Flink Forward 2022 - Squirreling Away $640 Billion - How Stripe Leverages Flink for Change Data Capture

Transcript

1. View Slide

2. An API that gets out of your way
   It’s so easy, we’ve embedded a bunch of examples right
   here. Copy some of these requests into your terminal and
   check out what happens.
   With wrappers in Ruby, PHP, Python and more, you can
   get started in minutes. Learn More ➤


   View Slide

3. As complexity grew…
   Then we had a ProblemFactory
   Started out with
   We had a problem, so we thought to use …


   View Slide

4. As data volume grew…
   Database scalability is a complicated topic…
   Started out with
   Had to make sure it was web scale
   Distributed transactions
   Change Data Capture


   View Slide

5. View Slide

6. Squirreling Away $640 Billion
   Flink Forward - San Francisco 2022
   Jeff Chao
   Staff Engineer / Tech Lead for Change Data Capture Infrastructure at Stripe
   How Stripe Leverages Flink for Change Data Capture


   View Slide

7. 7
   CDC at Stripe
   Agenda
   1 Aggregating Change Events
   2 How it Started, How it Ended
   3
   Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture
   Change Data Capture (CDC) is
   widely-used at Stripe to capture data
   changes from databases without critically
   impacting database reliability and
   scalability. CDC powers many critical
   financial use cases at Stripe such as the
   Stripe Dashboard, Stripe Search, Sigma,
   and Financial Reporting.
   From idea to production—things may
   seem straightforward at first, but the
   details matter. We detail our journey of
   how we leveraged Flink for Change Data
   Capture at Stripe in order to uphold the
   highest data quality standards. Freshness,
   Coverage, and Correctness SLOs are
   paramount to the success of platforms
   and applications running on top of our
   CDC infrastructure.
   Change Event Streams are ubiquitous
   across Stripe given the vast number of
   applications and employees generating
   datasets worldwide. Change Event
   Streams are independent from one
   another which leads to the typical
   challenges in distributed systems. One of
   the major use cases revolves around
   aggregating individual change events of a
   database transaction to support Stripe’s
   payments infrastructure.


   View Slide

8. Change Data Capture (CDC) is
   widely-used at Stripe to capture data
   changes from databases without critically
   impacting database reliability and
   scalability. CDC powers many critical
   financial use cases at Stripe such as the
   Stripe Dashboard, Stripe Search, Sigma,
   and Financial Reporting.
   8
   From idea to production—things may
   seem straightforward at first, but the
   details matter. We detail our journey of
   how we leveraged Flink for Change Data
   Capture at Stripe in order to uphold the
   highest data quality standards. Freshness,
   Coverage, and Correctness SLOs are
   paramount to the success of platforms
   and applications running on top of our
   CDC infrastructure.
   Change Event Streams are ubiquitous
   across Stripe given the vast number of
   applications and employees generating
   datasets worldwide. Change Event
   Streams are independent from one
   another which leads to the typical
   challenges in distributed systems. One of
   the major use cases revolves around
   aggregating individual change events of a
   database transaction to support Stripe’s
   payments infrastructure.
   Agenda
   CDC at Stripe
   1 Aggregating Change Events
   2 How it Started, How it Ended
   3
   Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture


   View Slide

9. View Slide

10. View Slide

11. Billing
    Capital Checkout
    Connect
    Invoicing
    Corporate
    Card
    Climate
    Atlas
    Radar
    Sigma
    Payouts
    Payments
    Terminal Treasury
    Issuing
    Revenue
    Recognition
    Payment
    Links
    Tax
    Identity
    Elements
    Data
    Pipeline
    Financial
    Connections


    View Slide

12. View Slide

13. 30%
    13
    23
    > 8000
    Remote
    Countries
    Employees
    CDC at Stripe


    View Slide

14. Correctness
    Freshness Coverage
    14
    Strict SLOs
    CDC at Stripe


    View Slide

15. Interoperable
    Abstract Away Internals
    Operational Excellence
    15
    Building a Platform
    Make sure that we abstract away
    database internals such as sharding
    topology and ensure a datastore-agnostic
    transport.
    Build a high leveraged platform which
    makes working with Change Events
    interoperable with other systems within
    the organization.
    Minimal toil given as we scale the number
    of datasets, ensure clean separation
    between infrastructure and user issues,
    create great operator experiences, reduce
    control plane and data plane blast radius,
    maintain good operator tooling/developer
    experience/processes.
    CDC at Stripe


