Need for Speed: Boost ruby with FFI

Let's make ruby the best language in the world by giving it the speed of C. Ruby's goal is maximize programmer happiness, not the happiness of computers. But sometimes we still need to give some sympathy to the poor machine, especially when our API requests timed out. There're multiple ways to speed up Ruby by running C under the hood. Among them, FFI (foreign function interface) is the one that give us the most pleasant experience. With FFI, we can use C libraries without writing a single line of C code. Better yet, we also get cross platform/implementation support for free. We'll start from how FFI works, then calling a simple c function from ruby. Explore more by bridging C structs to ruby class and handing C pointers. Conclude with a FFI example.

Transcript

1. Need for Speed
   Boost Ruby with FFI
   @johnlinvc


   View Slide

2. Me
   • John Lin ( ྛ⇉ᠳʣ
   • @johnlinvc
   • Head of Algorithm @
   Spoonrocket


   View Slide

3. What’s SpoonRocket?


   View Slide

4. The Problem


   View Slide

5. heroku/router: at=error
   code=H12

   desc="Request timeout"


   View Slide

6. Real World® Problem


   View Slide

7. We Need Speed


   View Slide

8. Change Language
   • Switch to Go / Scala / Java / C++


   View Slide

9. View Slide

10. Go Native
    • C extension
    • FFI


    View Slide

11. C Extension
    • Write the critical part using Ruby API in C
    • Need compiler on production environment
    • Not portable between Platforms


    View Slide

12. Foreign Function Interface
    • Mounting C function as Ruby method
    • Call functions using C Library libffi
    • Doesn’t need compiler
    • Portable between platforms


    View Slide

13. C-ext vs FFI


    View Slide

14. How Libffi works in C


    View Slide

15. View Slide

16. C Library Structure(ELF)
    9/8/2015 https://upload.wikimedia.org/wikipedia/commons/7/77/Elf-layout--en.svg
    ...
    .data
    .rodata
    .text
    Program header table
    ELF header
    Section header table
    {
    {
    https://en.wikipedia.org/wiki/Executable_and_Linkable_Format


    View Slide

17. Load Library
    void* dlopen(const char* path, int mode);
    • load a shared library file at path & relocate the
    address


    View Slide

18. Function Address
    λ ~/ nm /usr/lib/libruby.dylib
    0000000000027a75 T _InitVM_Enumerator
    00000000000088de T _Init_Array
    000000000012a65e T _Init_BareVM
    00000000000164e2 T _Init_Bignum
    0000000000037829 T _Init_Binding
    000000000001b08e T _Init_Comparable
    000000000001be5c T _Init_Complex
    000000000013c869 T _Init_Cont
    0000000000020721 T _Init_Dir
    00000000000032ec T _Init_Encoding
    00000000000239a6 T _Init_Enumerable
    000000000002906a T _Init_Enumerator
    000000000002caa7 T _Init_Exception


    View Slide

19. Find Function Address
    void* dlsym(void* handle, const char* symbol);
    • get address of a symbol from a library


    View Slide

20. Function call
    with cdecl


    View Slide

21. Call Function With Address
    In C
    typedef int func(void);
    func * f = (func*) 0x12345566;
    int res = f();


    View Slide

22. Define Function Signature
    ffi_status
    ffi_prep_cif(
    ffi_cif *cif,
    ffi_abi abi,
    unsigned int nargs,
    ffi_type *rtype,
    ffi_type **atypes);
    Define the signature of a function. cif stands for
    Call InterFace


    View Slide

23. Invoke Function
    void
    ffi_call(ffi_cif *cif,
    void (*fn)(void),
    void *rvalue,
    void **avalue);
    • ffi_call(): call the actual function by address, with
    return address and input parameters


    View Slide

24. dlopen()
    dlsym()
    ffi_prep_cif()
    ffi_call()


    View Slide

25. Ruby-FFI
    • Wrapper of C Library libffi
    • First appeared in Rubinius
    • Maintained by JRuby team
    • Available in MRI, JRuby & Rubinius(same
    interface)


    View Slide

26. Installing
    • gem install ffi


    View Slide

27. Hello FFI
    #!/usr/bin/env ruby
    require 'ffi'
    module LIBC
    extend FFI::Library
    ffi_lib FFI::Library::LIBC
    attach_function :printf, [:string], :int
    end
    LIBC.printf("hello FFI\n")


    View Slide

28. Loading Library
    • Loading Multiple Libs

    ffi_lib "foo", "bar"
    • Loading all possible names of a Lib

    ffi_lib [“foo", “foo-1.2”]


    View Slide

29. Attach Function
    • Function rename

    attach_function :c_print, :printf, [:string], :int
    • Function with variable length

    attach_function :printf, [:string, :varargs], :int



    View Slide

30. Supported C Types
    • Integer : singed/unsigned of various length
    • Floating Point: float / double
    • String: NULL terminated char array.
    • Pointer: pointer


    View Slide

31. Define C Structs
    class Timeval < FFI::Struct
    layout :tv_sec => :ulong,
    :tv_usec => :ulong
    end
    struct timeval {
    unsinged long tv_sec; /* seconds since 1/1/1970 */
    unsinged long tv_usec;/* and microseconds */
    };
    C
    Ruby


    View Slide

32. Accessing C Struct
    module LibC
    extend FFI::Library
    ffi_lib FFI::Library::LIBC
    attach_function :gettimeofday, [ :pointer, :pointer ], :int
    end
    t = Timeval.new
    LibC.gettimeofday(t.pointer, nil)
    puts "t.tv_sec=#{t[:tv_sec]} t.tv_usec=#{t[:tv_usec]}"
    int gettimeofday(struct timeval * tp, void * tzp);
    C signature
    Ruby


    View Slide

33. Define Callback
    module LibC
    extend FFI::Library
    ffi_lib FFI::Library::LIBC
    callback :qsort_cmp, [ :pointer, :pointer ], :int
    attach_function :qsort,
    [ :pointer, :ulong, :ulong, :qsort_cmp ], :void
    end
    void qsort(void *base, size_t nel, size_t width,
    int (*compar)(const void *, const void *));
    C signature
    Ruby


    View Slide

34. Using Callback
    pointer = FFI::MemoryPointer.new(:int, 2)
    ary = [ 2, 1 ]
    pointer.write_array_of_int32(ary)
    size_of_int = 4
    LibC.qsort(pointer, ary.count, size_of_int) do |p1, p2|
    i1 = p1.read_int32
    i2 = p2.read_int32
    i1 < i2 ? -1 : i1 > i2 ? 1 : 0
    end
    p pointer.get_array_of_int32(0, ary.count)


    View Slide

35. Features
    • Load C library
    • Invoke C function
    • Auto convert between Ruby types & C types
    • Define/Access C Struct
    • Using block/Proc as callback


    View Slide

36. Benchmark
    • Find Eigenvalue & Eigenvector of a matrix
    • Benchmark the runtime of
    • Ruby Matrix in Stdlib
    • C Extension with LAPACK
    • FFI with LAPACK


    View Slide

37. Performance
    N=1000 N=10000 N=100000
    Ruby 0.3 2.87 30.3
    FFI 0.02 0.19 2.1
    C-Ext 0.01 0.1 0.99


    View Slide

38. Take aways
    • Don’t give up ruby if you need speed.
    • How FFI works under the hood
    • FFI core features


    View Slide

39. Q&A


    View Slide

40. References
    • Linker & Loaders
    • Libffi
    • ruby-ffi Gem
    • Race car Image
    • x86 call convention


    View Slide
