Galactic archaeology and asteroseismology of white dwarf stars

jjhermes
March 11, 2021

Galactic archaeology and asteroseismology of white dwarf stars

Colloquium, 45 min. March 2021: SAC Seminar, Aarhus University, Aarhus, Denmark

jjhermes

March 11, 2021
Tweet

More Decks by jjhermes

Other Decks in Science

Transcript

  1. Galactic archaeology
    and asteroseismology of
    white dwarf stars
    http://jjherm.es
    @jotajotahermes
    J.J. Hermes

    View Slide

  2. View Slide

  3. View Slide

  4. JJ Hermes, Boston University | SAC Seminar | 4
    1. White Dwarfs
    are Stellar Fossils
    that We Can
    Directly Age-Date
    2. We Are Using TESS
    to Better Model These
    Stellar Fossils

    View Slide

  5. • a stellar remnant that is
    no longer fusing in its
    core
    • the endpoints of
    everything < 8 M¤
    • electron degeneracy
    limits WD mass to <
    1.4 M¤
    A ‘typical’ 0.6 solar-mass
    white dwarf
    electron degenerate
    C/O core
    (r = 8500 km)
    non-degenerate He
    layer
    (260 km) non-degenerate H
    layer
    (30 km)
    [thermal reservoir]
    [insulating blanket]
    JJ Hermes, Boston University | SAC Seminar | 5
    What Do We Mean by ‘White Dwarf’?

    View Slide

  6. A ‘typical’ 0.6 solar-mass
    white dwarf
    electron degenerate
    C/O core
    (r = 8500 km)
    non-degenerate He
    layer
    (260 km) non-degenerate H
    layer
    (30 km)
    [thermal reservoir]
    [insulating blanket]
    JJ Hermes, Boston University | SAC Seminar | 6
    White Dwarfs are Excellent for Ages: They Simply Radiate
    Their Stored Heat, Which is Not Replenished
    65,000 K (0.001 Gyr)
    25,000 K (0.02 Gyr)
    13,000 K (0.31 Gyr)
    10,500 K (0.56 Gyr)
    7100 K (1.5 Gyr)
    5100 K (5 Gyr)
    3300 K
    (11 Gyr)

    View Slide

  7. Gaia has revolutionized our ability to nd white dwarfs
    Gaia Collaboration,
    Babusiaux et al. 2018
    • Before Gaia we knew of
    ~35,000 white dwarfs
    (mostly from SDSS)
    • Gentile Fusillo et al. 2019
    catalog nearly half
    a million candidates
    from Gaia DR2
    JJ Hermes, Boston University | SAC Seminar | 7

    View Slide

  8. Gaia eDR3: We Are Directly Testing Ages in Wide WD+WD
    Tyler Heintz (BU), also
    Kareem El-Badry (Berkeley)
    JJ Hermes, Boston University | SAC Seminar | 8
    El-Badry, Rix & Heintz 2021:
    arXiv: 2101.05282
    1565 high-confidence, wide
    (>100 au) binaries with 2 WDs!

    View Slide

  9. Soon We Will Have a Better-Calibrated Sample of Wide WD
    Co-PI: Jennifer Van Saders JJ Hermes, Boston University | SAC Seminar | 9
    200 pc sample from
    El-Badry et al. 2018, 2021
    >16,000 high-confidence, wide (>100 au) binaries with 1 WD!

    View Slide

  10. 0.6 M¤
    0.9 M¤
    1.1 M¤
    Gaia Reveals Interesting Physics in White Dwarf Cooling
    JJ Hermes, Boston University | SAC Seminar | 10
    Tremblay et al. 2019

    View Slide

  11. 0.6 M¤
    0.9 M¤
    1.1 M¤
    JJ Hermes, Boston University | SAC Seminar | 11
    Tremblay et al. 2019
    White dwarfs within 100 pc in Gaia
    • Gaia CMD showed an
    overdensity aside from
    expected cooling tracks

    View Slide

  12. JJ Hermes, Boston University | SAC Seminar | 12
    Tremblay et al. 2019
    DA (H-atmosphere) white dwarfs within 100 pc in Gaia
    • The overdensity
    appears better focusing only
    on DA white dwarfs

    View Slide

  13. 20% of core is
    crystallized
    80% of core is
    crystallized
    JJ Hermes, Boston University | SAC Seminar | 13
    Tremblay et al. 2019
    DA (H-atmosphere) white dwarfs within 100 pc in Gaia
    • The overdensity
    appears better focusing only
    on DA white dwarfs

    View Slide

  14. 107.5 yr,
    0.4 M¤
    107.5 yr,
    1.3 M¤
    +100.02 yr
    Onset of crystallization
    80% of mass is
    crystallized
    JJ Hermes, Boston University | SAC Seminar | 14
    Tremblay et al. 2019
    Crystallization causes a pile-up in white dwarf cooling
    Predicted theoretically by
    Van Horn 1968

