  1. 1 KYOTO UNIVERSITY
    KYOTO UNIVERSITY
    Metric Recovery from Unweighted k-NN Graphs
    Ryoma Sato

    View Slide

  2. 2 / 45 KYOTO UNIVERSITY
    I introduce my favorite topic and its applications
     Metric recovery from unweighted k-NN graphs is my
    recent favorite technique.
    I like this technique because
    The scope of applications is broad, and
    The results are simple but non-trivial.
     I first introduce this problem.
     I then introduce my recent projects that used this technique.
    - Towards Principled User-side Recommender
    Systems (CIKM 2022)
    - Graph Neural Networks can Recover the Hidden
    Features Solely from the Graph Structure (ICML 2023)

    View Slide

  3. 3 / 45 KYOTO UNIVERSITY
    Metric Recovery from Unweighted k-NN Graphs
    Morteza Alamgir, Ulrike von Luxburg. Shortest path distance in random k-nearest neighbor graphs. ICML 2012.
    Tatsunori Hashimoto, Yi Sun, Tommi Jaakkola. Metric recovery from directed unweighted graphs. AISTATS 2015.

    View Slide

  4. 4 / 45 KYOTO UNIVERSITY
    k-NN graph is generated from a point cloud
     We generate a k-NN graph from a point cloud.
     Then, we discard the coordinates of nodes.
    generate
    edges
    discard
    coordinates
    nodes have coordinates
    for visualization
    but they are random

    View Slide

  5. 5 / 45 KYOTO UNIVERSITY
    Metric recovery asks to estimate the coodinates
     The original coordinates are hidden now.
     Metric recovery from unweighted k-NN graphs is a problem
    of estimating the coordinates from the k-NN graph.
    estimate

    View Slide

  6. 6 / 45 KYOTO UNIVERSITY
    Only the existences of edges are observable
     Unweighted means the edge lengths are neither available.
     This is equivalent to the setting where only the 01-adjacency
    matrix of the k-NN graph is available.
    estimate

    View Slide

  7. 7 / 45 KYOTO UNIVERSITY
    Given 01-adjacency, estimate the coordinates
     Problem (Metric Recovery from Unweighted k-NN Graphs)
    In: The 01-adjacency matrix of a k-NN graph
    Out: The latent coordinates of the nodes
     Very simple.
    estimate

    View Slide

  8. 8 / 45 KYOTO UNIVERSITY
    Why Is This Problem Challenging?

    View Slide

  9. 9 / 45 KYOTO UNIVERSITY
    Standard node embedding methods fail
     The type of this problem is node embedding.
    I.e., In: graph, Out: node embeddings.
     However, the following example tells standard embeddings
    techniques fail.

    View Slide

  10. 10 / 45 KYOTO UNIVERSITY
    Distance is opposite in the graph and latent space
     The shortest-path distance between nodes A and B is 21.
    The shortest-path distance between nodes A and C is 18.
     Standard node embedding methods would embed node C
    closer to A than node B to A, which is not consistent with
    the ground truth latent coordinates.
    10-NN graph
    The coordinates are
    supposed to be hidden,
    but I show them for
    illustration.

    View Slide

  11. 11 / 45 KYOTO UNIVERSITY
    Critical assumption does not hold
     Embedding nodes that are close in the input graph close
    is the critical assumption in various embedding methods.
     This assumption does NOT hold in our situation.
    10-NN graph
    The coordinates are
    supposed to be hidden,
    but I show them for
    illustration.

    View Slide

  12. 12 / 45 KYOTO UNIVERSITY
    Solution

    View Slide

  13. 13 / 45 KYOTO UNIVERSITY
    Edge lengths are important
     Why the previous example fails?
     If the edge lengths were took into consideration,
    the shortest path distance would be a consistent estimator of
    the latent distance.
     Step 1: Estimate the latent edge lengths.
    10-NN graph
    The coordinates are
    supposed to be hidden,
    but I show them for
    illustration.

    View Slide

  14. 14 / 45 KYOTO UNIVERSITY
    Densities are important
     Observation: Edges are longer in sparse regions
    and shorter in dense regions.
     Step 2: Estimate the densities.
     But how? We do not know the coordinates of the points...
    10-NN graph
    The coordinates are
    supposed to be hidden,
    but I show them for
    illustration.