    View Slide

16. 16
    Agenda
    CDC at Stripe
    1 Aggregating Change Events
    2 How it Started, How it Ended
    3
    Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture
    Change Data Capture (CDC) is
    widely-used at Stripe to capture data
    changes from databases without critically
    impacting database reliability and
    scalability. CDC powers many critical
    financial use cases at Stripe such as the
    Stripe Dashboard, Stripe Search, Sigma,
    and Financial Reporting.
    From idea to production—things may
    seem straightforward at first, but the
    details matter. We detail our journey of
    how we leveraged Flink for Change Data
    Capture at Stripe in order to uphold the
    highest data quality standards. Freshness,
    Coverage, and Correctness SLOs are
    paramount to the success of platforms
    and applications running on top of our
    CDC infrastructure.
    Change Event Streams are ubiquitous
    across Stripe given the vast number of
    applications and employees generating
    datasets worldwide. Change Event
    Streams are independent from one
    another which leads to the typical
    challenges in distributed systems. One of
    the major use cases revolves around
    aggregating individual change events of a
    database transaction to support Stripe’s
    payments infrastructure.


    View Slide

17. Why?
    17
    Aggregating Change Events
    Product teams working with payments data use transactions
    Arbitrary number of tables in a database transaction
    They should be able to get transactions back out from the CDC path
    They shouldn’t have to become stream processing experts


    View Slide

18. 18
    Vitess
    Debezium Kafka
    Platform
    Platform
    User
    Aggregating Change Events
    Architecture
    Mongo
    Kafka
    Flink


    View Slide

19. What is a Change Event?
    19
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events


    View Slide

20. What is a Change Event?
    20
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Stream: charges
    Aggregating Change Events


    View Slide

21. What is a Change Event?
    21
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events
    {
    "id" : "transaction-id",
    "global_position": 1,
    "source_position": 1,
    }


    View Slide

22. What is a Change Event?
    22
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events
    {
    "id" : "transaction-id",
    "global_position": 1,
    "source_position": 1,
    }


    View Slide

23. What is a Change Event?
    23
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events
    {
    "id" : "transaction-id",
    "global_position": 1,
    "source_position": 1,
    }


    View Slide

24. What is a Change Event?
    24
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events
    {
    "id" : "transaction-id",
    "global_position": 1,
    "source_position": 1,
    }


    View Slide

25. What is a Change Event?
    25
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events


    View Slide

26. What is a Change Event?
    26
    {
    "ts_utc" : 1659375300000,
    "attributes": { ... },
    "data": [
    {
    "operation": "CREATE",
    "source": { ... },
    "transaction": { ... },
    "key": "some-unique-constraint",
    "before": null,
    "after": { ... },
    "attributes": { ... }
    }
    ]
    }
    Aggregating Change Events


    View Slide

27. Change Events Can Come From Anywhere
    27
    {
    "data": [
    {"source": { ... }}
    ]
    },
    {
    "data": [
    {"source": { ... }}
    ]
    },
    {
    "data": [
    {"source": { ... }}
    ]
    },
    Stream: charges
    Stream: audits
    Stream: disputes
    Aggregating Change Events


    View Slide

28. Databases Have Transactions
    28
    Aggregating Change Events
    BEGIN
    INSERT INTO charges
    UPDATE audits ...
    COMMIT


    View Slide

29. What is a Transaction Metadata Event?
    29
    // BEGIN Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "BEGIN",
    "total_events": null,
    "per_source_event_counts": null,
    }
    // COMMIT Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "COMMIT",
    "total_events": 3,
    "per_source_event_counts": [{ ... }],
    }
    Aggregating Change Events


    View Slide

30. What is a Transaction Metadata Event?
    30
    // BEGIN Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "BEGIN",
    "total_events": null,
    "per_source_event_counts": null,
    }
    // COMMIT Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "COMMIT",
    "total_events": 3,
    "per_source_event_counts": [{ ... }],
    }
    Aggregating Change Events


    View Slide

31. What is a Transaction Metadata Event?
    31
    // BEGIN Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "BEGIN",
    "total_events": null,
    "per_source_event_counts": null,
    }
    // COMMIT Marker
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "COMMIT",
    "total_events": 3,
    "per_source_event_counts": [{ ... }],
    }
    Aggregating Change Events
    [
    {
    "source" : "keyspace.table1",
    "total_events": 1,
    },
    {
    "source" : "keyspace.table2",
    "total_events": 1,
    }
    ]


