Using OBS for automated & dependable builds of Windows binaries & creation of installers

Transcript

1. Using OBS for automated & dependable builds of Windows binaries & creation of installers Fridrich Štrba Software Engineer & TrainedMonkey™ LibreOffice Team
2. © Novell, Inc. All rights reserved. 2 Who Am I? • Software Engineer in LibreOffice Team • Diverse background • FLOSS enthusiast • Enjoying Win32 porting of FLOSS applications • Working in free time on various projects
3. © Novell, Inc. All rights reserved. 3 Agenda • Differences Between Windows and Linux and Impact on Porting of FLOSS to Windows • Description of Our Windows Cross-Compiling Projects and How To Use Them • Future Directions
4. Differences Between Windows and Linux and Impact on Porting of FLOSS to Windows
5. © Novell, Inc. All rights reserved. 5 Linux • Shared libraries • Package management – Different package management tools (rpm, dpkg,...) • Dependency tracking – RPM tool keeps database of packages and their dependencies • Automatic upgrading possible – In openSUSE / SLE – satsolver tools a powerful dependency resolution – zypper dup
6. © Novell, Inc. All rights reserved. 6 Windows • Very little core shared (C runtime and Win32 API) • No centralized package management • Application in charge of installing all dependencies • Application installer in charge of upgrading
7. © Novell, Inc. All rights reserved. 7 Porting of FLOSS to Windows • Linux way of doing – Majority of FLOSS originally developed for Linux • Where to find the dependencies ? – Tor Lillqvist's web-page of binaries – GnuWin32 packages with their secret sauce • Toolchain for the build – http://www.mingw.org • A lot of insider information needed just to be able to build – Different tutorials focus on the setting of the build environment and location of the dependencies
8. Our approach
9. © Novell, Inc. All rights reserved. 9 Build from sources the Linux way • Why ? – Maintainability – Possibility to provide customer support – Clean stack of libraries • OpenSUSE Build Service – We have the best tool !!! > Build Service makes the building for us > All dependent libraries rebuilt and clean stack available at every point of time
10. © Novell, Inc. All rights reserved. 10 Elements of Our Solution • Cross-compiling framework • Infrastructure package • Toolchain • Porting strategy • Installer creation
11. © Novell, Inc. All rights reserved. 11 Cross-compiling framework • Long tradition of cross-compiling for Windows – Availability of the tools – Speed of the tools – OBS has cross-mingw packages since long time – Still rather manual work • Different existing cross-compiling frameworks – http://mingw-cross.sourceforge.net – http://fedoraproject.org/wiki/SIGs/MinGW – Inspired by the Fedora framework > “There should be no reinvented wheels; no wheel should be reinvented; the number of reinvented wheels should be equal to zero.”
12. © Novell, Inc. All rights reserved. 12 Infrastructure package mingw32-filesystem • Use of cross-binutils – Capacity to read information about the binaries • Macros for builds – Importance to be isolated from native environment • Scripts – Script for requires – Script for provides – Script for debuginfo extraction • Postinstall tweaks
13. © Novell, Inc. All rights reserved. 13 Example objdump information: The Import Tables (interpreted .idata section contents) vma: Hint Time Forward DLL First Table Stamp Chain Name Thunk 00016000 00016050 00000000 00000000 00016530 00016124 DLL Name: KERNEL32.dll vma: Hint/Ord Member­Name Bound­To 161f8 109 DeleteCriticalSection . . . . 163aa 803 VirtualQuery 00016014 000160ac 00000000 00000000 00016554 00016180 DLL Name: msvcrt.dll vma: Hint/Ord Member­Name Bound­To 163ba 5 _close 163c4 47 _lseek 163ce 54 _open 163d6 60 _read 163de 104 _write 00016028 000160c4 00000000 00000000 000165bc 00016198 DLL Name: msvcrt.dll vma: Hint/Ord Member­Name Bound­To 163e8 56 __dllonexit . . . . 164cc 760 vfprintf 0001603c 00000000 00000000 00000000 00000000 00000000
14. © Novell, Inc. All rights reserved. 14 mingw32-find-requires.sh: #!/bin/bash if [ "$1" ] then package_name="$1" fi [ ­z "$OBJDUMP" ] && OBJDUMP=i686­pc­mingw32­objdump # Get the list of files. filelist=`sed "s/['\"]/\\\&/g"` dlls_to_exclude="advapi32.dll [...] wsock32.dll" exclude_pattern="" for i in $dlls_to_exclude; do if test "$exclude_pattern" == ""; then exclude_pattern=$i; else exclude_pattern=$exclude_pattern"|"$i; fi done dlls=$(echo $filelist | tr [:blank:] '\n' | grep ­Ei '\.(dll|exe)$') for f in $dlls; do $OBJDUMP ­p $f | grep 'DLL Name' | tr [:upper:] [:lower:] | grep ­Eo '[­._\+[:alnum:]]+\.dll' | grep ­Ev "$exclude_pattern" | sed 's/\(.*\)/mingw32(\1)/' done | sort ­u