    View Slide

  15. 15 / 45 KYOTO UNIVERSITY
    Density can be estimated from PageRank
     Solution: A PageRank-like estimator solves it.
    The stationary distribution of random walks (plus a simple
    transformation) is a consistent estimator of the density.
     The higher the rank is, the denser there is.
     This can be computed solely from the unweighted graph.
    10-NN graph
    Stationary distribution
    of simple random walks
    ≈ PageRank

    View Slide

  16. 16 / 45 KYOTO UNIVERSITY
    Given 01-adjacency, estimate the coordinates
     Problem definition (again)
    In: The 01-adjacency matrix of a k-NN graph
    Out: The latent coordinates of the nodes
     Very simple.
    estimate

    View Slide

  17. 17 / 45 KYOTO UNIVERSITY
    Procedure to estimate the coordinates
    1. Compute the stationary distribution of random walks.
    2. Estimate the density around each node.
    3. Estimate the edge lengths using the estimated densities.
    4. Compute the shortest path distances using the estimated
    edge lengths and compute the distance matrix.
    5. Estimate the coordinates from the distance matrix
    by, e.g., multidimentional scaling.
     This is a consistent estimator [Hashimoto+ AISTATS 2015].
    Tatsunori Hashimoto, Yi Sun, Tommi Jaakkola. Metric recovery from directed unweighted graphs. AISTATS 2015.
    (up to rigid transform)

    View Slide

  18. 18 / 45 KYOTO UNIVERSITY
    We can recover the coordinates consistently
    The latent coordinates can be consistently estimated
    solely from the unweighted k-NN graph.
    Take Home Message

    View Slide

  19. 19 / 45 KYOTO UNIVERSITY
    Towards Principled User-side Recommender Systems (CIKM 2022)
    Ryoma Sato. Towards Principled User-side Recommender Systems. CIKM 2022.

    View Slide

  20. 20 / 45 KYOTO UNIVERSITY
    Let’s consider item-to-item recommendations
     We consider item-to-item recommendations.
     Ex: “Products related to this item” panel in Amazon.com.

    View Slide

  21. 21 / 45 KYOTO UNIVERSITY
    User-side recsys realizes user’s desiderata
     Problem: We are unsatisfactory with the official recommender
    system.
     It provides monotone recommendations.
    We need serendipity.
     It provides recommendations biased towards specific
    companies or countries.
     User-side recommender systems [Sato 2022] enable users
    to build their own recommender systems that satisfy their
    desiderata even when the official one does not support them.
    Ryoma Sato. Private Recommender Systems: How Can Users Build Their Own Fair Recommender Systems without
    Log Data? SDM 2022.

    View Slide

  22. 22 / 45 KYOTO UNIVERSITY
    We need powerful and principled user-side Recsys
     [Sato 2022]’s user-side recommender system is realized in an
    ad-hoc manner, and the performance is not so high.
     We need a way to build user-side recommender systems in a
    systematic manner and a more powerful one.
    Hopefully one that is as strong as the official one.
    Ryoma Sato. Private Recommender Systems: How Can Users Build Their Own Fair Recommender Systems without
    Log Data? SDM 2022.

    View Slide

  23. 23 / 45 KYOTO UNIVERSITY
    Official (traditional) recommender systems
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    Step 1. training
    Step 2. inference
    recommendations
    Official (traditional) recsys

    View Slide

  24. 24 / 45 KYOTO UNIVERSITY
    Users cannot see the data, algorithm, and model
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    recommendations
    These parts are not
    observable for users
    (industrial secrets)

    View Slide

  25. 25 / 45 KYOTO UNIVERSITY
    How can we build our Recsys without them?
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    recommendations
    But they are crucial
    information to build
    new Recsys...

    View Slide

  26. 26 / 45 KYOTO UNIVERSITY
    We assume the model is embedding-based
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    recommendations
    (Slight) Assumption:
    The model embeds items and
    recommends near items.
    This is a common strategy in Recsys.
    We do not assume the way it embeds.
    It can be matrix factorization,
    neural networks, etc.

    View Slide

  27. 27 / 45 KYOTO UNIVERSITY
    We can observe k-NN graph of the embeddings
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    recommendations
    Observation:
    These outputs have sufficient information
    to construct the unweighted k-NN graph.
    I.e., users can build the k-NN graph by
    accessing each item page, and observing
    what the neighboring items are.

    View Slide

  28. 28 / 45 KYOTO UNIVERSITY
    We can estimate the embeddings!
    Recsys Algorithm
    log data
    catalog
    auxiliary data
    Ingredients
    Recsys model
    sourece item
    recommendations
    Solution:
    Estimate the item embeddings of
    the official Recsys.
    They are considered to be secret,
    but we can estimate them from
    the weighted k-NN graph!
    They contain much information!

    View Slide

  29. 29 / 45 KYOTO UNIVERSITY
    We realize our desiderata with the embeddings
     We can do many things with the estimated embeddings.
     We can compute recommendations by ourselves and
    with our own postprocessings.
     If you want more serendipity,
    recommend 1st, 2nd, 4th, 8th, ... and 32nd nearest items
    or add noise to the embeddings.
     If you want to decrease the bias to specific companies,
    add negative biases to the score of these items so as to
    suppress these companies.

    View Slide

  30. 30 / 45 KYOTO UNIVERSITY
    Experiments validated the theory
     In the experiments
    I conducted simulations
    and showed that the hidden
    item embeddings can be
    estimated accurately.
    I built a fair Recsys for Twitter, which runs
    in the real-world, on the user’s side.
    Even though the official Recsys
    is not fair w.r.t. gender, mine is, and
    it is more efficient than the existing one.