    View Slide

32. -- 4 events
    BEGIN -- Transaction Metadata Event
    INSERT INTO charges -- Change Event
    UPDATE audits ... -- Change Event
    COMMIT -- Transaction Metadata Event
    Putting It All Together
    32
    Aggregating Change Events


    View Slide

33. What is an Aggregated Change Event?
    33
    {
    "ts_utc" : 1659375300000,
    "data": [
    {
    "operation": "CREATE",
    "transaction": { “id”: "txn1"},
    "before": null,
    "after": { ... },
    },
    {
    "operation": "UPDATE",
    "transaction": { “id”: "txn1"},
    "before": { ... },
    "after": { ... },
    },
    ]
    }
    Aggregating Change Events


    View Slide

34. What is an Aggregated Change Event?
    34
    {
    "ts_utc" : 1659375300000,
    "data": [
    {
    "operation": "CREATE",
    "transaction": { “id”: "txn1"},
    "before": null,
    "after": { ... },
    },
    {
    "operation": "UPDATE",
    "transaction": { “id”: "txn1"},
    "before": { ... },
    "after": { ... },
    },
    ]
    }
    ● One transaction with two events
    having the same transaction ID.
    ● Events may arrive from an
    arbitrary number of tables.
    Aggregating Change Events


    View Slide

35. 35
    Transaction Metadata Event
    Stream (one)
    Flatmap
    Flink Job Graph
    Change Event
    Stream (many; one per table)
    Windowed
    Aggregation
    Side Output
    Aggregated Change Event
    Stream
    Aggregating Change Events


    View Slide

36. Multiple Sources
    36
    Union
    Join Connect
    Aggregating Change Events


    View Slide

37. Joins elements of the same
    key within the same window.
    ● Produces pairwise
    elements
    Join
    37
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Event
    1
    BEGIN
    ,
    Event
    1
    COMMIT
    ,
    Event
    2
    BEGIN
    ,
    Event
    2
    COMMIT
    ,
    Event
    3
    BEGIN
    ,
    Event
    3
    COMMIT
    ,
    Aggregating Change Events


    View Slide

38. Unions multiple streams of
    the same type into a single
    stream.
    ● Requires streams of the
    same type
    Union
    38
    38
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    (No output; won’t compile because streams are of different types)
    Aggregating Change Events


    View Slide

39. Connect
    39
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Event
    1
    BEGIN
    , Event
    2
    COMMIT
    ,
    Event
    3
    BEGIN
    , COMMIT
    ,
    , ,
    Unions multiple streams,
    potentially of different types.
    ● Similar to Unions
    Aggregating Change Events


    View Slide

40. 40
    Support for streams of different types
    Support for flexible stream combination semantics
    Don’t need pairwise outputs
    Aggregating Change Events
    What Do We Need?


    View Slide

41. Flink Job Definition
    41
    val mainStream =
    transactionMetadataEventStream // uid and name omitted.
    .connect(changeEventStream) // Union different types.
    Aggregating Change Events


    View Slide

42. 42
    Transaction Metadata Event
    Stream (one)
    Flatmap
    Flink Job Graph
    Change Event
    Stream (many; one per table)
    Windowed
    Aggregation
    Side Output
    Aggregated Change Event
    Stream
    Aggregating Change Events


    View Slide

43. Connected Streams
    43
    Custom
    Either
    Aggregating Change Events


    View Slide

44. Wraps an event containing one
    of two types, either from left or
    right stream.
    ● Out-of-box
    ● No concept of keys
    Either.left =
    Either.right = null
    Either
    44
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Event
    1
    BEGIN
    , Either.left = null
    Either.right =
    ,
    …
    Aggregating Change Events


    View Slide

45. WrappedEvent.key = txn-1
    WrappedEvent.left = null
    WrappedEvent.right =
    Custom
    45
    WrappedEvent.key = txn-1
    WrappedEvent.left =
    WrappedEvent.right = null
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Event
    1
    BEGIN
    ,
    , …
    Wraps an event containing one
    of two types, either from left or
    right stream, and a common
    key among both events.
    ● Small and simple code
    addition
    ● Need to extract keys
    Aggregating Change Events


    View Slide

46. 46
    Wrap elements of a connected stream
    Be able to identify keys to support
    aggregations later
    Aggregating Change Events
    What Do We Need?


