Talking SQL to Strangers

Talking SQL to Strangers

SQL has become increasingly popular during the last few years: both among databases that didn’t had SQL interface before and, what’s interesting, among systems that are not databases at all. Thought the idea of exposing SQL as an API for your system might seem logically plausible, a technical complexity of making this happen is way off compared to more “common” (let’s say HTTP REST) solutions. Let’s fix this!

B9b7a5ffa24e2af6f877a7950461ba0f?s=128

Oleksii Kachaiev

May 29, 2020
Tweet

Transcript

  1. Talking SQL to strangers Oleksii Kachaiev, @kachayev Principal Engineer @

    Riot Games, League of Legends June, 2020
  2. SQL as a Language • old invention, popularized by RDMS

    in 70s • a few years of being "not cool" • collateral damage of NoSQL movement? • what do we have now? • databases that never talked SQL (Druid, Cassandra[1] etc) • not even databases (Spark, Flink, Kafka etc) [1] limitations applied
  3. SQL as an API • GraphQL is a query language

    made it to be an API • (probably for a wrong reason) • Strata talk comparing GraphQL and SQL • (mostly recognized as a smart trolling) • this talk: how to expose SQL API • (dealing with why as we go)
  4. SQL as an API: Demo • camille-sql • running SQL

    queries over local Maven artifacts
  5. Maven Artifacts Tree % tree ~/.m2/repository/ | less /Users/okachaiev/.m2/repository ├──

    aleph │ └── aleph │ └── 0.4.7-alpha5 │ ├── _remote.repositories │ ├── aleph-0.4.7-alpha5.jar │ ├── aleph-0.4.7-alpha5.jar.sha1 │ ├── aleph-0.4.7-alpha5.pom │ └── aleph-0.4.7-alpha5.pom.sha1 ├── ant │ └── ant │ └── 1.6.5 │ ├── _remote.repositories │ ├── ant-1.6.5.jar │ ├── ant-1.6.5.jar.sha1 │ ├── ant-1.6.5.pom │ └── ant-1.6.5.pom.sha1
  6. camille-sql: Running Server % bin/camille-server [INFO] Scanning for projects... [INFO]

    [INFO] -----------------< org.okachaiev.camille:camille-sql >------------------ [INFO] Building Camille SQL 1.0-SNAPSHOT [INFO] --------------------------------[ jar ]--------------------------------- [INFO] [INFO] >>> exec-maven-plugin:1.2.1:java (default-cli) > validate @ camille-sql >>> [INFO] [INFO] <<< exec-maven-plugin:1.2.1:java (default-cli) < validate @ camille-sql <<< [INFO] [INFO] [INFO] --- exec-maven-plugin:1.2.1:java (default-cli) @ camille-sql --- Artifacts repository path: /Users/okachaiev/.m2/repository/ Running server on localhost:26727
  7. camille-sql: PSQL Client % PGPASSWORD=nopass psql "sslmode=disable host=localhost port=26727" psql

    (12.2, server 9.5.0) Type "help" for help. okachaiev=>
  8. camille-sql: Queries okachaiev=> select * from artifacts limit 6; uid

    | group_id | artifact_id | name | url ------------+--------------------------+--------------------------+---------------------+------------------------------------------ 3227713579 | alandipert | desiderata | desiderata | https://github.com/alandipert/desiderata 3382955103 | aopalliance | aopalliance | AOP alliance | http://aopalliance.sourceforge.net 1507835947 | asm | asm-parent | ASM | http://asm.objectweb.org/ 226341444 | backport-util-concurrent | backport-util-concurrent | Backport of JSR 166 | http://backport-jsr166.sourceforge.net/ 1712481681 | biz.aQute | bndlib | BND Library | http://www.aQute.biz/Code/Bnd 2280883480 | biz.aQute.bnd | biz.aQute.bndlib | biz.aQute.bndlib | https://bnd.bndtools.org/ (6 rows) okachaiev=> select * from versions where filesize > 10000 limit 5; uid | version | filesize | last_modified | sha1 ------------+---------+----------+-------------------------+------------------------------------------ 3345961009 | 1.3.2 | 337129 | 2019-07-04 23:36:26.464 | ff84d15cfeb0825935a170d7908fbfae00498050 1053708643 | 1.0.1 | 26514 | 2019-07-04 23:23:20.322 | 49c100caf72d658aca8e58bd74a4ba90fa2b0d70 2740841946 | 1.6.5 | 1034049 | 2019-07-05 05:37:10.953 | 7d18faf23df1a5c3a43613952e0e8a182664564b 925895164 | 0.4.4 | 42645 | 2020-02-01 06:45:59.599 | 2522f7f1b4bab169a2540406eb3eb71f7d6e3003 136773645 | 1.9 | 263965 | 2019-07-04 23:25:30.09 | 9ce04e34240f674bc72680f8b843b1457383161a (5 rows)
  9. camille-sql: Queries okachaiev=> SELECT group_id, COUNT(*) AS n_files okachaiev-> FROM

