Connecting the Bean: the bumpy road of BLE on Android (lite)

Abbreviated version of my bluetooth talk as seen at Droidcon DE.

Transcript

1. Connecting the bean: The bumpy road of BLE on Android Hugo Visser Little Robots source: https://www.flickr.com/photos/klaasjan/6295632164
3. @botteaap +HugoVisser hugo@littlerobots.nl
4. The bumpy road of BLE on Android LightBlue Bean 3 Prototyping Arduino + BLE Accelerometer, LED, temperature Coin cell battery punchthrough.com/bean
5. The bumpy road of BLE on Android LightBlue Bean 3 Prototyping Arduino + BLE Accelerometer, LED, temperature Coin cell battery punchthrough.com/bean
6. The bumpy road of BLE on Android LightBlue Bean Unofficial Android SDK est. July 2014 bitbucket.org/littlerobots/beanlib MIT License 4
7. The bumpy road of BLE on Android LightBlue Bean Unofficial Android SDK est. July 2014 bitbucket.org/littlerobots/beanlib MIT License 4
8. The bumpy road of BLE on Android 5 Android BLE Platform API since Android 4.3 (API 18) Part of bluedroid BT Classic + BLE support
9. The bumpy road of BLE on Android 6 First steps Declare permissions in AndroidManifest.xml <uses-permission android:name="android.permission.BLUETOOTH"/> <uses-permission android:name="android.permission.BLUETOOTH_ADMIN"/> <uses-feature android:name="android.hardware.bluetooth_le" android:required="true"/> Require Bluetooth BLE if essential to the app
10. The bumpy road of BLE on Android 7 First steps Check for BLE support if (!getPackageManager().hasSystemFeature(PackageManager.FEATURE_BLUETOOTH_LE)) { // awww snap :( No LE support }
11. The bumpy road of BLE on Android 8 First steps Get the Bluetooth Adapter BluetoothManager bluetoothManager = (BluetoothManager) getSystemService(Context.BLUETOOTH_SERVICE); mBluetoothAdapter = bluetoothManager.getAdapter(); (but…this also works) mBluetoothAdapter = BluetoothAdapter.getDefaultAdapter();
12. The bumpy road of BLE on Android 9 First steps if (mBluetoothAdapter == null || !mBluetoothAdapter.isEnabled()) { Intent enableBtIntent = new Intent(BluetoothAdapter.ACTION_REQUEST_ENABLE); startActivityForResult(enableBtIntent, REQUEST_ENABLE_BT); } Check that bluetooth is enabled
13. The bumpy road of BLE on Android Find me a device BluetoothAdapter. startLeScan() and LeScanCallback 10 public boolean startLeScan (BluetoothAdapter.LeScanCallback callback)
14. The bumpy road of BLE on Android Small bump #1 What does false mean? Most likely: Bluetooth is disabled (but you checked) Or…infamous bugs (check logcat) 11
15. The bumpy road of BLE on Android Small bump #2 How many callbacks per device? a) One b) Many c) It depends 12
16. The bumpy road of BLE on Android Small bump #2 How many callbacks per device? a) One b) Many c) It depends 13
17. The bumpy road of BLE on Android Find me type of device public boolean startLeScan (UUID[] serviceUuids, BluetoothAdapter.LeScanCallback callback) Does not work with 128 bit UUIDs Solution: DIY filtering stackoverflow.com/questions/18019161/startlescan-with-128-bit- uuids-doesnt-work-on-native-android-ble-implementation 14
18. The bumpy road of BLE on Android Now for some good news 15
19. The bumpy road of BLE on Android Now for some good news 15
20. The bumpy road of BLE on Android BluetoothLeScanner Filtering Batching of results* Power modes* ParcelUuid uuid = ParcelUuid.fromString("a495ff10-c5b1-4b44-b512-1370f02d74de"); BluetoothManager bm = (BluetoothManager) getSystemService(BLUETOOTH_SERVICE); BluetoothAdapter adapter = bm.getAdapter(); ScanFilter scanFilter = new Builder().setServiceUuid(uuid).build(); ScanSettings settings = new ScanSettings.Builder().build(); * this asterix might spoil the party 16
21. The bumpy road of BLE on Android BluetoothLeScanner adapter.getBluetoothLeScanner().startScan(singletonList(scanFilter), settings, new ScanCallback() { @Override public void onScanResult(int callbackType, ScanResult result) { // process the result, there's currently only one callbackType defined } @Override public void onBatchScanResults(List<ScanResult> results) { // terms and conditions apply } @Override public void onScanFailed(int errorCode) { // handle error based on the errorCode! } }); 17
22. The bumpy road of BLE on Android *one more thing Power modes & batching require hardware support 18
23. The bumpy road of BLE on Android Connecting 19
24. The bumpy road of BLE on Android BluetoothGatt Manages the connection to the peripheral Don’t forget to close() when done, manage reference carefully! 20
