  1. Hirofumi Ichihara LINE Corporation コンテナ ネットワーキング

  2. • 市原 裕史 • LINE Corporation • インフラプラットフォーム室 Verda2 Team

    • Network Software Developer • SDN/NFV • OpenStack Neutron • Docker • Kubernetes ABOUT ME
  3. 仮想計算機からコンテナへ Server VM OS Hyper Visor VM VM Server OS

    Container Container Container Container Server OS Process Process 1991年 Linux リリース 2010年 OpenStack リリース 2014年 Kubernetes リリース OS OS OS
  4. モノリシックからマイクロサービスへ Process 機能A 機能B 機能C 機能D Process 機能A Process 機能C

    Process 機能B Process 機能D
  5. Container Container Container Container Container Container Container Container Container Container

    Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container コンテナの世界 Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container Container
  6. 数⼗億のコンテナを制御 https://cloud.google.com/containers/?hl=ja

  7. Container Orchestration Tool

  8. ベアメタルから仮想ネットワーク ロードバランサ FWルール管理 ルーティング 管理 サーバ スイッチ ルータ ファイアウォール Compute

    node vSwitch vRouter vFW Network node vLB vSwitch VM VM VM VM FWルール管理 ルーティング 管理 VM: 仮想計算機 vSwitch: 仮想スイッチ vRouter: 仮想ルータ vFW:仮想ファイアウォール vLB: 仮想ロードバランサ
  9. 仮想ネットワークから コンテナネットワーク Worker Container Container Container Container Container Container Router

    + FW + LB + Switch FWルール管理、NAT管理、ルーティング管理、バラン シング管理、MACアドレス管理、セッション管理
  10. コンテナネットワーク技術 Router + FW + LB + Switch • Linux

    bridge, veth, routing • iptables, ipvs, ipset, conntrack • OpenVSwitch, VPP, cilium, Tungsten Fabric
  11. 仮想計算機のIPアドレス ライフサイクル 同じIPアドレスで復帰 VM 1 192.168.100.10 Compute node VM 2

    192.168.100.11 Compute node VM 1 192.168.100.10 VM 2 192.168.100.11 Compute node Compute node
  12. コンテナのIPアドレス ライフサイクル Worker Container 1 192.168.100.10 Worker Container 2 192.168.101.11

    Worker Worker Container 2 192.168.101.11 Container 1 192.168.101.12 異なるIPアドレス で復帰
  13. ライフサイクルの変⾰

  14. Container Container Kubernetes Services 機能 仮想IPとサービスプロキシ l user space proxy

    l iptables proxy l ipvs proxy サービスディスカバリ l DNS サービスタイプ l ClusterIP l NodePort l LoadBalancer l ExternalName https://kubernetes.io/docs/concepts/services-networking/service/ Pod Pod Pod Service
  15. リソースを Service 化 nginx nginx nginx LB Web Service

  16. ClusterIP deployment 作成 Worker1 nginx Worker2 nginx apiVersion: apps/v1 kind:

    Deployment metadata: name: my-nginx spec: selector: matchLabels: run: my-nginx replicas: 2 template: metadata: labels: run: my-nginx spec: containers: - name: my-nginx image: nginx ports: - containerPort: 80 $ kubectl create -f my-nginx.yaml https://kubernetes.io/docs/concepts/services-networking/connect-applications-service/#exposing-pods-to-the-cluster
  17. ClusterIP service 作成 apiVersion: v1 kind: Service metadata: name: my-nginx

    labels: run: my-nginx spec: ports: - port: 80 protocol: TCP selector: run: my-nginx Worker1 nginx Worker2 nginx $ kubectl create -f svc.yaml Load Balancer 80 80 https://kubernetes.io/docs/concepts/services-networking/connect-applications-service/#exposing-pods-to-the-cluster プロトコルは TCP/UDP に対応。また ver1.12 から SCTP を alpha サポート
  18. ClusterIP 作成されたリソース Worker1 nginx Worker2 nginx $ kubectl get pods

