UP Lecture 24

UP Lecture 24

Compilers
Intermediate Code
(202505)

Javier Gonzalez-Sanchez PRO

December 29, 2023

Transcript

28 slides
  1. Dr. Javier Gonzalez-Sanchez | Compilers | 2 jgs A Compiler

    in Action Lexer Parser Semantic Analyzer Code Generation Words Tokens Sentences Symbol table Uniqueness Type matching Translation Source Code ➔ Intermediate Code Intermediate Code ➔ Machine or Binary Code Analysis Compilation Assembly
  2. Dr. Javier Gonzalez-Sanchez | Compilers | 3 jgs High-Level Languages

    X,E,G,O,O #e1,I,I,0,7 @ OPR 19, AX STO x, AX LIT 5, AX OPR 21, AX LOD #e1,AX CAL 1, AX OPR 0, AX 5 Virtual Machine (interpreter) // sorce code int x; int foo () { read (x); print (5); } main () { foo (); } Lexer Parser Semantic Analyzer Code Generation 01001010101000010 01010100101010010 10100100000011011 11010010110101111 00010010101010010 10101001010101011 Assembler compilation execution
  3. Dr. Javier Gonzalez-Sanchez | Compilers | 4 jgs High-Level Languages

    X,E,G,O,O #e1,I,I,0,7 @ OPR 19, AX STO x, AX LIT 5, AX OPR 21, AX LOD #e1,AX CAL 1, AX OPR 0, AX 5 Virtual Machine (interpreter) // sorce code int x; int foo () { read (x); print (5); } main () { foo (); } Lexer Parser Semantic Analyzer Code Generation 01001010101000010 01010100101010010 10100100000011011 11010010110101111 00010010101010010 10101001010101011 Assembler compilation execution
  4. Dr. Javier Gonzalez-Sanchez | Compilers | 5 jgs Assignment #4

    Lexer Parser Semantic Analyzer Code Generation Report Errors JTable with Tokens Report Errors Draw a Tree Report Errors Create Symbol Table Following lectures
  5. Dr. Javier Gonzalez-Sanchez | Compilers | 6 jgs Source Code

    { int a; int b; int c; int d; if (a != 5) { b = c + d; } print (a); }
  6. Dr. Javier Gonzalez-Sanchez | Compilers | 7 jgs Intermediate (Object)

    Code a,int,global 0 b,int,global 0 c,int,global 0 d,int,global 0 #E1,int,label,9 #P,int,label,1 @ lod a, 0 lit 5, 0 opr 14, 0 jmc #e1, false lod c, 0 lod d, 0 opr 2, 0 sto b, 0 lod a, 0 opr 21, 0 opr 1, 0 Symbol table Instructions
  7. Dr. Javier Gonzalez-Sanchez | Compilers | 8 jgs Translate Source

    to Object { int a; int b; int c; int d; if (a != 5) { b = c + d; } print (a); } a,int,global 0 b,int,global 0 c,int,global 0 d,int,global 0 #E1,int,label,9 #P,int,label,1 @ lod , 0 lit 5, 0 opr 14, 0 jmc #e1, false lod c, 0 lod d, 0 opr 2, 0 sto b, 0 lod a, 0 opr 21, 0 opr 1, 0
  8. Dr. Javier Gonzalez-Sanchez | Compilers | 9 jgs A Simple

    Virtual Machine CPU ALU Register Memory
  9. Dr. Javier Gonzalez-Sanchez | Compilers | 10 jgs Memory program

    A Simple Virtual Machine CPU ALU Register Code sto 0, s sto 0, d sto 0, c sto 0, d lod s, 0 lit “s”, 0 opr 14, 0 jmc #a1, false lod b, 0 Symbol Table
  10. Dr. Javier Gonzalez-Sanchez | Compilers | 11 jgs A Simple

    Virtual Machine CPU ALU Register PC Memory program Code sto 0, s sto 0, d sto 0, c sto 0, d lod s, 0 lit “s”, 0 opr 14, 0 jmc #a1, false lod b, 0 Symbol Table
  11. Dr. Javier Gonzalez-Sanchez | Compilers | 13 jgs Instructions ▪

    LIT <value>, <register_id> Put a constant value in a CPU register Examples: LIT 5, 0 LIT 5.5, 0 LIT 'a', 0 LIT ”hello”, 0 LIT true, 0
  12. Dr. Javier Gonzalez-Sanchez | Compilers | 14 jgs Instructions ▪

    LOD <variable>, <register_id> Search for <variable> in the symbol table Read its value Put the value of <variable> in the CPU register Examples: LOD a, 0 LOD hello, 0 LOD cse340, 0
  13. Dr. Javier Gonzalez-Sanchez | Compilers | 15 jgs Instructions ▪

