Floating Point 101
Search
kida
February 06, 2013
Programming
340
7
Share
Embed
Copy iframe code
Copy JS code
Copy link
Start on current slide
Floating Point 101
A very very basic introduction to FP.
With some inaccuracies.
kida
February 06, 2013
Transcript
67 slides
FLOATING 101 POINT
FLOATING 100.999998 POINT
engineers we are
researchers we are
3.14159265358979 3238462643383279 5028841971693993 7510582097494459 2307816406286208 NUMBERS WE PLAY WITH ALL
DAY LONG
well, sometimes even at night. (yawn).
So, what is a floating point?
A floating point is ± D 1 .D 2 D
3 ···D n x Be
A floating point is sign ± D 1 .D 2
D 3 ···D n x Be
A floating point is significand ± D 1 .D 2
D 3 ···D n x Be
A floating point is base ± D 1 .D 2
D 3 ···D n x Be
A floating point is exponent ± D 1 .D 2
D 3 ···D n x Be
A floating point represents ± (D 1 + D 2
* B-1 + D 3 * B-2 + … + D n * B(n-1)) * Be
For example + 3.14 x 100 = (3 + 1*0.1
+ 4*0.01)*1 = 3.14
The point can float ! + 3.14 x 10-1 =
0.314
The point can float ! + 3.14 x 10+1 =
31.4
What if B = 2 ? + 1.00 x 2+2
= 4.0
Like machines do. http://grouper.ieee.org/groups/754/
Normalization of floating point
Multiple representations + 0.01 x 22 = 1.0 + 0.10
x 21 = 1.0 + 1.00 x 20 = 1.0
Normalized representation + 0.01 x 22 = 1.0 + 0.10
x 21 = 1.0 + 1.00 x 20 = 1.0
Normalized representation + (1.)000 x 20 1 is omitted
Normalized representation + (1.)000 x 20 there's room for an
extra digit!
Excess-127 representation -127 → 0 -126 → +1 … -1
→ +126 0 → +127
#include <float.h> FLT_MIN, FLT_MAX, ... #include <math.h> M_PI, M_E, NAN,
INFINITY, ...
Why no exact representation for 0.1?
FLOATING POINT REAL NUMBERS is used to represent
FLOATING POINT RATIONAL NUMBERS denotes a (finite) subset of
0.1 cannot be expressed as a power of 2 +
??? x 2??
+ 00 x 20 1 It's also a matter of
precision
+ 01 x 20 1 1.25 It's also a matter
of precision
+ 10 x 20 1 1.25 1.5 It's also a
matter of precision
+ 11 x 20 1 1.25 1.5 1.75 It's also
a matter of precision
+ 11 x 20 π/2 It's also a matter of
precision
+ 11 x 20 π/2 It's also a matter of
precision
+ 00 x 21 1 1.25 1.5 1.75 2.0 Not
just a matter of precision or basis...
+ 01 x 21 1 1.25 1.5 1.75 2.0 2.5
Not just a matter of precision or basis...
+ 10 x 21 1 1.25 1.5 1.75 2.0 2.5
3.0 Not just a matter of precision or basis...
Like death and taxes rounding errors are a fact of
life. http://wiki.octave.org/FAQ
+ 110 x 21 Operands that differ greatly + 100
x 2-2
+ 110000 x 21 Operands that differ greatly + 000101
x 21
+ 110000 x 21 Operands that differ greatly + 000101
x 21 = 110
None
Operands that are really close + 111 x 21 -
110 x 21 = 001 x 21
Operands that are really close + 111 x 21 -
110 x 21 = 100 x 2-2
None
Fixed point representation + 100.001010 = 22 + 2-3+ 2-5
= 4.15625
POINT WHAT'S THE WITH FLOATING
FP ARITHMETIC IS FAST Embedded in HW.
Single precision up to ~10+38. FP REPRESENTS A WIDE RANGE
HE APPROVES FP
Anyway, errors still there.
Okay, what about increasing the number of digits use decimal
representations estimating errors think before you type
More digits, please! double (52 significant bits) long double (112
significant bits) arbitrary precision * * language support needed
Use decimal representations! decimal (C# only) BigDecimal (Java only) std::decimal
(C++, coming soon)* * after IEEE-754 2008
Estimate the error of your algo rel_err = fabs(f –
fp) / f
Use float to represent time float time; while (true) time
+= 0.20;
Use float to represent time float time; while (true) time
+= 0.20; This is BAD. And you should feel BAD.
Compare float numbers (a == b)
Compare float numbers (a == b) fabs(a -b) <= FLT_EPSILON
Compare float numbers (a == b) fabs(a -b) <= FLT_EPSILON
fabs(a - b) <= max(fabs(a),fabs(b)) * pc
There is no silver bullet.
Use libraries (when available).
Vector addition (naive) float t[SIZE]; float result; for (i =
0; i < SIZE; ++i) result += t[i];
RESCUE GNU GSL TO THE
None
that's all folks! @lorisfichera – https://kid-a.github.com References and source code
available at https://github.com/kid-a/floating-point-seminar Credits Font: Yanone Kaffeesatz (http://www.yanone.de/typedesign/kaffeesatz/)
