1. AN INTRODUCTION TO THE INTERNET OF THINGS
2. AN INTRODUCTION TO THE INTERNET OF THINGS 2 2 WHAT IS IoT? Internet of Things Refers to the interconnection via the Internet of computing devices embedded in everyday objects, enabling them to send and receive data.
3. AN INTRODUCTION TO THE INTERNET OF THINGS 3 On/Off Switch Generates Data Can Connect to the Internet INTERNET OF THINGS
4. AN INTRODUCTION TO THE INTERNET OF THINGS 4 INTERNET OF “YOUR” THINGS Lights Thermostat Alarm System Security Cameras Heart Rate Monitor Calory intake monitor Agriculture
5. AN INTRODUCTION TO THE INTERNET OF THINGS 5 Navigation Systems Insurance Companies Automobile Manufacturers Formula 1 CONNECTED CARS
6. AN INTRODUCTION TO THE INTERNET OF THINGS 6 CONNECTED HOMES
7. AN INTRODUCTION TO THE INTERNET OF THINGS 7 CONNECTED COWS
8. AN INTRODUCTION TO THE INTERNET OF THINGS 8 IoT DEVICES Popular devices that are used today to generate data are the low cost, credit card- sized computers such as the Raspberry Pi Tessel IO boards Arduino MKRFOX 1200 Nucleo Boards
9. AN INTRODUCTION TO THE INTERNET OF THINGS 9 RASPBERRY PI Both the Pi3 and 4 have the following features • 4 USB ports • 40 GPIO pins • Full HDMI port • Ethernet port • Camera interface (CSI) • • Display Interface (DSI) • Micro SD card slot • Combined 3.5mm audio jack and composite video Raspberry Pi 3 Raspberry Pi 4
10. AN INTRODUCTION TO THE INTERNET OF THINGS 10 TESSEL Features of the Tessel 2 • 2 USB ports • Reliable Wi-Fi • Ethernet Jack • JavaScript and Rust Support
11. AN INTRODUCTION TO THE INTERNET OF THINGS 11 ARDUINO MKRFOX 1200 Features • LPWAN Device with a SigFox Network subscription for one year. • 32-bit computational power • Rich set of I/O interfaces
12. AN INTRODUCTION TO THE INTERNET OF THINGS 12 NUCLEO BOARDS Nucleo-F103RB LoRa mbed Enabled Shield
13. AN INTRODUCTION TO THE INTERNET OF THINGS 13 Low Power Wide Area Networks Cellular Wi-Fi Bluetooth Low Energy IoT NETWORKS • SigFox • LoRa • 3G • 4G • 5G
14. AN INTRODUCTION TO THE INTERNET OF THINGS 14 IoT SOLUTION CORE ESSENTIALS Device Connectivity Data Processing & Processing Local Cloud Devices Cloud Gateway Local Gateway
15. AN INTRODUCTION TO THE INTERNET OF THINGS 15
16. AN INTRODUCTION TO THE INTERNET OF THINGS 16 Azure IoT Connectivity and analytics products Azure IoT Edge and device support products Azure IoT Hub Azure IoT Central Time Series Insights Azure IoT Edge Azure Sphere Azure RTOS
17. AN INTRODUCTION TO THE INTERNET OF THINGS 17 Device Connectivity Data Processing & Processing Local Cloud Devices Cloud Gateway Local Gateway AZURE IoT HUB Azure IoT Hub
18. AN INTRODUCTION TO THE INTERNET OF THINGS 18 WHY IoT HUB Scalability Security Extensibility Device Monitoring
19. AN INTRODUCTION TO THE INTERNET OF THINGS 19 Telemetry Information flowing from a device to other systems for conveying status of device and environment Inquiries Requests from devices looking to gather required information or to initiate activities Commands Commands from other systems to a device or a group of devices to perform specific activities Notifications Information flowing from other systems to a device (group) for conveying status changes COMMUNICATION SCENARIOS
20. AN INTRODUCTION TO THE INTERNET OF THINGS 20 THANK YOU!
