1. Master of Android Theme
   DroidKaigi 2019

   2019/02/07 (Thu)

   @konifar


   View Slide

2. @konifar
   https://github.com/konifar/


   View Slide

3. Kyash
   • I work for Japanese Fintech company called Kyash.

   • It makes easy to create Visa card and send money to
   anyone via app!
   https://play.google.com/store/apps/details?id=co.kyash


   View Slide

4. https://github.com/konifar/master-of-android-theme


   View Slide

5. Android Theme


   View Slide

6. Android Theme Overview
   • Technically the same as Style.

   • Theme is “Global”, Style is “Local”.

   • It’s important to use Theme especially since Material
   Design appeared.


   View Slide

7. themes.xml
   <br/><item name=“colorPrimary">@color/blue_grey_300</item><br/><item name=“colorPrimaryDark”>@color/blue_grey_400</item><br/><item name="colorAccent">@color/green_A200</item><br/>


   View Slide

8. colorPrimary
   colorPrimaryDark
   colorAccent


   View Slide

9. Two common problems


   View Slide

10. 1. Too many parent themes


    View Slide

11. 2. Too many attributes
    android:windowLightStatusBar
    android:actionMenuTextColor
    android:windowBackground
    android:textColor
    android:disabledAlpha
    colorButtonNormal
    colorSwitchThumbNormal
    textColorLink


    View Slide

12. Today I’ll talk about
    1. Apply theme

    - Which parent theme should we implement?

    - How should we inherit and manage themes?

    - How can we change theme and night mode dynamically?

    2. Theme attributes

    - Which attributes affect where?

    - How can we find all the attributes for AppCompat and Material Components?

    - Which should we apply theme or style?


    View Slide

13. Today I’ll talk about
    1. Apply theme

    - Which parent theme should we implement?

    - How should we inherit and manage themes?

    - How can we change theme and night mode dynamically?

    2. Theme attributes

    - Which attributes affect where?

    - How can we find all the attributes for AppCompat and Material Components?

    - Which should we apply theme or style?


    View Slide

14. Today I’ll talk about
    1. Apply theme

    - Which parent theme should we implement?

    - How should we inherit and manage themes?

    - How can we change theme and night mode dynamically?

    2. Theme attributes

    - Which attributes affect where?

    - How can we find all the attributes for AppCompat and Material Components?

    - Which should we apply theme or style?


    View Slide

15. 1. Apply theme


    View Slide

16. ...
    android:theme="@style/AppTheme">



    android:name=".MainActivity"
    android:theme=“@style/AppTheme">
    parent="Theme.AppCompat.DayNight.NoActionBar">
    AndroidManifest.xml
    themes.xml


    View Slide

17. ...
    android:theme="@style/AppTheme">



    android:name=".MainActivity"
    android:theme=“@style/AppTheme">
    parent="Theme.AppCompat.DayNight.NoActionBar">
    AndroidManifest.xml
    themes.xml


    View Slide

18. Inheritance
    parent="Base.Theme.AppCompat.Light"/>
    <br/><item name="windowActionBar">false</item><br/><item name="windowNoTitle">true</item><br/>
    parent (higher priority than dot style)
    dot


    View Slide

19. Inheritance
    parent="Base.Theme.AppCompat.Light"/>
    <br/><item name="windowActionBar">false</item><br/><item name="windowNoTitle">true</item><br/>
    parent (higher priority than dot style)
    dot
    Theme.AppCompat.Light.NoActionBar inherites Theme.AppCompat.Light
    with some attributes which is related to ActionBar.


    View Slide

20. Inheritance
    parent="Base.Theme.AppCompat.Light"/>
    <br/><item name="windowActionBar">false</item><br/><item name="windowNoTitle">true</item><br/>
    parent (higher priority than dot style)
    dot


    View Slide

21. When should we use parent
    inheritance style?


    View Slide

22. When should we use parent inheritance?
    • Inherit the theme which is provided by the library like
    AppCompat, MaterialComponents.

    • Manage the API version differences.


