Что нового в Fragment 1.4

Видео версия https://youtu.be/UWuuqbNIWpE

Крайний релиз Jetpack Fragment вышел очень интересным на фичи, что заслужил озвучить изменения в отдельном видео, а именно:
🔥 Новый менеджер состояний
🔥 Несколько back stack
🔥 FragmentStrictMode
💪 Новые проверки кода в Android Lint
🚀 Улучшение работы анимаций
🔨 Исправление багов в работе ЖЦ Fragment

Transcript

1. Fragment 1.4
   Кирилл Розов, Android Broadcast, декабрь 2021
   Как похорошели Fragment


   View Slide

2. FragmentContainer.getFragment


   View Slide

3. android:layout_width="match_parent"
   android:layout_height="match_parent"
   android:name="dev.androidbroadcast.fragmentdemo.FirstFragment"
   android:tag="first"
   !"


   View Slide

4. android:layout_width="match_parent"
   android:layout_height="match_parent"
   android:name="dev.androidbroadcast.fragmentdemo.FirstFragment"
   android:tag="first"
   !"


   View Slide

5. val fragment = supportFragmentManager.findFragmentById(R.id.fragment_container)
   val homeFragment: HomeFragment = fragment as HomeFragment


   View Slide

6. val fragmentContainer: FragmentContainerView = …
   val homeFragment: HomeFragment = fragmentContainer.getFragment()


   View Slide

7. Новый менеджер состояний
   теперь единственный


   View Slide

8. Что изменили
   ! Исправили множество багов с навигацией

   ! Управление состоянием Fragment

   ! Заложена поддержка для множественного back stack

   ! Упрощение жизненного цикла Fragment [результатов пока не видно]


   View Slide

9. View Slide

10. View Slide

11. FragmentStrictMode


    View Slide

12. supportFragmentManager.strictModePolicy =
    FragmentStrictMode.Policy.Builder()
    .penaltyDeath()
    .penaltyListener(…)
    .penaltyLog()
    .detectFragmentReuse()
    .detectFragmentTagUsage()
    .detectRetainInstanceUsage()
    .detectTargetFragmentUsage()
    .detectWrongFragmentContainer()
    .detectSetUserVisibleHint()
    .build()


    View Slide

13. supportFragmentManager.strictModePolicy =
    FragmentStrictMode.Policy.Builder()
    .penaltyDeath()
    .penaltyListener(…)
    .penaltyLog()
    .detectFragmentReuse()
    .detectFragmentTagUsage()
    .detectRetainInstanceUsage()
    .detectTargetFragmentUsage()
    .detectWrongFragmentContainer()
    .detectSetUserVisibleHint()
    .build()


    View Slide

14. penaltyDeath
    2021-12-11 17:08:56.170 12010-12010/dev.androidbroadcast.fragmentdemo E/FragmentStrictMode: Policy
    violation with PENALTY_DEATH in dev.androidbroadcast.fragmentdemo.FirstFragment
    androidx.fragment.app.strictmode.SetUserVisibleHintViolation: Attempting to set user visible hint
    to true for fragment FirstFragment{300fd8d} (9fbf6047-2ed5-4952-b7bd-4d513035c141 id=0x7f0800c5)
    at
    androidx.fragment.app.strictmode.FragmentStrictMode.onSetUserVisibleHint(FragmentStrictMode.kt:131)
    at androidx.fragment.app.Fragment.setUserVisibleHint(Fragment.java:1335)
    at dev.androidbroadcast.fragmentdemo.FirstFragment.onViewCreated(FirstFragment.kt:26)
    at androidx.fragment.app.Fragment.performViewCreated(Fragment.java:3019)
    at androidx.fragment.app.FragmentStateManager.createView(FragmentStateManager.java:551)
    at
    androidx.fragment.app.FragmentStateManager.moveToExpectedState(FragmentStateManager.java:261)
    at androidx.fragment.app.FragmentStore.moveToExpectedState(FragmentStore.java:113)
    at androidx.fragment.app.FragmentManager.moveToState(FragmentManager.java:1374)
    at androidx.fragment.app.FragmentManager.dispatchStateChange(FragmentManager.java:2841)
    at androidx.fragment.app.FragmentManager.dispatchViewCreated(FragmentManager.java:2777)
    at androidx.fragment.app.Fragment.performViewCreated(Fragment.java:3020)
    at androidx.fragment.app.FragmentStateManager.createView(FragmentStateManager.java:551)
    at
    androidx.fragment.app.FragmentStateManager.moveToExpectedState(FragmentStateManager.java:261)
    at androidx.fragment.app.FragmentStore.moveToExpectedState(FragmentStore.java:113)
    at androidx.fragment.app.FragmentManager.moveToState(FragmentManager.java:1374)
    at androidx.fragment.app.FragmentManager.dispatchStateChange(FragmentManager.java:2841)
    at androidx.fragment.app.FragmentManager.dispatchActivityCreated(FragmentManager.java:2784)
    at
    androidx.fragment.app.FragmentController.dispatchActivityCreated(FragmentController.java:262)
    at androidx.fragment.app.FragmentActivity.onStart(FragmentActivity.java:478)
    at androidx.appcompat.app.AppCompatActivity.onStart(AppCompatActivity.java:246)


