Reactive UIs with Data Binding

Presented at the AppDevcon conference in Amsterdam

Transcript

1. Reactive UIs with Data Binding Hugo Visser @botteaap hugo@littlerobots.nl
2. Data binding in a nutshell Views are encapsulated in a single ViewDataBinding class By binding data (a model) to a ViewDataBinding the view will update Click listeners and 2-way binding can update the model from the view Data is bound using expressions and converted using BindingAdapters
4. Philosophical: “It’s jsp for Android” Data Binding allows you do to a lot of things and isn’t opinionated No extensive documentation or samples at launch did not help Establish best practices in your team!
5. Referencing views: findViewById class MyActivity: AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContentView(R.layout.activity_main) val firstName = findViewById<TextView>(R.id.first_name) // "bind" the TextView to a value firstName.text = "Hugo" } }
6. Referencing views: Kotlin synthetic properties import kotlinx.android.synthetic.main.activity_main.* class MyActivity: AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContentView(R.layout.activity_main) // "bind" the TextView to a value first_name.text ="Hugo" } }
7. Data Binding 1. Enable in build.gradle 2. Add kotlin-kapt 3. Convert layout to data binding layout
8. build.gradle apply plugin: 'com.android.application' apply plugin: 'kotlin-android' apply plugin: 'kotlin-kapt' android { dataBinding { enabled = true } }
9. Convert layout <layout xmlns:android="http://schemas.android.com/apk/res/android"> <LinearLayout android:layout_width="match_parent" android:layout_height="match_parent" android:orientation="vertical"> <TextView android:id="@+id/first_name" android:layout_width="wrap_content" android:layout_height="wrap_content" /> </LinearLayout> </layout>
10. ViewDataBinding class MyActivity: AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { val binding = DataBindingUtil.setContentView<ActivityMainBinding>(this, R.layout.activity_main) binding.firstName.text = "Hugo" } }
11. Binding a model class MyActivity: AppCompatActivity() { override fun onCreate(savedInstanceState: Bundle?) { val binding = DataBindingUtil.setContentView<ActivityMainBinding>(this, R.layout.activity_main) binding.person = Person("Hugo", "Visser") } }
12. Demo
13. Binding expressions android:text="@{user.displayName}" android:text="@{user.displayName ?? user.lastName}" android:padding="@{large ? @dimen/largePadding : @dimen/smallPadding}" android:text="@{@plurals/banana(bananaCount)}" android:text="@{@string/nameFormat(firstName, lastName)}" android:checked="@={viewModel.agreeToTerms}" app:clipToOutline="@{true}" app:avatarUrl="@{user.avatar}"
14. Binding expressions? android:text="@{String.valueOf(index + 1)}" android:visibility="@{age > 13 ? View.GONE : View.VISIBLE}"
15. Organising the data to bind A (single) model backing the view, e.g. a view model Works well with MVVM style architectures View model ≠ ViewModel, but it can be. Also: click listeners for actions that do not deal with model state
16. Organising the data to bind <data> <variable name="viewModel" type="nl.littlerobots.databindingsamples.ExampleViewModel"/> <variable name="closeClickListener" type="android.view.View.OnClickListener"/> </data>
17. Organising the data to bind <Button android:onClick="@{closeClickListener}" /> <TextView android:text="@{viewModel.person.lastName}" />
18. Binding Adapters Create framework calls that set values on views Might convert the attribute value in the process https://developer.android.com/topic/libraries/data-binding/binding-adapters
19. Binding Adapters public class BindingAdapters { @BindingAdapter("price") public static void bindPrice(TextView view, Price price) { if (price == null) { view.setText(null); } else { view.setText(PriceFormatUtil.format(view.getContext(), price)); } } }
20. Binding Adapters <TextView app:price="@{viewModel.selectedConferenceTicket.price}" android:layout_width="wrap_content" android:layout_height="wrap_content" />
21. Binding Adapters in Kotlin @BindingAdapter("price") // Note that the price object can be null! fun bindPrice(view: TextView, price: Price?) { } object BindingAdapters { @BindingAdapter("price") @JvmStatic fun bindPrice(view: TextView, price: Price?) { } }
22. Binding Adapters in Kotlin // Let’s be clever :) @BindingAdapter("price") fun TextView.bindPrice(price: Price?) { }
23. Non-static Binding Adapters in Kotlin class BindingAdapters(private val priceFormatter: MyPriceFormatter) { @BindingAdapter("price") fun bindPrice(view: TextView, price: Price?) { } } public interface DataBindingComponent { nl.littlerobots.databindingsamples.BindingAdapters getBindingAdapters(); }
24. Binding Adapters in Kotlin val myComponent: DataBindingComponent = … // Somewhere globally, or per activity etc DataBindingUtil.setDefaultComponent(myComponent) // For a specific binding val binding = DataBindingUtil.setContentView<ActivityMainBinding>(this, R.layout.activity_main, myComponent)
