Kotlin Coroutines. Flow is coming

As a part of kotlinx.coroutines 1.2 Flow was introduced as a cold asynchronous data stream. How does it work? What we can do with it? Is it that we waiting so long for replacing Rx? The talk has answers to them.

Transcript

1. Kotlin Coroutines

   Flow is coming


   View Slide

2. Kirill Rozov
   krl.rozov@gmail.com
   Lead Android Developer@
   @kirill_rozov


   View Slide

3. android_broadcast
   News for Android Devs


   View Slide

4. 1. Channels

   2. Flows

   3. Custom operator

   4. Concurrent Flow

   5. Flow constraints

   6. Adapter

   7. Reactive Stream

   8. Backpressure

   9. Third paNy integrations
   Agenda


   View Slide

5. Async in Kotlin
   // Single value
   suspend fun foo(p: Params): Value =
   withContext(Dispatchers.Default) { bar(p) }
   // Collection of values
   suspend fun foo(p: Params): List =
   buildList { while (hasMore) add(nextValue) }
   // Stream of values
   fun foo(p: Params): Sequence =
   sequence { while (hasMore) yield(nextValue) }


   View Slide

6. Async in Kotlin
   // Single value
   suspend fun foo(p: Params): Value =
   withContext(Dispatchers.Default) { bar(p) }
   // Collection of values
   suspend fun foo(p: Params): List =
   buildList { while (hasMore) add(nextValue) }
   // Stream of values
   fun foo(p: Params): Sequence =
   sequence { while (hasMore) yield(nextValue) }
   Blocking


   View Slide

7. Channels


   View Slide

8. Channels
   fun CoroutineScope.fooProducer(p: Params)
   : ReceiveChannel {
   return produce { while (hasMore) send(nextValue) }
   }


   View Slide

9. Channels
   fun CoroutineScope.fooProducer(p: Params)
   : ReceiveChannel {
   return produce { while (hasMore) send(nextValue) }
   }
   val values: ReceiveChannel = fooProducer(p)
   if (someCondition) {
   return anotherResult // Oops! Leaked channel
   }
   // ... do further work with values ...


   View Slide

10. • Works with data sources that are intrinsically hot

    Data sources that exist without application’s requests for them

    • incoming network connections

    • event streams

    • Synchronization primitives

    • For transfer data between coroutines

    • Synchronize access to the same data from multiply coroutines
    Channels


    View Slide

11. Flows


    View Slide

12. Flow is a cold asynchronous data stream that
    executed sequentially (in the same coroutine)
    emits values and completes normally or with an
    exception
    kotlin.github.io/kotlinx.coroutines/kotlinx-coroutines-core/kotlinx.coroutines.flow/-flow/


    View Slide

13. GlobalScope.launch {
    flowOf(1, 2, 3)
    .map { it * it }
    .collect { print(it) }
    }
    Flow


    View Slide

14. Flow
    interface Flow {
    suspend fun collect(collector: FlowCollector)
    }


    View Slide

15. Flow
    interface Flow {
    suspend fun collect(collector: FlowCollector)
    }
    interface FlowCollector {
    suspend fun emit(value: T)
    }


    View Slide

16. Builders
    // From fixed set of values
    val flowA = flowOf(1, 2, 3)
    // From function type () -> T
    val flowB = { repeat(3) { it + 1 } }.asFlow()
    // Sequential call to the emit() function
    val flowC = flow {
    emit(1)
    emit(2)
    emit(3)
    }


    View Slide

17. fun Iterator.asFlow(): Flow
    fun Iterable.asFlow(): Flow
    fun emptyFlow(): Flow
    fun Array.asFlow(): Flow
    fun IntRange.asFlow(): Flow
    fun Sequence.asFlow(): Flow
    fun (() -> T).asFlow(): Flow
    fun flow(
    block: suspend FlowCollector.() -> Unit
    ): Flow
    Builders


    View Slide

18. • map / mapNotNull

    • switchMap

    • combineLatest

    • debounce / sample

    • delayEach / delayFlow

    • Zlter / ZlterNot / ZlterIsInstance / ZlterNotNull

    • zip

    • catch

    • onEach / onCompletion

    • \atMapConcat / \atMapMerge

    • \a]enConcat / \a]enMerge
    Intermediate

    Operators
    * Full list of available operators can be found in official documentation kotlin.github.io/kotlinx.coroutines/kotlinx-coroutines-core/kotlinx.coroutines.flow/-flow/


    View Slide

19. • collect

    • single / Zrst

    • toList / toSet / toCollection

    • count

    • fold / reduce

    • launchIn / produceIn / broadcastIn
    Terminal
    Operators


    View Slide

20. Custom Operator


    View Slide

21. Built-in

    Operators
    interface Flow {
    suspend fun collect(collector: FlowCollector)
    }
    // Extension-oriented design approach
    fun Flow.map(
    transform: suspend (value: T) -> R
    ): Flow


