  1. 2 December 2005
    Information Visualisation
    Case Studies and Course Review
    Prof. Beat Signer
    Department of Computer Science
    Vrije Universiteit Brussel
    beatsigner.com

    View Slide

  2. Beat Signer - Department of Computer Science - [email protected] 2
    May 25, 2023
    Analyse Case Studies
    ▪ Analysis of existing systems provides foundation for
    considering all the possibilities when designing new
    systems
    ▪ use analysis framework introduced earlier
    - what, why and how?
    - four levels of validation
    ▪ data/task abstraction
    - types of data abstraction
    - derived data
    - …
    ▪ visual encoding/interaction idioms
    - encoding design choices
    - faceting between multiple views
    - …

    View Slide

  3. Beat Signer - Department of Computer Science - [email protected] 3
    May 25, 2023
    Scagnostics SPLOM
    ▪ Scalable idiom for the exploration of scatterplot
    matrices (SPLOMs)
    ▪ scagnostics = scatterplot computer-guided diagnostics

    View Slide

  4. Beat Signer - Department of Computer Science - [email protected] 4
    May 25, 2023
    Scagnostics SPLOM …
    ▪ Use nine measurements
    that categorise the point
    distribution of scatterplots
    ▪ monotonic, stringy, skinny,
    convex, striated, sparse,
    clumpy, skewed and outlying
    ▪ Show measurements in a
    new scagnostics SPLOM
    ▪ scatterplot of scatterplots
    ▪ each point in the scagnostics
    SPLOM represents an entire
    scatterplot of the original
    SPLOM

    View Slide

  5. Beat Signer - Department of Computer Science - [email protected] 5
    May 25, 2023
    Scagnostics SPLOM …

    View Slide

  6. Beat Signer - Department of Computer Science - [email protected] 6
    May 25, 2023
    Scagnostics SPLOM …
    ▪ Linked highlighting between views
    ▪ Selection of point triggers popup view with full scatterplot
    Scagnostics SPLOM
    What(Data) Table.
    What(Derived) Nine quantitative attributes per scatterplot (pairwise combination of
    original attributes).
    Why(Tasks) Identify, compare, and summarise; distributions and correlation.
    How(Encode) Scatterplot, scatterplot matrix.
    How (Manipulate) Select.
    How (Facet) Juxtaposed small-multiple views coordinated with linked
    highlighting, popup detail view.
    Scale Original attributes: dozens.

    View Slide

  7. Beat Signer - Department of Computer Science - [email protected] 7
    May 25, 2023
    Hierarchical Clustering Explorer (HCE)
    ▪ Systematic exploration of multidimensional table
    ▪ Originally designed for genomics domain
    ▪ multidimensional table with two key attributes (genes and
    experimental conditions) and a quantitative value attribute
    (activity of gene under experimental condition)
    ▪ derived data is a cluster hierarchy of items based on a similarity
    measure between items
    ▪ scalability target: 100-20'000 gene attributes and 2-80
    experimental condition attributes
    ▪ Scalability through combination of visual encoding and
    interaction idioms

    View Slide

  8. Beat Signer - Department of Computer Science - [email protected] 8
    May 25, 2023
    Hierarchical Clustering Explorer (HCE) …

    View Slide

  9. Beat Signer - Department of Computer Science - [email protected] 9
    May 25, 2023
    Hierarchical Clustering Explorer (HCE) …
    Hierarchical Clustering Explorer (HCE)
    What(Derived) Hierarchical clustering of table rows and columns (for cluster
    heatmap); quantitative derived attributes for each attribute and
    pairwise attribute combination; quantitative derived attribute for
    each ranking criterion and original attribute combination.
    Why(Tasks) Find correlation between attributes; find clusters, gaps, outliers,
    trends within items.
    How(Encode) Cluster heatmap, scatterplots, histograms.
    How(Reduce) Dynamic filtering; dynamic aggregation.
    How (Manipulate) Navigate with pan/scroll.
    How (Facet) Multiform with linked highlighting and shared spatial position;
    overview-detail with selection in overview populating detail view
    Scale Genes (key attribute): 20'000. Conditions (key attribute): 80. Gene
    activity in condition (quantitative value attribute): 20'000 × 80 =
    1'600'000.