    View Slide

47. Flink Job Definition
    47
    val mainStream =
    transactionMetadataEventStream // uid and name omitted.
    .connect(changeEventStream) // Union different types.
    .flatMap(new WrappedEventFunction) // Like Either type, but with extra fields.
    .keyBy(_.key) // Group events with the same transaction ID.
    Aggregating Change Events


    View Slide

48. 48
    Transaction Metadata Event
    Stream (one)
    Flatmap
    Flink Job Graph
    Change Event
    Stream (many; one per table)
    Windowed
    Aggregation
    Side Output
    Aggregated Change Event
    Stream
    Aggregating Change Events


    View Slide

49. Aggregation Characteristics
    Arbitrary number of Change Event Streams
    One Transaction Metadata Event Stream
    Change Events must have the same
    transaction IDs
    Handle late arriving or duplicate Change
    Events and Transaction Metadata Events
    Don’t result in infinite state growth
    49
    Aggregating Change Events


    View Slide

50. Windowing
    50
    Session
    Sliding
    Tumbling
    Aggregating Change Events


    View Slide

51. Tumbling Windows
    51
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Aggregating Change Events


    View Slide

52. Tumbling Windows
    52
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    Aggregating Change Events


    View Slide

53. Tumbling Windows
    53
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    ● Late-arriving events? Add delay.
    Aggregating Change Events


    View Slide

54. Tumbling Windows
    54
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    ● Late-arriving events? Add delay.
    Aggregating Change Events


    View Slide

55. Tumbling Windows
    55
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    ● Late-arriving events? Add delay.
    ● Large delay? Trade-off: Freshness vs Correctness.
    Aggregating Change Events


    View Slide

56. Tumbling Windows
    56
    Assigns elements to windows
    of a fixed size.
    ● Windows don’t overlap
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    ● Late-arriving events? Add delay.
    ● Large delay? Trade-off: Freshness vs Correctness.
    ● Not quite right…
    Aggregating Change Events


    View Slide

57. Sliding Windows
    57
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT BEGIN COMMIT
    Event
    3
    Assigns elements to windows
    of a fixed size, but with a slide
    interval.
    ● Almost like a tumbling
    window, but with windows
    overlapping
    Aggregating Change Events


    View Slide

58. Sliding Windows
    58
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    Event
    2
    BEGIN COMMIT
    ● Late-arriving events? Same as tumbling windows.
    ● Slide interval? Explosion of windows
    ● Not quite right…
    Aggregating Change Events
    Assigns elements to windows
    of a fixed size, but with a slide
    interval.
    ● Almost like a tumbling
    window, but with windows
    overlapping


    View Slide

59. Session Windows
    59
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    BEGIN COMMIT
    Event
    3
    Aggregating Change Events
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity


    View Slide

60. Session Windows
    60
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

61. Session Windows
    61
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

62. Session Windows
    62
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    ● Session gap too small? Incomplete aggregates
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

63. Session Windows
    63
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    ● Session gap too small? Incomplete aggregates
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

64. Session Windows
    64
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    ● Session gap too small? Incomplete aggregates
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

65. Session Windows
    65
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    ● Session gap too small? Incomplete aggregates
    ● Session gap too big? Trade-off: Freshness vs Correctness
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

66. Session Windows
    66
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    ● Session gap too small? Incomplete aggregates
    ● Session gap too big? Trade-off: Freshness vs Correctness
    ● Not quite right…
    Assigns elements that are seen
    relatively close to each other.
    ● Arbitrarily-sized windows;
    no fixed start and end
    ● Windows don’t overlap
    ● Windows close based on a
    defined gap of inactivity
    Aggregating Change Events


    View Slide

67. Global Windows
    67
    Assigns elements to a single
    window.
    ● Only a single window per
    key
    ● Window never closes
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    BEGIN COMMIT
    Event
    3
    Aggregating Change Events


    View Slide

68. Global Windows
    68
    Assigns elements to a single
    window.
    ● Only a single window per
    key
    ● Window never closes
    time
    Change Events
    Transaction
    Metadata Events
    Event
    1
    BEGIN COMMIT
    Event
    2
    BEGIN COMMIT
    Event
    3
    ● Outputs never get evaluated and materialized
    ● Needs more…
    Aggregating Change Events


    View Slide

69. Global Windows + Custom Stateful Trigger
    69
    Assign elements to a Global Window and add a custom
    stateful trigger.
    ● Flexibly define open/close conditions for
    non-overlapping windows
    ● Reasonably handle late-arriving events
    ● Avoid infinite state growth and reduce likelihood of
    incomplete aggregates
    Aggregating Change Events


