Secrets of Android Jetpack

In recent years, Android Jetpack has been developing at an incredible pace and keeping track of all the new products is not easy. The report will provide an overview of the latest API and the future of their AndroidX, which are changing the approach to developing Android apps.

Transcript

1. SECRETS OF ANDROID JETPACK
   KIRILL ROZOV / REPLIKA.AI


   View Slide

2. • Activity
   • Fragment
   • Core
   • ViewModel
   • LiveData
   • Navigation
   AGENDA
   2


   View Slide

3. • Develop Android apps for 8+ years
   • Kotlin Lover
   • Mobile Lead at Replika.ai
   • Author of “Android Broadcast” Project
   • Cohost of Android Dev Virtual Meetups
   • Cohost of Mobile People Talks podcast
   WHO AM I?
   KIRILL ROZOV
   @kirill_rozov @krlrozov


   View Slide

4. View Slide

5. ACTIVITY


   View Slide

6. class MainActivity : AppCompatActivity() {

   override fun onCreate(savedInstanceState: Bundle?) {

   super.onCreate(savedInstanceState)

   setContentView(R.layout.activity_main)

   }

   }

   CONTENT VIEW
   6


   View Slide

7. class MainActivity : AppCompatActivity(R.layout.activity_main)
   CONTENT VIEW
   7


   View Slide

8. class MainActivity : AppCompatActivity() {

   var pictureUri: Uri? = null

   fun onPictureTaken(uri: Uri?, isImageSaved: Boolean) {

   "# Process the image

   }

   fun takePicture() {

   val pictureUri: Uri = Uri.fromFile(File.createTempFile("androidx-secrets", System.currentTimeMillis().toString()))

   this.pictureUri = pictureUri

   val intent = Intent(MediaStore.ACTION_IMAGE_CAPTURE).putExtra(MediaStore.EXTRA_OUTPUT, pictureUri)

   startActivityForResult(intent, REQUEST_CODE_TAKE_PHOTO)

   }

   override fun onActivityResult(requestCode: Int, resultCode: Int, data: Intent?) {

   if (requestCode "$ REQUEST_CODE_TAKE_PHOTO) {

   onPictureTaken(pictureUri, resultCode "$ Activity.RESULT_OK)

   } else {

   super.onActivityResult(requestCode, resultCode, data)

   }

   }

   companion object {

   const val REQUEST_CODE_TAKE_PHOTO = 1

   }

   }
   ACTIVITY RESULT
   8


   View Slide

9. class MainActivity : AppCompatActivity() {

   var pictureUri: Uri? = null

   val takePhoto = registerForActivityResult(TakePicture()) { isImageSaved "#

   onPictureTaken(pictureUri, isImageSaved)

   this.pictureUri = null

   }

   fun onPictureTaken(uri: Uri?, isImageSaved: Boolean) {

   "# Process the image

   }

   fun takePicture() {

   val pictureUri =

   Uri.fromFile(File.createTempFile("androidx-secrets", System.currentTimeMillis().toString()))

   this.pictureUri = pictureUri

   takePhoto.launch(pictureUri)

   }

   ACTIVITY RESULT API
   9


   View Slide

10. class TakePicture : ActivityResultContract() {

    override fun createIntent(context: Context, input: Uri): Intent {

    return Intent(MediaStore.ACTION_IMAGE_CAPTURE)

    .putExtra(MediaStore.EXTRA_OUTPUT, input)

    }

    override fun getSynchronousResult(

    context: Context, input: Uri

    ): SynchronousResult? {

    return null

    }

    override fun parseResult(resultCode: Int, intent: Intent?): Boolean {

    return resultCode "$ Activity.RESULT_OK

    }

    }
    ACTIVITY RESULT API
    10


    View Slide

11. • CreateDocument
    • OpenDocument
    • OpenDocumentTree
    • OpenMultipleDocuments
    • GetContent
    • GetMultipleContent
    • PickContact
    • StartActivityForResult
    • StartIntentSenderForResult
    • TakePicture
    • TakePicturePreview
    • TakeVideo
    • RequestPermission
    • RequestMultiplePermissions
    PREDEFINED CONTRACTS
    11