    artifacts okachaiev-> LEFT JOIN versions ON artifacts.uid=versions.uid okachaiev-> GROUP BY group_id okachaiev-> ORDER BY n_files DESC; group_id | n_files ----------------------------+--------- org.apache.hadoop | 84 org.apache.maven | 54 org.codehaus.plexus | 50 org.apache.commons | 49 com.fasterxml.jackson.core | 45 com.twitter | 44 com.nimbusds | 38 org.typelevel | 37 org.scala-lang | 31 org.apache.maven.doxia | 24 (10 rows)
  10. Building Blocks • server/client protocol • SQL query lifecycle •

    parser • planner • optimizer • execution • bridge between the two
  11. Protocol • the goal: to choose wisely to have clients

    • e.g. you have a good client for HTTP: browser • not the case for SQL, databases use different protocols • JDBC makes them look similar in Java • (but we're looking a layer deeper)
  12. Protocol: PGWIRE • originally PostgreSQL • own low-level binary serialization

    format • own somewhat documented control flow • why? • clients: psql, SQL IDEs, BI • adoption outside PostgreSQL: Cockroach, Materialize • high performance streaming for large datasets
  13. Sequence Diagram (simplified)

  14. Protocol: Ignoring Today • SSL handshake (custom) • authentication handshake

    • prepared statements & bindings • data copy • cursors, suspensions, cancellation • (and a lot more)
  15. Protocol: Implementation • Netty to run TCP server • custom

    Codec to deal with network serialization • sequence of Handlers • mapping between transport and application level logic • Handler to orchestrate main loop: get query, execute, send result set • async i/o is an absolute overkill in this case
  16. Protocol: Example Serialization public ByteBuf toByteBuf(ByteBufAllocator allocator) { final ByteBuf

    buf = allocator.buffer(12 + this.totalLength); buf.writeByte('E'); // not included in length buf.writeInt(11 + this.totalLength); // length, self-included buf.writeByte('S'); // magical constant buf.writeBytes(this.severity.getBytes()); buf.writeZero(1); // null-termination buf.writeByte('C'); // magical constant buf.writeBytes(this.code.getBytes()); buf.writeZero(1); // null-termination buf.writeByte('M'); // magical constant buf.writeBytes(this.message.getBytes()); buf.writeZero(2); // double null-termination return buf; }
  17. Life of a Query: Theory • parse • plan (compile)

    • optimize • execute
  18. Life of a Query: Practice • leverage Apache Calcite •

    not the easiest framework to work with • alternatives: • Catalyst (too much Spark) • ZetaSQL (too young)
  19. Life of a Query: Calcite • parse ← lexer, dialect

    • plan (compile) ← catalog (databases, "tables") • optimize ← statistics (CBO), rules folding • execution ← scan definitions
  20. Life of a Query: Lexer • SQL is standard, right?

    well... it depends • Lex is a set of rules that defines parsing • using MYSQL_ANSI: double quotes, case insensitive • still problematic to deal with • expressions like E"\n" • ; as a query termination (standard but optional)
  21. Life of a Query: Parser • Babel-based parser • Default

    Calcite dialect (uppercase, "`" for quoting) SELECT `group_id`, COUNT(*) AS `n_files` FROM `versions` GROUP BY `group_id` ORDER BY `n_files` DESC
  22. Life of a Query: Catalog • schema: tables, functions, types

    etc • table: tables, views, temp views etc • table is anything that implements Table interface • declare "statically": • 2 tables • each table defines own row type • enough information for compilation
  23. Register Tables (Statically) this.resolver = new MavenArtifactsResolver(baseFolder); this.artifactsTable = new

    MavenArtifactsTable(this.resolver); this.versionsTable = new MavenArtifactVersionsTable(this.resolver); ... SchemaPlus rootSchema = calciteConnection.getRootSchema(); rootSchema.add("artifacts", artifactsTable); rootSchema.add("versions", versionsTable);
  24. Table Defines Row Type protected final RelProtoDataType protoRowType = new