    -o wide NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE my-nginx-6458ff55f-d2qtj 1/1 Running 0 5h34m 10.244.2.2 worker2 <none> my-nginx-6458ff55f-pdmgn 1/1 Running 0 5h34m 10.244.1.4 worker1 <none> $ kubectl get services NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE my-nginx ClusterIP 10.99.125.234 <none> 80/TCP 5h17m Load Balancer 10.244.1.4:80 10.244.2.2:80 10.99.125.234:80
  19. ClusterIP 作成されたリソース $ curl http://10.99.125.234 <!DOCTYPE html> <html> <head> <title>Welcome

    to nginx!</title> … <p><em>Thank you for using nginx.</em></p> </body> </html> 10.99.125.234:80 my-nginx Service (http)
  20. PodのIPアドレスの変更 Worker1 nginx Worker2 nginx Load Balancer 10.244.1.4:80 10.244.2.2:80 10.99.125.234:80

    Worker3 nginx 10.244.3.2:80
  21. PodのIPアドレスの変更 10.99.125.234:80 my-nginx Service (http)

  22. ClusterIP どのように通信するのか? $ kubectl get services NAME TYPE CLUSTER-IP EXTERNAL-IP

    PORT(S) AGE my-nginx ClusterIP 10.99.125.234 <none> 80/TCP 5h17m $ ip a | grep "inet " inet 127.0.0.1/8 scope host lo inet 10.0.2.15/24 brd 10.0.2.255 scope global enp0s3 inet 192.168.33.10/24 brd 192.168.33.255 scope global enp0s8 inet 172.17.0.1/16 brd 172.17.255.255 scope global docker0 inet 10.244.0.1/24 scope global cni0 inet 10.244.0.0/32 scope global flannel.1 $ ip r default via 10.0.2.2 dev enp0s3 10.0.2.0/24 dev enp0s3 proto kernel scope link src 10.0.2.15 10.244.0.0/24 dev cni0 proto kernel scope link src 10.244.0.1 linkdown 10.244.1.0/24 via 10.244.1.0 dev flannel.1 onlink 10.244.2.0/24 via 10.244.2.0 dev flannel.1 onlink 172.17.0.0/16 dev docker0 proto kernel scope link src 172.17.0.1 linkdown 192.168.33.0/24 dev enp0s8 proto kernel scope link src 192.168.33.10 10.99.125.234 に疎通可能そうなネットワークインターフェースは⾒当たらない
  23. • Ubuntu 16.04.5 • kubeadm v1.12.2 • Kubernetes v1.12.2 •

    kubectl v1.12.2 • flannel v0.10.0 試験環境 Master 192.168.33.10 Worker1 192.168.33.11 Worker2 192.168.33.12 nginx Pod 10.244.1.4:80 nginx Pod 10.244.2.2:80 Kubernetes Controller
  24. ClusterIP with iptables $ sudo iptables-save … -A KUBE-SERVICES !

    -s 10.244.0.0/16 -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp -- dport 80 -j KUBE-MARK-MASQ -A KUBE-SERVICES -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp --dport 80 -j KUBE-SVC- BEPXDJBUHFCSYIC3 … -A KUBE-SVC-BEPXDJBUHFCSYIC3 -m statistic --mode random --probability 0.50000000000 -j KUBE-SEP-ISOVEE5LNFCUUY5T -A KUBE-SVC-BEPXDJBUHFCSYIC3 -j KUBE-SEP-C6VVNBMP4A5PJSYL … -A KUBE-SEP-C6VVNBMP4A5PJSYL -s 10.244.2.2/32 -j KUBE-MARK-MASQ -A KUBE-SEP-C6VVNBMP4A5PJSYL -p tcp -m tcp -j DNAT --to-destination 10.244.2.2:80 … -A KUBE-SEP-ISOVEE5LNFCUUY5T -s 10.244.1.4/32 -j KUBE-MARK-MASQ -A KUBE-SEP-ISOVEE5LNFCUUY5T -p tcp -m tcp -j DNAT --to-destination 10.244.1.4:80 worker1, worker2 ともに全く同じルールが追加されている
  25. ClusterIP with iptables $ sudo iptables-save … -A KUBE-SERVICES !

