[Constantine Mars] Android Wear 2.0: Great Changes Upcoming this Fall

Presentation from GDG DevFest Ukraine 2016.
Learn more at: https://devfest.gdg.org.ua

Transcript

1. Android Wear 2.0 Great Changes Upcoming this Fall Constantine Mars Organizer @ GDG Dnipro Senior Mobile Developer @ DataArt
2. David Singleton, VP of Engineering at Google
4. What you can do with the new generation watches? And why? :)
5. Hardware Key platform features and supported watches
6. #dfua Goodbye tethering! BLE WiFi Cellular
7. #dfua Great chances to get direct access to Play
8. #dfua Officially supported watches LG Watch Urbane 2nd Edition Huawei Watch
9. #dfua Officially supported watches LG Watch Urbane 2nd Edition Huawei Watch Display: 1.4 inches, 400 x 400 pixels (~286 ppi) CPU:Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 512 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1 LE Network: No cellular connectivity Battery: 300 mAh (48h) Display: 1.38 inches, 480 x 480 pixels (~348 ppi) CPU: Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 768 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1 LE, GPS, NFC Network: GSM, HSPA, LTE Battery: 570 mAh (60h)
10. Complications Personal expression and utility
11. #dfua Personal expression and utility Modern by LG Ranger by Zuhanden GoogleFit Today
12. #dfua Or simply an personal expression :) HeyKittyKitty by WatchMaster
13. #dfua Complications “any feature in a timepiece beyond the simple display of hours and minutes” (Wikipedia)
14. #dfua Complication types -Short text -Long text -Range of values -Icon (small picture) -Image (big picture)
15. Complications coding
16. #dfua Each position need to be identified private static final int LEFT_DIAL_COMPLICATION = 0; private static final int RIGHT_DIAL_COMPLICATION = 1; public static final int[] COMPLICATION_IDS = {LEFT_DIAL_COMPLICATION, RIGHT_DIAL_COMPLICATION}; Complication ID
17. #dfua Each position must be mapped with array of supported types // Left and right dial supported types. public static final int[][] COMPLICATION_SUPPORTED_TYPES = { {ComplicationData.TYPE_SHORT_TEXT}, {ComplicationData.TYPE_SHORT_TEXT} }; Complication supported types
18. #dfua Data Providers and system trigger .onComplicationDataUpdate() sometimes /* Called when there is updated data for a complication id. */ @Override public void onComplicationDataUpdate( int complicationId, ComplicationData complicationData) { Log.d(TAG, "onComplicationDataUpdate() id: " + complicationId); mActiveComplicationDataSparseArray.put(complicationId, complicationData); invalidate(); } ComplicationData receiving
19. #dfua .onDraw() is the moment of drawing. ComplicationData where stored earlier @Override public void onDraw(Canvas canvas, Rect bounds) { ComplicationData complicationData; for (int i = 0; i < COMPLICATION_IDS.length; i++) { complicationData = mActiveComplicationDataSparseArray .get(COMPLICATION_IDS[i]); // ... Complications rendering
20. #dfua Complication may be deactivated or contain wrong data type if ((complicationData != null) && (complicationData.isActive(currentTimeMillis)) && (complicationData.getType() == ComplicationData.TYPE_SHORT_TEXT)) { ComplicationText mainText = complicationData.getShortText(); CharSequence complicationMessage = mainText.getText(getApplicationContext(), currentTimeMillis); Complications rendering
21. #dfua Actual drawing is trivial canvas.drawText( complicationMessage, 0, complicationMessage.length(), complicationsX, mComplicationsY, mComplicationPaint); Complications rendering
22. Data Providers
23. #dfua Android Wear role in data exchange
24. #dfua Data Providers
25. Data Providers coding
26. #dfua <service android:name=".RandomNumberProviderService" android:label="@string/complications_provider_random_number" android:icon="@drawable/ic_watch_white"> Data Provider Service attributes Extend ComplicationProviderService