    View Slide

70. What Makes an Aggregation Complete?
    70
    Aggregating Change Events
    BEGIN transaction marker seen
    COMMIT transaction marker seen
    All Change Events of the transaction seen
    All Change Events are globally and locally ordered


    View Slide

71. Custom Stateful Trigger:
    TransactionBoundaryTrigger
    71
    if transaction metadata event:
    if begin transaction marker:
    update begin marker state
    else:
    update commit marker state
    update bitmap state
    using commit marker’s total event count
    set timeout state and register event time timer
    else:
    update bitmap state
    with change event’s global position
    set timeout state and register event time timer
    if should trigger(begin, commit, total events):
    clear window
    TriggerResult.FIRE_AND_PURGE
    else:
    TriggerResult.CONTINUE
    Reference
    Aggregating Change Events
    // ChangeEvent#transaction
    {
    "id" : "transaction-id",
    "global_position": 1,
    "source_position": 1,
    }
    // TransactionMetadataEvent
    {
    "id" : "transaction-id",
    "ts_utc": 1659375300000,
    "marker": "COMMIT",
    "total_events": 3,
    "per_source_event_counts": [{ ... }],
    }


    View Slide

72. val mainStream =
    transactionMetadataEventStream // uid and name omitted.
    .connect(changeEventStream) // Union different types.
    .flatMap(new WrappedEventFunction) // Like Either type, but with extra fields.
    .keyBy(_.key) // Group events with the same transaction ID.
    Flink Job Definition
    72
    .window(GlobalWindows.create)
    .trigger(new TransactionBoundaryTrigger(...)) // Flexible windowing semantics.
    .process(new KeyedProcessor(...))
    Aggregating Change Events


    View Slide

73. 73
    Transaction Metadata Event
    Stream (one)
    Flatmap
    Flink Job Graph
    Change Event
    Stream (many; one per table)
    Windowed
    Aggregation
    Side Output
    Aggregated Change Event
    Stream
    Aggregating Change Events


    View Slide

74. val mainStream =
    transactionMetadataEventStream // uid and name omitted.
    .connect(changeEventStream) // Union different types.
    .flatMap(new WrappedEventFunction) // Like Either type, but with extra fields.
    .keyBy(_.key) // Group events with the same transaction ID.
    .window(GlobalWindows.create)
    .trigger(new TransactionBoundaryTrigger(...)) // Flexible windowing semantics.
    .process(new KeyedProcessor(...))
    Flink Job Definition
    74
    mainStream // Side output to DLQ.
    .getSideOutput(...)
    .addSink(...)
    mainStream // Output aggregated change events.
    .addSink(...)
    Aggregating Change Events


    View Slide

75. 75
    Agenda
    CDC at Stripe
    1 Aggregating Change Events
    2 How it Started, How it Ended
    3
    Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture
    Change Data Capture (CDC) is
    widely-used at Stripe to capture data
    changes from databases without critically
    impacting database reliability and
    scalability. CDC powers many critical
    financial use cases at Stripe such as the
    Stripe Dashboard, Stripe Search, Sigma,
    and Financial Reporting.
    From idea to production—things may
    seem straightforward at first, but the
    details matter. We detail our journey of
    how we leveraged Flink for Change Data
    Capture at Stripe in order to uphold the
    highest data quality standards. Freshness,
    Coverage, and Correctness SLOs are
    paramount to the success of platforms
    and applications running on top of our
    CDC infrastructure.
    Change Event Streams are ubiquitous
    across Stripe given the vast number of
    applications and employees generating
    datasets worldwide. Change Event
    Streams are independent from one
    another which leads to the typical
    challenges in distributed systems. One of
    the major use cases revolves around
    aggregating individual change events of a
    database transaction to support Stripe’s
    payments infrastructure.