15. © Novell, Inc. All rights reserved. 15 mingw32-find-provides.sh: #!/bin/bash if [ "$1" ] then package_name="$1" fi [ ­z "$OBJDUMP" ] && OBJDUMP=i686­pc­mingw32­objdump filelist=`sed "s/['\"]/\\\&/g"` dlls=$(echo $filelist | tr [:blank:] '\n' | grep '\.dll$') for f in $dlls; do basename=`basename $f | tr [:upper:] [:lower:]` echo "mingw32($basename)" done
16. © Novell, Inc. All rights reserved. 16 mingw32-find-debuginfo.sh: #!/bin/sh if [ ­z "$1" ] ; then BUILDDIR="." else BUILDDIR=$1 fi for f in `find $RPM_BUILD_ROOT ­type f ­name "*.exe" ­or ­name "*.dll"` do case $(i686­pc­mingw32­objdump ­h $f 2>/dev/null | egrep ­o '(debug[\.a­z_]*|gnu.version)') in *debuglink*) continue ;; *debug*) ;; *gnu.version*) echo "WARNING: "`echo $f | sed ­e "s,^$RPM_BUILD_ROOT/*,/,"`" is already stripped!" continue ;; *) continue ;; esac echo extracting debug info from $f i686­pc­mingw32­objcopy ­­only­keep­debug $f $f.debug || : pushd `dirname $f` i686­pc­mingw32­objcopy ­­add­gnu­debuglink=`basename $f.debug` ­­strip­unneeded `basename $f` || : popd done find $RPM_BUILD_ROOT ­type f ­name "*.exe.debug" ­or ­name "*.dll.debug" | sed ­n ­e "s#^$RPM_BUILD_ROOT##p" > $BUILDDIR/debugfiles.list
17. © Novell, Inc. All rights reserved. 17 Toolchain • Self built – Cross-binutils – Cross-compiler – Win32 API and C runtime headers and import libraries • Win32 API and C runtime – First approach > http://www.mingw.org mingw-rt and w32api sources – Choice of http://mingw-w64.sourceforge.net » Better responsiveness of developers » Better API coverage » More complete COM+ headers
18. © Novell, Inc. All rights reserved. 18 Porting strategy • Difference with Fedora – Don't link to a particular openSUSE / SLE release • Work upstream – As little as possible non-upstreamed patches • No “secret sauce” – Windows is not POSIX
19. © Novell, Inc. All rights reserved. 19 Installer creation – First approach • MSI with Wix – http://wix.sourceforge.net – Framework written in C# > Some tools can be run using Mono – Windows only in fact > A critical tool P/Invokes MSI.DLL > Possible to use emulator (wine) – not as clean as one would like > Looked into implementing a replacement of msi.dll for Linux (gave up) > OBS home:hiberis project
20. © Novell, Inc. All rights reserved. 20 Installer creation – Second approach • Nullsoft Scriptable Installer System – http://nsis.sourceforge.net/Main_Page – Written in C and C++ – Command-line tools compilable and usable on Linux > Can be called during the RPM build process > NSI files > Installers wrapped in an RPM package > 7-zip is able to unpack RPM packages just fine » http://www.7-zip.org – Experimental Evolution installer » http://fridrich.blogspot.com/2010/05/experimental-evolution-installer-for.html
21. Future Directions
22. © Novell, Inc. All rights reserved. 22 So, what is this good for? • Old way of developing Evolution on Windows – A long list of dependencies and hackish tweaks > Zero attraction power for new developers » http://www.go-evolution.org/Building_Evolution_on_Windows » http://www.go-evolution.org/Windows • Our way – The development environment is easy to set » zypper si ­d mingw32­evolution­data­server » Using the tried and true tools present on Linux box – Debugging made easy » Installer of debugging symbols that contains a debugger » No need to compile yourself to debug a problem » Limitations because there is nothing like debugedit for windows binaries
23. © Novell, Inc. All rights reserved. 23 MS-DOS cross-compiler toolchain • Needed urgently for a product • Inspired by the Windows cross-compiling framework • Cloned in about a day – Reusing of the experience with Windows cross-compiling – Using DJGPP libraries > http://www.delorie.com/djgpp – Lives in openSUSE Build Service > home:fstrba:msdos project
24. © Novell, Inc. All rights reserved. 24 Status of the project • About 190 active packages in the repositories – 190 source packages targeting win32 – 186 source packages targeting win64 – An authoritative source for GTK+ port of Webkit on Windows • Work done in free time as a hobby • Enthusiastic community of package maintainers born – Taking over package by package according to their interest • Positive community feedback > “By far openSUSE Build Service contains most comprehensive collection of mingw software/libraries. No real competitors that I know of.” » http://old.nabble.com/Re%3A-win32---win64-Gtk%2B-apt-repo--p28979375.html
25. Q&A