    View Slide

  31. 31 / 45 KYOTO UNIVERSITY
    Users can recover the item embeddings
    Users can “reverse engineer” the official item
    embeddings solely from the observable information.
    Take Home Message

    View Slide

  32. 32 / 45 KYOTO UNIVERSITY
    Graph Neural Networks can Recover the Hidden Features
    Solely from the Graph Structure (ICML 2023)
    Ryoma Sato. Graph Neural Networks can Recover the Hidden Features Solely from the Graph Structure. ICML 2023.

    View Slide

  33. 33 / 45 KYOTO UNIVERSITY
    We call for the theory for GNNs
     Graph Neural Networks (GNNs) take a graph with node
    features as input and output node embeddings.
     GNNs is a popular choice in various graph-related tasks.
     GNNs are so popular that understanding GNNs by theory is
    an important topic in its own right.
    e.g., What is the hypothesis space of GNNs?
    (GNNs do not have a universal approximation power.)
    Why GNNs work well in so many tasks?

    View Slide

  34. 34 / 45 KYOTO UNIVERSITY
    GNNs apply filters to node features
     GNNs apply filters to the input node features and extract
    useful features.
     The input node features have long been considered
    to be the key to success.
    If the features have no useful signals, GNNs will not work.

    View Slide

  35. 35 / 45 KYOTO UNIVERSITY
    Good node features are not always available
     However, informative node features are not always available.
     E.g., social network user information may be hidden for
    privacy reasons.

    View Slide

  36. 36 / 45 KYOTO UNIVERSITY
    Uninformative features degrade the performance
     If we have no features at hand, we usually input
    uninformative node features such as the degree features.
     No matter how such features are filtered, only uninformative
    embeddings are obtained.
    “garbage in, garbage out.”
    This is common sense.

    View Slide

  37. 37 / 45 KYOTO UNIVERSITY
    Can GNNs work with uninformative node features?
     Research question I want to answer in this project:
    Do GNNs really not work when the input node features
    are uninformative?
     In practice, GNNs sometimes work just with degree features.
    The reason is a mystery, which I want to elucidate.

    View Slide

  38. 38 / 45 KYOTO UNIVERSITY
    We assume latent node features behind the graph
     (Slight) Assumption:
    The graph structure is formed by connecting nodes whose
    latent node features z*
    v
    are close to each other.
     The latent node features z*
    v
    are not an observable
    e.g., "true user preference vector"
    Latent features that contain users’
    preferences, workplace, residence, etc.
    Those who have similar
    preferences and residence
    have connections.
    We can only observe the way they are
    connected, not the coordinates.

    View Slide

  39. 39 / 45 KYOTO UNIVERSITY
    GNNs can recover the lantent feature
     Main results:
    GNNs can recover the latent node features z*
    v
    even when the
    input node features are uninformative.
     z*
    v
    contains the preferences of users, which is useful for tasks.

    View Slide

  40. 40 / 45 KYOTO UNIVERSITY
    GNNs create useful node features themselves
     GNNs can create completely new and useful node
    features by absorbing information from the graph structure,
    even when the input node features are uninformative.
     A new perspective that overturns the existing view of filtering
    input node features.

    View Slide

  41. 41 / 45 KYOTO UNIVERSITY
    GNNs can recover the coordinates with some tricks
     How to prove it?
    → Metric recovery from k-NN graphs as you may expect.
     But be careful when you apply it.
    What GNNs can do (the hypothesis space of GNNs) is limited.
     The metric recovery algorithm is compatible with GNNs.
    Stationary distribution → GNNs can do random walks.
    Shortest path → GNNs can simulate Bellman-Ford.
    MDS → This is a bit tricky part. We send the matrix to
    some nodes and solve it locally.
     GNNs can recover the metric with slight additional errors.

    View Slide

  42. 42 / 45 KYOTO UNIVERSITY
    Recovered features are empicirally useful
     In the experiments,
    We empirically confirmed
    this phenomenon.
    The recovered features are useful for various downstream tasks,
    even when the input features x
    syn
    are uninformative.

    View Slide

  43. 43 / 45 KYOTO UNIVERSITY
    GNNs can create useful features by themselves
    GNNs can create useful node features by absorbing
    information from the underlying graph.
    Take Home Message

    View Slide

  44. 44 / 45 KYOTO UNIVERSITY
    Conclusion

    View Slide

  45. 45 / 45 KYOTO UNIVERSITY
    I introduced my favorite topic and its applications
     Metric recovery from unweighted k-NN graphs is my
    recent favorite technique.
    I like this technique because
    The scope of applications is broad, and
    The results are simple but non-trivial.
    The latent coordinates can be consistently estimated
    solely from the unweighted k-NN graph.
    Take Home Message

    View Slide