    View Slide

  15. No crystallization
    Latent heat from crystallization
    Gaia Observed
    Latent heat from
    crystallization, plus
    gravitational energy
    from 16O sedimentation
    JJ Hermes, Boston University | SAC Seminar | 15
    Tremblay et al. 2019
    This overdensity is exactly where we expect crystallization!
    Gaia WD Luminosity Function

    View Slide

  16. JJ Hermes, Boston University | SAC Seminar | 16
    (What is latent heat? Why does it stall cooling?)
    • Latent heat: extra energy
    required to carry out a
    first-order phase transition
    • (When smoking a brisket
    the moisture in the meat
    undergoes a 1st-order
    phase transition at 160F
    [70C] from evaporative
    cooling)

    View Slide

  17. “Long after our roiling, boiling life-giving star runs out of fuel,
    it will slowly form a cold, dead, super-dense crystal sphere
    about the size of the Earth that will linger like a translucent
    tombstone.” – Deborah Netburn, The Los Angeles Times
    JJ Hermes, Boston University | SAC Seminar | 17

    View Slide

  18. Adding tangential velocities to the Gaia CMD…
    100 pc sample from
    Gentile Fusillo et al. 2019 JJ Hermes, Boston University | SAC Seminar | 18
    0.6 M¤
    1.2 M¤

    View Slide

  19. 1. Fundamental physics from White Dwarfs in Gaia CMD
    JJ Hermes, Boston University | SAC Seminar | 19
    • Most (>90%) of WDs Should Cool
    Predictably & Eventually Crystallize,
    Releasing Latent Heat
    • We are Testing Expectations with Wide,
    Coeval WD+WD Binaries
    65,000 K (0.001 Gyr)
    25,000 K (0.02 Gyr)
    13,000 K (0.31 Gyr)
    10,500 K (0.56 Gyr)
    7100 K (1.5 Gyr)
    5100 K (5 Gyr)
    3300 K
    (11 Gyr)

    View Slide

  20. He
    P.I. zone
    (30-20 kK)
    H
    P.I. zone
    (13-10 kK)
    N2
    Ll
    2
    DAV Propagation Diagram
    Core Surface
    p-modes
    σ2 > L
    l
    2, N2
    convection
    zone
    log σ2 (s-2)
    g-modes
    σ2 < L
    l
    2, N2
    DBV:
    aka V477 Her
    DAV:
    aka ZZ Ceti
    Fontaine & Brassard 2008
    Aerts, JCD, Kurtz 2010 JJ Hermes, Boston University | SAC Seminar | 20

    View Slide

  21. White Dwarfs: g-modes, not all
    modes are observed excited
    (much like delta Scuti p-modes)
    5 min 4 min
    6 min
    Solar p-modes
    BiSON; Thompson et al. 2003
    2 min
    3 min
    4 min
    5 min
    6 min
    10 min
    JJ Hermes, Boston University | SAC Seminar | 21
    n

    View Slide

  22. White Dwarfs: g-modes, not all
    modes are observed excited
    (much like delta Scuti p-modes)
    Adiabatic Model: 11,245 K, 0.632 M¤
    ,
    10-4.12 MH
    /MWD
    (Romero et al. 2012)
    2 min
    3 min
    4 min
    5 min
    6 min
    10 min
    JJ Hermes, Boston University | SAC Seminar | 22
    l=1
    l=2

    View Slide

  23. KIC 08626021: Østensen et al.
    2011, 2013
    JJ Hermes, Boston University | SAC Seminar | 23
    The Most Studied Kepler Pulsating WD: A Hot DBV
    Red: Location of
    m=0 models of
    Giammichele et
    al. 2018
    Blue: Location of
    m=0 models of
    Bischoff-Kim et
    al. 2014

    View Slide

  24. Core Surface
    ß 99% of mass
    X(O) = 78.03% ± 4.2%
    X(C) = 21.96% ± 4.2%
    X(He) = 0.0113% ± 0.006%
    KIC 08626021: Giammichele et
    al. 2018
    JJ Hermes, Boston University | SAC Seminar | 24
    Toulouse Models Predict A Large, O-Dominated Core

    View Slide

  25. JJ Hermes, Boston University | SAC Seminar | 25
    Toulouse Models Neglected to Include Neutrino Cooling
    Timmes et al. 2018
    KIC 08626021: Giammichele et
    al. 2018

    View Slide

  26. JJ Hermes, Boston University | SAC Seminar | 26
    Toulouse Models Now Updated to Include Neutrino Cooling
    KIC 08626021: Charpinet et al.
    2019
    8 observed modes &
    many free parameters
    There is great potential
    in getting this right!
    Gaia CMD position
    infers: 0.73 ± 0.12 M¤
    Black: Models of Giammichele et al. 2018
    Red: Models of Charpinet et al. 2019 including
    neutrino cooling

