1. WSO2 Social Initial Architecture
2. Data Model each comment is an json activity. activity consists of an actor, a verb, an object, and a target. "inReplyTo": [{ "id": "comment:773ab234g3c4323" }] }, "target": { "type": "gadget" "id": "rxt:9374d-23a3-3141" } } { "actor": { "id": "manu@wso2.com" }, "verb": "http://activitystrea.ms/schema/1. 0/pos", "object": { "objectType": "comment", "content": "<p>This is a comment</p>",
3. Data Model : Why JSON: plays well with Jaggery. Extensibility: eg: can add activities like ‘build’,’promoted’ for apps in future. Interoperability: eg: import some activities from JIRA.
4. Data Store published using BAM DataPublisher. important fields (eg: actor, timestamp) are stored as separate “columns”. use native index for now, move to BAM indexing when available.
5. Data Retrieve CQL is used to directly query Cassandra. pro: Real time update. Simple for basic queries. cons: May have to use many secondary indexes. Some client side processing required.
6. Integration embedded via iframe http://<host>/social/comments?for=rxt: cc2a13d3
7. Roles Step 1 : filter by actor’s permissions for the target Step 2 : each activity has a role it’s visible to. roles are keep separate from the normal permission roles. pro: relays on existing carbon role API. cons: implementing is not that smooth (a) pre-calculate per user. OR (b) combine at view time.
