Andropower of Kotlin DSL

DSL is a good way to write code declaratively. Kotlin simplifies many things for us and gave the possibility to write our own DSL for APIs. In the talk, you can find out how to write Kotlin DSL and how it can be applied to improve Android APIs.

Transcript

1. Andropower of Kotlin DSL


   View Slide

2. Kirill Rozov
   krl.rozov@gmail.com
   Lead Android Developer@


   View Slide

3. android_broadcast
   News for Android Devs


   View Slide

4. Agenda
   • What is DSL?

   • Kotlin DSL

   • How to build own DSL

   • Where to apply Kotlin DSL


   View Slide

5. A domain-specific language (DSL) is a computer language
   specialised to a particular application domain. DSL is opposite for
   general-purpose language (GPL), which is broadly applicable across
   domains
   wikipedia.org/wiki/Domain-specific_language


   View Slide

6. Examples of DSL Languages
   • SQL

   • HTML

   • CSS

   • Regular expressions


   View Slide

7. DSL positives


   View Slide

8. DSL positives
   +Stricter API for specific domain


   View Slide

9. DSL positives
   +Stricter API for specific domain
   +Better solve special tasks


   View Slide

10. DSL negatives


    View Slide

11. DSL negatives
    — Non-trivial to validate the correct interaction of the DSL with the host
    language at compile time

    Harder to debug the DSL program and to provide IDE code completion


    View Slide

12. DSL negatives
    — Non-trivial to validate the correct interaction of the DSL with the host
    language at compile time

    Harder to debug the DSL program and to provide IDE code completion
    — Can be difficult to combine with a host application in a GPL

    Need to either store program written in DSL in a separate file or embed it in a string literal


    View Slide

13. DSL negatives
    — Non-trivial to validate the correct interaction of the DSL with the host
    language at compile time

    Harder to debug the DSL program and to provide IDE code completion
    — Can be difficult to combine with a host application in a GPL

    Need to either store program written in DSL in a separate file or embed it in a string literal
    — The separate syntax requires separate learning


    View Slide

14. As opposed to external DSLs, which have their own independent
    syntax, internal DSLs are part of programs written in a general-
    purpose language, using exactly the same syntax


    View Slide

15. As opposed to external DSLs, which have their own independent
    syntax, internal DSLs are part of programs written in a general-
    purpose language, using exactly the same syntax
    … and Kotlin has it


    View Slide

16.


    This is a title


    Hello
    world!


    DSL Sample .html


    View Slide

17. DSL Sample .java


    View Slide

18. HtmlBuilder htmlBuilder = createHtml();
    htmlBuilder.head()
    .title("This is a title");
    htmlBuilder.body()
    .add(p("Hello”))
    .add(p("world!"));
    String html = htmlBuilder.build();
    DSL Sample .java


    View Slide

19. val html = html {
    head {
    title("This is a title")
    }
    body {
    p("Hello")
    p("world!")
    }
    }
    DSL Sample .kt


    View Slide

20. Libraries with Kotlin DSL
    • Kotlin Anko UI DSL

    github.com/Kotlin/anko

    • Gradle Kotlin DSL

    github.com/gradle/kotlin-dsl

    • kotlinx.html

    github.com/Kotlin/kotlinx.html

    • Spek

    spekframework.org

    • Kakao

    github.com/agoda-com/Kakao


    View Slide

21. xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical" >
    android:id="@+id/name"
    android:layout_width="match_parent"
    android:layout_height="wrap_content" />
    android:id="@+id/say_hello"
    android:layout_width="match_parent"
    android:layout_height="wrap_content" />

    Android Layout XML


    View Slide

22. verticalLayout {
    val name = editText()
    button("Say Hello") {
    onClick { toast("Hello, ${name.text}!") }
    }
    }
    Anko UI


    View Slide

23. apply(plugin = "java-library")
    dependencies {
    "api"("junit:junit:4.12")
    "implementation"("junit:junit:4.12")
    "testImplementation"("junit:junit:4.12")
    }
    configurations {
    "implementation" {
    resolutionStrategy.failOnVersionConflict()
    }
    }
    Gradle Kotlin DSL


    View Slide

24. Kotlin DSL building blocks


    View Slide

25. Kotlin DSL building blocks
    • Extension function

    String.capitalize()

    • Operator overloading

    mutableList += “item”

    • Infix function call

    1 to “one”