    View Slide

23. parent="Base.Theme.AppCompat.Light"/>


    View Slide

24. parent=“Base.V7.Theme.AppCompat.Light">
    parent="Base.Theme.AppCompat.Light"/>
    res/values/themes_base.xml
    parent="Platform.AppCompat.Light"><br/><item name=“viewInflaterClass”>androidx…</item><br/>…<br/>


    View Slide

25. parent=“Base.V21.Theme.AppCompat.Light”>
    res/values-v21/themes_base.xml
    parent="android:Theme.Material.Light.NoActionBar"><br/><!-- Update link colors pre-v23 --><br/><item name="android:textColorLink">?android:attr/colorAccent</item><br/>…<br/>
    parent="Base.Theme.AppCompat.Light"/>


    View Slide

26. parent=“Base.V28.Theme.AppCompat.Light”>
    res/values-v28/themes_base.xml
    parent="Base.V26.Theme.AppCompat.Light"><br/><!-- We can use the platform styles on API 28+ --><br/><item name="dialogCornerRadius">?android:attr/dialogCornerRadius</item><br/>
    parent="Base.Theme.AppCompat.Light"/>


    View Slide

27. Name rules of theme


    View Slide

28. Theme.AppCompat.Light.DarkActionBar


    View Slide

29. • Theme

    All theme we use is named with `Theme` prefix.

    • ThemeOverlay

    Special themes that overlay the base theme and redefine some of the properties to be
    applied to a specific views.
    Theme.AppCompat.Light.DarkActionBar
    Prefix


    View Slide

30. • AppCompat

    Defined in https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/
    appcompat/res/values/themes.xml

    • MaterialComponents

    Defined in https://github.com/material-components/material-components-android/blob/
    master/lib/java/com/google/android/material/theme/res/values/themes.xml

    • Design

    Same as AppCompat. Just alias defined by MaterialComponents.
    Theme.AppCompat.Light.DarkActionBar
    Theme (Library) name


    View Slide

31. Theme.AppCompat ~.Light ~.DayNight
    Theme.AppCompat.Light.DarkActionBar
    Background brightness


    View Slide

32. ~.AppCompat.Light ~.Light.DarkActionBar ~.NoActionBar
    NoActionBar is used with ToolBar
    Theme.AppCompat.Light.DarkActionBar
    ActionBar(Toolbar) brightness


    View Slide

33. Theme.AppCompat.Light.DarkActionBar
    • AppCompat

    • MaterialComponents
    • (None)

    • Light

    • DayNight
    • (None)

    • DarkActionBar

    • NoActionBar
    We can find theme we want by combining these parts.


    View Slide

34. Theme.MaterialComponents.Light.DarkActionBar.Bridge
    parent=“Theme.MaterialComponents.Light.DarkActionBar.Bridge”>
    // parent=“Theme.AppCompat.Light.DarkActionBar”>
    Bridge themes inherit from AppCompat themes, but also define the mandatory new
    Material Components theme attributes to migrate to MaterialComponents easily.

    https://github.com/material-components/material-components-android/blob/master/docs/getting-
    started.md#bridge-themes-bridge-themes


    View Slide

35. Change theme
    programmatically


    View Slide

36. Activity
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    // Set before setContentView()
    setTheme(R.style.AppTheme)
    …
    }


    View Slide

37. Fragment
    override fun onCreateView(
    inflater: LayoutInflater, container: ViewGroup?,
    savedInstanceState: Bundle?
    ): View? {
    val contextThemeWrapper =
    ContextThemeWrapper(activity, R.style.AppTheme)
    val localInflater =
    inflater.cloneInContext(contextThemeWrapper)
    val view = localInflater.inflate(
    R.layout.fragment_main, container, false
    )
    return view.rootView
    }


    View Slide

38. Switch DayNight mode
    Programmatically


    View Slide

39. DayNight theme
    parent="Theme.MaterialComponents.DayNight.NoActionBar" /><br/><item name=“android:textColor"><br/>@color/text_color<br/></item><br/><item name=“android:colorBackground”><br/>@color/background_color<br/></item><br/>…<br/>


    View Slide

40. @color/blue_grey_900
    @color/blue_grey_50
    @color/blue_grey_900
    @color/blue_grey_50
    res/values/colors.xml
    res/values-night/colors.xml


    View Slide

41. colorBackground
    textColor


    View Slide

42. Change mode programmatically
    val mode = if (isNightMode) {
    AppCompatDelegate.MODE_NIGHT_YES
    } else {
    AppCompatDelegate.MODE_NIGHT_NO
    }
    activity.delegate.setLocalNightMode(mode)
    // Change mode immediately


    View Slide

43. View Slide

44. 2. Theme attributes


    View Slide

45. Read code
    • Android Framework

    https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/themes.xml

    https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/attrs.xml

    • AppCompat

    https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/themes_base.xml

    https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/attrs.xml

    • MaterialComponents

    https://github.com/material-components/material-components-android/blob/master/lib/java/com/google/android/material/theme/
    res/values/themes_base.xml

    https://github.com/material-components/material-components-android/blob/master/lib/java/com/google/android/material/theme/
    res/values/attrs.xml