    View Slide

  27. JJ Hermes, Boston University | SAC Seminar | 27
    7.5
    8.5 8.0
    Blue: K2 Pulsating WDs log(g) = 9
    20,000 K
    10,000 K
    Kepler/K2 Observed 90 Pulsating White Dwarfs
    Hermes et al. 2021, in prep.
    81 DAV (H-atm.) WDs
    First 27 published in Hermes et al. 2017
    Grey: All 2166 WDs
    7 DBV (He-atm.) WDs
    Analysis in Vanderbosch et al. 2021
    2 DOV (pre-WDs, C/O-atm.)

    View Slide

  28. 1000 s 200 s
    500 s 125 s
    l=1
    l=2
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    JJ Hermes, Boston University | SAC Seminar | 28

    View Slide

  29. 1000 s 200 s
    500 s 125 s
    l=1
    l=2
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    (consecutive g-modes evenly
    spaced in period, not frequency)
    JJ Hermes, Boston University | SAC Seminar | 29

    View Slide

  30. l = 1
    n = 1
    l = 1
    n = 2
    l = 1
    n = 3
    SDSSJ0051+0339, g=17.6, K2 Campaign 8
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    Chris Clemens et al. in prep.
    Kepler and TESS makes some short-period
    mode identification relatively trivial
    JJ Hermes, Boston University | SAC Seminar | 30

    View Slide

  31. 0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    Mode Period (s)
    N
    l = 1
    n = 1
    l = 1
    n = 2
    l = 1
    n = 3
    n = 1 n = 2 n = 3 n = 4
    If we only plot identified l=1 (m=0) modes:
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    Chris Clemens et al. in prep.
    JJ Hermes, Boston University | SAC Seminar | 31

    View Slide

  32. 0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    Mode Period (s)
    N
    n = 1 n = 2 n = 3 n = 4
    l = 1
    n = 1
    l = 1
    n = 2
    l = 1
    n = 3
    If we only plot identified l=1 (m=0) modes:
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    Chris Clemens et al. in prep.
    JJ Hermes, Boston University | SAC Seminar | 32

    View Slide

  33. 0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 DAV periods, observed
    Full evolutionary models computed
    by Romero et al. 2012
    Chris Clemens et al. in prep.
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    JJ Hermes, Boston University | SAC Seminar | 33

    View Slide

  34. Drawing from a random distribution of all
    hydrogen layer masses
    Full evolutionary models computed
    by Romero et al. 2012
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 DAV periods, observed
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 random MH
    simulation
    Chris Clemens et al. in prep.
    White Dwarf Seismologist’s Dilemma: Often Few Modes
    JJ Hermes, Boston University | SAC Seminar | 34

    View Slide

  35. 0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 DAV periods, observed
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 random MH
    simulation
    l=1 canonical MH
    simulation
    Full evolutionary models computed
    by Romero et al. 2012
    Only drawing from the models with
    canonically thick (10-4 MH
    /M★
    )
    hydrogen layers
    Chris Clemens et al. in prep.
    Most (>80%) of DAs Have Thick H Layers
    JJ Hermes, Boston University | SAC Seminar | 35

    View Slide

  36. 0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 DAV periods, observed
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    0
    1
    2
    3
    4
    5
    6
    7
    8
    50 100 150 200 250 300 350 400 450
    l=1 random MH
    simulation
    l=1 canonical MH
    simulation
    Full evolutionary models computed
    by Romero et al. 2012
    Only drawing from the models with
    canonically thick (10-4 MH
    /M★
    )
    hydrogen layers
    Chris Clemens et al. in prep.
    Most (>80%) of DAs Have Thick H Layers
    10-15 s offset: Could be that He-layer
    masses too thick in canonical models
    à Would lead to systematically
    younger WD cooling ages (~10%)
    JJ Hermes, Boston University | SAC Seminar | 36

    View Slide

  37. JJ Hermes, Boston University | SAC Seminar | 37
    We Have Strong Motivation to Keep Going with TESS

    View Slide

  38. JJ Hermes, Boston University | SAC Seminar | 38
    We Have Strong Motivation to Keep Going with TESS
    Blue: TESS Pulsating WDs
    Grey: All 3383 WDs with T < 17 mag 7.5
    8.5 8.0
    log(g) = 9
    20,000 K
    10,000 K
    So Far TESS Has Detected Oscillations in 62 Pulsating WDs

