Creating D3 Components

Who doesn’t love a good chart? When done correctly, charts can expose beauty in any form of data. Chris Price, creator of D3FC talks us through the logical leaps and the painful doubling-backs of building charts on D3. Working in financial services, it’s no surprise that charts form a part of the apps he creates. It’s a journey of pain, joy, frustration and enlightenment.

Transcript

1. Creating D3 components Chris Price / @100pxls
2. d3 data join components d3fc
3. d3 the basics
4. DOM abstraction selection var selection = d3.select('#id'); selection.select('div') .selectAll('.class-name');
5. DOM abstraction manipulation selection.text('inner text') .attr('class', 'class-name') .style({ height: 'auto' }) .each(function(data) { var element = this; // ... }) .append('span');
6. DOM abstraction events selection.on('click.foo', function(data) { var element = this; // ... });
7. DOM abstraction XHR d3.json('/some/url', function(error, data) { // ... });
8. DOM abstraction animation selection.style('background', 'blue') .transition() .duration(100) .ease('linear') .style('background', 'red');
9. layout algorithms scales var scale = d3.scale.linear() .domain([-10, 10]) .range([0, 500]); scale(-5); // 125 scale.invert(125); // -5 scale.ticks(3); // [-10, 0, 10]
10. layout algorithms specialised layouts var layout = d3.layout.pie() .padAngle(Math.PI/10); layout([3,1,2]); // [ { // "data":3, // "value":3, // "padAngle":0.314..., // "startAngle":0, // "endAngle":2.984... // }, ... ]
11. layout algorithms geometric primitives var polygon = d3.geom.polygon( [[0,0],[0,1],[1,1],[1,0]]); polygon.area(); // 1 polygon.centroid(); // [0.5,0.5]
12. layout algorithms geographic projections var mercator = d3.geo.projection( function(λ, φ) { return [ λ, Math.log(Math.tan(π / 4 + φ / 2)) ]; });
13. SVG helpers axis renderers var scale = d3.linear.scale() .domain([-10, 10]) .range([0, 100]); var axis = d3.svg.axis() .scale(scale); d3.select('svg') .call(axis);
14. SVG helpers path data generators var line = d3.svg.line(); line([[0,0],[50,50]]); // "M0,0L50,50" d3.select('svg') .append('path') .datum([[0,0],[50,50]]) .attr('d', line); // <path d="M0,0L50,50"></path>
15. miscellaneous data/time formatting var format = d3.time.format("%a, %e %B %Y"); format(new Date(2015, 4, 7)); // "Thu, 7 May 2015" var d = format.parse("Fri, 8 May 2015"); d.toString(); // "Fri May 08 2015 00:00:00 GMT+0000 (GMT)" d3.time.year.ceil(d, 1); // "Fri Jan 01 2016 00:00:00 GMT+0000 (GMT)"
16. examples
17. multi-series line chart
18. collision detection
19. shiboronoi
20. d3 DOM abstraction layout algorithms SVG helpers miscellaneous data binding
21. data join contains spoilers
23. data join the HTML <h1>USS Missouri Crew List</h1> <ul> <li></li> <li></li> <li></li> </ul>
24. data join the data var data = [ { name: 'Adams', rank: 'Captain' }, { name: 'Krill', rank: 'Commander' }, { name: 'Ryback', rank: 'Chief Petty Officer' } ];
25. data join render loop // ... function render() { requestAnimationFrame(render); } requestAnimationFrame(render);
26. data join selection // ... function render() { var container = d3.select('ul'); container.selectAll('li'); requestAnimationFrame(render); } // ...
27. data join the join // ... var container = d3.select('ul'); container.selectAll('li') .data(data); requestAnimationFrame(render); // ...
28. data join update selection // ... var updateSelection = container.selectAll('li') .data(data); updateSelection.text(function(d) { return d.name + ' (' + d.rank + ')'; }); // ...
29. data join update selection <h1>USS Missouri Crew List</h1> <ul> <li>Adams (Captain)</li> <li>Krill (Commander)</li> <li>Ryback (Chief Petty Officer)</li> </ul>
31. data join add an item to the data var data = [ { name: 'Adams', rank: 'Captain' }, { name: 'Krill', rank: 'Commander' }, { name: 'Ryback', rank: 'Chief Petty Officer' }, { name: 'Strannix', rank: 'Civilian' } ];
32. data join ...no change <h1>USS Missouri Crew List</h1> <ul> <li>Adams (Captain)</li> <li>Krill (Commander)</li> <li>Ryback (Chief Petty Officer)</li> </ul>
33. data join enter selection // ... var updateSelection = container.selectAll('li') .data(data); updateSelection.enter() .append('li'); updateSelection.text(function(d) { return d.name + ' (' + d.rank + ')'; }); // ...
34. data join a change! <h1>USS Missouri Crew List</h1> <ul> <li>Adams (Captain)</li> <li>Krill (Commander)</li> <li>Ryback (Chief Petty Officer)</li> <li>Strannix (Civilian)</li> </ul>
35. data join remove an item from the data var data = [ { name: 'Krill', rank: 'Commander' }, { name: 'Ryback', rank: 'Chief Petty Officer' }, { name: 'Strannix', rank: 'Civilian' } ];
36. data join a change... <h1>USS Missouri Crew List</h1> <ul> <li>Krill (Commander)</li> <li>Ryback (Chief Petty Officer)</li> <li>Strannix (Civilian)</li> <li>Strannix (Civilian)</li> </ul>
37. data join exit selection // ... updateSelection.enter() .append('li'); updateSelection.text(function(d) { return d.name + ' (' + d.rank + ')'; }); updateSelection.exit() .remove(); // ...
38. data join a change! <h1>USS Missouri Crew List</h1> <ul> <li>Krill (Commander)</li> <li>Ryback (Chief Petty Officer)</li> <li>Strannix (Civilian)</li> </ul>
39. data join spoilers <h1>USS Missouri Crew List</h1> <ul> <li>Ryback (Chief Petty Officer)</li> </ul> var data = [ { name: 'Ryback', rank: 'Chief Petty Officer' } ];
40. data join idempotent transformation of data into nodes
41. demo
42. components (functions)
43. components just functions function caseyRyback(selection) { selection.text('Another cold day in Hell.'); } function dramaticEffect(selection) { selection.style('fontWeight', 'bold'); } var selection = d3.select('span'); caseyRyback(selection); dramaticEffect(selection);
44. components invoked with call function caseyRyback(selection) { selection.text('Another cold day in Hell.'); } function dramaticEffect(selection) { selection.style('fontWeight', 'bold'); } var selection = d3.select('span') .call(caseyRyback) .call(dramaticEffect);
45. components factories function caseyRybackFactory() { function caseyRyback(selection) { selection.text('Another cold day in Hell.'); } return caseyRyback; } var component = caseyRybackFactory(); d3.select('span') .call(component);
46. components configurable function caseyRybackFactory() { var quote = 'Another cold day in Hell.'; function caseyRyback(selection) { selection.text(quote); } caseyRyback.quote = function(value) { if (!arguments.length) { return quote; } quote = value; return caseyRyback; }; return caseyRyback; }
47. components configurable var component = caseyRybackFactory() .quote('Keep the faith, Strannix.'); d3.select('span') .call(component);
48. components convention based unit of re-use
49. demo
50. our experience d3fc
51. d3fc a toolkit for rapidly developing bespoke charts embraces d3 small and composable prioritises simplicity a curated and consistent set of examples
