Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields -
Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields • Large Image / Video Uploads -
Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields • Large Image / Video Uploads • Data Formatting / Validation -
Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields • Large Image / Video Uploads • Data Formatting / Validation • Random Error Probability -
Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields • Large Image / Video Uploads • Data Formatting / Validation • Random Error Probability • HUD, Progress Bar, UI Refreshing -
Problems / Features • Client Demo • Slow Network Connectivity
• Mandatory Fields • Large Image / Video Uploads • Data Formatting / Validation • Random Error Probability • HUD, Progress Bar, UI Refreshing • Session Setup etc… -
How to configure? • HTTP Server Communication – Start Server
-‐ Open a Socket – Receive Incoming Connections – Response Handling – Stop Server -‐ Close Socket -
Open a Socket I • Create Socket object CFSocketRef socket
= CFSocketCreate(kCFAllocatorDefault, PF_INET, SOCK_STREAM, IPPROTO_TCP, 0, NULL, NULL); • Get Native Socket int reuse = true; int fileDescriptor = CFSocketGetNative(socket); setsockopt(fileDescriptor, SOL_SOCKET, SO_REUSEADDR, (void *)&reuse, sizeof(int)); -
Open a Socket II • Bind Socket to address struct
sockaddr_in address; memset(&address, 0, sizeof(address)); address.sin_len = sizeof(address); address.sin_family = AF_INET; address.sin_addr.s_addr = htonl(INADDR_ANY); NSInteger portNumber = 8080; address.sin_port = htons(portNumber); CFDataRef addressData = CFDataCreate(NULL, (const UInt8 *)&address, sizeof(address)); CFSocketSetAddress(socket, addressData); -
Receive Incoming Connections I • Constructing File Handler NSFileHandle *listeningHandle
= [[NSFileHandle alloc] initWithFileDescriptor:fileDescriptor closeOnDealloc:YES]; [listeningHandle acceptConnectionInBackgroundAndNotify]; • Attach Connection Listener [[NSNotificationCenter defaultCenter] addObserver:self selector:@selector(receiveIncomingConnectionNotification:) name:NSFileHandleConnectionAcceptedNotification object:nil]; -
Receive Incoming Connections II • Receive File Handler NSDictionary *userInfo
= [notification userInfo]; NSFileHandle *incomingFileHandle = [userInfo objectForKey:NSFileHandleNotificationFileHandleItem]; • Attach Incoming Data Listener [[NSNotificationCenter defaultCenter] addObserver:self selector:@selector(receiveIncomingDataNotification:) name:NSFileHandleDataAvailableNotification object:incomingFileHandle]; -
Two File Handlers I • Connection Listening – Manually
Created Once for Socket, which listens to new connections. • Data Listening – Automatically Created for each new connection, which listens to new available data. -
Two File Handlers II Opened Socket Broadcasting Connections Your
Listener / Connection Handler. A Receiver for incoming connections Each Connection’s Data Handler given by Connection Handler Available Data from Notification Object Comes from Data Handler -
Receive Incoming Data I • Handle Incoming Data NSFileHandle *incomingFileHandle
= [notification object]; NSData *data = [incomingFileHandle availableData]; NSString *strIncomingData = [[[NSString alloc] initWithData:data encoding:NSUTF8StringEncoding] autorelease]; • Create HTTP Message to store date CFHTTPMessageRef incomingRequest = CFHTTPMessageCreateEmpty(kCFAllocatorDefault, TRUE); CFHTTPMessageAppendBytes(incomingRequest, [data bytes], [data length]); CFHTTPMessageIsHeaderComplete(incomingRequest); -
Receive Incoming Data II • Sample Incoming Data GET /
HTTP/1.1 Host: 127.0.0.1:8080 Accept-‐Encoding: gzip, deflate Accept: text/html,application/xhtml+xml,application/xml;q=0.9,/*;q=0.8 User-‐Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_10) AppleWebKit/538.34.48 (KHTML, like Gecko) Version/8.0 Safari/538.35.8 Accept-‐Language: en-‐us DNT: 1 Connection: keep-‐alive -
Handling Response I • Parsing Request Data NSURL *requestURL =
NSMakeCollectable(CFHTTPMessageCopyRequestURL(ref)); NSString *httpMethod = NSMakeCollectable(CFHTTPMessageCopyRequestMethod(ref)); NSDictionary *httpHeaderFields = NSMakeCollectable(CFHTTPMessageCopyAllHeaderFields(ref)); NSData *httpBody = NSMakeCollectable(CFHTTPMessageCopyBody(ref)); -
Handling Response II • Create HTTP Response NSInteger responseCode =
200; CFHTTPMessageRef response = CFHTTPMessageCreateResponse(kCFAllocatorDefault, responseCode, NULL, kCFHTTPVersion1_1); • Add Response header fields CFHTTPMessageSetHeaderFieldValue(response, (CFStringRef)@"Content-‐Type", (CFStringRef)@"text/plain"); CFHTTPMessageSetHeaderFieldValue(response, (CFStringRef)@"Connection", (CFStringRef)@"close"); -
Handling Response III • Add Data Length in header fields
NSString *dataLength = [NSString stringWithFormat:@”%d", fileData.length]; CFHTTPMessageSetHeaderFieldValue(response, (CFStringRef)@"Content-‐ Length", (CFStringRef)dataLength); • Serialize HTTP Response in Data CFDataRef headerData = CFHTTPMessageCopySerializedMessage(response); -
Sending Response • Write HTTP Header Data and Response Data
[incomingFileHandle writeData:(NSData*)headerData]; [incomingFleHandle writeData:fileData]; • Close file handler and Remove Listeners [incomingFileHandle closeFile]; [[NSNotificationCenter defaultCenter] removeObserver:self name:NSFileHandleDataAvailableNotification object:incomingFileHandle]; -
Stop Server • Remove Connection Listener [[NSNotificationCenter defaultCenter] removeObserver:self
name:NSFileHandleConnectionAcceptedNotification object:nil]; • Close Socket [listeningHandle closeFile]; CFSocketInvalidate(socket); CFRelease(socket); -
Configure in App (swift syntax J) • Start Server func
application(application: UIApplication!, didFinishLaunchingWithOptions launchOptions: NSDictionary!) -‐> Bool func applicationWillEnterForeground(application: UIApplication!) • Stop Server func applicationDidEnterBackground(application: UIApplication!) -
Solutions • Set up Core Data or SQLite for dynamic
tables • Add delay before Response Handling • Configure Error Probability On Response • Configure Session Setup • Add Server States (Idle / Running) • Add Configurations like Port no, etc… -
Frameworks Needed • #import <sys/socket.h> – For #defines like AF_INET
protocol family • #import <netinet/in.h> – Socket address structure and others defined • #import <CFNetwork/CFNetwork.h> – Core Network APIs (need to add into project)