    • Lambda outside of parentheses

    reader.use { it.readLine() }

    • Lambda with receiver

    StringBuilder.() -> Unit


    View Slide

26. Lambda with receiver
    fun buildString(body: (StringBuilder) -> Unit): String {
    val builder = StringBuilder()
    body(builder)
    return builder.toString()
    }


    View Slide

27. Lambda with receiver
    fun buildString(body: (StringBuilder) -> Unit): String {
    val builder = StringBuilder()
    body(builder)
    return builder.toString()
    }
    buildString {
    it.append("Hello")
    it.append(' ')
    it.append("world")
    }


    View Slide

28. Lambda with receiver
    fun buildString(body: (StringBuilder) -> Unit): String {
    val builder = StringBuilder()
    body(builder)
    return builder.toString()
    }
    buildString {
    it.append("Hello")
    it.append(' ')
    it.append("world")
    }
    it: StringBuilder ->


    View Slide

29. Lambda with receiver
    fun buildString(body: (StringBuilder) -> Unit): String {
    val builder = StringBuilder()
    body(builder)
    return builder.toString()
    }


    View Slide

30. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    body(builder)
    return builder.toString()
    }


    View Slide

31. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

32. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

33. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

34. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

35. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

36. Lambda with receiver
    fun buildString(body: StringBuilder.() -> Unit): String {
    val builder = StringBuilder()
    builder.body()
    return builder.toString()
    }


    View Slide

37. Lambda with receiver
    buildString {
    append("Hello")
    append(' ')
    append("world")
    }


    View Slide

38. Lambda with receiver
    buildString {
    append("Hello")
    append(' ')
    append("world")
    }
    this: StringBuilder


    View Slide

39. with from std library
    inline fun with(receiver: T, block: T.() -> R): R {
    return receiver.block()
    }
    with(StringBuilder()) {
    append("Hello")
    append(' ')
    append("world")
    }


    View Slide

40. with from std library
    with(StringBuilder()) {
    append("Hello")
    append(' ')
    append("world")
    }


    View Slide

41. with from std library
    with(StringBuilder()) {
    append("Hello")
    append(' ')
    append("world")
    }
    new StringBuilder()
    .append("Hello")
    .append(' ')
    .append("world");


    View Slide

42. StrictModeCompat
    github.com/kirich1409/StrictModeCompat


    View Slide

43. StrictMode.ThreadPolicy threadPolicy =
    new StrictModeCompat.ThreadPolicy.Builder()
    .detectResourceMismatches()
    .detectUnbufferedIo()
    .penaltyLog()
    .build();
    StrictMode.VmPolicy vmPolicy = new StrictModeCompat.VmPolicy.Builder()
    .detectFileUriExposure()
    .detectLeakedRegistrationObjects()
    .detectContentUriWithoutPermission()
    .penaltyLog()
    .penaltyFlashScreen()
    .build();
    StrictModeCompat.setPolicies(threadPolicy, vmPolicy);
    Android StrictMode Sample


    View Slide

44. initStrictMode {
    threadPolicy {
    resourceMismatches = true
    unbufferedIo = true
    penalty {
    log = true
    }
    }
    vmPolicy {
    fileUriExposure = true
    leakedRegistrationObjects = true
    contentUriWithoutPermission = true
    penalty {
    log = true
    flashScreen = true
    }
    }
    }
    Android StrictMode Sample


    View Slide

45. fun initStrictMode(
    config: StrictModeConfig.() -> Unit
    ) {
    …
    }
    Android StrictMode Sample


    View Slide

46. fun initStrictMode(
    config: StrictModeConfig.() -> Unit
    ) {
    …
    }
    Android StrictMode Sample


    View Slide

47. fun initStrictMode(
    config: StrictModeConfig.() -> Unit
    ) {
    …
    }
    Android StrictMode Sample


    View Slide

48. class StrictModeConfig {
    var threadPolicyConfig = ThreadPolicyConfig()
    private set
    var vmPolicyConfig = VmPolicyConfig()
    private set
    fun threadPolicy(config: ThreadPolicyConfig.() -> Unit) {
    threadPolicyConfig.apply(config)
    }
    fun vmPolicy(config: VmPolicyConfig.() -> Unit) {
    vmPolicyConfig.apply(config)
    }
    }
    Android StrictMode Sample


    View Slide

49. class ThreadPolicyConfig {
    var customSlowCalls = false
    var diskReads = false
    var diskWrites = false
    var network = false
    var resourceMismatches = false
    var unbufferedIo = false
    var penaltyConfig = PenaltyConfig()
    private set
    fun penalty(config: PenaltyConfig.() -> Unit) {
    penaltyConfig.apply(config)
    }
    }
    Android StrictMode Sample