    -s 10.244.0.0/16 -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp -- dport 80 -j KUBE-MARK-MASQ -A KUBE-SERVICES -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp --dport 80 -j KUBE-SVC- BEPXDJBUHFCSYIC3 … -A KUBE-SVC-BEPXDJBUHFCSYIC3 -m statistic --mode random --probability 0.50000000000 -j KUBE-SEP-ISOVEE5LNFCUUY5T -A KUBE-SVC-BEPXDJBUHFCSYIC3 -j KUBE-SEP-C6VVNBMP4A5PJSYL … -A KUBE-SEP-C6VVNBMP4A5PJSYL -s 10.244.2.2/32 -j KUBE-MARK-MASQ -A KUBE-SEP-C6VVNBMP4A5PJSYL -p tcp -m tcp -j DNAT --to-destination 10.244.2.2:80 … -A KUBE-SEP-ISOVEE5LNFCUUY5T -s 10.244.1.4/32 -j KUBE-MARK-MASQ -A KUBE-SEP-ISOVEE5LNFCUUY5T -p tcp -m tcp -j DNAT --to-destination 10.244.1.4:80 10.99.125.234:80 (my-nginx service)への通信は KUBE-SVC-BEPXDJBUHFCSYIC3へジャンプ
  26. ClusterIP with iptables $ sudo iptables-save … -A KUBE-SERVICES !

    -s 10.244.0.0/16 -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp -- dport 80 -j KUBE-MARK-MASQ -A KUBE-SERVICES -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp --dport 80 -j KUBE-SVC- BEPXDJBUHFCSYIC3 … -A KUBE-SVC-BEPXDJBUHFCSYIC3 -m statistic --mode random --probability 0.50000000000 -j KUBE-SEP-ISOVEE5LNFCUUY5T -A KUBE-SVC-BEPXDJBUHFCSYIC3 -j KUBE-SEP-C6VVNBMP4A5PJSYL … -A KUBE-SEP-C6VVNBMP4A5PJSYL -s 10.244.2.2/32 -j KUBE-MARK-MASQ -A KUBE-SEP-C6VVNBMP4A5PJSYL -p tcp -m tcp -j DNAT --to-destination 10.244.2.2:80 … -A KUBE-SEP-ISOVEE5LNFCUUY5T -s 10.244.1.4/32 -j KUBE-MARK-MASQ -A KUBE-SEP-ISOVEE5LNFCUUY5T -p tcp -m tcp -j DNAT --to-destination 10.244.1.4:80 確率 0.5 で KUBE-SEP-ISOVEE5LNFCUUY5T もしくは KUBE-SEP-C6VVNBMP4A5PJSYLへジャンプする
  27. ClusterIP with iptables $ sudo iptables-save … -A KUBE-SERVICES !

    -s 10.244.0.0/16 -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp -- dport 80 -j KUBE-MARK-MASQ -A KUBE-SERVICES -d 10.99.125.234/32 -p tcp -m comment --comment "default/my-nginx: cluster IP" -m tcp --dport 80 -j KUBE-SVC- BEPXDJBUHFCSYIC3 … -A KUBE-SVC-BEPXDJBUHFCSYIC3 -m statistic --mode random --probability 0.50000000000 -j KUBE-SEP-ISOVEE5LNFCUUY5T -A KUBE-SVC-BEPXDJBUHFCSYIC3 -j KUBE-SEP-C6VVNBMP4A5PJSYL … -A KUBE-SEP-C6VVNBMP4A5PJSYL -s 10.244.2.2/32 -j KUBE-MARK-MASQ -A KUBE-SEP-C6VVNBMP4A5PJSYL -p tcp -m tcp -j DNAT --to-destination 10.244.2.2:80 … -A KUBE-SEP-ISOVEE5LNFCUUY5T -s 10.244.1.4/32 -j KUBE-MARK-MASQ -A KUBE-SEP-ISOVEE5LNFCUUY5T -p tcp -m tcp -j DNAT --to-destination 10.244.1.4:80 10.99.125.234:80 への通信が各 nginx Podの アドレス 10.244.2.2, 10.244.1.4 へ DNAT される
  28. ClusterIP with ipvs $ sudo ipvsadm -Ln IP Virtual Server