    RelProtoDataType() { public RelDataType apply(RelDataTypeFactory typeFactory) { return new RelDataTypeFactory.Builder(typeFactory) .add("uid", SqlTypeName.BIGINT) .add("group_id", SqlTypeName.VARCHAR, 1023) .add("artifact_id", SqlTypeName.VARCHAR, 255) .add("name", SqlTypeName.VARCHAR) .add("url", SqlTypeName.VARCHAR) .build(); } };
  25. Life of a Query: Logical Plan select group_id, name from

    artifacts ↓ Root { kind: SELECT, rel: rel#5:LogicalProject#5, rowType: RecordType(VARCHAR(1023) group_id, VARCHAR name), fields: [<0, group_id>, <1, name>], } ↓ LogicalProject(group_id=[$1], name=[$3]) LogicalTableScan(table=[[artifacts]])
  26. Life of a Query: Logical Plan select group_id, name from

    artifacts where group_id = 'nrepl' order by artifact_id limit 20 ↓ LogicalProject(group_id=[$0], name=[$1]) LogicalSort(sort0=[$2], dir0=[ASC], fetch=[20]) LogicalProject(group_id=[$1], name=[$3], artifact_id=[$2]) LogicalFilter(condition=[=($1, 'nrepl')]) LogicalTableScan(table=[[artifacts]])
  27. Life of a Query: Logical Plan select group_id, count(*) as

    n_files from artifacts left join versions on artifacts.uid=versions.uid group by group_id order by n_files desc ↓ LogicalSort(sort0=[$1], dir0=[DESC]) LogicalAggregate(group=[{0}], n_files=[COUNT()]) LogicalProject(group_id=[$1]) LogicalJoin(condition=[=($0, $5)], joinType=[left]) LogicalTableScan(table=[[artifacts]]) LogicalTableScan(table=[[versions]])
  28. Life of a Query: Execution • minimal requirement: definition of

    "full scan" @Override public Enumerable<Object[]> scan(DataContext root) { // better replace this with something interesting :) return Linq4j.emptyEnumerable(); }
  29. Life of a Query: Execution • result is a Linq4j

    enumerable (collection or dynamic) • analog of C# LINQ (Language Integrated Queries) • Items.Select(*).Where(Item.Version > 1).Take(5) • a few years later, Spark popularized the idea for Big Data • Linq4j does heavy-lifting (folding relational operators)
  30. Life of a Query: Optimizations • generic optimizations provided by

    the framework • cost-based optimizations • opt out by setting Statistics.UNKNOWN • specifics: • skip calculating file size (projection pruning) • skip reading checksum (projection pruning) • jump to subfolder (predicate push-down)
  31. Projection Pruning • extremely common technique for big data analytics

    • (parquet, hehe) @Override public Enumerable<Object[]> scan( DataContext root, int[] projects) { // now we know what columns are necessary return Linq4j.emptyEnumerable(); }
  32. Predicate Push-Down • Calcite supports basic filters push-down • analysis

    of predicate is... non trivial @Override public Enumerable<Object[]> scan(DataContext root, List<RexNode> filters, int[] projects) { // now we also know predicates return Linq4j.emptyEnumerable(); }
  33. Predicate Push-Down Exact match: select * from artifacts where group_id

    = 'nrepl'; Exact prefix: select * from artifacts where group_id LIKE 'com.apache.%';
  34. Predicate Push-Down What if... select * from artifacts where group_id

    = 'nrepl' OR group_id = 'maven'; select * from artifacts where group_id = 'nrepl' AND group_id = 'maven'; What if... select * from artifacts where LOWER(group_id) + CAST("spark" AS VARCHAR) = 'com.apache.spark';
  35. Predicates • do not need to read the code •

    analysis is too rigit and inflexible • might be easily "broken" by user or even compiler • imperative code quickly turns into a mess • visitor pattern helps, still :( • pattern matching, pls • logical PL, ideally
  36. Optimization: toRel • table as a relational expression • opt-out

    from being a TableScan • e.g. artifacts might be defined as DISTINCT over versions • or, both artifacts and version tables are Project + Filter applied to virtual files table • in both cases, JOIN between them might be folded
  37. Optimization: toRel • nice part of relational algebra: it's an

    algebra • hardest part of relational algebra: it's an algebra
  38. Stitch Them Together • leverage Avatica (part of Calcite project)

    • standard JDBC interface • registers Calcite as a driver • local & remote connections
  39. HAVING Q and A Oleksii Kachaiev camille-sql
