JUnit 5 Extensions: From Conditional Test Execution to Test Templates

JUnit 5 has finally arrived! It introduces a completely new extension model that allows to customize almost every aspect of test execution. For example, it lets you define custom conditions to decide whether a test should be executed or skipped. Test lifecycle callbacks allow to encapsulate common setup/teardown code in an extension. An extension can pass values or inject dependencies to a test by post-processing test instances, or resolving test method parameters. Moreover, you can even write an extension that specifies how a test method becomes a template for multiple tests and how to invoke those, e.g. multiple times with different parameters or a different setup. In this talk, we will go on an example-driven tour of the new extension API using real-world testing scenarios. We will learn about the utilities an extension can use, e.g. how it should store state, so you will be ready to write your own extensions after this session. The talk will be interesting for experienced Java developers with prior knowledge of JUnit (at least JUnit 4).

Transcript

1. 5
   JUNIT 5 EXTENSIONS
   MARC PHILIPP


   View Slide

2. 5
   MARC PHILIPP
   So ware Engineer at
   JUnit Maintainer since 2012
   Twi er:
   Web:
   @marcphilipp
   marcphilipp.de


   View Slide

3. 5
   JUNIT 5 IS HERE!
   5.0
   September 10, 2017
   5.1
   February 18, 2018
   5.2
   April 29, 2018


   View Slide

4. 5
   ✋
   SHOW OF HANDS


   View Slide

5. 5
   J U N I T 5
   P L AT F O R M
   Another Test
   P A R T Y
   T H I R D
   J U P I T E R
   V I N TA G E


   View Slide

6. 5
   JUNIT JUPITER
   P L AT F O R M
   J U P I T E R


   View Slide

7. 5
   JUNIT JUPITER API
   programming model for test authors
   extension model for extension authors


   View Slide

8. 5
   PROGRAMMING MODEL
   import org.junit.jupiter.api.*;
   import static org.junit.jupiter.api.Assertions.*;
   class SimpleTest {
   @Test
   @DisplayName("1 + 1 = 2")
   void onePlusOneEqualsTwo() {
   assertEquals(2, 1 + 1);
   }
   }


   View Slide

9. 5
   EXTENSION MODEL
   import org.junit.jupiter.api.extension.*;
   class MyCustomExtension
   implements BeforeEachCallback, AfterEachCallback {
   @Override
   public void beforeEach(ExtensionContext context) {
   // setup
   }
   @Override
   public void afterEach(ExtensionContext context) {
   // teardown
   }
   }


   View Slide

10. 5
    EXTENSION REGISTRATION
    Declara ve: @ExtendWith on classes or methods
    Programma c: @RegisterExtension on fields
    Global: via ServiceLoader
    You can register as many extensions as you need
    simultaneously


    View Slide

11. 5
    PROGRAMMING MODEL MEETS
    EXTENSION MODEL
    import org.junit.jupiter.api.*;
    import org.junit.jupiter.api.extension.*;
    import static org.junit.jupiter.api.Assertions.*;
    @ExtendWith(MyCustomExtension.class)
    class SimpleTest {
    @RegisterExtension Extension myExtension = new AnotherExtension(42);
    @Test
    @ExtendWith({FooExtension.class, BarExtension.class})
    void onePlusOneEqualsTwo() {
    assertEquals(2, 1 + 1);
    }
    }


    View Slide

12. 5
    CONDITIONAL TEST
    EXECUTION


    View Slide

13. 5
    DEMO
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

14. 5
    EXTENSION CONTEXT
    Represents the current node in the test tree, e.g. test
    method or class
    Provides access to meta informa on about such a node,
    e.g. display name, method, class


    View Slide

15. 5
    EXTENSION CONTEXT
    root : ExtensionContext
    displayName = "JUnit Jupiter"
    parent
    class1 : ExtensionContext
    displayName = "TestClass1"
    parent
    test1 : ExtensionContext
    displayName = "test1()"
    parent
    test2 : ExtensionContext
    displayName = "test2()"
    parent
    class2 : ExtensionContext
    displayName = "TestClass2"
    parent
    test3 : ExtensionContext
    displayName = "test3()"


    View Slide

16. 5
    LESSONS LEARNED
    Using custom logic to determine whether a test
    class/method should be skipped
    Registering an extension globally
    Deac va ng a condi on without changing the code


    View Slide

17. 5
    REUSABLE TEST
    SETUP & TEARDOWN


    View Slide

18. 5
    DEMO
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

19. 5
    WHY THE STORE ABSTRACTION?
    An extension needs to save and retrieve data, e.g. to clean
    up in the end
    Extensions are instan ated once and called for mul ple
    tests
    Using instance variables would be error‑prone
    extensionContext
    .getStore(Namespace.create(...))
    .getOrComputeIfAbsent("key", key -> ...)


