View Slide

8. Agenda
   Why need to learn Swift Compiler (Optimizer)?
   Basis of Swift Compiler
   Swift Intermediate Language (SIL)
   SIL Optimizer


   View Slide

9. Agenda
   Why need to learn Swift Compiler (Optimizer)?
   Basis of Swift Compiler
   Swift Intermediate Language (SIL)
   SIL Optimizer


   View Slide

10. Agenda
    Why need to learn Swift Compiler (Optimizer)?
    Basis of Swift Compiler
    Swift Intermediate Language (SIL)
    SIL Optimizer


    View Slide

11. Agenda
    Why need to learn Swift Compiler (Optimizer)?
    Basis of Swift Compiler
    Swift Intermediate Language (SIL)
    SIL Optimizer


    View Slide

12. Swift Compiler


    View Slide

13. Why need to learn
    Swift Compiler (Optimizer)?


    View Slide

14. Why learn about Swift Compiler?
    Increase ways to solve difficult problems in Swift Coding
    Compiling Time, Compiler Bugs, Effective Code …
    Start Contributing to Swift Language
    So Fun


    View Slide

15. Why learn about Optimizer?
    Easy to learn!
    Helpful to know what happened on Compiling for Product
    And how to try to solve problems related to Optimizer


    View Slide

16. Agenda
    Why need to learn Swift Compiler (Optimizer)?
    Basis of Swift Compiler
    Swift Intermediate Language
    SIL Optimizer


    View Slide

17. Basis of Swift Compiler


    View Slide

18. Basis of Swift Compiler
    Looks Difficult?
    Don’t be afraid! I’ll describe Complier easily!


    View Slide

19. Flow of Compiling Swift Code

    App


    View Slide

20. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Flow of Compiling Swift Code


    View Slide

21. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Flow of Compiling Swift Code


    View Slide

22. AST
    Flow of Compiling Swift Code
    Convert to Abstract Syntax Tree by grammar rule of Swift
    Syntax Tree is a format for compiler to understand Code easy
    Parser


    View Slide

23. AST AST
    (Typed)
    Flow of Compiling Swift Code
    AST to Typed AST
    Checking Type of the Code by generated AST or Type-Error
    Sema


    View Slide

24. AST
    (Typed)
    SIL
    Flow of Compiling Swift Code
    SILGen
    Typed AST to Swift Intermediate Language(SIL)
    IR (Intermediate Representation)


    View Slide

25. SIL IR
    (LLVM)
    Flow of Compiling Swift Code
    IRGen
    Swift Intermediate Language Code to LLVM IR
    LLVM is a backend of Swift


    View Slide

26. IR
    (LLVM)

    App
    Flow of Compiling Swift Code
    Convert to executable, like iOS App, Command Line Tools …
    Other compiler phases like Linker are here (not touch today)


    View Slide

27. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Flow of Compiling Swift Code


    View Slide

28. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Flow of Compiling Swift Code


    View Slide

29. SIL
    SIL is one of topic of talk topic!
    Let’s focus on SIL!


    View Slide

30. Agenda
    Why need to learn Swift Compiler (Optimizer)?
    Basis of Swift Compiler
    Swift Intermediate Language
    SIL Optimizer


    View Slide

31. Swift Intermediate Language


    View Slide

32. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Swift Intermediate Language


    View Slide

33. SIL
    Swift Intermediate Language
    Intermediate Representation(IR) of Swift
    Used for specialized optimization for Swift


    View Slide

34. SIL
    Swift Intermediate Language
    LLVM IR is also optimized later
    IR
    (LLVM)
    Some effective optimization cannot be run on LLVM IR


    View Slide

35. Swift Intermediate Language
    Let’s convert this code to SIL!
    print("Hello, World")
    hello.swift


    View Slide

36. SIL
    Two kinds of SIL


    View Slide

37. Two kinds of SIL


    View Slide

38. Two kinds of SIL
    raw
    SIL
    canonical
    SIL


    View Slide

39. raw
    SIL
    canonical
    SIL
    Two kinds of SIL
    raw SIL is generated by SILGen (from AST)
    canonical SIL is optimized raw SIL by SIL Optimizer


    View Slide

40. Swift Intermediate Language
    raw
    SIL
    print("Hello, World")
    hello.swift


    View Slide

41. View Slide

42. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()


    View Slide

43. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()



    View Slide

44. Structure of SIL Code
    SIL Module
    Generated from Swift Source File


    View Slide

45. Structure of SIL Code
    SIL Module
    Meta information
    (Imported libraries, Function signature, Witness Table …)