    View Slide

12. class MainActivity : AppCompatActivity() {

    val requestPermissionForTrackUserResult =

    registerForActivityResult(RequestPermission()) { permissionGranted "#

    if (permissionGranted) {

    trackUser()

    }

    }

    @RequiresPermission(Manifest.permission.ACCESS_FINE_LOCATION)

    fun trackUser() {

    "# Start track user

    }

    fun requestPermissionForTrackUser() {

    requestPermissionForTrackUserResult.launch(Manifest.permission.ACCESS_FINE_LOCATION)

    }

    }
    ACTIVITY RESULT API FOR PERMISSIONS
    12


    View Slide

13. FRAGMENT


    View Slide

14. class MainFragment : Fragment() {

    override fun onCreateView(

    inflater: LayoutInflater,

    container: ViewGroup?,

    savedInstanceState: Bundle?

    ): View? {

    return inflater.inflate(R.layout.fragment_main, container, false)

    }

    }
    FRAGMENT’S VIEW
    14


    View Slide

15. class MainFragment : Fragment(R.layout.fragment_main)
    FRAGMENT’S VIEW
    15


    View Slide

16. • Callback via parent Fragment/Activity
    • Target Fragment
    • Shared View Model
    SHARE RESULT
    BETWEEN FRAGMENTS
    16


    View Slide

17. class FromFragment : Fragment() {

    override fun onCreate(savedInstanceState: Bundle?) {

    super.onCreate(savedInstanceState)

    childFragmentManager.setFragmentResultListener(

    EndFragment.REQUEST_KEY, this

    ) { requestKey: String, result: Bundle "#

    val isSuccess = result.getBoolean(EndFragment.KEY_SUCCESS)

    "# Do something with the result"%

    }

    }

    fun startFragment() {

    childFragmentManager.commit { add(android.R.id.content, EndFragment(), FRAGMENT_END) }

    }

    }
    FRAGMENT RESULT API
    17


    View Slide

18. class EndFragment : Fragment() {

    fun updateResult(success: Boolean) {

    val result = bundleOf(KEY_SUCCESS to success)

    parentFragmentManager.setFragmentResult(REQUEST_KEY, result)

    }

    }
    FRAGMENT RESULT API
    18


    View Slide

19. class MainFragment : Fragment() {

    @Inject

    lateinit var deps: Deps

    }
    DI IN FRAGMENT
    19


    View Slide

20. class MainFragment : Fragment() {

    @Inject

    private lateinit var deps: Deps

    }
    DI IN FRAGMENT
    20


    View Slide

21. class MainFragment : Fragment() {

    @Inject

    private var deps: Deps

    }
    DI IN FRAGMENT
    21


    View Slide

22. class MainFragment : Fragment() {

    @Inject

    private val deps: Deps

    }
    DI IN FRAGMENT
    22


    View Slide

23. class MainFragment @Inject constructor(

    private val deps: Deps

    ) : Fragment()
    DI IN FRAGMENT
    23


    View Slide

24. class FragmentFactory {

    open fun instantiate(

    classLoader: ClassLoader,

    className: String

    ): Fragment

    }
    FRAGMENT FACTORY
    24


    View Slide

25. class InjectFragmentFactory(

    providers: Map, Provider
    ) : FragmentFactory() {

    private val providers =

    providers.mapKeys { (fragmentClass, _) "# fragmentClass.name }

    override fun instantiate(

    classLoader: ClassLoader, className: String

    ): Fragment {

    return providers[className]"'get()

    "( super.instantiate(classLoader, className)

    }

    }
    FRAGMENT FACTORY
    25


    View Slide

26. "# Set the fragmentFactory as default for every FragmentActivity in the app

    class SetFragmentFactory(

    private val fragmentFactory: FragmentFactory

    ) : Application.ActivityLifecycleCallbacks {

    override fun onActivityCreated(

    activity: Activity, savedInstanceState: Bundle?