    version 1.2.1 (size=4096) Prot LocalAddress:Port Scheduler Flags -> RemoteAddress:Port Forward Weight ActiveConn InActConn TCP 10.99.125.234:80 rr -> 10.244.1.4:80 Masq 1 0 0 -> 10.244.2.2:80 Masq 1 0 0 worker1, worker2 ともに全く同じルールが追加されている
  29. Worker iptablesによってパケットの書き換え Worker Pod Worker nginx Pod 10.244.1.4:80 nginx Pod

    10.244.2.2:80 10.99.125.234 iptables 10.244.1.4 10.244.1.4
  30. 更に複雑な例 Network Policy

  31. Pod へのクラスタ内外の通信のアクセス許可をコントロールする Network Policy Worker Pod Worker Pod Pod Pod

    Pod Pod https://kubernetes.io/docs/tasks/administer-cluster/declare-network-policy/ https://kubernetes.io/docs/concepts/services-networking/network-policies/
  32. label: app=foo 試験環境 Worker1 10.150.0.2 Worker2 10.150.0.3 • kubernetes 1.11.2-gke.18

    • kubectl v1.10.7 Client A 10.48.1.16 label: app=bar Client B 10.48.1.17 label: app=hello hello-app
  33. Network Policy 着信制限 https://cloud.google.com/kubernetes-engine/docs/tutorials/network-policy $ kubectl run hello-web --labels app=hello

    --image=gcr.io/google-samples/hello-app:1.0 --port 8080 --expose kind: NetworkPolicy apiVersion: networking.k8s.io/v1 metadata: name: hello-allow-from-foo spec: policyTypes: - Ingress podSelector: matchLabels: app: hello ingress: - from: - podSelector: matchLabels: app: foo Worker1 label: app=hello hello-app 8080 Firewall label: app=foo
  34. Network Policy 着信制限 結果 https://cloud.google.com/kubernetes-engine/docs/tutorials/network-policy $ kubectl run -l app=foo

    --image=alpine --restart=Never --rm -i test-1 -- wget -qO- --timeout=2 http://hello- web:8080 Hello, world! Version: 1.0.0 Hostname: hello-web-76d4fc9f5b-c98kz $ kubectl run -l app=bar --image=alpine --restart=Never --rm -i test-1 -- wget -qO- --timeout=2 http://hello- web:8080 If you don't see a command prompt, try pressing enter. wget: download timed out pod default/test-1 terminated (Error) label: app=hello Worker1 hello-app 8080 Firewall label: app=foo label: app=bar Client A Client B
  35. Network Policy 着信制限 iptables -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:K7cgKlec-rOcRZmV"

    -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:r0vz6Rgdk8ddL4bG" -m conntrack --ctstate INVALID -j DROP -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:ziYb2WzOoIMVstsP" -j MARK --set-xmark 0x0/0x1000000 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:8YswtCBJpM8NBzfl" -m comment --comment "Start of policies" -j MARK --set- xmark 0x0/0x2000000 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:zmd0DgaOCBkFFlYd" -m mark --mark 0x0/0x2000000 -j cali-pi- _6OJfcXg5T4SeuT6eE80 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:8dNeQcZoZeI9oNzW" -m comment --comment "Return if policy accepted" -m mark --mark 0x1000000/0x1000000 -j RETURN -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:WAdLtw9Uyo9c3Vfi" -m comment --comment "Drop if no policies passed packet" -m mark --mark 0x0/0x2000000 -j DROP -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:nvKHosQ-U2PISrW5" -j cali-pri-k8s_ns.default -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:ETIe11gXYxo1RL5F" -m comment --comment "Return if profile accepted" -m mark --mark 0x1000000/0x1000000 -j RETURN -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:tp5L1HaKwMICs94e" -m comment --comment "Drop if no profiles matched" -j DROP Network Policy 適⽤後に追加されたルール
  36. Network Policy 着信制限 iptables -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:K7cgKlec-rOcRZmV"