    View Slide

46. Structure of SIL Code
    SIL Module
    SIL Function
    SIL Function
    SIL Function
    Meta information
    (Imported libraries, Function signature, Witness Table …)


    View Slide

47. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims
    sil_stage raw


    View Slide

48. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    sil_stage raw
    raw or canonical


    View Slide

49. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims


    View Slide

50. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims


    View Slide

51. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims
    $Builtin.Int


    View Slide

52. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims
    $Builtin.Int


    View Slide

53. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims
    $Builtin.Int
    My Builtin Literal talk is avalible on YouTube


    View Slide

54. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    import Builtin
    import Swift
    import SwiftShims
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {


    View Slide

55. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()


    View Slide

56. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()


    View Slide

57. Structure of SIL Code
    SIL Module
    SIL Function
    SIL Function
    SIL Function
    Meta information
    (imported libraries, vtable, function signature,witness table …)


    View Slide

58. Structure of SIL Code
    Converted from Swift Function
    SIL Function


    View Slide

59. sil_stage raw
    import Builtin
    import Swift
    import SwiftShims
    %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %4
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer) // user: %5
    (%5, %6) = destructure_tuple %4 : $(Array, Builtin.RawPointer) // users: %24, %21, %7
    %7 = pointer_to_address %6 : $Builtin.RawPointer to [strict] $*Any // user: %14
    %8 = string_literal utf8 "Hello, World" // user: %13
    %9 = integer_literal $Builtin.Word, 12 // user: %13
    %10 = integer_literal $Builtin.Int1, -1 // user: %13
    %11 = metatype $@thin String.Type // user: %13
    // function_ref String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    %12 = function_ref @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %13
    %13 = apply %12(%8, %9, %10, %11) : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String // user: %15
    %14 = init_existential_addr %7 : $*Any, $String // user: %15
    store %13 to [init] %14 : $*String // id: %15
    // function_ref default argument 1 of print(_:separator:terminator:)
    %16 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String // user: %17
    %17 = apply %16() : $@convention(thin) () -> @owned String // users: %23, %21
    // function_ref default argument 2 of print(_:separator:terminator:)
    %18 = function_ref @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String // user: %19
    %19 = apply %18() : $@convention(thin) () -> @owned String // users: %22, %21
    // function_ref print(_:separator:terminator:)
    %20 = function_ref @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> () // user: %21
    %21 = apply %20(%5, %17, %19) : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    destroy_value %19 : $String // id: %22
    destroy_value %17 : $String // id: %23
    destroy_value %5 : $Array // id: %24
    %25 = integer_literal $Builtin.Int32, 0 // user: %26
    %26 = struct $Int32 (%25 : $Builtin.Int32) // user: %27
    // _allocateUninitializedArray(_:)
    sil [serialized] [always_inline] [_semantics "array.uninitialized_intrinsic"] @$ss27_allocateUninitializedArrayySayxG_BptBwlF : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned Array<τ_0_0>, Builtin.RawPointer)
    // String.init(_builtinStringLiteral:utf8CodeUnitCount:isASCII:)
    sil [serialized] [always_inline] [readonly] [_semantics "string.makeUTF8"] @$sSS21_builtinStringLiteral17utf8CodeUnitCount7isASCIISSBp_BwBi1_tcfC : $@convention(method) (Builtin.RawPointer, Builtin.Word, Builtin.Int1, @thin String.Type) -> @owned String
    // default argument 1 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA0_ : $@convention(thin) () -> @owned String
    // default argument 2 of print(_:separator:terminator:)
    sil hidden_external [serialized] @$ss5print_9separator10terminatoryypd_S2StFfA1_ : $@convention(thin) () -> @owned String
    // print(_:separator:terminator:)
    sil @$ss5print_9separator10terminatoryypd_S2StF : $@convention(thin) (@guaranteed Array, @guaranteed String, @guaranteed String) -> ()
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'


    View Slide

60. …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'


    View Slide

61. “main” Function of Swift
    print("Hello, World")
    hello.swift
    Body code is surrounded by Main function
    Main function works as entry point like other languages


    View Slide

62. Structure of SIL Code
    SIL Function
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block


    View Slide

63. Structure of SIL Code
    SIL Function
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block
    SIL Basic Block


    View Slide

64. Structure of SIL Code
    SIL Basic Block
    Basic Block is kind of Scope in Swift Function
    Increased as Conditional Branches of program


    View Slide

65. …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'


    View Slide

66. …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    bb represents Basic Block