    View Slide

20. 5
    STORE
    Map ‑like interface for extensions to save and retrieve
    data, e.g. store.put(key, value)
    Accessed via a Namespace : Enables sharing data across
    extensions, but makes it a deliberate decision (e.g.
    Namespace.GLOBAL )
    Reading from a Store follows the hierarchy upwards, if a
    key is not found


    View Slide

21. 5
    STORE
    root : ExtensionContext
    displayName = "JUnit Jupiter"
    parent
    class1 : ExtensionContext
    displayName = "TestClass1"
    parent
    store
    test1 : ExtensionContext
    displayName = "test1()"
    a : Store
    + get(Object, Class): T, ...
    parent
    b : Store
    + get(Object, Class): T, ...
    parent
    c : Store
    + get(Object, Class): T, ...
    Namespace
    store
    Namespace
    store
    Namespace


    View Slide

22. 5
    AUTOMATIC CLEAN‑UP
    CloseableResource instances in a Store are automa cally
    closed when the scope of the corresponding
    ExtensionContext ends.
    class DockerClientResource implements CloseableResource {
    private final DockerClient dockerClient;
    DockerClientResource() {
    var config = DefaultDockerClientConfig.createDefaultConfigBuilder
    dockerClient = DockerClientBuilder.getInstance(config).build();
    }
    DockerClient get() {
    return dockerClient;
    }
    @Override public void close() throws Throwable {
    dockerClient.close();
    }
    }


    View Slide

23. 5
    LESSONS LEARNED
    Using the Store class for extension state
    Using Lifecycle Callbacks to enable reuse of common
    setup/teardown code
    Implemen ng mul ple Extension interfaces in a single
    extension


    View Slide

24. 5
    RESOLVING TEST
    PARAMETERS


    View Slide

25. 5
    DEMO
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

26. 5
    LESSONS LEARNED
    How to resolve test method parameters in an
    Extension ?
    You can also inject parameters into test class constructors
    and @BeforeEach / @AfterEach methods etc.


    View Slide

27. 5
    PROVIDING
    ARGUMENTS FOR
    PARAMETERIZED
    TESTS


    View Slide

28. 5
    DEMO
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

29. 5
    LESSONS LEARNED
    Using Parameterized Tests
    Wri ng a custom ArgumentsProvider that loads data
    from a JSON file, …


    View Slide

30. 5
    FROM TESTS TO TEST
    TEMPLATES


    View Slide

31. 5
    DEMO
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

32. 5
    LESSONS LEARNED
    Execu ng a test mul ple mes with different contexts
    Implemen ng a TestInvocationContextProvider


    View Slide

33. 5
    SUPPORT CLASSES
    Package org.junit.platform.commons.support contains:
    AnnotationSupport to scan for custom annota ons,
    including meta‑annota ons
    ReflectionSupport for classpath scanning, finding
    methods, invoking them etc.


    View Slide

34. 5
    SUMMARY


    View Slide

35. 5
    EXTENSION POINTS
    Lifecycle: BeforeAllCallback , BeforeEachCallback ✅,
    BeforeTestExecutionCallback ,
    TestExecutionExceptionHandler ,
    AfterTestExecutionCallback , AfterEachCallback ✅,
    AfterAllCallback
    Other: ExecutionCondition ✅,
    TestInstancePostProcessor , ParameterResolver ✅,
    TestTemplateInvocationContextProvider ✅


    View Slide

36. 5
    JUNIT JUPITER IS EXTENSIBLE
    A lot of extension points to choose from
    The JUnit team will add more in future releases
    Combining mul ple extension points in one extension is
    very powerful!


    View Slide

37. 5
    THIRD‑PARTY EXTENSIONS
    Spring, Mockito, Docker, Wiremock, JPA,
    Selenium/WebDriver, DbUnit, Ka a, Jersey, GreenMail,
    S3Mock, Citrus Framework, XWiki, …
    h ps:/
    /github.com/junit‑team/junit5/wiki/Third‑party‑
    Extensions


    View Slide

38. 5
    GETTING STARTED
    User Guide:
    Sample projects for Gradle, Maven, and Ant:
    Javadoc:
    h p:/
    /junit.org/junit5/docs/current/user‑guide/
    h ps:/
    /github.com/junit‑team/junit5‑samples
    h p:/
    /junit.org/junit5/docs/current/api/


    View Slide

39. 5
    WANTED: FEEDBACK!
    StackOverflow:
    Code & Issues:
    Twi er:
    h p:/
    /stackoverflow.com/ques ons/tagged/junit5
    h ps:/
    /github.com/junit‑team/junit5/
    h ps:/
    /twi er.com/juni eam


    View Slide

40. 5
    EXAMPLE CODE
    h ps:/
    /github.com/marcphilipp/junit5‑extensions‑demo


    View Slide

41. 5
    QUESTIONS?
    or
    @marcphilipp @juni eam


    View Slide

42. 5
    THANKS!


    View Slide