    View Slide

15. penaltyLog
    2021-12-11 17:10:19.516 12163-12163/dev.androidbroadcast.fragmentdemo D/FragmentStrictMode: Policy violation in
    dev.androidbroadcast.fragmentdemo.FirstFragment
    androidx.fragment.app.strictmode.SetUserVisibleHintViolation: Attempting to set user visible hint to true for fragment
    FirstFragment{300fd8d} (e2010f02-eb83-416b-a7ac-05aaa3befd12 id=0x7f0800c5)
    at androidx.fragment.app.strictmode.FragmentStrictMode.onSetUserVisibleHint(FragmentStrictMode.kt:131)
    at androidx.fragment.app.Fragment.setUserVisibleHint(Fragment.java:1335)
    at dev.androidbroadcast.fragmentdemo.FirstFragment.onViewCreated(FirstFragment.kt:26)
    at androidx.fragment.app.Fragment.performViewCreated(Fragment.java:3019)
    at androidx.fragment.app.FragmentStateManager.createView(FragmentStateManager.java:551)
    at androidx.fragment.app.FragmentStateManager.moveToExpectedState(FragmentStateManager.java:261)
    at androidx.fragment.app.FragmentStore.moveToExpectedState(FragmentStore.java:113)
    at androidx.fragment.app.FragmentManager.moveToState(FragmentManager.java:1374)
    at androidx.fragment.app.FragmentManager.dispatchStateChange(FragmentManager.java:2841)
    at androidx.fragment.app.FragmentManager.dispatchViewCreated(FragmentManager.java:2777)
    at androidx.fragment.app.Fragment.performViewCreated(Fragment.java:3020)
    at androidx.fragment.app.FragmentStateManager.createView(FragmentStateManager.java:551)
    at androidx.fragment.app.FragmentStateManager.moveToExpectedState(FragmentStateManager.java:261)
    at androidx.fragment.app.FragmentStore.moveToExpectedState(FragmentStore.java:113)
    at androidx.fragment.app.FragmentManager.moveToState(FragmentManager.java:1374)
    at androidx.fragment.app.FragmentManager.dispatchStateChange(FragmentManager.java:2841)
    at androidx.fragment.app.FragmentManager.dispatchActivityCreated(FragmentManager.java:2784)
    at androidx.fragment.app.FragmentController.dispatchActivityCreated(FragmentController.java:262)
    at androidx.fragment.app.FragmentActivity.onStart(FragmentActivity.java:478)
    at androidx.appcompat.app.AppCompatActivity.onStart(AppCompatActivity.java:246)


    View Slide

16. penaltyListener
    FragmentStrictMode.Policy.Builder()
    .penaltyListener() { vialotation: Violation !"
    }


    View Slide

17. penaltyListener
    FragmentStrictMode.Policy.Builder()
    .penaltyListener() { vialotation: Violation !"
    }
    Firebase.crashlytics.recordException(vialotation)


    View Slide

18. supportFragmentManager.strictModePolicy =
    FragmentStrictMode.Policy.Builder()
    .penaltyDeath()
    .penaltyListener(…)
    .penaltyLog()
    .detectFragmentReuse()
    .detectFragmentTagUsage()
    .detectRetainInstanceUsage()
    .detectTargetFragmentUsage()
    .detectWrongFragmentContainer()
    .detectSetUserVisibleHint()
    .build()


    View Slide

19. detectFragmentReuse
    !" Повторное использование Fragment, который был удален из FragmentManager
    val firstFragment =
    fragmentManager.findFragmentByTag(FRAGMENT_TAG_FIRST) !7 return
    fragmentManager.commit {
    remove(firstFragment)
    }
    fragmentManager.commit {
    !" Добавление Fragment, удалённого ранее
    add(R.id.fragment_container, firstFragment, FRAGMENT_TAG_FIRST)
    }


    View Slide

20. detectFragmentTagUsage
    !" Использование тэга при добавление Fragment в XML
    android:name="dev.androidbroadcast.fragmentdemo.FirstFragment"
    android:tag="first"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    !"