    View Slide

67. …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'
    Basic Block is increased as Conditional Branches
    bb1 …:
    …
    bb represents Basic Block
    if, while, switch, … in Swift


    View Slide

68. Structure of SIL Code
    SIL Basic Block
    SIL Instruction
    SIL Instruction
    SIL Instruction
    SIL Instruction
    SIL Instruction


    View Slide

69. Structure of SIL Code
    Converted from Swift Code
    SIL Instruction


    View Slide

70. %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF …
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned …)
    …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'


    View Slide

71. %2 = integer_literal $Builtin.Word, 1 // user: %4
    // function_ref _allocateUninitializedArray(_:)
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF …
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned …)
    …
    // main
    sil [ossa] @main : $@convention(c) (Int32, UnsafeMutablePointer>>) -> Int32 {
    bb0(%0 : $Int32, %1 : $UnsafeMutablePointer>>):
    return %26 : $Int32 // id: %27
    } // end sil function 'main'


    View Slide

72. Structure of SIL Code
    Converted from Swift Code
    SIL Instruction
    Conformed to Static Single Assignment format


    View Slide

73. Static Single Assignment (SSA)
    Each variable cannot be assigned value twice
    %2 = integer_literal $Builtin.Word, 1
    %3 = function_ref @$ss27_allocateUninitializedArrayySayxG_BptBwlF …
    %4 = apply %3(%2) : $@convention(thin) <τ_0_0> (Builtin.Word) -> (@owned …)
    A left value starts from % is variable
    Instruction with assigning is %n = instruction


    View Slide

74. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B


    View Slide

75. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B
    Removing Dead(not used) Code of Function


    View Slide

76. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B ← return and %7 should be marked as Live (used) Code


    View Slide

77. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B ← return and %7 should be marked as Live (used) Code


    View Slide

78. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B ← return and %7 should be marked as Live (used) Code
    ← %5 and %6 should be marked as Live (used) Code


    View Slide

79. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B ← return and %7 should be marked as Live (used) Code
    ← %5 and %6 should be marked as Live (used) Code


    View Slide

80. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B ← return and %7 should be marked as Live (used) Code
    ← %5 and %6 should be marked as Live (used) Code
    ← Marked as Dead Code because referred by return


    View Slide

81. Why converting SSA?
    Very easy to track how code is using each variable
    /// Body of SIL Function
    // A: integer variable
    %2 = integer_literal
    %3 = function_ref Int.init(:)
    %4 = apply %3(%2)
    // B: integer variable
    %5 = integer_literal
    %6 = function_ref Int.init(:)
    %7 = apply %5(%6)
    return %7 // return B
    Searching for variable proceeds by Unidirectional flow


    View Slide

82. Dead Code Elimination
    Constant Propagation
    Why converting SSA?
    Very easy to track how code is using each variable


    View Slide

83. Structure of SIL Code
    Converted from Swift Code
    SIL Instruction
    The Code Style is conformed to SSA
    Reference: docs/SIL.rst in apple/swift


    View Slide

84. Recap of SIL
    raw SIL and canonical SIL
    SIL consists of Module, Function, Basic Block and Instruction
    SIL is conformed to Single Static Assignment Format


    View Slide

85. Agenda
    Why need to learn Swift Compiler (Optimizer)?
    Basis of Swift Compiler
    Swift Intermediate Language (SIL)
    SIL Optimizer


    View Slide

86. SIL Optimizer


    View Slide

87. How SIL Optimizer works


    View Slide

88. raw to canonical
    raw
    SIL
    canonical
    SIL


    View Slide

89. raw to canonical
    raw
    SIL
    canonical
    SIL
    SIL Code Optimization


    View Slide

90. raw to canonical
    raw
    SIL
    canonical
    SIL
    SIL Optimizer
    SIL Code Optimization


    View Slide

91. Role of SIL Optimizer
    SIL Optimizer has two important roles on Compiler Phase
    Optimization SIL Code
    Diagnostic SIL Code


    View Slide

92. Role of SIL Optimizer
    SIL Optimizer has two important roles on Compiler Phase
    SIL Code
    Diagnostic SIL Code
    Optimization


    View Slide

93. by SIL Optimizer
    Optimization specialized for Swift Language
    Optimization
    Generic Specialization
    Witness and VTable Devirtualization etc


    View Slide

94. Role of SIL Optimizer
    SIL Optimizer has two important roles on Compiler Phase
    SIL Code
    SIL Code
    Diagnostic
    Optimization


    View Slide

95. by Compiler
    Each phase of Compiler diagnoses your Swift Code
    Checking Grammar on Parser Phase (to AST)
    Checking Type on Sema Phase (to typed AST)
    ??? on SIL Optimizer Phase (to canonical SIL)
    Compiler will show error if diagnostic fails
    Diagnostic