    View Slide

46. Read code
    • Android Framework

    https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/themes.xml

    https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/attrs.xml

    • AppCompat

    https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/themes_base.xml

    https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/attrs.xml

    • MaterialComponents

    https://github.com/material-components/material-components-android/blob/master/lib/java/com/google/android/material/theme/
    res/values/themes_base.xml

    https://github.com/material-components/material-components-android/blob/master/lib/java/com/google/android/material/theme/
    res/values/attrs.xml



    View Slide

47. Categories


    View Slide

48. • Colors

    colorPrimary

    colorSecondary

    • Drawables

    selectableItemBackground

    editTextBackground

    • Text appearances

    textAppearance

    textAppearanceMedium

    • Shape appearances

    shapeAppearanceSmallComponent

    shapeAppearanceMediumComponent
    • Widget styles

    actionBarStyle

    tabStyle

    • Themes

    actionBarTheme

    dialogTheme

    • Window configurations

    windowNoTitle

    windowActionBar


    View Slide

49. https://material.io/design/material-studies/owl.html


    View Slide

50. AppTheme


    View Slide

51. fontFamily=“@font/rubik_medium”

    lineSpacingExtra

    TextAppearance
    textAppearanceBody1

    textAppearanceBody2

    textAppearanceButton

    textAppearanceHeadline1

    …


    View Slide

52. cornerFamily=“cut”

    cornerSize=“0dp”
    ShapeAppearance
    shapeAppearanceMediumComponent


    View Slide

53. AppTheme.Personalize AppTheme.Browse AppTheme.Learn


    View Slide

54. colorPrimary

    colorPrimaryVariant

    colorSecondary
    colorPrimary

    colorPrimaryVariant

    colorSecondary
    colorPrimary

    colorPrimaryVariant

    colorSecondary
    Color


    View Slide

55. colorBackground

    textColor
    colorBackground

    textColor
    colorBackground

    textColor
    Color


    View Slide

56. bottomNavigationStyle

    Widget.MaterialComponents.BottomNavigationView.Colored
    Widget style


    View Slide

57. Window configuration
    v19 windowTranslucentStatus=“true”
    V21 statusBarColor=“@android:color/transparent”
    V23
    statusBarColor=“@android:color/transparent"

    windowLightStatusBar=“true”


    View Slide

58. parent="Theme.MaterialComponents.DayNight.NoActionBar">

    @color/…
    @color/…


    @style/…
    @style/..


    @style/…




    @style/…



    View Slide

59. • Colors

    colorPrimary

    colorSecondary

    • Drawables

    selectableItemBackground

    editTextBackground

    • Text appearances

    textAppearance

    textAppearanceMedium

    • Shape appearances

    shapeAppearanceSmallComponent

    shapeAppearanceMediumComponent
    • Widget styles

    actionBarStyle

    tabStyle

    • Themes

    actionBarTheme

    dialogTheme

    • Window configurations

    windowNoTitle

    windowActionBar
    ① ②
    ③


    View Slide

60. Attributes reference list
    • I summarized all the attributes per each categories to a
    simple markdown table.

    https://github.com/konifar/android-theme-attrs-to-markdown-table

    • This repository would be help you to find the attribute
    and know each meaning.


    View Slide

61. https://github.com/konifar/android-theme-attrs-to-markdown-table/blob/
    master/outputs/color_attrs.md


    View Slide

62. https://github.com/konifar/android-theme-attrs-to-markdown-table/blob/
    master/outputs/color_attrs.md


    View Slide

63. Colors


    View Slide

64. https://material.io/develop/android/theming/color/
    AppCompat MaterialComponents Example
    colorPrimary colorPrimary Toolbar
    colorPrimaryDark colorPrimaryVariant StatusBar
    colorAccent colorSecondary FAB, ProgressBar
    colorBackground colorBackground Background
    colorBackgroundFloating colorSurface CardView
    Differences between AppCompat and MC


    View Slide

65. New “colorOn~” for MaterialComponents
    • colorOnPrimary

    • colorOnSecondary

    • colorOnBackground

    • colorOnSurface

    • colorOnError


    View Slide

66. colorOnSurface


    View Slide

67. colorOnPrimary colorOnSecondary


    View Slide

68. Text colors
    textColorPrimary
    textColorLink
    textColorHint
    editTextColor


    View Slide

69. Component colors
    colorButtonNormal
    colorControlActivated
    colorSwitchThumbNormal
    colorControlNormal
    colorForeground
    colorControlHighlight (Ripple color)