    View Slide

22. Custom

    Operator
    fun Flow.sqrts(): Flow {
    return flow { // this: FlowCollector
    collect { number ->
    val value = sqrt(number.toDouble())
    emit(value)
    }
    }
    }


    View Slide

23. Custom

    Operator
    fun Flow.sqrts(): Flow {
    return flow { // this: FlowCollector
    collect { number ->
    val value = sqrt(number.toDouble())
    emit(value)
    }
    }
    }
    GlobalScope.launch {
    flowOf(1, 2, 3)
    .map { sqrt(it.toDouble()) }
    .sqrts()
    .collect()
    }


    View Slide

24. Custom

    Operator
    fun Flow.sqrts(): Flow {
    return flow { // this: FlowCollector
    collect { number ->
    val value = sqrt(number.toDouble())
    emit(value)
    }
    }
    }
    GlobalScope.launch {
    flowOf(1, 2, 3)
    .map { sqrt(it.toDouble()) }
    .sqrts()
    .collect()
    }


    View Slide

25. Concurrent Flow


    View Slide

26. emi]er
    collector


    View Slide

27. emi]er
    collector


    View Slide

28. emi]er
    collector
    Coroutine A
    Coroutine B


    View Slide

29. Concurrent Flow
    fun Flow.buffer(
    capacity: Int = Channel.UNLIMITED
    ): Flow = flow {
    val channel = coroutineScope.produce(capacity) {
    collect { send(it) }
    }
    channel.consumeEach { emit(it) }
    }


    View Slide

30. Concurrent Flow
    fun Flow.buffer(capacity: Int): Flow
    fun Flow.produceIn(
    scope: CoroutineScope
    ): ReceiveChannel
    fun Flow.broadcastIn(
    scope: CoroutineScope,
    start: CoroutineStart = CoroutineStart.LAZY
    ): BroadcastChannel
    fun channelFlow(
    block: suspend ProducerScope.() -> Unit
    ): Flow


    View Slide

31. Flow Constraints


    View Slide

32. • Context preservation

    Flow encapsulates its own execution context and never propagates or leaks it
    downstream
    Flow Constraints


    View Slide

33. Context

    Preservation
    flow {
    withContext(Dispatchers.Default) {
    emit(longComputation())
    }
    }


    View Slide

34. Context

    Preservation
    flow {
    withContext(Dispatchers.Default) {
    emit(longComputation())
    }
    }
    java.lang.IllegalStateException: Flow invariant is violated: flow was collected in
    [Context A info], but emission happened in [Context B info]. Please refer to
    'flow' documentation or use 'flowOn' instead


    View Slide

35. Context

    Preservation
    flow { emit(longComputation()) }
    .flowOn(Dispatchers.Default)


    View Slide

36. Context

    Preservation
    flow {
    GlobalScope.launch(Dispatchers.IO) // is prohibited
    withContext(Dispatchers.Default) // is prohibited
    emit(1) // OK
    coroutineScope {

    emit(2) // OK -- still the same coroutine

    }
    }


    View Slide

37. • Context preservation

    Flow encapsulates its own execution context and never propagates or leaks it
    downstream
    • Exception transparency

    Flow implementations never catch or handle exceptions that occur in
    downstream Flow Constraints


    View Slide

38. flow {
    try {
    emitValue()
    } catch (e: Exception) {
    println("Error handled $e")
    }
    }
    .map { process1() }
    .collect { process2() }
    Exception

    Transparency


    View Slide

39. flow { emitValue() }
    .map { process1() }
    // catches exceptions in emitValue() and process1()
    .catch { e -> println("Error handled $e") }
    // throws exceptions from process2()
    .collect { process2() }
    Exception

    Transparency


    View Slide

40. Old ways adapter


    View Slide

41. interface Stream {
    fun subscribe(callback: Callback)
    fun unsubscribe(callback: Callback)
    }
    interface Callback {
    fun onNext(item: D)
    fun onError(error: Throwable)
    fun onCompleted()
    }
    Old ways adapter


    View Slide

42. val stream = Stream()
    callbackFlow { // this: ProducerScope
    // ProducerScope extends SendChannel
    val callback = object : Callback {
    override fun onNext(item: Value) { offer(item) }
    override fun onError(error: Throwable) { close(error) }
    override fun onCompleted() { close() }
    }
    stream.subscribe(callback)
    awaitClose { stream.unsubscribe(callback) }
    }
    Old ways adapter


    View Slide

43. Reactive Streams


    View Slide

44. RxJava Operator
    fun Observable.filter(
    predicate: (T) -> Boolean
    ): Observable = ObservableFilter(this, predicate)


