ScaleConf Cape Town - Debug like a pro on Kubernetes

~ @gianarb - https://gianarb.it ~
Debug like a pro on
Kubernetes
ScaleConf - Cape Town - 2019

View Slide

Gianluca Arbezzano
Site Reliability Engineer @InfluxData
● http://gianarb.it
● @gianarb
What I like:
● I make dirty hacks that look awesome
● I grow my vegetables
● Travel for fun and work

View Slide

1. Yo n !
Your team knows
and use Docker for
local development
and testing
2. Kub te !
Everyone speaks
about kubernetes.
3. Hir !
You don’t know why
but you hired a
DevOps that kind of
know k8s.
3. Ex i m !
You are moving
everything and
everyone to
kubernetes

View Slide

Inspired by a true story

View Slide

View Slide

You need a good book
1. Short
2. Driven by experiences
3. Practical
4. Easy

View Slide

We need to make our
hands dirty

View Slide

Spin up a cluster that you
can break
Bring developers in the loop

View Slide

Deploy CI on Kubernetes

View Slide

Run your code in prod

View Slide

Don’t be scared and write your
own tools!

View Slide

K8s as code: From YAML to code (golang)
1. You have the ability to use Golang autocomplete as documentation, reference for every
kubernetes resources
2. You feel less a YAML engineer (great feeling btw)
3. Code is better than YAML! You can reuse it, compile it, embed it in other projects.

View Slide

Tiny cli
to make
the
migration
to golang
Some
manual
refactoring

View Slide

Tiny cli
to make
the
migration
to golang
Some
manual
refactoring
● Continue to improve our CI to validate that YAML and Go file are the same,
and the resources in Kubernetes are like the Go file.
● Maybe we will be able to remove the YAML at some point.

View Slide

GitOps
Your Git repository is the entrypoint for all your code changes.
Infrastructure is ‘as code’, so the place where you make it happen should be Git.

View Slide

Examples
● Everything has an API because you should USE it TO make something good!
(cURL is good but you can make something better)
● Some of our tools:
○ Backup and Restore Operator for Persistent Volumes
○ We have a service to create runtime isolated environment to allow devs to test or product
people to have a safe environment to demo, try. We also use it for the integration and smoke
tests.
○ We have a tool to replicate environment locally on minikube to install and configure all the
dependencies

View Slide

Instrumentation and
Observability

View Slide

We need to have processes and tools that give us
the ability to take a real time picture of our system

View Slide

Observability
Events, metrics, logs and traces

View Slide

Observability
It is all about how we collect and aggregate the data

View Slide

Normal state vs Current state

View Slide

You need knowledgeable devs to drive the team

View Slide

Instrumentation code is a first citizen in your
codebase: OpenCensus
● Open Source project sponsored by Google
● It is a SPEC plus a set of libraries in different languages to instrument your
application
● To collect metrics, traces and events.

View Slide

OpenCensus
Common
Interface to
collect stats
and traces
from your app
Different
exporters to
persist your
data

View Slide

gianarb.it ~ @gianarb
# HELP http_requests_total The total number of HTTP requests.
# TYPE http_requests_total counter
http_requests_total{method="post",code="200"} 1027 1395066363000
http_requests_total{method="post",code="400"} 3 1395066363000
# Escaping in label values:
msdos_file_access_time_seconds{path="C:\\DIR\\FILE.TXT",error="Cannot find file:\n\"FILE.TXT\""}
1.458255915e9
# Minimalistic line:
metric_without_timestamp_and_labels 12.47
# A weird metric from before the epoch:
something_weird{problem="division by zero"} +Inf -3982045
# A histogram, which has a pretty complex representation in the text format:
# HELP http_request_duration_seconds A histogram of the request duration.
# TYPE http_request_duration_seconds histogram
http_request_duration_seconds_bucket{le="0.05"} 24054
http_request_duration_seconds_bucket{le="1"} 133988
http_request_duration_seconds_bucket{le="+Inf"} 144320
http_request_duration_seconds_sum 53423
http_request_duration_seconds_count 144320

