  1. Introduction to
    Design Patterns
    June 7th, 2019
    Kenju Wagatsuma
    Cookpad Inc.

    View full-size slide

  2. TOC
    ● Introduction to Design patterns
    ● Design patterns examples
    ● Pattern Language
    ● Resources for learning

    View full-size slide

  3. Introduction to Design patterns

    View full-size slide

  4. What is Design patterns?
    ● reusable solutions to specific problems in software
    development
    ○ … is not a silver bullet to all problems
    ○ … is framework agnostic
    ○ … was firstly introduced by so-called “Gang of Four”
    in 1994
    ■ Erich Gamma, Richard Helm, Ralph Johnson, John Vlissides

    View full-size slide

  5. How Design patterns used?
    patterns Definition Example
    Creational
    patterns
    create objects Factory method / Builder / Singleton /
    Prototype / Lazy initialization
    Structural
    patterns
    relationships among
    objects
    Adapter / Bridge / Composite / Decorator /
    Facade / Proxy
    Behavioral
    patterns
    how each objects
    behave
    Command / Iterator / Observer / Strategy /
    Visitor

    View full-size slide

  6. Why to use Design patterns?
    ● lingua franca of software development
    ○ “This class can be refactored with Decorator
    pattern...”
    ● proven ways for re-architecturing for specific cases
    ○ many programmers have used Design patterns for
    few decades...

    View full-size slide

  7. Design patterns are just tools
    ● 🙅 It is all or nothing
    ○ “Singleton pattern is good (or bad)”
    ○ “You should use decorator patterns never”
    ● 🙆 It solves specific problems
    ○ “Singleton pattern is good (or bad) when …”
    ○ “You should use decorator patterns to solve this
    problem because...”

    View full-size slide

  8. Design patterns Examples

    View full-size slide

  9. Factory pattern
    function TextCreative(props) {
    this.id = props.id;
    this.text = props.text;
    }
    function ImageCreative(props) {
    this.id = props.id;
    this.image = props.image;
    }
    function CreativeFactory() {}
    CreativeFactory.prototype.create = function(props) {
    if (props.type === ‘text’) {
    return new TextCreative(props);
    }
    else if (props.type === ‘image’) {
    return new ImageCreative(props);
    }
    else {
    throw new Error(`${props.type} is invalid`);
    }
    }

    View full-size slide

  10. Decorator pattern
    function Creative(props) {
    this.id = props.id;
    }
    /* define decorators */
    function addPopup(creative) {
    creative.onLoad(function() {
    popUp.show(‘creative loaded’);
    });
    }
    function addImage(creative, imageUrl) {
    creative.loadImage(imageUrl);
    }
    const creative = new Creative({
    id: ‘foo-bar’,
    });
    const decorators = [
    addPopup,
    addImage,
    ];
    decorators.forEach((decorator) => {
    decorator(creative);
    });

    View full-size slide

  11. Command pattern
    const creatives = ['cr1', 'cr2', 'cr3'];
    function SingleSelectionCommand() {
    const idx = Math.floor(
    Math.random() * creatives.length);
    return creatives[idx];
    }
    function MultipleSelectionCommand(props) {
    const selected = new Set();
    for (let i = 0; i < props.count; i++) {
    selected.add(SingleSelectionCommand());
    }
    return Array.from(selected);
    }
    /** define command executor */
    function CreativeSelector(props) {}
    CreativeSelector.prototype.execute = function(
    command,
    props,
    ) {
    return command(props);
    }
    /** execute commands */
    const selector = new CreativeSelector();
    const single = selector.execute(SingleSelectionCommand, {});
    const multi = selector.execute(MultipleSelectionCommand, {
    count: 2,
    });

    View full-size slide

  12. Pattern Language

    View full-size slide

  13. 👈 Please have a look at this
    great answer to the Quora’s
    question

    View full-size slide

  14. Pattern Language
    Each “patterns” consists of...
    Pattern Name
    Context Problem Solution

    View full-size slide

  15. Resources for your learning

    View full-size slide

  16. “GoF”
    ● Creational
    ○ Abstract Factory/Builder/Factory
    Method/Prototype/Singleton
    ● Structural
    ○ Adapter/Bridge/Composite/Decorator/Facad
    e/Flyweight/Proxy
    ● Behavioural
    ○ Chain of
    Responsibility/Command/Interpreter/Iterato
    r/Mediator/Memento/Observer/State/Strate
    gy/Template Method/Visitor
    ※ some patterns can be outdated or too common nowadays

    View full-size slide

  17. FREE (online version)
    for example...
    ● Command
    ● Observer
    ● Prototype
    ● Singleton
    ● State
    ● Component
    ● Event Queue
    ● Object Pool
    ● Dirty Flag
    ● etc.

    View full-size slide

  18. FREE (online version)
    for example...
    ● Constructor
    ● Module
    ● Revealing Module
    ● Singleton
    ● Observer
    ● Mediator
    ● Prototype
    ● Command
    ● Facade
    ● etc.
