  1. Automating Citrix with PowerShell
    GUY LEECH (@GUYRLEECH) CUGC XL CENTRAL, APRIL 2021

    View Slide

  2. Why?
     Usually easier/quicker than using consoles/installers from (multiple) vendors (once automated)
     Save time & increase reliability of bulk/repeated operations
     Repeatability
     Eliminate human error (once you've tested scripts thoroughly)
     Scheduled tasks
     Easy to import/export to csv/xml/json and send emails & other methods of notification
     Large number of scripts and learning resources out there
     But check/test all scripts before running them as admin on production systems!
    @guyrleech

    View Slide

  3. What?
     CVAD builds – install and configure
     Creating new end-points
     Reboot schedules
     Updates
     Backups
     Problem identification/mitigation
     Daily Health Checks
     NetScaler builds & configuration
     … whatever is tedious, time consuming, error prone, boring, not fun, etc
     But only if it's worthwhile/time efficient
    @guyrleech

    View Slide

  4. Creating New MCS Devices
     Active Directory Machine Accounts
     Get-AcctIdentityPool
     New-AcctADAccount
     Create new machine
     New-ProvVM
     -ADAccountName
     -ProvisioningSchemeName
     -RunAsynchronously
     Add to Machine Catalog
     New-BrokerMachine
     Add to Delivery Group
     Add-BrokerMachinesToDesktopGroup
     Using PowerShell to Create New Citrix MCS Machines | ScriptRunner
    @guyrleech

    View Slide

  5. Creating New PVS Devices
     Active Directory Machine Accounts
     Citrix won't do it for you – use ActiveDirectory module or ADSI to find unused machine
     Also check PVS, Hypervisor & CVAD for orphans/remnants
     Create new machine
     New-VM via VMware PowerCLI (-template)
     Add to PVS
     New-PvsDevice with MAC address via Get-NetworkAdapter
     Add-PvsDiskLocatorToDevice
     Add-PvsDeviceToDomain
     Add to Machine Catalog
     New-BrokerMachine (must specify -HypervisorConnectionUid & -HostedMachineId)
     Add to Delivery Group
     Add-BrokerMachinesToDesktopGroup
     Using PowerShell to Create new Citrix PVS Machines | ScriptRunner
    @guyrleech

    View Slide

  6. Configuring/Changing CVAD via PowerShell
     Set-BrokerMachine
     -InMaintenanceMode
     Set-BrokerDesktopGroup (aka Delivery Group)
     -InMaintenanceMode
     -Enabled
     Set-BrokerCatalog
     Disconnect-BrokerSession / Stop-BrokerSession
     Send-BrokerSessionMessage
    @guyrleech

    View Slide

  7. Admin/Checking CVAD via PowerShell
     Get-BrokerSession
     Filter left for speed: -username, -machinename, -sessionstate, etc
     Get-BrokerMachine
     -InMaintenanceMode
     -Filter e.g. -Filter { InMaintenanceMode -eq 'True' -or RegistrationState -ne 'Registered' }
     Get-PvsDevice
     "join" with Get-PvsDiskInfo, hypervisor, CVAD
     Get-BrokerCatalog
     Get-BrokerDesktopGroup
     Get-BrokerController
    @guyrleech

    View Slide

  8. CVAD PowerShell Considerations
     -AdminAddress (on every call, consider splatting)
     Set-PVSConnection (once)
     -MaxRecordCount & -ReturnTotalRecordCount
     Cloud – create credential profile via downloaded secrets csv file
     But then most things are the same as on-premises, with a few restrictions
     PowerShell view in Citrix Studio – helps you figure out the "how"
     (Legacy) Snapins versus Modules (latter from 1912 LTSR onwards)
     But still not real modules – won't work with Pwsh 7.x
     Account used to run – least privileged
    @guyrleech

    View Slide

  9. Scheduled Tasks
     Least privileged service account (with "log on as a batch job" privilege)
     Test command line via (legacy) cmd.exe running as account set to run task
     Write a log file (Start-Transcript/Stop-Transcript)
     Use a single management machine ("jump box") – install all cmdlets, SDKs, etc
     Create separate task folders
     Notifications on success/failure - email
     Gotchas
     Single quotes
     Nested quotes (if all else fails, base64 encode the command line)
     Array flattening (resurrect with –split)
     $true/$false treated as string literals (use [switch] or [bool]::Parse() )
     Easy to copy with PowerShell
    @guyrleech

    View Slide

  10. CVAD PowerShell Pre-requisites
     PowerShell cmdlets
     Installed with Studio (but don't use a Delivery Controller)
     PowerShell MSI files from CVAD ISO
     Remote PowerShell SDK (for Cloud ONLY)
     PVS (7.8 onwards) uses console dlls for modules
     Not available on PowerShell Gallery, etc
    @guyrleech

    View Slide

  11. Guy's Top Tips
     Test, test, test (automate with Pester?)
     Boundary conditions – too big/small?
     Bad input – users do the stupidest things
     Scale – works ok with 2 but what about 2222 ?
     What if ("no sane person should ever do this but …")
     Document – are comments in the code really enough?
     No Clear Text Passwords
     Least Privilege
     Annotate
     Error Handling & Reporting
     Change & Version Control
     Use a Jump Box, not production servers
     Backup
     Systems before changing
     Scripts, config files, command lines, scheduled tasks
     Audit trail (Write-EventLog) @guyrleech

    View Slide

  12. Useful Resources
     github.com/guyrleech
     github.com/guyrleech/Citrix
     carlwebster.com
     workspace-guru.com
     github.com/citrix
     www.scriptrunner.com/en/software/script-collections/
     developer.cloud.com
     jgspiers.com
    @guyrleech

    View Slide

  13. The End (or is it the Beginning?)
     Go forth and automate
     Or fifth šŸ˜„