25. The bumpy road of BLE on Android Auto connect? Advice against using autoConnect = true Behaviour is unclear Disconnect to cancel does not work on 4.3 Recommendation: manage (re)connection in your app 21
26. The bumpy road of BLE on Android BluetoothGattCallback Typical sequence: 1. onConnectionStateChange() 2. call discoverServices() 3. onServicesDiscovered() 4. read / write characteristics and / or subscribe to updates 5. close() when done 22
27. The bumpy road of BLE on Android Connection & discovery BluetoothDevice device = ... // obtained from scanning device.connectGatt(this, false, new BluetoothGattCallback() { @Override public void onConnectionStateChange(BluetoothGatt gatt, int status, int newState) { if (status == BluetoothGatt.GATT_SUCCESS) { if (newState == BluetoothGatt.STATE_CONNECTED) { if (!gatt.discoverServices()) { // requesting service failed, make sure we clean up gatt.close(); } } } else { // connection failed, clean up gatt.close(); } } public void onServicesDiscovered(BluetoothGatt gatt, int status) { // find the service we like to use mSerialService = gatt.getService(BEAN_SERIAL_CHARACTERISTIC_UUID); if (mSerialService == null) { // service is not found, close the client gatt.close(); } } }); 23
28. The bumpy road of BLE on Android Not in the docs Limited amount of LE connections (total!) 4 connections on 4.3 7 on 4.4+ 24
29. The bumpy road of BLE on Android Characteristics public void onServicesDiscovered(BluetoothGatt gatt, int status) { BluetoothGattCharacteristic characteristic = service.getCharacteristic(BEAN_SERIAL_CHARACTERISTIC_UUID); if (!gatt.readCharacteristic(characteristic)) { gatt.close(); } } @Override public void onCharacteristicRead(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic, int status) { if (status == BluetoothGatt.GATT_SUCCESS) { byte[] value = characteristic.getValue(); String stringValue = characteristic.getStringValue(0); } else if (status == BluetoothGatt.GATT_INSUFFICIENT_AUTHENTICATION) { boolean bonding = gatt.getDevice().createBond(); // note: API 19 gatt.close(); } else { gatt.close(); } } 25
30. The bumpy road of BLE on Android Notifications public void onServicesDiscovered(BluetoothGatt gatt, int status) { BluetoothGattService service = gatt.getService(UUID.fromString("a495ff10-c5b1-4b44-b512-1370f02d74de")); BluetoothGattCharacteristic characteristic = service.getCharacteristic(BEAN_SERIAL_CHARACTERISTIC_UUID); if (characteristic == null) { gatt.close(); return; } if (gatt.setCharacteristicNotification(characteristic, true)) { UUID descriptorUuid = UUID.fromString("2902-0000-1000-8000-00805f9b34fb"); // remember? BluetoothGattDescriptor descriptor = characteristic.getDescriptor(descriptorUuid); descriptor.setValue(BluetoothGattDescriptor.ENABLE_NOTIFICATION_VALUE); if (!gatt.writeDescriptor(descriptor)) { gatt.close(); } } } public void onDescriptorWrite(BluetoothGatt gatt, BluetoothGattDescriptor descriptor, int status) { if (status != BluetoothGatt.GATT_SUCCESS) { gatt.close(); } } 26
31. The bumpy road of BLE on Android Profit! @Override public void onCharacteristicChanged(BluetoothGatt gatt, BluetoothGattCharacteristic characteristic) { // handle updated value } 27
32. The bumpy road of BLE on Android Notification limits There’s a hard limit on the number of notifications you can have: 4 on Android 4.3 7 on Android 4.4 15 on Android 5 28
33. The bumpy road of BLE on Android Writing characteristics public void write(byte[] data) { mCharacteristic.setValue(data); if (!mGatt.writeCharacteristic(mCharacteristic)) { mGatt.close(); } // important: wait for onCharacteristicWrite callback before attempting the next write! } 29
34. The bumpy road of BLE on Android Juggling writes By design the Bean SDK does a lot of writing Split data in 20 byte packets, write to characteristic Assemble packets from notifications Single characteristic for read/write makes it harder 30
35. The bumpy road of BLE on Android Conclusions Android has full support for BLE, maturing in Lollipop The BLE related API’s are really low level Error checking all over the place Documentation could use some work 31
36. The bumpy road of BLE on Android Observations Complexity managing multiple characteristics in a single callback. Low level interface seems straightforward, but is difficult to get right. Bean SDK has GattClient to solve some of those problems 32
37. The bumpy road of BLE on Android Learn more bitbucket.org/littlerobots/beanlib d.android.com/guide/topics/connectivity/bluetooth-le.html punchthrough.com/bean 33
38. The bumpy road of BLE on Android Thank you @botteaap google.com/+hugovisser hugo@littlerobots.nl www.littlerobots.nl 34
