1. ; Mehdi Cherti (Appstat, LAL/CNRS) Supervised by Balázs Kégl (LAL/CNRS) and Alexandre Gramfort (CNRS LTCI) Py-Earth: Multivariate Adaptive Regression Splines ( MARS) in Python October 26, 2015 1 / 25
2. ; Py-Earth: Multivariate Adaptive Regression Splines ( MARS) in Python Mehdi Cherti (Appstat, LAL/CNRS) Supervised by Balázs Kégl (LAL/CNRS) and Alexandre Gramfort (CNRS LTCI) October 26, 2015 Mehdi Cherti (Appstat, LAL/CNRS) Supervised by Balázs Kégl (LAL/CNRS) and Alexandre Gramfort (CNRS LTCI) Py-Earth: Multivariate Adaptive Regression Splines ( MARS) in Python October 26, 2015 1 / 25
3. October 26, 2015 2 / 25
4. Introduction MARS is a regression technique for high dimensional data: introduced rst by Jerome H.Friedman in 1991 it is non-linear and non-parametric Py-earth is an implementation of MARS in Python, created by Jason Crudy The goal is to bring Py-earth into scikit-learn October 26, 2015 2 / 25
5. Introduction MARS is a regression technique for high dimensional data: introduced rst by Jerome H.Friedman in 1991 it is non-linear and non-parametric Py-earth is an implementation of MARS in Python, created by Jason Crudy The goal is to bring Py-earth into scikit-learn October 26, 2015 2 / 25
6. Introduction MARS is a regression technique for high dimensional data: introduced rst by Jerome H.Friedman in 1991 it is non-linear and non-parametric Py-earth is an implementation of MARS in Python, created by Jason Crudy The goal is to bring Py-earth into scikit-learn October 26, 2015 2 / 25
7. Introduction MARS is a regression technique for high dimensional data: introduced rst by Jerome H.Friedman in 1991 it is non-linear and non-parametric Py-earth is an implementation of MARS in Python, created by Jason Crudy The goal is to bring Py-earth into scikit-learn October 26, 2015 2 / 25
8. Introduction MARS is a regression technique for high dimensional data: introduced rst by Jerome H.Friedman in 1991 it is non-linear and non-parametric Py-earth is an implementation of MARS in Python, created by Jason Crudy The goal is to bring Py-earth into scikit-learn October 26, 2015 2 / 25
9. Setup Setup : Multivariate regression with multiple outputs : (X i , Y i ) where i is the ith example Xi is a vector describing each example i Yi is a real-valued vector describing the true outputs of the example i We want to nd a model f which predicts Y from X with low generalization mean squared error (MSE) October 26, 2015 3 / 25
10. Setup Setup : Multivariate regression with multiple outputs : (X i , Y i ) where i is the ith example Xi is a vector describing each example i Yi is a real-valued vector describing the true outputs of the example i We want to nd a model f which predicts Y from X with low generalization mean squared error (MSE) October 26, 2015 3 / 25
11. Setup Setup : Multivariate regression with multiple outputs : (X i , Y i ) where i is the ith example Xi is a vector describing each example i Yi is a real-valued vector describing the true outputs of the example i We want to nd a model f which predicts Y from X with low generalization mean squared error (MSE) October 26, 2015 3 / 25
12. Setup Setup : Multivariate regression with multiple outputs : (X i , Y i ) where i is the ith example Xi is a vector describing each example i Yi is a real-valued vector describing the true outputs of the example i We want to nd a model f which predicts Y from X with low generalization mean squared error (MSE) October 26, 2015 3 / 25
13. How does MARS work ? Basic building block : Hinge functions, y = max(x − k, 0) or y = max(k − x, 0) October 26, 2015 4 / 25
14. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
15. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
16. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
17. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
18. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
19. How does MARS work ? The algorithm constructs adaptively a set of basis functions : B k (X) Each basis function is a product of hinge functions, for instance : Bk(X) = max(X1 − 5, 0)max(X2 + 4, 0) The model is a linear combination of those basis functions Y = K k=1 αkBk(X) The specicity of MARS comes from how the basis functions are created and added to the model October 26, 2015 5 / 25
20. How does MARS work ? Two steps, the forward pass and the pruning pass We over-generate a set of basis functions in the forward pass We prune unncessary basis functions in the pruning pass October 26, 2015 6 / 25