    View Slide

45. RxJava Operator
    class ObservableFilter(
    private val source: ObservableSource,
    private val predicate: (T) -> Boolean
    ) : Observable(), HasUpstreamObservableSource {
    override fun source(): ObservableSource = source
    override fun subscribeActual(observer: Observer) {
    source.subscribe(FilterObserver(observer, predicate))
    }
    internal class FilterObserver(
    actual: Observer,
    private val filter: (T) -> Boolean
    ) : BasicFuseableObserver(actual) {
    override fun onNext(t: T) {
    if (sourceMode == QueueFuseable.NONE) {
    try {
    if (filter(t)) downstream.onNext(t)
    } catch (e: Throwable) {
    fail(e)
    }
    } else {
    downstream.onNext(null)
    }
    }
    override fun requestFusion(mode: Int) = transitiveBoundaryFusion(mode)
    override fun poll(): T? {
    while (true) {
    val v = qd.poll()
    if (v == null || filter(v)) return v
    }
    }
    }
    }
    fun Observable.filter(
    predicate: (T) -> Boolean
    ): Observable = ObservableFilter(this, predicate)


    View Slide

46. Flow Operator
    fun Flow.filter(
    predicate: suspend (T) -> Boolean
    ): Flow {
    return flow {
    collect {
    if (predicate(it)) emit(it)
    }
    }
    }


    View Slide

47. Migration from
    RxJava
    RxJava 2 Coroutine
    Single Deferred !❄
    Maybe Deferred !❄
    Completable Job !❄
    Observable
    Channel !
    Flow ❄
    Flowable


    View Slide

48. fun Observable.toFlow(): Flow
    fun Single.toFlow(): Flow
    fun Maybe.toFlow(): Flow
    fun Flowable.toFlow(): Flow
    RxJava2 to Flow

    Adapters


    View Slide

49. fun Observable.toFlow(): Flow
    fun Single.toFlow(): Flow
    fun Maybe.toFlow(): Flow
    fun Flowable.toFlow(): Flow
    NO FROM THE BOX :) WRITE YOU OWN
    RxJava2 to Flow

    Adapters


    View Slide

50. Third-paNy library
    integration


    View Slide

51. @Dao
    interface SampleDao {
    }
    // Request data and observe changes with RxJava
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): Observable>
    Room
    // Blocking request data
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): List


    View Slide

52. @Dao
    interface SampleDao {
    }
    // Request data and observe changes with RxJava
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): Observable>
    Room
    // Blocking request data
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): List
    // Request data using Coroutines
    @Query("SELECT * FROM ENTITIES")
    suspend fun queryEntities(): List


    View Slide

53. @Dao
    interface SampleDao {
    }
    // Request data and observe changes with RxJava
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): Observable>
    Room
    // Blocking request data
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): List
    // Request data using Coroutines
    @Query("SELECT * FROM ENTITIES")
    suspend fun queryEntities(): List
    // Request data and observe changes using Coroutines
    @Query("SELECT * FROM ENTITIES")
    fun queryEntities(): Flow>


    View Slide

54. val database = getSampleDatabase()
    GlobalScope.launch {
    database.sampleDao.queryEntities().collect {
    // Handle updates of entities
    }
    }
    Room


    View Slide

55. interface GitHubService {
    }
    RetroZt
    @GET("users/{user}/repos")
    fun listRepos(
    @Path("user") user: String
    ): Call>


    View Slide

56. interface GitHubService {
    }
    RetroZt @GET("users/{user}/repos")
    suspend fun listRepos(
    @Path("user") user: String
    ): List
    @GET("users/{user}/repos")
    fun listRepos(
    @Path("user") user: String
    ): Call>


    View Slide

57. interface GitHubService {
    }
    RetroZt @GET("users/{user}/repos")
    suspend fun listRepos(
    @Path("user") user: String
    ): List
    @GET("users/{user}/repos")
    fun listRepos(
    @Path("user") user: String
    ): Flow>
    @GET("users/{user}/repos")
    fun listRepos(
    @Path("user") user: String
    ): Call>


    View Slide

58. fun Call.asFlow(): Flow = callbackFlow {
    enqueue(object : Callback {
    override fun onFailure(call: Call, error: Throwable) {
    close(error)
    }
    override fun onResponse(call: Call, response: Response) {
    if (response.isSuccessful) {
    offer(response.body()!!)
    close()
    } else {
    close(RetrofitError(response.errorBody()))
    }
    }
    })
    awaitClose {
    if (!isCanceled) {
    cancel()
    }
    }
    }
    class RetrofitError(val errorBody: ResponseBody?) : Throwable()
    RetroZt


    View Slide

59. val service = getGitHubService()
    GlobalScope.launch {
    service.listRepos("user-id")
    .asFlow()
    .collect {
    // handle response
    }
    }
    RetroZt


    View Slide

60. • Flow will be primary way to handle async stream
    of data

    • Channels will be used:

    • for hot streams

    • “under-the-hood” in some Flow operators

    • as synchronization primitive between
    Coroutines
    What will be the
    next?


    View Slide

61. Thank you!
    krl.rozov@gmail.com
    @android_broadcast
    @kirill_rozov


    View Slide