    ) {

    if (activity is FragmentActivity) {

    activity.supportFragmentManager.fragmentFactory =

    this.fragmentFactory

    }

    }

    }
    FRAGMENT FACTORY
    26


    View Slide

27. • Injection in Fragment constructor
    • No more Component.inject(*Fragment)
    • Less re lection/more performance
    • Possibility to obfuscate Fragments
    FRAGMENT FACTORY
    BONUSES
    27


    View Slide

28. fragmentManager.commit {

    add(android.R.id.content, NextFragment(), FRAGMENT_TAG)

    }
    FRAGMENT TRANSCATION
    28


    View Slide

29. fragmentManager.commit {

    add(

    android.R.id.content,

    fragmentClass = NextFragment")class.java,

    args = null,

    tag = FRAGMENT_TAG

    )

    }
    FRAGMENT TRANSCATION
    29


    View Slide

30. fragmentManager.commit {

    add(

    android.R.id.content,

    args = null,

    tag = FRAGMENT_TAG

    )

    }

    FRAGMENT TRANSCATION
    30


    View Slide

31. ANDROIDX CORE


    View Slide

32. val builder = SpannableStringBuilder()

    builder.append("Hello")

    builder.setSpan(

    StyleSpan(Typeface.ITALIC), 0, builder.length, SPAN_INCLUSIVE_EXCLUSIVE

    )

    builder.append(",")

    val start = builder.length

    builder.append("World!")

    builder.setSpan(

    StyleSpan(Typeface.BOLD), start, builder.length, SPAN_INCLUSIVE_EXCLUSIVE

    )
    BUILD SPANNED STRING
    33


    View Slide

33. buildSpannedString {

    italic { append("Hello") }

    append(",")

    bold { append("World!") }

    }
    BUILD SPANNED STRING
    34


    View Slide

34. val activityManager = context.getSystemService(Context.ACTIVITY_SERVICE)

    val activityManager = context.getSystemService()
    SYSTEM SERVICES
    35


    View Slide

35. val activityManager: Any? = context.getSystemService(Context.ACTIVITY_SERVICE)

    val activityManager: ActivityManager? = context.getSystemService()
    SYSTEM SERVICES
    36


    View Slide

36. val attrs = context.obtainStyledAttributes(

    attributes, R.styleable.CustomView, defStyleAttr, 0

    )

    main = attrs.getBoolean(R.styleable.CustomView_main, false)

    attrs.recycle()

    CUSTOM VIEW ATTRIBUTES
    37


    View Slide

37. context.withStyledAttributes(

    set = attributes,

    attrs = R.styleable.CustomView,

    defStyleAttr = defStyleAttr

    ) {

    main = attrs.getBoolean(R.styleable.CustomView_main, false)

    }

    CUSTOM VIEW ATTRIBUTES
    38


    View Slide

38. fun makeArgs(): Bundle {

    val args = Bundle()

    args.putString(KEY1, "value")

    args.putInt(KEY2, 1)

    return args

    }
    BUNDLE
    39


    View Slide

39. fun makeArgs(): Bundle {

    return Bundle().apply {

    putString(KEY1, "value")

    putInt(KEY2, 1)

    }

    }
    BUNDLE
    40


    View Slide

40. fun makeArgs(): Bundle {

    return Bundle(2).apply {

    putString(KEY1, "value")

    putInt(KEY2, 1)

    }

    }
    BUNDLE
    41


    View Slide

41. fun makeArgs(): Bundle {

    return bundleOf(KEY1 to "value", KEY2 to 1)

    }
    BUNDLE
    42


    View Slide

42. fun bundleOf(vararg pairs: Pair) = Bundle(pairs.size).apply {

    for ((key, value) in pairs) {

    when (value) {

    null "* putString(key, null)

    is Boolean "* putBoolean(key, value)

    is Byte "* putByte(key, value)

    is Char "* putChar(key, value)

    is Double "* putDouble(key, value)

    is Float "* putFloat(key, value)

    is Int "* putInt(key, value)

    is Long "* putLong(key, value)

    is Short "* putShort(key, value)