    View Slide

  39. White Dwarfs Are Faint, But TESS Data is Still Valuable
    JJ Hermes, Boston University | SAC Seminar | 39

    View Slide

  40. White Dwarfs Are Faint, But TESS Data is Still Valuable
    JJ Hermes, Boston University | SAC Seminar | 40

    View Slide

  41. WD 0158-160 (TIC 257459955): T=14.1 mag
    JJ Hermes, Boston University | SAC Seminar | 41
    Bell et al. 2019
    TESS DAVs: Bognar et al. 2020
    9 observed l=1 modes
    Gaia parallax implies a
    distance of 68.14 ± 0.28 pc
    Seismic distance, Model 2: 66.5 ± 2.5 pc
    Seismic distance, Model 1/3: 87.7 ± 7.9 pc

    View Slide

  42. The 20-Second Cadence Is Often Necessary for Our Science
    JJ Hermes, Boston University | SAC Seminar | 42
    Pulsation amplitudes have been, on
    average, 35% underestimated by the
    2-min cadence so far in Cycle 3

    View Slide

  43. 2. TESS Will Keep Refining Models of White Dwarf Interiors
    JJ Hermes, Boston University | SAC Seminar | 43
    • Boutique Asteroseismology of WDs Still
    Hard, But Improving, Especially With
    Ensemble Approaches at Short Periods
    • In Many Cases, 20-second TESS
    Data Is Crucial
    • We Are Working Onwards Towards
    Constraining WD Core Compositions
    and Envelopes!
    65,000 K (0.001 Gyr)
    25,000 K (0.02 Gyr)
    13,000 K (0.31 Gyr)
    10,500 K (0.56 Gyr)
    7100 K (1.5 Gyr)
    5100 K (5 Gyr)
    3300 K
    (11 Gyr)

    View Slide

  44. Adding tangential velocities to the Gaia CMD…
    100 pc sample from
    Gentile Fusillo et al. 2019 JJ Hermes, Boston University | SAC Seminar | 44
    0.6 M¤
    1.2 M¤

    View Slide

  45. Massive WDs descended from 4-8 solar-mass ZAMS stars
    Cheng et al. 2019 JJ Hermes, Boston University | SAC Seminar | 45
    • Massive WDs
    should come from
    stars that spend
    <0.5 Gyr on the
    main sequence

    View Slide

  46. Something is delaying cooling in some massive WDs
    JJ Hermes, Boston University | SAC Seminar | 46
    • Models include
    crystallization:
    something else is
    slowing them down!
    • Fast kinematics
    suggests these have
    had their ages
    “reset”!
    • But why are they
    piling up?
    Cheng et al. 2019

    View Slide

  47. 0.0 0.2 0.4 0.6 0.8 1.0
    0.0
    0.2
    0.4
    0.6
    0.8
    1.0
    Sedimentation Cooling Delay [Gyr]
    °3.5
    °3.0
    °2.5
    °2.0
    °1.5
    0
    2
    4
    Q Branch
    0.9 MØ C/O WD
    Z = 0.035
    Clustering, hNi = 3,000
    Clustering, hNi = 1,000
    Clustering, hNi = 300
    Single-particle Diffusion
    °3.5
    °3.0
    °2.5
    °2.0
    °1.5
    0
    2
    4
    Q Branch
    1.0 MØ C/O WD
    Z = 0.035
    °3.5
    °3.0
    °2.5
    °2.0
    °1.5
    0
    2
    4
    Q Branch
    1.1 MØ C/O WD
    Z = 0.035
    °3.5
    °3.0
    °2.5
    °2.0
    °1.5
    log(L/LØ)
    0
    2
    4
    Q Branch
    1.18 MØ C/O WD
    Z = 0.035
    0.0 0.2 0.4 0.6 0.8 1.0
    m [MØ]
    0.0
    0.2
    0.4
    0.6
    Mass Fraction
    22Ne
    12C
    16O
    initial
    final
    Something is delaying cooling in some massive WDs
    JJ Hermes, Boston University | SAC Seminar | 47
    • That something could be 22Ne
    sedimentation (perhaps in
    clusters) in C/O-rich cores
    Bauer et al. 2020
    Bildsten & Hall 2001

    View Slide

  48. 1. Fundamental physics from White Dwarfs in Gaia CMD
    JJ Hermes, Boston University | SAC Seminar | 48
    • Most (>90%) of WDs Should Cool
    Predictably & Crystallize, Releasing Latent
    Heat
    • We are Testing Expectations with Wide,
    Coeval WD+WD Binaries
    • Pile-ups among ~7% of massive WDs
    reveal crystallization PLUS poorly
    modeled physics (perhaps related to
    mergers & sedimentation of 22Ne
    clusters?)
    65,000 K (0.001 Gyr)
    25,000 K (0.02 Gyr)
    13,000 K (0.31 Gyr)
    10,500 K (0.56 Gyr)
    7100 K (1.5 Gyr)
    5100 K (5 Gyr)
    3300 K
    (11 Gyr)

    View Slide
