1. Setup Hybrid Clusters using Kubernetes Federation Kyle bai R&D @ inwinSTACK www.inwinstack.com
2. About Me ⽩白凱仁(Kyle Bai) • Interested in emerging technologies. • COSCUP, Kubernetes Day and OpenStack Day Speaker. • OpenStack and Kubernetes Projects Contributor(100+ PR). • Certified Kubernetes Administrator. @kairen(k2r2.bai@gmail.com) https://kairen.github.io/
3. Agenda • Why Federation? • Federation Architecture • How to setup Kubernetes Federation • Bonus
4. Why Federation?
5. Dev Test Multiple Clusters Product
6. Dev Test Multiple Clusters Product US EU AP TW
7. Dev Test Multiple Clusters Product US EU AP TW
8. Multiple Clusters TW Local Dev
9. Multiple Clusters TW US Test TW Local Dev
10. Multiple Clusters US EU … AP Product TW US Test TW Local Dev
11. Multiple Clusters • Serving users from clusters closest to them. • Avoiding provider lock-in: By making it easier to migrate applications across clusters, federation prevents cluster provider lock-in. • High availability: Ability to federate clusters across different regions/ cloud providers.
12. Federation Federation makes it easy to manage multiple clusters. • Sync resources across clusters: Federation provides the ability to keep resources in multiple clusters in sync. • Cross cluster discovery: Federation provides the ability to auto-configure DNS servers and load balancers with backends from all clusters.
13. Federation Pros • Keep your app synced across clusters. • Configure network resources (services, ingress) to route traffic across clusters. • Single place to apply policies. • Policy-based Resource Placement(OPA).
14. Use cases for Federation • Geographically Distributed Deployments: Spread Deployments across clusters in different parts of the world. • Hybrid Cloud: Extend Deployments from on-premise clusters to the cloud. • Application Migration: Simplify the migration of applications from on- premise to the cloud or between cloud providers.
15. Federation Architecture
16. Overview Federation Control Plane
17. Overview Federation Control Plane Federated Resources
18. Overview Federation Control Plane Federated Resources Federated Clusters
19. Federation API Server The Kubernetes federation API server validates and configures data for the API objects which include pods, services, replicationcontrollers, and others.
20. Federation Controller Manager The federation controller manager is a daemon that embeds the core control loops shipped with federation. • Watches Federation API Server • Clusters - federation/v1beta1/cluster • API Resources - v1/foo • Watches All Kubernetes Clusters • API Resources - v1/foo • Reconciles • Compare and update • Handles cascading deletion
21. How to place? • Placement can be controlled per-resource via annotations. • Annotations supported: • federation.kubernetes.io/replica-set-preferences • federation.kubernetes.io/deployment-preferences • federation.alpha.kubernetes.io/cluster-selector • federation-controller evaluates annotations to produce final placement
22. How to setup Kubernetes Federation
23. Prerequisites(1/2) • In this demon, we will deploy clusters in different regions: • US West: Oregon (us-west) • Asia: Tokyo(ap-northeast) • My OpenStack: Taipei(os-taipei) • Install the following tools on host: • kubectl • kubefed: if os is Mac OS X, you need build from Federation source code. • kops, kubespray, kubeadm • AWS CLI
24. Prerequisites(2/2) Amazon Web Services: • IAM: Identity and Access Management. • EC2: Kubernetes cluster. • ELB: Kubernetes service load balancer. • Route53: Public domain for Kubernetes API, Service, … etc • S3: Store kops state. • VPC: Cluster Network. Godaddy: • Buy your own domain name.
25. Deme Clusters kubefed init ${FED_CONTEXT} \ --image=kairen/fcp-amd64:v1.10.0-alpha \ --host-cluster-context=${US_WEST_CONTEXT} \ --dns-provider=aws-route53 \ --dns-zone-name=${DOMAIN_NAME}
26. Deme Clusters kubefed join os-taipei \ --host-cluster-context=${US_WEST_CONTEXT} \ --cluster-context=${OS_CONTEXT}
27. Deme Topology
28. Bonus
29. Federation + OPA(Open Policy Agent ) Current Use Cases • Federated Workload Placement • Pod Scheduling • Authorization • Admission Control • Audit Future Use Cases • Storage policy • Network policy
30. Federation + OPA(Open Policy Agent )
31. Federation Cons • Increased network bandwidth and cost: The federation control plane watches all clusters to ensure that the current state is as expected. • Reduced cross cluster isolation: A bug in the federation control plane can impact all clusters. • Maturity: The federation project is relatively new and is not very mature. • Not all resources are available and many are still alpha and beta.
32. Federation support API resources • Cluster • ConfigMap • DaemonSets • Deployment • Events • HPA • Ingress • Jobs • Namespaces • ReplicaSets • Secrets • Services * Only support API version for extensions/v1beta1, v1
33. Federation v2 https://github.com/kubernetes-sigs/federation-v2 The prototype builds on the sync controller (a.k.a. push reconciler) from Federation v1. • Possible to implement a custom scheduler • Policies modeled as CRDs • Use existing RBAC • Can plug into policy engine • Implemented as an aggregated API server • Secured with ServiceAccounts https://github.com/font/k8s-example-apps/tree/master/sample-fed-v2-demo
34. Federation v2 The following abstractions support the propagation of a logical federated type: • Template: defines the representation of the resource common across clusters. • Placement: defines which clusters the resource is intended to appear in. • Override: optionally defines per-cluster field-level variation to apply to the template. https://docs.google.com/document/d/159cQGlfgXo6O4WxXyWzjZiPoIuiHVl933B43xhmqPEE/edit
35. Thanks