27. #dfua <intent-filter> <action android:name="android.support.wearable.complications.ACTION_COMPLICATION_UPDA TE_REQUEST"/> </intent-filter> <meta-data android:name="android.support.wearable.complications.SUPPORTED_TYPES" android:value="RANGED_VALUE,SHORT_TEXT,LONG_TEXT"/> Data Provider declaration
28. #dfua Update period <meta-data android:name="android.support.wearable.complications.UPDATE_PERIOD_SECONDS" android:value="120"/> Data Provider declaration
29. #dfua @Override public void onComplicationActivated( int complicationId, int dataType, ComplicationManager complicationManager) { … } @Override public void onComplicationUpdate( int complicationId, int dataType, ComplicationManager complicationManager) { … } @Override public void onComplicationDeactivated(int complicationId) { … } Data Provider methods
30. #dfua @Override public void onComplicationUpdate(int complicationId, int dataType, ComplicationManager complicationManager) { // Retrieve or generate your data int randomNumber = (int) Math.floor(Math.random() * 10); String randomNumberText = String.format(Locale.getDefault(), "%d!", randomNumber); Exposing data to complications Called according to update period time
31. #dfua ComplicationData complicationData = null; switch (dataType) { case ComplicationData.TYPE_SHORT_TEXT: complicationData = new ComplicationData.Builder( ComplicationData.TYPE_SHORT_TEXT) .setShortText(ComplicationText.plainText(randomNumberText)) .build(); break; Exposing data to complications
32. #dfua @Override public void onComplicationUpdate( int complicationId, int dataType, ComplicationManager complicationManager) { … if (complicationData != null) { complicationManager.updateComplicationData( complicationId, complicationData); } Exposing data to complications
33. Notifications updated
34. #dfua Notifications in Android Wear 1.X
35. #dfua Android Wear 2.0 Notifications Material Design for Wearables, Dark Theme
36. #dfua Android Wear 2.0 Notifications
37. #dfua Notifications preview
38. #dfua Notifications messaging style
39. Notifications coding
40. #dfua Notification noti = new NotificationCompat.Builder() .setContentTitle(messages.length + " new messages with " + sender) .setContentText("subject") .setSmallIcon(R.drawable.new_message) // 2) set the style to MessagingStyle .setStyle(new NotificationCompat.MessagingStyle( getResources().getString(R.string.reply_name)) .addMessage(messages[0]) .addMessage(messages[1]); Notifications with modern MessagingStyle set MessagingStyle
41. #dfua NotificationCompat.Action action = new NotificationCompat.Action.Builder(R.drawable.ic_reply_icon, getString(R.string.label), replyPendingIntent) .addRemoteInput(remoteInput) .setAllowGeneratedReplies(true) .build(); Notifications with SmartReply Allow SmartReply
42. New Input Methods
43. #dfua New input methods
44. #dfua Voice input, Emoji
45. #dfua Keyboard, Handwriting
46. #dfua Wait, a Keyboard??? LG Watch Urbane 2nd Edition Display: 1.38 inches, 480 x 480 pixels (~348 ppi) CPU: Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 768 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1, LE, GPS, NFC Network: GSM, HSPA, LTE Battery: 570 mAh (60h) Size x2 bigger than first phones
47. Material Design for Wearables
48. #dfua 1D Layout Do Don’t
49. #dfua UI Anatomy
50. #dfua Navigation Drawer
51. #dfua Action Drawer
52. #dfua Dark Theme
53. #dfua Brightness values 1 App color - Default color 2 Dark background - 15% 3 Lighter background - 30% 4 UI element - 40% 5 Lighter UI element - 65% 6 Accent - 100%
54. #dfua Interaction types
55. Quick look at Google Fit
56. #dfua Wearables area at Google I/O
57. #dfua Google Fit infrastructure
58. #dfua Existing Google Fit APIs Sensors API Recording API History API
59. #dfua Upcoming APIs Beat to Beat API Goals API Profile API
60. #dfua Real Time Gym Activity Recognition
61. #dfua Real Time Gym Activity Recognition Live demo from Google I/O
62. #dfua Recognized exercises
64. Questions? Thank you! Constantine Mars @ConstantineMars +ConstantineMars
