Engines: Team Development on Rails

(Canada on Rails, 2005)

"Rails Engines provide a means to share common functionality across many projects, in a package that's easy to both update *and* override.

"This presentation will explain the concepts behind Engines and demonstrate how they work within a Rails application. I will also discuss how Engines has dramatically enhanced collaboration within our own development team, and how such collaboration can be extended into the Rails community as a whole."

Transcript

1. rails engines
   rails-engines.org
   James Adam


   View Slide

2. “Hello”


   View Slide

3. a bit of background


   View Slide

4. for many clients
   we build applications
   simultaneously


   View Slide

5. common
   functional
   aspects


   View Slide

6. User Control
   Auditing
   Reporting
   Job Scheduling
   Charts & Graphs
   Data Storage
   Help Systems
   Content Management


   View Slide

7. many applications
   many aspects
   lots of code
   ✕
   lots of maintenance


   View Slide

8. i am lazy
   i am a
   conscientious
   developer


   View Slide

9. Reuse is overrated


   View Slide

10. Reuse is essential
    ... it just depends on the context


    View Slide

11. e.g.
    a simple
    help system


    View Slide

12. db/migrate/001_add_help.rb
    class AddHelp < ActiveRecord::Migration
    def self.up
    create_table :help_pages do |t|
    t.column :key, :string
    t.column :title, :string
    t.column :content, :text
    end
    end
    def self.down
    drop_table :help_pages
    end
    end


    View Slide

13. models/help_page.rb
    class HelpPage < ActiveRecord::Base
    end


    View Slide

14. helpers/help_helper.rb
    module HelpHelper
    def help_link(key=nil)
    key ||= params[:controller] + ‘/’ +
    params[:action]
    page = HelpPage.find_by_key(key)
    unless page.nil?
    link_to(‘[help]’, {:controller => ‘help’,
    :action => ‘show’,
    :id => page},
    {:class => ‘help_link’})
    end
    end
    end


    View Slide

15. and in our application:
    MeatSword :: Basket

    Please find your basket contents below.
    <%= help_link %>

    <% @cart.items.each do |item| %>
    <%= render :partial => ‘cart/item’ %>
    <%= link_to(‘[X]’, :action => ‘remove’,
    :id => item) %>
    <%= help_link ‘remove_item’ %>
    <% end %>


    View Slide

16. public/stylesheets/help.css
    a.help_link {
    text-decoration: underline;
    color: #0F0;
    font-size: 0.8em;
    }
    a.help_link:hover {
    text-decoration: none;
    color: #000;
    background-color: #0F0;
    }


    View Slide

17. generators


    View Slide

18. rails generators
    $ script/generate model HelpPage
    create app/models/help_page.rb
    create test/fixtures/help_pages.yml
    create test/unit/help_page_test.rb
    $ script/generate controller Help
    create app/controllers/help_controller.rb
    create app/helpers/help_helper.rb
    create test/functional/... # and so on
    $ script/generate scaffold HelpPage Help
    create app/views/help/show.rhtml
    create app/views/help/edit.rhtml # ... etc
    generators


    View Slide

19. a package of
    code templates
    processed by ERb
    generators


    View Slide

20. script/generate my_help_system
    our help generator
    generators
    Text
    create app/models/help_page.rb
    create app/controllers/help_controller.rb
    create app/helpers/help_helper.rb
    create app/views/help/show.rhtml
    create app/views/help/edit.rhtml
    create app/views/help/list.rhtml
    create app/views/help/_form.rhtml
    create db/migrations/001_add_help.rb
    create lib/help_system.rb
    create lib/tasks/help.rake
    create public/stylesheets/help.css
    create test/unit/help_test.rb
    create test/fixtures/help_pages.yml
    $


    View Slide

21. generators
    complete
    subsystem


    View Slide

22. generators
    share with
    rubygems


    View Slide

23. meanwhile, in our app:
    class HelpPage < ActiveRecord::Base
    # only words containing the
    # letter ‘x’ are important
    def summarize(limit=20)
    content.split.select { |word|
    word.include?(’x’)
    }.flatten[0..limit].join
    end
    end


    View Slide

24. generators
    difficult to
    maintain


    View Slide

25. plugins


    View Slide

26. plugins
    init.rb
    start-up


    View Slide

27. plugins
    install.rb
    post-install


    View Slide

28. plugins
    lib/
    added to $LOAD_PATH


    View Slide

29. plugins
    shareable


    View Slide

30. sharing with
    svn:externals
    plugins


    View Slide

31. $ svn propset svn:externals \
    ‘my_plugin svn://server/my_plugin’ \
    vendor/plugins
    property 'svn:externals' set


    View Slide

32. View Slide

33. $ svn update vendor/plugins
    A vendor/plugins/my_plugin/monkey.rb


    View Slide

34. monkey.rb monkey.rb monkey.rb


    View Slide

35. plugins
    maintainable


    View Slide

36. help plugin
    help.rb help_helper.rb help_controller.rb
    show.rhtml help.css 001_add_help.rb


    View Slide

37. plugins
    only code


    View Slide

38. engines


    View Slide

39. a login system?


    View Slide

40. huge, monolithic,
    apocalyptic
    high-level
    components?


    View Slide

41. easy way to annoy
    DHH?