    View Slide

96. func wrongReturnType() -> String {
    return 2020
    }
    wrong-type.swift
    by Compiler
    Diagnostic


    View Slide

97. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Diagnostic of Type Check


    View Slide

98. AST AST
    (Typed)
    SIL IR
    (LLVM)

    App
    Diagnostic of Type Check
    OK
    NG
    error:
    cannot convert return expression of type 'Int' to return type 'String'


    View Slide

99. func wrongReturnType() -> String {
    return 2020
    }
    wrong-type.swift
    Diagnostic of return


    View Slide

100. func wrongReturnType() -> String {
     }
     wrong-type.swift
     Diagnostic of return


     View Slide

101. SIL
     AST AST
     (Typed)
     IR
     (LLVM)

     App
     OK OK OK
     Diagnostic of return


     View Slide

102. raw
     SIL
     canonical
     SIL
     Diagnostic in SIL Optimizer
     NG
     error: missing return in a function expected to return 'String'
     SIL Code Optimization


     View Slide

103. Diagnostic of return
     func wrongReturnType() -> String {
     }
     no-return.swift
     … // some code
     fatalError()


     View Slide

104. AST AST
     (Typed)
     SIL IR
     (LLVM)

     App
     OK
     Diagnostic of return
     OK OK OK OK
     No error by fatalError


     View Slide

105. Examples
     Diagnostic of Grammar by Parser
     Diagnostic of validation no-return by SIL Optimizer
     Diagnostic
     Diagnostic of Overflow by SIL Optimizer
     Diagnostic of Type (of return) by Sema
     etc


     View Slide

106. Role of SIL Optimizer
     SIL Optimizer has two important role on Compiler Phase
     Optimizing SIL Code
     SIL Code
     Diagnostic
     Guaranteeing safety as other roles of each phase


     View Slide

107. raw SIL
     raw
     SIL
     canonical
     SIL
     SIL Optimizer
     Optimizing


     View Slide

108. raw SIL
     raw
     SIL
     canonical
     SIL
     Optimizing
     Many Passes optimize your code in order
     Pass Pass
     Pass Pass
     Each Pass has role for optimization and diagnostic


     View Slide

109. Example of Pass in SIL Optimizer
     Dead Code Elimination
     Constant Propagation
     Memory Promotion
     Other Diagnostic etc


     View Slide

110. Pass Pipeline has information that which Pass must be called
     Pass Pipeline
     Pass Pass
     Pass Pass
     SIL Optimizer calls only registered Pass on Pipeline
     is Pass Pipeline


     View Slide

111. How Pass PipeLine is built
     Pass Pass
     Pass Pass
     Pipeline is built from optimization level of Compiler
     -Onone : Minimum optimization for debugging situation
     -O : Optimization for production code
     -Osize : Optimization for reducing size than performance


     View Slide

112. Which Pass is called or not?
     lib/SILOptimizer/PassManager/PassPipeline.cpp
     https://github.com/apple/swift


     View Slide

113. Which Pass is called or not?
     lib/SILOptimizer/PassManager/PassPipeline.cpp
     addMandatoryDiagnosticOptPipeline
     getOnonePassPipeline
     etc


     View Slide

114. List of Passes
     include/swift/SILOptimizer/PassManager/Passes.def
     https://github.com/apple/swift


     View Slide

115. Recap of SIL Optimizer
     SIL Optimizer’s roles are Optimization and Diagnostic
     raw SIL is optimized by Passes in SIL Optimizer
     Pipeline has information which Pass must be called
     Pass Pipeline is built by optimization level


     View Slide

116. SIL Optimizer


     View Slide

117. More Deeper Dive into SIL Optimizer


     View Slide

118. Two kinds of Pass
     For SIL Module
     For SIL Function
     Run by each SIL Module
     Run by each SIL Function


     View Slide

119. Two kinds of Pass
     For SIL Module
     For SIL Function
     Dead Function Elimination
     Global Variable Optimization
     Dead Code Elimination
     Alloc Box to Stack
     etc
     etc


     View Slide

120. How to know what kind of Pass
     Passes are developed by C++ Class in Compiler Code
     Each Pass inherits two kinds of Bass Class
     SILModuleTransform
     SILFunctionTransform


     View Slide

121. How to know what kind of Pass
     For SIL Module
     For SIL Function
     Dead Function Elimination
     Global Variable Optimization
     Dead Code Elimination
     Alloc Box to Stack
     etc
     etc