    View Slide

76. From Idea to Production
    76
    Coverage
    Platform
    State
    How it Started, How it Ended


    View Slide

77. State
    77
    How it Started, How it Ended


    View Slide

78. How It Started


    View Slide

79. How It Started How It Ended


    View Slide

80. Infinite keys due to continuous stream of new transactions
    Observations
    80
    How it Started, How it Ended
    Using a Global Window; possible windows not closing properly
    No trigger timeouts firing
    No watermarks being generated


    View Slide

81. Idle
    Sub Tasks
    Observations
    81
    charges
    (partitions = 2)
    Transaction
    Metadata Events
    audits
    (partitions = 1)
    disputes
    (partitions = 1)
    Source Sub Tasks
    How it Started, How it Ended


    View Slide

82. Fix
    82
    Fixed an upstream issue where transaction IDs were getting mixed up
    Reduce parallelism on Source Sub Tasks for all streams
    Make sure parallelism ≤ ∑ Topic Partitions
    Generally, check with SplitEnumerator classes
    How it Started, How it Ended


    View Slide

83. How It Started


    View Slide

84. How It Started How It Ended


    View Slide

85. State size still growing, but slower
    Observations
    85
    How it Started, How it Ended
    Event time timers firing, sometimes
    Watermarks are being generated, but not for all sub tasks


    View Slide

86. New Observations
    86
    charges
    (partitions = 2)
    Transaction
    Metadata Events
    audits
    (partitions = 1)
    disputes
    (partitions = 1)
    Source Sub Tasks
    Low volume stream
    How it Started, How it Ended


    View Slide

87. Possible Fix
    87
    Switch from event time to processing time
    Less precise
    Could cause premature trigger firing, resulting in incomplete aggregates
    How it Started, How it Ended


    View Slide

88. Actual Fix
    88
    Add idleness property on sources
    Can still use event time
    More precise
    Not perfect; can still result in incomplete aggregates in edge cases
    That’s the reality of streaming
    How it Started, How it Ended


    View Slide

89. Platform
    89
    How it Started, How it Ended


    View Slide

90. How It Started


    View Slide

91. How It Started How It Ended


    View Slide

92. Don’t want to redeploy every time a new dataset (Kafka Topic) is added
    Observations
    92
    How it Started, How it Ended
    Blows away Freshness SLO’s error budget
    Poor developer onboarding experience


    View Slide

93. Fix
    93
    Instead of Kafka Topic List Subscriber, use Regex Subscriber
    Subscribe to all topics (for a keyspace) by default
    Control plane (external) service produces an event to Broadcast Stream
    On broadcast element, use Broadcast State to keep onboarded datasets in state
    On element, check Broadcast State and filter for onboarded datasets
    How it Started, How it Ended


    View Slide

94. Coverage
    94
    How it Started, How it Ended


    View Slide

95. How It Started


    View Slide

96. How It Started How It Ended


    View Slide

97. Observations
    Incomplete aggregates still happening, but not frequently
    97
    How it Started, How it Ended
    Kafka by default is at-least-once delivery
    Many independent streams operating at different speeds


    View Slide

98. Storage will be expensive. Trade-off between confidence and
    cost-efficiency: KV store or bloom filter
    Move incomplete aggregate measurement out of the Flink Job and into a
    system downstream
    Fix
    98
    How it Started, How it Ended
    New system needs to dedupe events… for all time?


    View Slide

99. How It Started


    View Slide

100. How It Started How It Ended


     View Slide

101. 101
     Agenda
     CDC at Stripe
     1 Aggregating Change Events
     2 How it Started, How it Ended
     3
     Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture
     Change Data Capture (CDC) is
     widely-used at Stripe to capture data
     changes from databases without critically
     impacting database reliability and
     scalability. CDC powers many critical
     financial use cases at Stripe such as the
     Stripe Dashboard, Stripe Search, Sigma,
     and Financial Reporting.
     From idea to production – things may
     seem straightforward at first, but the
     details matter. We detail our journey of
     how we leveraged Flink for Change Data
     Capture at Stripe in order to uphold the
     highest data quality standards. Freshness,
     Coverage, and Correctness SLOs are
     paramount to the success of platforms
     and applications running on top of our
     CDC infrastructure.
     Change Event Streams are ubiquitous
     across Stripe given the vast number of
     applications and employees generating
     datasets worldwide. Change Event
     Streams are independent from one
     another which leads to the typical
     challenges in distributed systems. One of
     the major use cases revolves around
     aggregating individual change events of a
     database transaction to support Stripe’s
     payments infrastructure.


     View Slide

102. Aggregating Change Events is relatively
     straightforward, but the details matter
     Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture
     Wrap Up
     102
     Change Data Capture (CDC) is widely-used at
     Stripe to improve database reliability and scalability
     Flink is a critical component in Stripe’s CDC
     infrastructure that allows us to work with financial
     streaming data with high data quality guarantees


     View Slide

103. Thank you!
     103
     Squirreling Away $640 Billion: How Stripe Leverages Flink for Change Data Capture


     View Slide