21. How does MARS work ? Two steps, the forward pass and the pruning pass We over-generate a set of basis functions in the forward pass We prune unncessary basis functions in the pruning pass October 26, 2015 6 / 25
22. How does MARS work ? Two steps, the forward pass and the pruning pass We over-generate a set of basis functions in the forward pass We prune unncessary basis functions in the pruning pass October 26, 2015 6 / 25
23. How does MARS work ? The forward pass October 26, 2015 7 / 25
24. How does MARS work ? The forward pass October 26, 2015 8 / 25
25. How does MARS work ? The forward pass October 26, 2015 9 / 25
26. How does MARS work ? The forward pass October 26, 2015 10 / 25
27. How does MARS work ? The forward pass y = (α0 + α1 max(x1 − 3, 0) + α2 max(3 − x1, 0)+ α3 max(x1 − 3, 0)max(x2 − 7, 0) + α4 max(x1 − 3, 0)max(7 − x2, 0)+ α5 max(x2 − 12, 0) + α6 max(12 − x2, 0)) (1) October 26, 2015 11 / 25
28. What have been done ? Github repo : https://github.com/jcrudy/py-earth git clone https://github.com/jcrudy/py-earth cd py-earth python setup.py install The state of the code: Py-earth supported already a lot of features and the important parts were there However, it was not ready to be deployable to scikit-learn it was not supporting multiple outputs October 26, 2015 12 / 25
29. What have been done ? Github repo : https://github.com/jcrudy/py-earth git clone https://github.com/jcrudy/py-earth cd py-earth python setup.py install The state of the code: Py-earth supported already a lot of features and the important parts were there However, it was not ready to be deployable to scikit-learn it was not supporting multiple outputs October 26, 2015 12 / 25
30. What have been done ? improve code quality  Clean the code (pep8) and adapt it to coding guidelines of scikit-learn  Enchance documentation  Add more unit tests October 26, 2015 13 / 25
31. What have been done ? improve code quality  Clean the code (pep8) and adapt it to coding guidelines of scikit-learn  Enchance documentation  Add more unit tests October 26, 2015 13 / 25
32. What have been done ? improve code quality  Clean the code (pep8) and adapt it to coding guidelines of scikit-learn  Enchance documentation  Add more unit tests October 26, 2015 13 / 25
33. What have been done ? new features Support for multiple outputs Support for output weights Support of estimation of variable importance Implement FastMARS (Jerome H.Friedman, 1993) October 26, 2015 14 / 25
34. What have been done ? new features Support for multiple outputs Support for output weights Support of estimation of variable importance Implement FastMARS (Jerome H.Friedman, 1993) October 26, 2015 14 / 25
35. What have been done ? new features Support for multiple outputs Support for output weights Support of estimation of variable importance Implement FastMARS (Jerome H.Friedman, 1993) October 26, 2015 14 / 25
36. What have been done ? new features Support for multiple outputs Support for output weights Support of estimation of variable importance Implement FastMARS (Jerome H.Friedman, 1993) October 26, 2015 14 / 25
37. Example : 1D example October 26, 2015 15 / 25
38. Example : 2D example October 26, 2015 16 / 25
39. Example : multiple outputs October 26, 2015 17 / 25
40. Example : multiple outputs 20 inputs, 3 outputs, only 2 informative inputs, the rest is noise October 26, 2015 18 / 25
41. Example : multiple outputs The graph (a crop of it) of basis functions looks like this : October 26, 2015 19 / 25
42. Example : variable importance October 26, 2015 20 / 25
43. Example : variable importance y = sin(πx0 x1) + 20(x2 − 0.5)2 + 10x3 + 5x4 + 5 ∗ N(0, 1) The code in the previous slide gives: October 26, 2015 21 / 25
44. Example : FastMARS October 26, 2015 22 / 25
45. Example : FastMARS Top : Normal, Bottom : FastMARS October 26, 2015 23 / 25
46. Future Close current issues, keep working on code quality to merge it into scikit-learn Still, some features are missing, new features: Deal with missing values Support categorical variables October 26, 2015 24 / 25
47. Future Close current issues, keep working on code quality to merge it into scikit-learn Still, some features are missing, new features: Deal with missing values Support categorical variables October 26, 2015 24 / 25
48. Future Close current issues, keep working on code quality to merge it into scikit-learn Still, some features are missing, new features: Deal with missing values Support categorical variables October 26, 2015 24 / 25
49. Thank you Thank you for listening October 26, 2015 25 / 25
