Making full use of Bus Pirate
Search
kitok
January 07, 2018
How-to & DIY
790
1
Share
Embed
Copy iframe code
Copy JS code
Copy link
Start on current slide
Making full use of Bus Pirate
#iotsecjp
kitok
January 07, 2018
Transcript
18 slides
この冬、BusPirateを 使い倒す きとけー(kitok)
[email protected]
⾃⼰紹介 • きとけー、きとけい、⽊藤 圭亮(kitokay, kitok) • キュアカイシャイン2年⽬(新プリキュア出た) • キャンプ2009卒、2012〜15チューター •
2016年からキャンプ講師 • ハードウェアリバースエンジニアリングを講義 • 2017年はBusPirateを使ってリバースする講義 • 温泉が好きです(温泉⾏きたい not ⾜湯)
今⽇の発表 • ほとんどデモなので、失敗したらごめんなさい
「この冬、Bus Pirateを使い倒す」 • Bus Pirateとは • Open Source Hardware and
Software Project • ハードウェア解析⽤の治具(?) • Mainlineはv3.6 • 千⽯電商、Switch Science • 4000円前後 • Switch Scienceのほうが少し安い
Bus Pirateで出来ること • 1-wire • I2C • SPI • JTAG
• Asynchronous serial(UART) • MIDI • PC Keyboard(PS/2) • HD447800 LCD • 2- and 3-wire libraries with bitwise pin control • Scriptable binary bitbang, 1-wire, I2C, SPI and UART 公式サイトより引⽤ 今⽇はここをデモ
Bus Pirateの概要図 PC USB-UART (FT232RL) BusPirate本体 (PIC24FJ64) MOSI/MISO Vcc, AUXなど
基本的にSerial経由で操作 • PyserialでPython Scriptable • 基本なpythonフレームワークは公開されてる • https://github.com/BusPirate • 基本的なやりかたも公開されてる
• http://dangerousprototypes.com/docs/Bus_Pirate_Scripting_in _Python • 例えば… • SPIのROMをdumpするとか • 1-wireでセンサデータを取得するとか • I2Cのデバイスの通信を取得するとか
とりあえず順番にデモ • UART • 1-wire • I2C • SPI •
JTAG • おまけ
UART • UARTモード • テストとして、出⼒したものを⼊⼒する • キーボード⼊⼒したものがターミナルに表⽰
モード切り替え • Hi-Z(⾼インピーダンスモード)→UARTモード • 初期はHi-Z mode、モード切り替えて使⽤ • Baud rate, stop
bitなどを設定 • オープンドレインでOutputの電圧を変更可能 • または3.3VのOutput • Inputはmax 5.5V • Transparent Bridgeにする
BusPirateの概要図 PC USB-UART (FT232RL) BusPirate本体 (PIC24FJ64) UART RX/TX PCからSerialが透過的に⾒える
1-wire • 1-wireの温度センサー • センサ系が多い(安価なデバイス) • DS18B20(秋⽉で変える1-wire温度センサIC)
I2C • I2CのROM dumpのデモ • I2Cで通信をするデバイスも多い • 例:Wiiのヌンチャク、SNESミニのコントローラ
こんな感じで接続 • Microchip 24LC64
SPI • SPIのEEPROMのdump • SPIは組込みのROMに使われることが多い • 例:ルーターのFlashROM(ファーム格納)
こんな感じで接続
ドキュメントの⽇本語化 • Bus Pirateチュートリアルを⽇本語化してます • ご協⼒いただける⼈は
[email protected]
まで • たぶん今⽉中にどっかでアナウンスします
• 他のリバエンツールも探ってます • 主にSDRツール(HackRF, YardStickとか) • IoTSecなんだから、無線もやらないとね! • 有⽤Toolsのドキュメント⽇本語化を進めたい
Bus Pirateをつかって • いろんな機器を分解して遊ぼう! • でも法的なところは守ろう • 知的財産権とか、著作権とか • リバースするのは違法ではないが、リバースして同
様の製品を作るのは違法 • 機器によっては、ファームウェアリバースは違法 • Let’s hacking with Bus Pirate!