    View Slide

42. plugins.succ


    View Slide

43. plugins + 1


    View Slide

44. plugins.succ
    (plus a little bit more that we
    found REALLY useful)


    View Slide

45. a mechanism
    for sharing
    MVC ‘slices’
    between your apps


    View Slide

46. class ArnoldController < ApplicationController
    def terminator
    @u = User.find_by_name(’Sarah Conner’)
    @u.destroy
    end
    def total_recall
    @quote = 'Get your ass to Mars!'
    render :text => @quote
    end
    def twins
    render :partial => ‘de_vito’,
    :locals => { :julius => User.find
    end
    def sixth_day
    User.find(:first).clone
    end
    end
    ruby code
    public
    assets


    <% for member in fellowship do %>

    <%= member.name %>
    <%= member.gift_from_galadrial
    <%= member.ringbearer? %>

    <% end %>

    New member?
    <%= form_tag :action => ‘add_dude’, :m
    <%= text_field :new_guy, :species %>
    <%= text_area :new_guy, :biography %
    <%= check_box :new_guy, :pawn_of_sau
    <%= end_form_tag %>

    views, partials
    class JazzMigration < ActiveRecord::Mi
    def self.up
    create_table :instruments do |t|
    t.column :name, :string
    t.column :type_id, :integer
    t.column :family, :string
    t.column :range, :integer, :defa
    t.column :position_id, :integer,
    end
    Instrument.create_default_instrume
    JazzPlayers.connect_to_instruments
    end
    def self.down
    JazzPlayers.disconnect_from_instru
    drop_table :instruments end
    database
    migrations


    View Slide

47. intuitive
    layout


    View Slide

48. control your
    environment
    Engines.start :help,
    :reporting,
    :user_basics,
    :user_interface


    View Slide

49. shared
    public assets


    <%= engine_stylesheet :help %>
    <%= engine_javascript :user_control %>
    MeatSword.com


    MeatSword :: Meat beyond Meat.


    View Slide

50. migrations
    rake db:migrate:engines
    $
    Migrated help
    Migrated meat_sword
    Migrated south


    View Slide

51. ... or just use them like
    plugins


    View Slide

52. developing
    engines


    View Slide

53. ....guess
    where
    the files go


    View Slide

54. init.rb
    init_engine.rb


    View Slide

55. generating an engine
    $ script/generate engine Help
    Author's name: James Adam
    Author's email: james.adam@gmail.com
    We can automatically generate a license for you:
    0) MIT 1) GPL 2) LGPL 3) None
    Please select a license: 0
    create vendor/plugins/help
    create vendor/plugins/help/README
    create vendor/plugins/help/install.rb
    create vendor/plugins/help/init_engine.rb
    create vendor/plugins/help/app
    create vendor/plugins/help/app/models
    create vendor/plugins/help/app/controllers
    create vendor/plugins/help/app/helpers
    create vendor/plugins/help/app/views
    create vendor/plugins/help/db


    View Slide

56. client customisation
    module HelpHelper
    def help_link(key=nil) # overrides method in engine
    key ||= params[:controller] + ‘/’ +
    params[:action]
    page = HelpPage.find_by_key(key)
    if page.nil?
    link_to(’Add help page?’, {:controller => ‘help’,
    :action => ‘create’, :key => key})
    else
    link_to(‘More information...’, # different text
    {:controller => ‘help’,
    :action => ‘show’,
    :id => page},
    {:class => ‘info_link’})
    end
    end
    end
    /app/helpers/help_helper.rb


    View Slide

57. extending & overriding
    class HelpController < ApplicationController
    def create # method NOT in engine
    if request.post?
    page = HelpPage.new(params[:new_page])
    unless page.save
    flash[:message] = ‘Oh noes!’
    end
    end
    end
    end
    /app/controllers/help_controller.rb


    View Slide

58. /app/views/help/show.rhtml
    overriding views
    src=’public/images/logo.jpg />
    NameOfThisParticularClient.com
    Help »
    <%= @page.title %>

    <%= render :partial => ‘index_links’ %>

    <%= @page.content %>



    View Slide

59. WARNING:
    INCOMING
    CUSS-WORD
    WARNING:
    INCOMING
    CUSS-WORD


    View Slide

60. WHAT
    THE HELL
    IS THIS
    BLACK MAGIC
    VOODOO?


    View Slide

61. a set of small
    extensions to Rails
    http://svn.rails-engines.org/plugins/engines/


    View Slide

62. dependencies_extensions.rb
    overriding code


    View Slide

63. action_view_extensions.rb
    action_mailer_extensions.rb
    overriding views


    View Slide

64. action_view_extensions.rb
    public assets


    View Slide

65. migration_extensions.rb
    migrations in plugins


    View Slide

66. testing_extensions.rb
    flexible fixtures


    View Slide

67. ruby_extensions.rb
    cheap configuration


    View Slide

68. engines.rb
    plugin management


    View Slide

69. engines are a
    mechanism for sharing
    maintainable code
    between your apps


    View Slide

70. where from here?


    View Slide

71. bundles


    <%= require_bundle :help %>
    MeatSword.org


    More meat than you can
    shake a stick at.


    View Slide

72. happy coexistence
    with Rails Core


    View Slide

73. feeding back to
    plugin system


    View Slide

74. opinionated
    open source


    View Slide

75. rails engines
    rails-engines.org
    James Adam
    dev.rails-engines.org
    www.rails-engines.org
    api.rails-engines.org
    issues/patches:
    propaganda:
    docs:


    View Slide
