Transcript
Desvendando Custom Drawing Matheus C. Candido Android @ Concrete speakerdeck.com/mcassiano
pixabay/somraya
val default = Paint() val smoother = Paint(FLAG_ANTI_ALIAS) val copy
= Paint(smoother)
FLAG_ANTI_ALIAS
stroke width paint.strokeWidth = 4f paint.strokeWidth = 6f paint.strokeWidth =
8f todos os valores são em pixels!
style Paint.Style.STROKE Paint.Style.FILL_AND_STROKE Paint.Style.FILL
join (ligações) Paint.Join.MITER Paint.Join.ROUND Paint.Join.BEVEL
cap (pontas) Source: Microsoft Xamarin Docs
pixabay/coyot
formas
formas canvas.drawRect( rectBounds, paint )
rectBounds???
formas canvas.drawRoundRect( rectFBounds, radiusX, radiusY, paint )
formas canvas.drawArc( rectFBounds, startAngle, sweepAngle, useCenter, paint )
formas canvas.drawCircle( centerX, centerY, radius, paint )
paths
transformações canvas.save() // faça alguma transformação canvas.restore()
transformações val count = canvas.save() // faça alguma transformação canvas.restoreToCount(count)
translate canvas.translate(deltaX, deltaY)
rotate canvas.rotate(degrees) canvas.rotate(degrees, pivotX, pivotY)
scale canvas.scale(scaleX, scaleY) canvas.scale(scaleX, scaleY, pivotX, pivotY)
skew canvas.skew(skewX, skewY)
clipping (recortes)
clipping (recortes) clipOutPath clipOutRect
clipping (recortes) clipRect clipPath
bitmaps
bitmaps drawables
bitmaps drawables Levels example: https://ryanharter.com/blog/2015/04/03/custom-drawables/
bitmaps drawables custom views
bitmaps drawables custom views item decorators
performance • evite alocações no onDraw • faça clip nas
regiões que não for desenhar • use as ferramentas de profiling para verificar overdraw e debugar quebra de frames
acessibilidade AccessibilityNodeProvider ExploreByTouchHelper
acessibilidade getVirtualViewAt(x: Float, y: Float) getVisibleVirtualViews(virtualViewIds: MutableList<Int>) onPerformActionForVirtualView( virtualViewId: Int,
action: Int, arguments: Bundle? ) onPopulateNodeForVirtualView( virtualViewId: Int, node: AccessibilityNodeInfoCompat )
acessibilidade ????
virtual view data class VirtualView( var id: Int = View.NO_ID,
var contentDescription: CharSequence, val rect: Rect = Rect() )
node provider override fun getVirtualViewAt( x: Float, y: Float ):
Int { val view = virtualViews.find{ it.rect.contains(x, y) } return view?.id ?: HOST_ID }
node provider override fun onPopulateNodeForVirtualView( virtualViewId: Int, node: AccessibilityNodeInfoCompat )
{ val view = virtualViews.find { it.id == virtualViewId } view?.let { node.setBoundsInParent(it.rect) node.contentDescription = it.contentDescription } }
exemplos
backgrounds (itemdecoration) Exemplo: https://github.com/ajarl/item-decoration-sample/blob/master/ app/src/main/java/com/example/itemdecorationsample/ItemDecoration.kt
backgrounds (itemdecoration) Exemplo: https://github.com/ajarl/item-decoration-sample/blob/master/ app/src/main/java/com/example/itemdecorationsample/ItemDecoration.kt
backgrounds (itemdecoration) Exemplo: https://github.com/ajarl/item-decoration-sample/blob/master/ app/src/main/java/com/example/itemdecorationsample/ItemDecoration.kt
histograma Exemplo: https://github.com/mcassiano/custom-drawing