    …

    }

    }

    }
    ⚠ UNDER THE HOOD
    43


    View Slide

43. LIFECYCLE


    View Slide

44. class MainFragment : Fragment() {

    private val viewModel: MainViewModel =

    ViewModelProvider(

    this,

    MainViewModel.Factory()

    ).get(MainViewModel")class.java)

    }
    VIEW MODEL CREATION
    45


    View Slide

45. class MainFragment : Fragment() {

    private val viewModel: MainViewModel by viewModels {
    MainViewModel.Factory()
    }

    }
    VIEW MODEL CREATION
    46


    View Slide

46. class MainFragment @Inject constructor(

    private val viewModelFactory: Provider

    ) : Fragment() {

    private val viewModel: MainViewModel by viewModels {
    viewModelFactory.get()
    }

    }
    VIEW MODEL CREATION
    47


    View Slide

47. VIEWMODEL. SAVING STATE
    48


    View Slide

48. "# androidx.lifecycle:lifecycle-viewmodel-savedstate"+version>

    class MainViewModel(savedStateHandle: SavedStateHandle) : ViewModel() {

    val text: MutableLiveData =

    savedStateHandle.getLiveData(STATE_TEXT)

    }
    VIEW MODEL. SAVING STATE
    49


    View Slide

49. class MainViewModel(private val githubService: GithubService) : ViewModel() {

    val users: LiveData
    while (true) {

    var delayDuration = 5_000L "# Ms

    try {

    emit(githubService.fetchUsers())

    break

    } catch (e: Exception) {

    delay(delayDuration)

    delayDuration *= 2

    }

    }

    }

    }
    LIVEDATA BUILDER + COROUTINE
    50


    View Slide

50. NAVIGATION


    View Slide

51.


    android:name=“HomeViewPagerFragment >


    app:destination=“@id/plant_detail_fragment" ",

    "-fragment>


    android:name="PlantDetailFragment"

    android:label=“@string/plant_detail_title" >


    "-fragment>

    "-navigation>
    NAVIGATION GRAPH. XML
    52


    View Slide

52. navHostFragment.navController.apply {

    graph = createGraph(AppNavGraph.id, AppNavGraph.Dest.home) {

    fragment(AppNavGraph.Dest.home) {

    label = getString(R.string.home_title)

    action(AppNavGraph.Action.toPlantDetail) {

    destinationId = AppNavGraph.Dest.plantDetail

    }

    }

    fragment(AppNavGraph.Dest.plantDetail) {

    label = getString(R.string.plant_detail_title)

    argument(AppNavGraph.Args.plantId) {

    type = NavType.StringType

    }

    }

    }

    }

    NAVIGATION GRAPH. KOTLIN DSL
    53
    object AppNavGraph {

    const val id = 1

    object Dest {

    const val home = 2

    const val plantDetail = 3

    }

    object Action {

    const val toPlantDetail = 4

    }

    object Args {

    const val plantId = "plantId"

    }

    }


    View Slide

53. • No preview
    • All ids by your hands
    • No “safe args” plugins
    NAVIGATION GRAPH.
    KOTLIN DSL
    54


    View Slide

54. • Hilt for Dagger 2 (Alpha)
    • Paging 3.0 (Alpha)
    • Benchmark
    • Startup (Alpha)
    • CameraX (Beta)
    • AsyncLayoutIn later
    • Constraint Layout 2.0 (Beta)
    • MotionLayout (Beta)
    • Vector Drawable
    • SavedState
    • Exif Interface
    • RecyclerView
    • and many more…
    MORE JETPACK LIBRARIES
    55


    View Slide

55. THANKS YOU!
    QUESTIONS TIME
    KIRILL ROZOV / REPLIKA.AI
    @kirill_rozov
    @krlrozov
    youtube.com/c/androidbroadcast


    View Slide