    View Slide

50. class PenaltyConfig {
    var death = false
    var deathOnNetwork = false
    var dialog = false
    var dropBox = false
    var flashScreen = false
    var log = false
    }
    Android StrictMode Sample


    View Slide

51. fun initStrictMode(
    config: StrictModeConfig.() -> Unit
    ) {
    StrictModeConfig().apply {
    config()
    val threadPolicy =
    buildThreadPolicy(threadPolicyConfig)
    StrictMode.setThreadPolicy(threadPolicy)
    val vmPolicy = buildVmPolicy(vmPolicyConfig)
    StrictMode.setVmPolicy(vmPolicy)
    }
    }
    Android StrictMode Sample


    View Slide

52. fun buildThreadPolicy(
    config: ThreadPolicyConfig
    ): ThreadPolicy {
    val builder = StrictModeCompat.ThreadPolicy.Builder()
    if (config.customSlowCalls) builder.detectCustomSlowCalls()
    if (config.diskReads) builder.detectDiskReads()
    …
    config.penaltyConfig.let {
    if (it.death) builder.penaltyDeath()
    if (it.deathOnNetwork) builder.penaltyDeathOnNetwork()
    …
    }
    return threadPolicyBuilder.build()
    }
    Android StrictMode Sample


    View Slide

53. initStrictMode {
    threadPolicy {
    resourceMismatches = true
    unbufferedIo = true
    penalty {
    log = true
    }
    }
    }
    Android StrictMode Sample
    this: StrictModeConfig
    this: ThreadPolicyConfig
    this: PenaltyConfig


    View Slide

54. initStrictMode {
    threadPolicy {
    resourceMismatches = true
    unbufferedIo = true
    penalty {
    log = true
    threadPolicy {
    …
    }
    }
    }
    }
    Android StrictMode Sample
    this: StrictModeConfig
    this: ThreadPolicyConfig
    this: PenaltyConfig


    View Slide

55. initStrictMode {
    threadPolicy {
    resourceMismatches = true
    unbufferedIo = true
    penalty {
    log = true
    threadPolicy {
    …
    }
    }
    }
    }
    Android StrictMode Sample
    this: StrictModeConfig
    this: ThreadPolicyConfig
    this: PenaltyConfig


    View Slide

56. @DslMarker
    annotation class StrictModeDsl
    Android StrictMode Sample


    View Slide

57. class StrictModeConfig() {
    var threadPolicyConfig = ThreadPolicyConfig()
    private set
    var vmPolicyConfig = VmPolicyConfig()
    private set
    fun threadPolicy(
    config: ThreadPolicyConfig.() -> Unit
    ) {
    threadPolicyConfig.apply(config)
    }
    fun vmPolicy(config: VmPolicyConfig.() -> Unit) {
    vmPolicyConfig.apply(config)
    }
    }
    Android StrictMode Sample


    View Slide

58. @StrictModeDsl
    class StrictModeConfig() {
    var threadPolicyConfig = ThreadPolicyConfig()
    private set
    var vmPolicyConfig = VmPolicyConfig()
    private set
    fun threadPolicy(
    config: @StrictModeDsl ThreadPolicyConfig.() -> Unit
    ) {
    threadPolicyConfig.apply(config)
    }
    fun vmPolicy(config: @StrictModeDsl VmPolicyConfig.() -> Unit) {
    vmPolicyConfig.apply(config)
    }
    }
    Android StrictMode Sample


    View Slide

59. initStrictMode {
    threadPolicy {
    resourceMismatches = true
    unbufferedIo = true
    penalty {
    log = true
    threadPolicy {
    …
    }
    }
    }
    }
    Android StrictMode Sample


    View Slide

60. Where to apply Kotlin DSL ?
    • As replacement of the Builder pattern

    • As mediator between different DSL and Kotlin code

    SQL, HTML, etc


    View Slide

61. Ideas to do


    View Slide

62. Ideas to do
    • Android System Notification


    View Slide

63. Ideas to do
    • Android System Notification
    • Android Spannable String

    Android-KTX already have basic implementation's


    View Slide

64. Ideas to do
    • Android System Notification
    • Android Spannable String

    Android-KTX already have basic implementation's
    • Alert Dialogs


    View Slide

65. Thank YOU!!!


    View Slide