    View Slide

21. detectWrongFragmentContainer
    !" Неправильный layout-контейнер для Fragment
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:name="dev.androidbroadcast.fragmentdemo.FirstFragment"
    android:tag="first"
    !"


    View Slide

22. detectWrongFragmentContainer
    !# Правильный layout-контейнер для Fragment
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:name="dev.androidbroadcast.fragmentdemo.FirstFragment"
    android:tag="first"
    !"


    View Slide

23. detectSetUserVisibleHint
    !" userVisibleHint уже deprecated
    fragment.userVisibleHint = false


    View Slide

24. detectRetainInstanceUsage
    !" retainInstance уже deprecated
    fragment.retainInstance = true
    if (fragment.retainInstance) {
    !!@
    }


    View Slide

25. detectTargetFragmentUsage
    !" setTargetFragment уже deprecated
    firstFragment.setTargetFragment(secondFragment, FRAGMENT_REEQUEST_CODE)


    View Slide

26. Fragment Result API
    class FirstFragment : Fragment() {
    parentFragmentManager.setFragmentResultListener(
    FRAGMENT_REQUEST_KEY,
    viewLifecycleOwner
    ) { requestKey: String, result: Bundle !"
    }
    }


    View Slide

27. Множественный Back Stack


    View Slide

28. Добавление Fragment в Back Stack
    Back Stack


    View Slide

29. Добавление Fragment в Back Stack
    supportFragmentManager.commit {
    replace(
    R.id.fragment_container,
    homeFragment,
    FRAGMENT_TAG_HOME
    )
    addToBackStack(null)
    }
    Back Stack
    HomeFragment


    View Slide

30. SavedState
    Back Stack


    View Slide

31. !" Добавляем начальный Fragment
    supportFragmentManager.commit {
    setReorderingAllowed(true)
    replace(R.id.fragment_container)
    }
    SavedState
    Back Stack
    HomeFragment


    View Slide

32. SavedState
    Back Stack
    HomeFragment


    View Slide

33. supportFragmentManager.commit {
    setReorderingAllowed(true)
    replace(R.id.fragment_container)
    addToBackStack("profile")
    }
    SavedState
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    supportFragmentManager.commit {
    setReorderingAllowed(true)
    replace(R.id.fragment_container)
    addToBackStack("profile")
    }


    View Slide

34. SavedState
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment


    View Slide

35. SavedState
    proZle
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    supportFragmentManager.saveBackStack("profile")


    View Slide

36. NotiZcationsFragment
    SavedState
    proZle
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    supportFragmentManager.saveBackStack("profile")
    supportFragmentManager.commit {
    setReorderingAllowed(true)
    replace(R.id.fragment_container)
    addToBackStack("notifications")
    }


    View Slide

37. SavedState
    proZle
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    NotiZcationsFragment


    View Slide

38. SavedState
    proZle
    supportFragmentManager.saveBackStack("notifications")
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    notiZcations
    NotiZcationsFragment


    View Slide

39. SavedState
    supportFragmentManager.saveBackStack("notifications")
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    notiZcations
    NotiZcationsFragment
    supportFragmentManager.restoreBackStack("profile")


    View Slide

40. SavedState
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment
    notiZcations
    NotiZcationsFragment


    View Slide

41. SavedState
    supportFragmentManager.clearBackStack("notifications")
    Back Stack
    HomeFragment
    ProZleFragment
    EditProZleFragment


    View Slide

42. View Slide

43. Новые Android Lint проверки


    View Slide

44. Новые проверки в Android Lint
    ! UseGetLayoutInflater
    Использование неправильного LayoutInflater в DialogFragment
    ! DialogFragmentCallbacksDetector
    Переопределение callback у Dialog, а не DialogFragment
    ! FragmentAddMenuProvider
    Использование неверного Lifecycle при использовании addMenuProvider
    ! DetachAndAttachFragmentInSameFragmentTransaction
    Выполнение attach и detach для одного и того же Fragment в рамках одной транзакции


    View Slide
