Building a Brewery

Building a Brewery

At the October 2022 online meeting, Mick Harrison gave us an overview of how he's put together and installed his new home brewery.

London Amateur Brewers

October 16, 2022
Tweet

More Decks by London Amateur Brewers

Other Decks in Education

Transcript

  1. Mick Harrison
    1
    Mix Brewery - V3

    View Slide

  2. Background
     Homebrewing for over 40 years!
     Owned a Brew-It-Yourself
    outlet in mid ‘90s
     Garage brewery
    in old house
     Licenced brewery
    with HMRC
    2

    View Slide

  3. I Have a Plan!
     House move makes ideal rebuild project
    3

    View Slide

  4. I Have a Plan!
    4

    View Slide

  5. The Build
    5
     Original plan was to start the refit in January but
    building delays pushed everything back 6 months
     Annex build allows for two must haves
    ◦ Dedicated electric supply for garage/brewery (10mm2)
    ◦ Proper brewery floor drainage and epoxy floor coating
    Date Action
    March New walls
    April Concrete floor/drainage
    May New stud wall between garage/brewery
    June Hygienic wall cladding & epoxy floor coating
    July/August Reinstall of brew kit incl. electric, plumbing
    September Test Brew ? October – done!

    View Slide

  6. The Build
    6
    Annex foundations
    New wall between
    annex and brewery

    View Slide

  7. The Build
    7
    Drainage and raised
    floor, part 1
    Stud wall partition
    Hygienic Cladding
    Epoxy primer

    View Slide

  8. The Build
    8
    Epoxy top coat

    View Slide

  9. The Build
    9
    Fermentation cabinet and controller
    Plumbing in progress

    View Slide

  10. The Build
    10
    References:
    Flooring - https://www.resincoat.co.uk/en/floor-paint/545-resincoat-
    brewery-floor-coating.html
    Wall Cladding - https://www.hygienicplastic.co.uk/product/pvc-8-x-4-x-
    2mm-2440-x-1220-x-2mm-white-wall-cladding/

    View Slide

  11. Equipment
     Mains town water in via GAC filter to remove
    chlorine/chloramine
     HLT - 100lt with 3kw heater and small recirc pump to
    keep even temperature
    Double layer camping mat insulation
     Mash Tun - 100lt, perforated false bottom
    Double layer camping mat insulation
     Boiler – Twin walled & insulated. 9kw heater but only
    use two of the elements
     Plate heat exchange to cool hot wort
     All control panels are DIY
     Just added extractor and electric bug zapper!
    11

    View Slide

  12. Does it Work?
    12
    Yes it does!

    View Slide

  13. Question time?
    13

    View Slide
