Developer happiness with DB Charmer

Lance Gleason
February 28, 2014

Developer happiness with DB Charmer

Presentation by Lance Gleason from Polyglot Programming Inc at the Atlanta Ruby Meetup and Jozi.rb in Johannesburg South Africa.

http://www.polyglotprogramminginc.com
http://www.polyglotprogramminginc.com/charming-large-databases-with-octopuses/

Lance Gleason

February 28, 2014
Tweet

More Decks by Lance Gleason

Other Decks in Programming

Transcript

  1. Introductions

    View full-size slide

  2. Twitter @lgleasain

    Github lgleasain

    !
    www.lancegleason.com

    www.polyglotprogrammincinc.com

    [email protected]

    !

    View full-size slide

  3. http://www.polyglotprogramminginc.com/purr-
    programming-2-0/

    View full-size slide

  4. www.purrprogramming.com

    View full-size slide

  5. Supporting More
    Users

    View full-size slide

  6. Optimized Queries

    View full-size slide

  7. How do you
    support this
    with
    ActiveRecord?

    View full-size slide

  8. production:
       blah:
           adapter:  mysql
           username:  blah
           host:  blah.local
           database:  blah
    !
       foo:
           adapter:  mysql
           username:  foo
           host:  foo.local
           database:  foo

    View full-size slide

  9. class  Foo  <  ActiveRecord::Model;  end
    !
    Foo.switch_connection_to(:blah)
    Foo.switch_connection_to('foo')
    Foo.switch_connection_to(Bar)
    Foo.switch_connection_to(Baz.connectio
    n)
    Foo.switch_connection_to(nil)

    View full-size slide

  10. class  MultiDbTest  <  ActiveRecord::Migration
         db_magic  :connection  =>  :second_db
    !
         def  self.up
             create_table  :test_table,  :force  =>  true  do  |t|
                 t.string  :test_string
                 t.timestamps
             end
         end
    !
         def  self.down
             drop_table  :test_table
         end
     end

    View full-size slide

  11. class  MultiDbTest  <  ActiveRecord::Migration
       def  self.up
           on_db  :second_db  do
               create_table  :test_table,  :force  =>  true  do
    |t|
                   t.string  :test_string
                   t.timestamps
               end
           end
       end
    !
       def  self.down
           on_db  :second_db  {  drop_table  :test_table  }
       end
    end

    View full-size slide

  12. class  MultiDbTest  <  ActiveRecord::Migration
       db_magic  :connections  =>  [:second_db,  :default]
    !
       def  self.up
           create_table  :test_table,  :force  =>  true  do  |t|
               t.string  :test_string
               t.timestamps
           end
       end
    !
       def  self.down
           drop_table  :test_table
       end
    end

    View full-size slide

  13. Auto Switch All
    Connections To Slaves

    View full-size slide

  14. class  Foo  <  ActiveRecord::Base
       db_magic  :slave  =>  :slave01
    end
    !
    class  Bar  <  ActiveRecord::Base
       db_magic  :slaves  =>
    [  :slave01,  :slave02  ]
    end

    View full-size slide

  15. Default Master Slave
    Class Connections

    View full-size slide

  16. class  Foo  <  ActiveRecord::Base
       db_magic  :connection  =>  :foo
    end
    class  Bar  <  ActiveRecord::Base
       db_magic  :connection  =>  :bar,  :slave
    =>  :bar_slave
    end

    View full-size slide

  17. Per Query Connection
    Management

    View full-size slide

  18. class  Foo  <  ActiveRecord::Model;  end
    !
    Foo.switch_connection_to(:blah)
    Foo.switch_connection_to('foo')
    Foo.switch_connection_to(Bar)
    Foo.switch_connection_to(Baz.connectio
    n)
    Foo.switch_connection_to(nil)

    View full-size slide

  19. User.on_master  do
       user  =  User.find_by_login('foo')
       user.update_attributes!(:activated
    =>  true)
    end

    View full-size slide

  20. Comment.on_master.last(:limit  =>  5)
    User.on_master.find_by_activation_code(code)
    User.on_master.exists?(:login  =>  login,  :password
    =>  password)

    View full-size slide

  21. Comment.on_db(:olap).count
    Post.on_db(:foo).find(:first)

    View full-size slide

  22. Sharding
    • Range

    View full-size slide

  23. Sharding
    • Range
    • hash_map

    View full-size slide

  24. Sharding
    • Range
    • hash_map
    • db_block_map

    View full-size slide

  25. Sharding
    • Range
    • hash_map
    • db_block_map
    • db_block_group_map

    View full-size slide

  26. Custom Sharding Methods

    View full-size slide

  27. Is it thread safe?

    View full-size slide

  28. No transaction rollbacks

    View full-size slide

  29. •MySQL Only

    View full-size slide

  30. •MySQL Only
    •Doesn’t Support Rails 4

    View full-size slide

  31. •Supports Postgres and MySQL

    View full-size slide

  32. •Supports Postgres and MySQL
    •Includes migrations for moving
    data between shards

    View full-size slide

  33. octopus:
       replicated:  true
       production:
           slave1:
               adapter:  mysql
               host:  localhost
               database:  octopus_shard2
           slave2:
               adapter:  mysql
               host:  localhost
               database:  octopus_shard3
           slave3:
               adapter:  mysql
               host:  localhost
               database:  octopus_shard4
           slave4:
               adapter:  mysql
               host:  localhost
               database:  octopus_shard5

    View full-size slide

  34. User.where(:name  =>
    "Thiago").limit(3).using(:slave_one)
    Octopus.using(:slave_two)  do
       User.create(:name  =>  "Mike")
    end

    View full-size slide

  35. class  CreateUsersOnBothShards  <
    ActiveRecord::Migration
       using(:brazil,  :canada)
    !
       def  self.up
           User.create!(:name  =>  "Both")
       end
    !
       def  self.down
           User.delete_all
       end
    end

    View full-size slide

  36. class  ApplicationController  <
    ActionController::Base
       around_filter  :select_shard
    !
       def  select_shard(&block)
           Octopus.using(:brazil,  &block)
       end
    end

    View full-size slide

  37. Alternatives

    View full-size slide

  38. Amazon Cloud
    Search

    View full-size slide

  39. Active Asari

    View full-size slide

  40. Twitter @lgleasain

    Github lgleasain

    !
    www.lancegleason.com

    www.polyglotprogrammincinc.com

    [email protected]

    !

    View full-size slide
