  1. http://jjherm.es
    Dr. J.J. Hermes
    Hubble Fellow
    University of North Carolina
    at Chapel Hill
    The Kepler Mission’s
    Search for Earth 2.0

    View Slide

  2. View Slide

  3. PI: Bill Borucki
    1983: Kepler design began
    1992: REJECTED by NASA
    Unsuitable detector technology
    1994: REJECTED by NASA
    Too expensive
    1996: REJECTED by NASA
    No proof of concept
    1998: REJECTED by NASA
    Space too harsh for detectors
    2000: ACCEPTED by NASA
    $550 million budget

    View Slide

  4. Kepler at a glance
    0.95-m aperture
    (Hubble is 2.4-m)
    95 megapixel camera
    (at time, largest unclassified
    camera launched into space)

    View Slide

  5. View Slide

  6. View Slide

  7. V = 13.3 mag
    Kepler First Light
    April 8, 2009

    View Slide

  8. View Slide

  9. V = 13.3 mag
    Kepler data is saved every 30 min
    for ~150,000 stars

    View Slide

  10. V = 13.3 mag
    Kepler makes a
    time-lapse movie of
    a star’s brightness

    View Slide

  11. View Slide

  12. Once a year, viewed from afar, the
    Earth causes an 84 ppm (0.0084%)
    dip in Sunlight for about 10 hrs

    View Slide

  13. View Slide

  14. Kepler-10 Light Curve

    View Slide

  15. Kepler-10 Light Curve
    Period = 45.29 days

    View Slide

  16. Kepler-10 Light Curve
    Period = 45.29 days

    View Slide

  17. Kepler-10 Light Curve
    Period = .84 days
    Period = 45.29 days

    View Slide

  18. Kepler-10 Light Curve
    Period = .84 days
    Period = 45.29 days

    View Slide

  19. Transit Yields Planet Radius
    10b Size
    Radius = 1.4 R
    !"#$%&'"()*&+,%-"..
    /,$."(0,12*.3
    Dr. Natalie Batalha et al. 2011

    View Slide

  20. Doppler Measurements Yield
    Planet Mass
    Mass = 4.6 M

    View Slide

  21. Transit and Doppler
    Measurements Yield Density
    +
    10b Size
    !"#$%&'"()*&+,%-"..
    /,$."(0,12*.3
    Mass
    Volume
    = 8.8 g/cm3
    Density

    View Slide

  22. Composition of Kepler-10b

    View Slide

  23. Kepler-10b was
    the first
    rocky planet
    discovered
    outside our
    own Solar
    System!
    (artist’s impression)

    View Slide

  24. Dr. Susan Thompson et al. 2017

    View Slide

  25. View Slide

  26. ~1 per star!
    Dr. Chris Burke et al. 2015

    View Slide

  27. Kepler has shown us that, on
    average, each of the ~200 billion
    stars in our Galaxy has a planet
    orbiting within 300 days!
    (artist’s impression)

    View Slide

  28. What about planets
    suitable for life?
    A planet is
    “habitable”
    if its surface
    0-100 C

    View Slide

  29. 15%(±13%) of Sun-like stars host
    potentially habitable planets!

    View Slide

  30. View Slide

  31. View Slide

  32. View Slide

  33. =
    Steve Howell
    The solar pressure on the Kepler spacecraft is ~50 µN m-2

    View Slide

  34. Kepler, resurrected as K2, balances
    against the pressure of Sunlight
    But it must stare at new fields in the
    ecliptic plane every 3 months

    View Slide

  35. View Slide

  36. (Mars)

    View Slide

  37. Juliette Becker et al. 2015
    K2 is still great at searching for new
    planets (though not Earth 2.0)!

    View Slide

  38. Dr. Aaron Rizzuto et al. 2018
    K2 shows young stars
    lack close-in planets!

    View Slide

  39. Looking in the Ecliptic with K2,
    we are finding worlds that could
    potentially find us!
    Transit of Venus 2012 (Jim Tiller, AP)

    View Slide

  40. View Slide

  41. Dr. Tim White et al. 2017

    View Slide

  42. View Slide

  43. Star Earth
    Pulsations (starquakes) let us see
    into the interiors of stars!

    View Slide

  44. Kepler is in Earth-trailing orbit:
    Porb
    = 372.5 days
    Kepler is currently
    >96 million miles
    from Earth
    Earth’s orbit
    Kepler’s orbit
    Sun
    Earth on
    March 5th
    Kepler,
    1 yrafter launch
    Kepler,
    4 yrslater
    Orbital
    direction

    View Slide

  45. View Slide

  46. Doug Caldwell
    In its 16th
    Campaign
    K2 is
    down to
    its last
    cup of
    hydrazine
    fuel!

    View Slide

  47. How common is life
    in the Universe?
    Kepler: Of the 150 Sun-like stars
    within 50 lightyears, odds are that
    roughly 20 have an Earth-like planet!

    View Slide

  48. View Slide

  49. View Slide