     View Slide

122. How to know what kind of Pass
     Dead Function Elimination
     class SILDeadFuncElimination : public SILModuleTransform {
     …
     }
     lib/SILOptimizer/IPO/DeadFunctionElimination.cpp


     View Slide

123. How to know what kind of Pass
     Dead Code Elimination
     class DCE : public SILFunctionTransform {
     …
     }
     lib/SILOptimizer/Transforms/DeadCodeElimination.cpp


     View Slide

124. Pass’s implementation
     Making Class from SILModule(Function)Transform
     Implementing run() as Entry Point


     View Slide

125. Reading Pass Code
     For example, let’s read AssumeSingleThreaded Pass
     The smallest Pass in Swift Compiler
     Optimizes program specialized for Single Thread


     View Slide

126. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     }
     /// Post treatment
     }
     };


     View Slide

127. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     }
     /// Post treatment
     }
     };


     View Slide

128. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     }
     /// Post treatment
     }
     };


     View Slide

129. Reading Pass Code
     Easy to understand if we know structure of SIL Code
     SIL Module
     SIL Function
     SIL Basic Block
     SIL Instruction


     View Slide

130. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     }
     /// Post treatment
     }
     };


     View Slide

131. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     /// Post treatment
     }
     };
     for (auto &BB : *getFunction()) {
     }


     View Slide

132. Reading Pass Code
     getFunction returns current scanning SILFunction
     for (auto &BB : *getFunction()) {
     }
     …
     SILFunction can be treated as SILBasicBlock Collection


     View Slide

133. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     }
     /// Post treatment
     }
     };
     for (auto &BB : *getFunction()) {
     }


     View Slide

134. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     /// Post treatment
     }
     };
     for (auto &I : BB) {
     }


     View Slide

135. Reading Pass Code
     }
     …
     for (auto &I : BB) {
     SILBasicBlock is SILInstruction Collection
     Scanning SILInstruction from top


     View Slide

136. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     if (auto RCInst = dyn_cast(&I))
     RCInst->setNonAtomic();
     }
     /// Post treatment
     }
     };
     for (auto &I : BB) {
     }


     View Slide

137. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     if (. )
     RCInst->setNonAtomic();
     }
     /// Post treatment
     }
     };
     for (auto &I : BB) {
     }
     auto RCInst = dyn_cast(&I)


     View Slide

138. Reading Pass Code
     Checking what kind of SILInstruction by casting
     RefCountingInst is instruction related to ARC
     auto RCInst = dyn_cast(&I)


     View Slide

139. Reading Pass Code
     If we want to check instruction is return or not
     Check type-cast by ReturnInst
     auto ReturnInst = dyn_cast(&I)


     View Slide

140. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     if (. )
     RCInst->setNonAtomic();
     }
     /// Post treatment
     }
     };
     for (auto &I : BB) {
     }
     auto RCInst = dyn_cast(&I)


     View Slide

141. lib/SILOptimizer/Transforms/AssumeSingleThreaded.cpp
     class AssumeSingleThreaded : public swift::SILFunctionTransform {
     /// The entry point to the transformation.
     void run() override {
     /// Checking option …
     for (auto &BB : *getFunction()) {
     for (auto &I : BB) {
     if (auto RCInst = dyn_cast(&I))
     }
     }
     /// Post treatment
     }
     };
     RCInst->setNonAtomic();


     View Slide

142. Reading Pass Code
     Setting Reference Count instruction as non Atomic
     RCInst->setNonAtomic();


     View Slide

143. What AssumeSingleThreaded?
     Scanning SIL Instruction related to Reference Count
     Marking Reference Count Instruction as non Atomic
     Called by each SIL Function


     View Slide

144. Now, you can read
     Swift Compiler Code!


     View Slide

145. Using docs/SIL.rst for reference of SIL Instruction
     Understanding C++ and LLVM for more deep dive
     Recap to read SIL Optimizer Code
     Understanding structure of SIL Code


     View Slide

146. For More your learning Compiler


     View Slide

147. Build Swift Compiler!
     You can clone from https://github.com/apple/swift
     It requires more than 60 GB ⚠ to build


     View Slide

148. SIL Optimizer may have bugs which not tracked
     There is many chance to contribute!
     Contribute to Swift Compiler!


     View Slide

149. Talk/Write about Swift Compiler!
     Swift Compiler is difficult topic
     Your talk/article would be helpful for next learner!


     View Slide

150. Thank you!
     Twitter: _ _ _ freddi _ _ _
     Give me a feed back and question!


     View Slide