View Slide

OpenMetrics
v2 Prometheus exposition format

View Slide


View Slide

func FetchMetricFamilies(url string, ch chanskipServerCertCheck bool) error {
defer close(ch)
var transport *http.Transport
if certificate != "" && key != "" {
cert, err := tls.LoadX509KeyPair(certificate, key)
if err != nil {
return err
}
tlsConfig := &tls.Config{
Certificates: []tls.Certificate{cert},
InsecureSkipVerify: skipServerCertCheck,
}
tlsConfig.BuildNameToCertificate()
transport = &http.Transport{TLSClientConfig: tlsConfig}
} else {
transport = &http.Transport{
TLSClientConfig: &tls.Config{InsecureSkipVerify: skipServerCertCheck},
}
}
client := &http.Client{Transport: transport}
return decodeContent(client, url, ch)
}
https://github.com/prometheus/prom2json/blob/master/prom2json.go#L123

View Slide

More to read
● OpenMetrics: https://github.com/OpenObservability/OpenMetrics
● OpenMetrics mailing list: https://groups.google.com/forum/#\protect\kern-.
1667em\relaxforum/openmetrics
● WIP branch for Python library
https://github.com/prometheus/client_python/tree/openmetrics
● Thanks RICHARD for your work! I got some slides from here:
https://promcon.io/2018-munich/slides/openmetrics-transforming-the-prometh
eus-exposition-format-into-a-global-standard.pdf

View Slide

@gianarb - [email protected]

View Slide

How do you “tell stories” about
concurrent systems?

View Slide

View Slide

OpenTracing

View Slide

I was just waiting for a new
standard!
cit. Troll

View Slide

© 2017 InfluxData. All rights reserved.
37
Typical problems with logs
¨ Which library do I need to use?
¨ Every library has a different format
¨ Every languages exposes a different format

View Slide

38
Tracing is not something new
¨ There are vendors
¨ Every vendor has their own format

View Slide

39
log log log
log log
log
Parent Span
Span Context / Baggage
Child
Child
Child Span
¨ Spans - Basic unit of timing and causality. Can be tagged with
key/value pairs.
¨ Logs - Structured data recorded on a span.
¨ Span Context - serializable format for linking spans across network
boundaries. Carries baggage, such as a request and client IDs.
¨ Tracers - Anything that plugs into the OpenTracing API to record
information.
¨ ZipKin, Jaeger, LightStep, others
¨ Also metrics (Prometheus) and logging

View Slide

40
OpenTracing
API
application logic
µ-service frameworks
Lambda functions
RPC & control-flow frameworks
existing instrumentation
tracing infrastructure
main()
I N S T A N A
J a e g e r
microservice process

View Slide

41
import "github.com/opentracing/opentracing-go"
import ".../some_tracing_impl"
func main() {
opentracing.SetGlobalTracer(
// tracing impl specific:
some_tracing_impl.New(...),
)
...
}
https://github.com/opentracing/opentracing-go
Opentracing: Configure the GlobalTracer

View Slide

42
func xyz(ctx context.Context, ...) {
...
span, ctx := opentracing.StartSpanFromContext(ctx, "op_name")
defer span.Finish()
span.LogFields(
log.String("event", "soft error"),
log.String("type", "cache timeout"),
log.Int("waited.millis", 1500))
...
}
Opentracing: Create a Span from the Context

View Slide

43
func xyz(parentSpan opentracing.Span, ...) {
...
sp := opentracing.StartSpan(
"operation_name",
opentracing.ChildOf(parentSpan.Context()))
defer sp.Finish()
...
}
Opentracing: Create a Child Span

View Slide

Golang and Kubernetes: pprof
● It is the Golang native profiler
● You can use it via the `go pprof` command
● `import "runtime/pprof"` writes runtime profiling data
● `import "net/http/pprof"` serves via HTTP server runtime profiling data

View Slide

package main
import (
"log"
"net/http"
_ "net/http/pprof"
)
func main() {
log.Println(http.ListenAndServe("localhost:6060", nil))
}

View Slide

$ go tool pprof http://localhost:6060/debug/pprof/heap
Fetching profile over HTTP from http://localhost:6060/debug/pprof/heap
Saved profile in
/home/gianarb/pprof/pprof.main.alloc_objects.alloc_space.inuse_objects.inuse_space.00
9.pb.gz
File: main
Type: inuse_space
Time: Oct 15, 2018 at 4:22pm (CEST)
Entering interactive mode (type "help" for commands, "o" for options)
(pprof) png
Generating report in profile001.png

