Progressive Delivery with Istio and Argo Rollouts

Production is the place where all applications should live. Even though you are using Continuous Integration and Delivery, you still might wonder every time you release a new version to production whether it will actually work or if you will run into unforeseen issues related to your production environment and/or load, and whether your production environment will become unavailable to your customers.

Progressive delivery is the next step after Continuous Delivery to test your application in production before it becomes fully available to all your user bases.

Embrace progressive delivery with techniques like the blue-green, canary release, shadowing traffic, or dark launches to validate the application in production using Kubernetes and tools like Istio, Prometheus, ArgoCD, or Argo Rollouts.

Transcript

1. Progressive Delivery with Istio and Argo Rollouts
2. Alex Soto (lordofthejars.com) • @alexsotob • asotobue@redhat.com • Currently Red Hat’s Director of Developer Experience • Featured speaker at technology events around the globe • A Java Champion since 2017 • Writer, University Professor, Radio collaborator • A big fan of testing and continuous delivery in 21st century
3. @kevindubois Kevin Dubois • Principal Developer Advocate at Red Hat • 18+ years of experience building and delivering software applications • Speak English, Dutch, French, Italian • Passionate about improving Dev Experience with Open Source @kevindubois@mastodon.social youtube.com/@thekevindubois linkedin.com/in/kevindubois github.com/kdubois
4. @alexsotob @alexsotob Today’s Objectives Progressive Delivery Delivery Techniques Kubernetes Let’s Wind Down
5. @alexsotob @alexsotob Progressive Delivery
6. @alexsotob @alexsotob What is Progressive Delivery? Build Test Security Checks Release Deploy Stage Deploy Prod Continuous Integration Continuous Delivery
7. @alexsotob @alexsotob What is Progressive Delivery? • No Big Bang • Deploy != Release • Metrics • Subset of Users
8. @alexsotob @alexsotob Why Progressive Delivery? • Decreases Downtime • Limits the tragedy • Put to production faster
9. @alexsotob @alexsotob Delivery Techniques
10. @alexsotob @alexsotob 10
11. @alexsotob @alexsotob Blue Green Deployment • All Or Nothing • Quick Rollback 11
12. @alexsotob @alexsotob Canary Releases • Small Percentage • Increase depending on the metrics 12
13. @alexsotob @alexsotob Dark Launches • Mirroring Traffic • Dark Canaries • Feature Flags 13
14. @alexsotob @alexsotob 14
15. @alexsotob @alexsotob 15 Production is not sacrosanct anymore
16. @alexsotob @alexsotob The New ¿Pyramid? 16
17. @alexsotob @alexsotob 17
18. @alexsotob @alexsotob Kubernetes
19. @alexsotob @alexsotob Blue - Green 19 apiVersion: v1 kind: Service metadata: name: my-service labels: app: mystuff spec: ports: - name: http port: 8000 selector: inservice: mypods type: LoadBalancer apiVersion: apps/v1 kind: Deployment metadata: name: mynode-deployment spec: replicas: 1 selector: matchLabels: app: mynode template: metadata: labels: app: mynode spec: containers: - name: mynode image: quay.io/rhdevelopers/mynode:v1 ports: - containerPort: 8000 kubectl label pod -l app=mypython inservice=mypods
20. @alexsotob @alexsotob Canary Releases kubectl scale deployment myapp-v1 --replicas=3 kubectl scale deployment myapp-v2 --replicas=1 20
21. @alexsotob @alexsotob Canary Release 21 apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: recommendation spec: hosts: - recommendation http: - route: - destination: host: recommendation subset: version-v1 weight: 75 - destination: host: recommendation subset: version-v2 weight: 25
22. @alexsotob @alexsotob Shadowing Traffic 22 apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: recommendation spec: hosts: - recommendation http: - route: - destination: host: recommendation subset: version-v1 mirror: host: recommendation subset: version-v2
23. @alexsotob @alexsotob Dark Canary 23 apiVersion: networking.istio.io/v1alpha3 kind: VirtualService metadata: name: recommendation spec: hosts: - recommendation http: - match: - headers: end-user: exact: Alexandra route: - destination: host: recommendation subset: version-v2 - route: - destination: host: recommendation subset: version-v1
25. @alexsotob @alexsotob Next Generation Microservices - Service Mesh 25 Code Independent (Polyglot) • Intelligent Routing and Load-Balancing • Smarter Canary Releases • Dark Launch • Chaos: Fault Injection • Resilience: Circuit Breakers • Observability & Telemetry: Metrics and Tracing • Security: Encryption & Authorization • Fleet wide policy enforcement
26. @alexsotob @alexsotob Sidecar Container 26
27. @alexsotob Sidecar Container Pod Container JVM Service A Sidecar Container Pod Container JVM Service C Sidecar Container Pod Container JVM Service B Sidecar Container With Istio The sidecar intercepts all network traffic
28. Live Demo
29. @alexsotob @alexsotob The most asked question in Istio sessions 29
30. @alexsotob @alexsotob 30 Argo Rollouts
31. @alexsotob @alexsotob Argo Rollouts 31 kubectl apply rollout Monitors Data
32. @alexsotob @alexsotob Rolling out automatically 32 apiVersion: argoproj.io/v1alpha1 kind: Rollout metadata: name: bubblebackend labels: app: bubblebackend spec: strategy: canary: steps: - setWeight: 20 - pause: duration: "1m" - setWeight: 50 - pause: duration: "2m" canaryService: bubble-backend-canary stableService: bubble-backend trafficRouting: istio: virtualService: name: bubble-backend routes: - primary …
33. Live Demo
34. @alexsotob @alexsotob Let’s Wind Down
35. @alexsotob @alexsotob Final Notes • State is always hard, start with stateless • Step by Step • Embrace GitOps • If you haven’t automatically destroyed something by mistake, you aren’t automating enough • Demos ◦ https://dn.dev/istio-tutorial ◦ https://github.com/redhat-developer-demos/bubbles-progressive-delivery 35