    -m conntrack --ctstate RELATED,ESTABLISHED -j ACCEPT -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:r0vz6Rgdk8ddL4bG" -m conntrack --ctstate INVALID -j DROP -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:ziYb2WzOoIMVstsP" -j MARK --set-xmark 0x0/0x1000000 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:8YswtCBJpM8NBzfl" -m comment --comment "Start of policies" -j MARK --set- xmark 0x0/0x2000000 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:zmd0DgaOCBkFFlYd" -m mark --mark 0x0/0x2000000 -j cali-pi- _6OJfcXg5T4SeuT6eE80 -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:8dNeQcZoZeI9oNzW" -m comment --comment "Return if policy accepted" -m mark --mark 0x1000000/0x1000000 -j RETURN -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:WAdLtw9Uyo9c3Vfi" -m comment --comment "Drop if no policies passed packet" -m mark --mark 0x0/0x2000000 -j DROP -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:nvKHosQ-U2PISrW5" -j cali-pri-k8s_ns.default -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:ETIe11gXYxo1RL5F" -m comment --comment "Return if profile accepted" -m mark --mark 0x1000000/0x1000000 -j RETURN -A cali-tw-cali7e6f9a42eba -m comment --comment "cali:tp5L1HaKwMICs94e" -m comment --comment "Drop if no profiles matched" -j DROP Network Policy 適⽤後に追加されたルール ジャンプ先の cali-pi-_6OJfcXg5T4SeuT6eE80 と cali-pri-k8s_ns.default のどちらかで条件を満たせば通信許可
  37. Network Policy 着信制限 iptables -A cali-pi-_6OJfcXg5T4SeuT6eE80 -m comment --comment "cali:9Zdqkrk8NUVBY_ck"

    -m set --match-set cali4- s:0Mv1nWHW09z0NgcXya-DCdb src -j MARK --set-xmark 0x1000000/0x1000000 -A cali-pi-_6OJfcXg5T4SeuT6eE80 -m comment --comment "cali:dR3oD81dXG8jV32f" -m mark --mark 0x1000000/0x1000000 -j RETURN $ sudo toolbox ipset list cali4-s:0Mv1nWHW09z0NgcXya-DCdb Spawning container root-gcr.io_google-containers_toolbox-20180309-00 on /var/lib/toolbox/root-gcr.io_google-containers_toolbox- 20180309-00. Press ^] three times within 1s to kill container. Name: cali4-s:0Mv1nWHW09z0NgcXya-DCdb Type: hash:ip Revision: 4 Header: family inet hashsize 1024 maxelem 1048576 Size in memory: 136 References: 3 Number of entries: 1 Members: 10.48.1.16 ipset エントリ cali4-s:0Mv1nWHW09z0NgcXya-DCdb に含まれる IP アドレスからの通信は許可のためのマーク app=foo ラベルを持つ Pod の IP アドレスが登録されている
  38. iptablesによってパケットのドロップ Worker Worker iptables ClientAから label: app=foo Client A 10.48.1.16

    label: app=bar Client B 10.48.1.17 label: app=hello hello-app ClientAから ClientBから ClientAから ClientBから
  39. Kubernetesの基本的な機能でさえ 複雑なLinuxネットワーキングの設定を 読み解く知識と経験が必要 Worker Pod Pod Pod Worker Pod Pod

    Pod すごくごちゃごちゃ した設定 すごくごちゃごちゃ した設定
  40. THANK YOU