    View Slide

70. Colors appendix
    • All attributes are here

    https://github.com/konifar/android-theme-attrs-to-markdown-table/blob/master/outputs/color_attrs.md

    • Default values are defined in themes_base.xml

    Android Platform: https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/
    themes.xml

    AppCompat: https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/
    themes_base.xml

    Material Components: https://github.com/material-components/material-components-android/blob/master/lib/java/
    com/google/android/material/theme/res/values/themes_base.xml



    View Slide

71. Widget styles


    View Slide

72. TabStyle


    View Slide

73. TabStyle
    <br/><item name=“tabStyle">@style/App.Widget.Design.TabLayout</item><br/><style name=“App.Widget.Design.TabLayout"<br/>parent="Widget.Design.TabLayout"><br/><item name="elevation">4dp</item><br/><item name="android:background">?attr/colorPrimary</item><br/><item name="tabTextColor">?attr/textColorPrimaryInverse</item><br/>


    View Slide

74. How can we find the widget
    style and attributes?


    View Slide

75. Step1 : Search theme attribute
    • Input widget name which you want to change style.

    • The naming rule is “xxxStyle” like toolbarStyle, buttonStyle,
    checkBoxStyle.


    View Slide

76. Step2 : Search default style
    • Input an expected default style.

    • The naming rule is “@style/Widget.~” like “Widget.AppCompat.Toolbar”


    View Slide

77. Step3 : Search style attributes
    • I usually search on GitHub repository.

    AppCompat: https://github.com/aosp-mirror/platform_frameworks_support/blob/master/appcompat/res/values/styles_base.xml

    MaterialComponents: https://github.com/material-components/material-components-android/find/master


    View Slide

78. Widget styles appendix
    • All attributes are here

    https://github.com/konifar/android-theme-attrs-to-markdown-table/blob/master/outputs/widget_style_attrs.md

    • Default values are defined in themes_base.xml

    Android Platform: https://github.com/aosp-mirror/platform_frameworks_base/blob/master/core/res/res/values/
    styles.xml

    AppCompat: https://github.com/aosp-mirror/platform_frameworks_support/blob/master/v7/appcompat/res/values/
    styles_base.xml

    Material Components: Each styles.xml in https://github.com/material-components/material-components-android/tree/
    master/lib/java/com/google/android/material



    View Slide

79. Shape appearance


    View Slide

80. • shapeAppearanceSmallComponent

    Buttons, Chips



    • shapeAppearanceMediumComponent

    Cards







    • shapeAppearanceLargeComponent

    Bottom Sheets



    View Slide

81. parent="ShapeAppearance.MaterialComponents.SmallComponent"><br/><item name="cornerFamily">cut</item><br/><item name="cornerSize">8dp</item><br/>


    View Slide

82. parent="ShapeAppearance.MaterialComponents.SmallComponent"><br/><item name="cornerFamily">cut</item><br/><item name="cornerSize">8dp</item><br/>
    !OVMM EQ EQ EQ
    DVU
    SPVOEFE


    View Slide

83. • chipStyle

    • materialCardViewStyle

    • buttonStyle

    • floatingActionButtonStyle
    ShapeAppearance in each widget style


    View Slide

84. cut shape for FAB

    @style/Moat.FloatingActionButton
    parent="@style/Widget.MaterialComponents.FloatingActionButton"><br/><item name="shapeAppearanceOverlay">@style/Moat.ShapeAppearance.Fab</item><br/>


    parent="ShapeAppearance.MaterialComponents.SmallComponent"><br/><item name="cornerFamily">cut</item><br/><item name="cornerSize">@null</item><br/>


    View Slide

85. Which should we use
    style or theme?


    View Slide

86. Depends on the design
    • We can customize almost widget by using theme.

    • If the design is common in the app, it should be defined as theme.

    • If the widget font or shape is specific in the app, it should be defined
    as style and apply it in layout.xml.


    View Slide

87. https://material.io/design/material-studies/fortnightly.html
    textAppearance should be defined as theme


    View Slide

88. https://material.io/design/material-studies/fortnightly.html
    It might be better to define this search edit
    text as style, not theme.
    Chip style should be defined as theme.


    View Slide

89. Summary


    View Slide

90. There are many theme attributes,
    but they are categorized to only
    seven types.


    View Slide

91. The most important thing is to
    know how to find the attributes
    you want to set.


    View Slide

92. The colors and widget styles
    which should be defined as
    theme depends on the design


    View Slide

93. Read the material design docs
    and use the material theming
    tools to use theme effectively.


    View Slide

94. Have fun using Android theme!

    Thank you for

    your kind attention.


    View Slide