    View Slide

  10. Beat Signer - Department of Computer Science - [email protected] 10
    May 25, 2023
    PivotGraph
    ▪ PivotGraph idiom encodes a network derived from the
    original network by aggregating groups of nodes and
    links into a roll-up
    ▪ grouping based on categorical attribute values on the nodes
    (up to two attributes)

    View Slide

  11. Beat Signer - Department of Computer Science - [email protected] 11
    May 25, 2023
    PivotGraph …

    View Slide

  12. Beat Signer - Department of Computer Science - [email protected] 12
    May 25, 2023
    PivotGraph …
    ▪ PivotGraph idiom is highly scalable
    ▪ summarises arbitrarily large number of nodes and links of the
    original network
    ▪ Visual complexity of the derived network depends on the
    number of attribute levels for the two roll-up attributes
    ▪ PivotGraph complements standard encoding idioms for
    networks (e.g. node-link and matrix views)
    ▪ might be used as a linked multiform view
    ▪ Well suited for comparison across attributes at the
    aggregate level
    ▪ but not good to understand topological network features

    View Slide

  13. Beat Signer - Department of Computer Science - [email protected] 13
    May 25, 2023
    PivotGraph …
    PivotGraph
    What(Data) Network.
    What(Derived) Derived network of aggregate nodes and links by roll-up into two
    chosen attributes.
    Why(Task) Cross-attribute comparison of node groups.
    How(Encode) Nodes linked with connection marks, size.
    How (Manipulate) Change: animated transitions.
    How (Reduce) Aggregation, filtering.
    Scale Nodes/links in original network: unlimited. Rollup attributes: 2.
    Levels per roll-up attribute: several, up to one dozen.

    View Slide

  14. Beat Signer - Department of Computer Science - [email protected] 14
    May 25, 2023
    InterRing
    ▪ Visual encoding and interaction idioms for tree exploration
    ▪ space-filling radial layout for encoding the hierarchy
    ▪ multifocus focus+context distortion approach for interaction
    ▪ structure-based colouring (redundant)
    - useful if shared colour coding used to coordinate with other views
    original hierarchy selected blue region enlarged selected tan region enlarged

    View Slide

  15. Beat Signer - Department of Computer Science - [email protected] 15
    May 25, 2023
    InterRing …
    ▪ Works well in combination with other views
    ▪ hierarchy view supports selection, navigation and roll-up/drill-
    down operations
    ▪ supports direct editing of the hierarchy
    InterRing
    What(Data) Tree.
    Why(Task) Selection, rollup/drilldown, hierarchy editing.
    How(Encode) Radial, space-filling layout. Colour by tree structure.
    How(Facet) Linked colouring and highlighting.
    How (Reduce) Embed: distort; multiple foci.
    Scale Nodes: hundreds if labelled, thousands if dense.
    Levels in tree: dozens.

    View Slide

  16. Beat Signer - Department of Computer Science - [email protected] 16
    May 25, 2023
    Course Summary
    1. Introduction
    ▪ classical information visualisations
    - London cholera map, Rose diagram, March on Moscow, …
    ▪ what-why-how question
    ▪ vis design
    - search space metaphor
    2. Human Perception and Colour Theory
    ▪ model of perceptual processing
    ▪ visible light and anatomy of the human eye
    ▪ brightness and contrast
    ▪ various guidelines
    ▪ colour spaces
    ▪ illusions

    View Slide

  17. Beat Signer - Department of Computer Science - [email protected] 17
    May 25, 2023
    Course Summary …
    3. Data Representation
    ▪ data types
    - items, attributes, links, positions, grids
    ▪ attribute types
    - categorical vs. ordinal and quantitative data
    - key vs. value semantics, temporal semantics
    ▪ dataset types
    - tables, networks and trees, fields, geometry, clusters, sets, lists
    ▪ task abstraction (why)
    - analyse: consume and produce
    - search: lookup, locate, browse and explore
    - query: identify, compare and summarise

    View Slide

  18. Beat Signer - Department of Computer Science - [email protected] 18
    May 25, 2023
    Course Summary …
    4. Validation
    ▪ validating four levels of design
    - domain validation, abstraction validation (what and why), idiom
    validation (how) and algorithm validation
    - threats to validity
    - downstream validation
    ▪ use cases