25. Reactive UI Inherently async nature of applications, data loading, events etc. Update to the model updates the view, without rebinding the model Bind the model only for view setup, interact with the model for view updates
26. Reactive UI override fun onCreate(savedInstanceState: Bundle?) { val binding: ActivityCheckOutBinding = … binding.viewModel = checkOutViewModel checkOutViewModel.loadTicketPrice() } class CheckOutViewModel { var price: Price? = null fun loadTicketPrice() { } }
27. Data Binding Observables android.databinding.Observable
28. Data Binding Observables class CheckOutViewModel: BaseObservable() { @Bindable var price: Price? = null set(value) { field = value notifyPropertyChanged(BR.price) } fun loadTicketPrice() { } }
29. Dependencies class CheckOutViewModel: BaseObservable() { @Bindable var price: Price? = null set(value) { field = value notifyPropertyChanged(BR.price) } @get:Bindable("price") val orderButtonEnabled: Boolean get() = price != null }
30. Dependencies class CheckOutViewModel { val price = ObservableField<Price>() val orderButtonEnabled = ObservableBoolean() fun loadTicketPrice() { val result = repository.retrieveTicketPrice() price.set(result) orderButtonEnabled.set(true) } }
31. Observable Prefer extending BaseObservable over Observable* classes Dependencies between @Bindable fields are very convenient for form input Architecture components ViewModel can also implement Observable https://developer.android.com/topic/libraries/data-binding/architecture
32. Using LiveData class CheckOutViewModel { // requires a cast to update, but doesn't expose mutability val price: LiveData<Price> = MutableLiveData() val couponCode = MutableLiveData<String>() // for two-way data binding }
33. Pass the lifecycle owner to the binding! class CheckOutViewModel { // requires a cast to update, but doesn't expose mutability val price: LiveData<Price> = MutableLiveData() val couponCode = MutableLiveData<String>() // for two-way data binding } // In Activity.onCreate() val binding = DataBindingUtil.setContentView<ActivityMainBinding>(this, R.layout.activity_main) binding.lifecycleOwner = this
34. Pass the lifecycle owner to the binding! class MyFragment: Fragment() { override fun onCreateView(inflater: LayoutInflater, container: ViewGroup?, savedInstanceState: Bundle?): View? { val binding = MyFragmentBinding.inflate(inflater, container, false) binding.lifecycleOwner = viewLifecycleOwner return binding.root } }
35. When to use Observable Model is mutated, but changes are only observed by the view / binding Updating of properties are not tied to a lifecyle
36. When to use LiveData Model property is also observed from an Activity or Fragment Needs to be aware of lifecycle Tip: when bridging RxJava observables → lifecycle
37. In practice Implement Observable in your ViewModel Mix and match the use of @Bindable properties and LiveData
39. Using includes for reusable components <layout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto"> <data> <variable name="model" type="nl.littlerobots.databindingsamples.MessageBannerModel"/> </data> <TextView android:layout_width="match_parent" android:layout_height="wrap_content" android:text="@{model.message}" /> </layout>
40. Using includes for reusable components <layout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto"> <data> <variable name="viewModel" type="..."/> <variable name="messageBannerModel" type="nl.littlerobots.databindingsamples.MessageBannerModel"/> </data> <LinearLayout> <include layout="@layout/include_message_banner" app:model="@{messageBannerModel}"/> </LinearLayout> </layout>
41. Providing context class MyViewModel(private val context: Context) { fun getComplicatedErrorMessage(): String { context.getString(...) } }
42. Providing context class MyViewModel { fun getComplicatedErrorMessage(context: Context): String { context.getString(...) } }
43. Providing context <TextView android:text="@{viewModel.getComplicatedErrorMessage(context)}" android:layout_width="wrap_content" android:layout_height="wrap_content" />
44. Applying bindings immediately When inflating a binding and adding it to a view group RecyclerView view holders ViewDataBinding.executePendingBindings()
45. Groupie for RecyclerView interfaces https://github.com/lisawray/groupie Provides a GroupAdapter for RecyclerView that shows a group Group can be a single item, collection of items, mix of item types Works great with Data Binding
46. Data bound Item example class SongItem(private val song: Song) : BindableItem<SongBinding>() { override fun getLayout(): Int = R.layout.song override fun bind(binding: SongBinding, position: Int) { binding.setSong(song) } }
47. Summary Data Binding allows for Reactive UIs w/ Observable and LiveData Adds a layer of separation and encapsulation for your screens / views Versatile and powerful: agree on usage and best patterns in your team!
48. Read the fine manual https://developer.android.com/topic/libraries/data-binding
49. Tips & tricks Custom views (includes)? Custom setters? executePendingBindings() Binding both model + click listeners DataBindingComponent Groupie for RV Callback with context