    STO <variable>, <register_id> Read a value from the CPU register Search for <variable> in the symbol table Store the value into the variable Examples: STO a, 0 STO hello, 0 STO cse340, 0
  14. Dr. Javier Gonzalez-Sanchez | Compilers | 16 jgs Example Source

    Code: { int a; int b; a = 10; b = a; Symbol Table: Type Name Scope Value int a global 0 int b global 0 Intermediate (Object) Code: LIT 10,0 STO a,0 LOD a,0 STO b,0
  15. Dr. Javier Gonzalez-Sanchez | Compilers | 17 jgs Instructions ▪

    OPR <operation>, <register_id> Read one or two values from the CPU register Do the operation <operation> Put the result into the CPU register Examples: OPR 1, 0 ; return OPR 2, 0 ; add OPR 3, 0 ; subtract
  16. Dr. Javier Gonzalez-Sanchez | Compilers | 18 jgs Operations Number

    Action 0 Exit program 1 Return 2 ADD: POP A, POP B, PUSH B+A 3 SUBTRACT: POP A, POP B, PUSH B-A 4 MULTIPLY: POP A, POP B, PUSH B*A 5 DIVIDE: POP A, POP B, PUSH B/A 6 MOD: POP A, POP B, PUSH (B mod A) 7 POW: POP A, POP B, PUSH (A to the power B) 8 OR: POP A, POP B, PUSH (B or A) 9 AND: POP A, POP B, PUSH (B and A) 10 NOT: POP A, PUSH (not A) 11 TEST GREATER THAN: POP A, POP B, PUSH (B>A) 12 TEST LESS THAN: POP A, POP B, PUSH (B<A) 13 TEST GREATER THAN OR EQUAL: POP A, POP B, PUSH (B>=A)
  17. Dr. Javier Gonzalez-Sanchez | Compilers | 19 jgs Operations Number

    Action 14 TEST LESS THAN OR EQUAL: POP A, POP B, PUSH (B<=A) 15 TEST EQUAL: POP A, POP B, PUSH (B=A) 16 TEST NOT EQUAL: POP A, POP B, PUSH (B<>A) 17 18 clear screen 19 read a value from the standard input 20 print a value to the standard output 21 print a value to the standard output and a newline character
  18. Dr. Javier Gonzalez-Sanchez | Compilers | 20 jgs Example {

    int a; int b; a = 10; b = a; a = a * 10; b = 2 + 3 + 4; } Type Name Scope Value int a global 0 int b global 0 LIT 10, 0 STO a, 0 LOD a, 0 STO b, 0 LOD a, 0 LIT 10, 0 OPR 4, 0 ; multiply STO a, 0 LIT 2, 0 LIT 3, 0 OPR 2, 0 ; add LIT 4, 0 OPR 2, 0 ; add STO b, 0 OPR 1,0 OPR 0,0
  19. Dr. Javier Gonzalez-Sanchez | Compilers | 21 jgs Code Generation

    * 1 2 * 4 5 + 3 > 1 * 2 > 3 + 4 * 5 LIT 1, 0 LIT 2, 0 OPR 4, 0 LIT 3, 0 LIT 4, 0 LIT 5, 0 OPR 4, 0 OPR 2, 0 OPR 11, 0
  20. Dr. Javier Gonzalez-Sanchez | Compilers | 22 jgs Review a,

    int, global, 0 b, int, global, 0 @ LIT 5, 0 STO a, 0 LIT 9, 0 STO b, 0 LOD a, 0 LOD b, 0 LIT 3, 0 OPR 4, 0 OPR 2, 0 STO a, 0 LOD a, 0 OPR 21,0 LIT "hello", 0 OPR 21,0 OPR 1, 0 OPR 0,0 Virtual Machine (interpreter) { int a; int b; a = 5; b = 9; a = a + b / 3; print (a); print ("hello"); } Lexer Parser Semantic Analyzer Code Generation 8 hello
  21. Dr. Javier Gonzalez-Sanchez | Compilers | 23 jgs Review {

    int a; int b; boolean foo; a = 10 + 20 + 30 + 40; print (a); foo = 340 > 126; print (foo); a = a / 2; print ("total:" + a); return; } Lexer Parser Semantic Analyzer Code Generation
  22. Dr. Javier Gonzalez-Sanchez | Compilers | 24 jgs Review Virtual

    Machine (interpreter) 100 true total: 50
  23. Dr. Javier Gonzalez-Sanchez | Compilers | 26 jgs We need

    a VM Use it to test your compiler. No changes required
  24. jgs Compilers Javier Gonzalez-Sanchez, Ph.D. [email protected] Spring 2025 Copyright. These

    slides can only be used as study material for the Compilers course at Universidad Panamericana. They cannot be distributed or used for another purpose.