    View Slide

  19. Beat Signer - Department of Computer Science - [email protected] 19
    May 25, 2023
    Course Summary …
    5. Data Presentation
    ▪ marks
    - item marks (points, lines, areas) and link marks (containment, connection)
    ▪ channels
    - position, colour, shape, tilt, size, area, volume
    - identity vs. magnitude channels
    ▪ expressiveness principle
    ▪ channel effectiveness (Steven's psychophysical power law)
    - discriminability, separability, popout, grouping
    ▪ relative vs. absolute judgements (Weber's law)
    ▪ colour encoding (hue, saturation and luminance)
    ▪ colourmaps
    - categorical or ordered (sequential or diverging)

    View Slide

  20. Beat Signer - Department of Computer Science - [email protected] 20
    May 25, 2023
    Course Summary …
    6. Data Processing and Visualisation Toolkits
    ▪ R, D3.js and Python
    ▪ various other solutions and toolkits
    7. Design Guidelines and Principles
    ▪ no unjustified 3D (and 2D)
    ▪ eyes beat memory
    ▪ resolution over immersion
    ▪ overview first, zoom and filter, details on demand
    ▪ responsiveness is required
    ▪ get it right in black and white
    ▪ function first, form next

    View Slide

  21. Beat Signer - Department of Computer Science - [email protected] 21
    May 25, 2023
    Course Summary …
    8. Visualisation Techniques
    ▪ tables
    - scatterplot, bubble plot, (stacked) bar chart, dot chart, line chart, steamgraph,
    heatmap, scatterplot matrix, parallel coordinates, radial bar chart, pie chart,
    polar area charts, …
    ▪ spatial data (geometry, fields)
    - choropleth map, topographic terrain map, …
    ▪ network and trees
    - node-link diagram, force-directed placement, adjacency matrix view, enclosure
    (containment), treemap, GrouseFlocks, …
    9. View Manipulation and Reduction
    ▪ element selection and selection highlighting
    ▪ item and attribute reduction (filtering and aggregation)
    ▪ semantic zooming

    View Slide

  22. Beat Signer - Department of Computer Science - [email protected] 22
    May 25, 2023
    Course Summary …
    10.Interaction
    ▪ faceting into multiple views
    - linked highlighting
    - share data and navigation
    - juxtaposing views vs. superimposing views as layers
    ▪ embed: focus+context
    - DOITrees, fisheye lens, …

    View Slide

  23. Beat Signer - Department of Computer Science - [email protected] 23
    May 25, 2023
    Course Summary …
    11.Dashboards
    ▪ what is a dashboard?
    ▪ 13 common mistakes in dashboard design
    - exceeding the boundaries of a single screen, supplying inadequate context for
    the data, displaying excessive detail or precision, …
    ▪ strategies for effective dashboard design
    - condensing information with summaries and exceptions
    - maximising the data-ink-ratio
    - designing dashboards for usability/UX
    12.Case Studies and Course Review
    ▪ Scagnostics SPLOM, Hierarchical Clustering Explorer,
    PivotGraph, InterRing
    ▪ what-why-how?

    View Slide

  24. Beat Signer - Department of Computer Science - [email protected] 24
    May 25, 2023
    Exam
    ▪ Exams take place on June 26/27/28, 2023
    ▪ Oral exam in English (20 mins slot)
    ▪ covers content of lectures and exercises
    ▪ counts 60% for the overall grade
    ▪ 5 mins questions about the assignment
    ▪ 15 mins questions about the course content (no preparation time)
    ▪ Overall grade = oral exam (60%) + assignment (40%)
    ▪ assignment is composed out of two grades
    - overall grade for project where students have some flexibility in distributing
    the grades (±2 points) (70%)
    - your contribution/knowledge to the project as checked in oral exam (30%)
    ▪ note that the grade for the oral exam as well as for the assign-
    ment have to be 8/20 or higher in order to pass the exam!