View Slide

View Slide

https://github.com/influxdata/influxdb/blob/4cbdc197b8117fee648d62e2e5be75c6575352f0/services/httpd/pprof.go
// handleProfiles determines which profile to return to the requester.
func (h *Handler) handleProfiles(w http.ResponseWriter, r *http.Request) {
switch r.URL.Path {
case "/debug/pprof/cmdline":
httppprof.Cmdline(w, r)
case "/debug/pprof/profile":
httppprof.Profile(w, r)
case "/debug/pprof/symbol":
httppprof.Symbol(w, r)
case "/debug/pprof/all":
h.archiveProfilesAndQueries(w, r)
default:
httppprof.Index(w, r)
}
}

View Slide

// archiveProfilesAndQueries collects the following profiles:
// - goroutine profile
// - heap profile
// - blocking profile
// - mutex profile
// - (optionally) CPU profile
//
// It also collects the following query results:
//
// - SHOW SHARDS
// - SHOW STATS
// - SHOW DIAGNOSTICS
//
// All information is added to a tar archive and then compressed, before
being
// returned to the requester as an archive file.

View Slide

var allProfs = []*prof{
{Name: "goroutine", Debug: 1},
{Name: "block", Debug: 1},
{Name: "mutex", Debug: 1},
{Name: "heap", Debug: 1},
}

View Slide

gz := gzip.NewWriter(&resp)
tw := tar.NewWriter(gz)
// Collect and write out profiles.
for _, profile := range allProfs {
if profile.Name == "cpu" {
if err := pprof.StartCPUProfile(&buf); err != nil {
http.Error(w, err.Error(), http.StatusInternalServerError)
return
}
sleep(w, time.Duration(profile.Debug)*time.Second)
pprof.StopCPUProfile()
} else {
prof := pprof.Lookup(profile.Name)
if prof == nil {
http.Error(w, "unable to find profile "+profile.Name, 500)
return
}
if err := prof.WriteTo(&buf, int(profile.Debug)); err != nil {
return
}
}
}

View Slide

// Collect and write out the queries.
var allQueries = []struct {
name string
fn func() ([]*models.Row, error)
}{
{"shards", h.showShards},
{"stats", h.showStats},
{"diagnostics", h.showDiagnostics},
}
tabW := tabwriter.NewWriter(&buf, 8, 8, 1, '\t', 0)
for _, query := range allQueries {
rows, err := query.fn()
if err != nil {
}

View Slide

func (h *Handler) showDiagnostics() ([]*models.Row, error) {
diags, err := h.Monitor.Diagnostics()
if err != nil {
return nil, err
}
// Get a sorted list of diagnostics keys.
sortedKeys := make([]string, 0, len(diags))
for k := range diags {
sortedKeys = append(sortedKeys, k)
}
sort.Strings(sortedKeys)
rows := make([]*models.Row, 0, len(diags))
for _, k := range sortedKeys {
row := &models.Row{Name: k}
row.Columns = diags[k].Columns
row.Values = diags[k].Rows
rows = append(rows, row)
}
return rows, nil
}

View Slide

Back to tracing - the cost of a retry

View Slide

Distributed Tracing - the cost of a retry

View Slide

Tracing is a debugging tool

View Slide

View Slide

Remote Debugging
in Kubernetes
Delve, GDB

View Slide

Remote Debugging
In Kubernetes
DOESN’T APPLY!

View Slide

That’s not totally true. You can expose the
debugger endpoint. It works. It doesn’t apply for
production workload.

View Slide

Summarize
● Make your hands dirty
● Bring developers in the ops loop
● Write tools!
● Observability events, Metrics, Logs, Traces
● Instrumentation code is a first citizen code in our app
● Tracing

View Slide

Credits and articles to read
● https://gianarb.it
● https://www.influxdata.com/blog/monitoring-kubernetes-architecture/
● https://www.honeycomb.io/observability/
● https://www.weave.works/technologies/gitops/

View Slide

Thanks
@gianarb

View Slide

ScaleConf Cape Town - Debug like a pro on Kubernetes

ScaleConf Cape Town - Debug like a pro on Kubernetes

Gianluca Arbezzano

More Decks by Gianluca Arbezzano

Other Decks in Technology

Featured

Transcript