    View Slide

  25. Beat Signer - Department of Computer Science - [email protected] 25
    May 25, 2023
    Exam …
    ▪ Submission of the assignment and video via
    Canvas
    ▪ deadline: May 29, 23:59 (CET)
    ▪ The exam will cover all the content presented in the
    lectures as well as any additional information from the
    exercise sessions
    ▪ includes the videos shown in some of the lectures
    ▪ Make sure that you understand the basic concepts
    ▪ however, we might ask questions at any level of detail to evaluate
    your knowledge
    ▪ Make sure that you can report about any aspects of the
    assignment

    View Slide

  26. Beat Signer - Department of Computer Science - [email protected] 26
    May 25, 2023
    Are You Interested in a Thesis?
    ▪ Various possibilities for BA, MA and PhD theses
    ▪ Data Physicalisation
    - extensible dynamic data physicalisation platform and framework
    ▪ Innovative Mixed Reality Interfaces
    - augmented realty board, museum guides, …
    ▪ Personal Information Management (PIM)
    ▪ Technology-enhanced Learning
    ▪ End-User Development and Human-AI Interaction
    ▪ Hybrid Positioning and Implicit Human-Computer Interaction
    ▪ Smart Environments and Cross-Domain Internet of Things (IoT)
    ▪ Next Generation Presentation Solutions (e.g. MindXpres)
    ▪ ...
    ▪ Do you have your own ideas? Come along to discuss them ...
    - https://wise.vub.ac.be/thesis-proposals

    View Slide

  27. Beat Signer - Department of Computer Science - [email protected] 27
    May 25, 2023
    Prof. Dr. Beat Signer
    Cross-MediaTechnology, Interac-
    tive Paper, Data Physicalisation
    Dr. Audrey Sanctorum
    User-defined XDI and IoT Inter-
    action, Human-AI Interaction
    CISA
    Human-Machine &
    Human-Information
    Interaction
    Information
    Systems &
    Management
    Information
    Visualisation
    & Navigation
    WEB & INFORMATION
    SYSTEMS ENGINEERING
    CROSS-MEDIA INFORMATION SPACES
    AND ARCHITECTURES (CISA)
    Maxim Van de Wynckel
    Hybrid Positioning, Implicit
    Human-Computer Interaction
    Yoshi Malaise
    Technology-enhanced Learning,
    Content-driven Presentations

    View Slide

  28. Beat Signer - Department of Computer Science - [email protected] 28
    May 25, 2023
    WEB & INFORMATION
    SYSTEMS ENGINEERING
    CISA
    Human-Machine &
    Human-Information
    Interaction
    Information
    Systems &
    Management
    Information
    Visualisation
    & Navigation
    CROSS-MEDIA INFORMATION SPACES
    AND ARCHITECTURES (CISA)
    Ekene Attoh
    IoT Middleware, Context-aware
    Computing, Implicit HCI
    Isaac Valadez
    Knowledge Physicalisation and
    Augmentation, Tangible UIs
    Xuyao Zhang
    Extensible Platform for Dynamic
    Data Physicalisation
    Ingela Rossing
    Dynamic Data Physicalisation
    Framework and Guidelines

    View Slide

  29. Beat Signer - Department of Computer Science - [email protected] 29
    May 25, 2023
    WEB & INFORMATION
    SYSTEMS ENGINEERING
    CISA
    Human-Machine &
    Human-Information
    Interaction
    Information
    Systems &
    Management
    Information
    Visualisation
    & Navigation
    CROSS-MEDIA INFORMATION SPACES
    AND ARCHITECTURES (CISA)
    Arun Sojan
    Physicalisation for Digital Twins
    Piet Van Der Paelt
    Julia-based Framework for
    Simulation and Optimisation
    Evan Cole
    Technology-enhanced Learning,
    Study Lenses
    Migdeily Cantera
    End-User Development, Mixed
    Reality IoT UIs, Intelligibility

    View Slide

  30. Beat Signer - Department of Computer Science - [email protected] 30
    May 25, 2023
    Final Project Presentations
    ▪ Each team will have 12 minutes to present
    their work
    ▪ dataset
    ▪ preprocessing
    ▪ visualisation and demo
    ▪ evaluation

    View Slide

  31. Beat Signer - Department of Computer Science - [email protected] 31
    May 25, 2023
    Further Reading
    ▪ This lecture is mainly based on the
    book Visualization Analysis & Design
    ▪ chapter 15
    - Analysis Case Studies

    View Slide

  32. Beat Signer - Department of Computer Science - [email protected] 32
    May 25, 2023
    References
    ▪ Visualization Analysis & Design, Tamara
    Munzner, Taylor & Francis Inc, (Har/Psc edition),
    May, November 2014,
    ISBN-13: 978-1466508910

    View Slide

  33. 2 December 2005
    Information Visualisation
    The End
    Good Luck with the Exam!

    View Slide
