Micronaut AOT: optimiser vos application pour le JIT et GraalVM

Transcript

1. Micronaut AOT
   Optimizing your apps for the JIT and GraalVM
   Cédric Champeau
   Micronaut Developer
   Oracle Labs


   View Slide

2. • Working at Oracle Labs on Micronaut
   ●
   Main focus on build plugins and dev
   productivitity
   • Formerly working at Gradle Inc
   • Author of static compiler of Groovy
   • Amateur astronomer
   ●
   @CedricChampeau
   ●
   https://www.astrobin.com/users/melix/
   About me
   Copyright © 2021, Oracle and/or its affiliates
   micronaut.io github.com/micronaut-projects/micronaut-core


   View Slide

3. • Micronaut is focused on modern
   architectures like Serverless and
   Microservices
   • Also a complete framework for any type of
   application
   • Lightweight, reactive (HTTP Client/Server
   based on Netty)
   • Annotation processor to compute framework
   infrastructure at compile time
   Micronaut
   Copyright © 2021, Oracle and/or its affiliates
   micronaut.io github.com/micronaut-projects/micronaut-core


   View Slide

4. Micronaut = Build Time Framework Infrastructure
   Copyright © 2021, Oracle and/or its affiliates
   Micronaut computes:
   • All dependency & configuration injection
   • Annotation metadata, meta-annotations
   • AOP proxies
   • Bean introspections
   • And all other framework infrastructure
   • Reflection, runtime proxy, and dynamic
   classloader free


   View Slide

5. GraalVM
   Copyright © 2021, Oracle and/or its affiliates
   • High-performance JDK distribution
   • Increases application throughput, reduces
   latency, reduces memory use
   • Graal just-in-time (JIT) compiler that runs on
   top of HotSpot, written in Java
   • native-image ahead-of-time (AoT) compiler
   compiles Java applications into small self-
   contained native binaries
   graalvm.org github.com/graalvm/graalvm-demos
   oracle.com/graalvm


   View Slide

6. Micronaut GraalVM
   ♥️
   Copyright © 2021, Oracle and/or its affiliates
   • Micronaut + GraalVM Native Image are a
   match made in heaven
   • Less work to configure Native Image
   because Micronaut eliminates reflection,
   runtime proxies, bytecode generation and
   dynamic classloading
   • Startup time 20ms and Memory
   Consumption 18MB!
   ♥️


   View Slide

7. Demo: your first Micronaut app
   Copyright © 2022
   8


   View Slide

8. Copyright © 2022, Oracle and/or its affiliates
   9


   View Slide

9. Copyright © 2022, Oracle and/or its affiliates
   10


   View Slide

10. Copyright © 2022, Oracle and/or its affiliates
    11


    View Slide

11. Micronaut AOT
    Copyright © 2021, Oracle and/or its affiliates
    12


    View Slide

12. 
    Optional extension to the Micronaut framework
    
    Available via build tool plugins (Gradle, Maven or CLI invocation)
    
    Performs deployment optimizations
    
    Generates an application which is tailored to a particular deployment environment
    
    Generates distinct optimizations for the “regular” JVM (aka “JIT mode”) or native (aka “GraalVM”)
    
    Can optimize
    
    CLI applications
    
    HTTP applications
    
    Functions (currently tested with AWS Lambda and Oracle Cloud Functions, Azure coming)
    Micronaut AOT
    Copyright © 2022, Oracle and/or its affiliates
    13


    View Slide

13. Demo: optimizing your Micronaut app
    Copyright © 2022, Oracle and/or its affiliates
    14


    View Slide

14. Copyright © 2022, Oracle and/or its affiliates
    15
    Add the Micronaut AOT
    plugin
    Configure
    optimizations


    View Slide

15. Copyright © 2022, Oracle and/or its affiliates
    16


    View Slide

16. Copyright © 2022, Oracle and/or its affiliates
    17


    View Slide

17. Copyright © 2022, Oracle and/or its affiliates
    18


    View Slide

18. Micronaut AOT
    Copyright © 2022, Oracle and/or its affiliates
    19


    View Slide

19. Building an application without Micronaut AOT
    Copyright © 2022, Oracle and/or its affiliates
    20
    Sources
    (.java, .groovy, .kt) class files
    javac
    +
    Annotation processing
    Resources
    (.yaml, .properties)
    Jar file
    packaging
    packaging Native binary
    native-image


    View Slide

20. Building an application with Micronaut AOT
    Copyright © 2022, Oracle and/or its affiliates
    21
    jar file
    (or classes + resources)
    class files
    AOT jar file Native AOT binary
    native-image
    Resource files
    Source files
    Metadata
    filtering
    AOT analysis


    View Slide

21. 
    Optimizing service loading
    
    pre-scans META-INF/service files (for some core types) and generates classes which avoid the use of
    service loader and permits parallel loading
    
    Generated loaders are different in JIT and native!
    
    Converting YAML files to Java
    
    Avoids parsing YAML files at application startup
    
    Reduces the size of the generated native binary
    
    Caching the environment
    
    Once the application is started, all environment variables and system properties are deemed immutable
    
    Pre-computing bean requirements
    
    Evaluates @Requires conditions at build time instead of runtime
    
    Reduces the size of the generated native binary
    Micronaut AOT Core Optimizations
    Copyright © 2022, Oracle and/or its affiliates
    22


    View Slide

22. public class StaticServicesLoader implements
    StaticOptimizations.Loader {
    @Override
    public SoftServiceLoader.Optimizations load() {
    Map> staticServices = new HashMapSoftServiceLoader.StaticServiceLoader>>();
    staticServices.put("io.micronaut.context.env.PropertySourceLoader", new
    PropertySourceLoaderFactory());
    staticServices.put("io.micronaut.http.HttpResponseFactory", new HttpResponseFactoryFactory());
    staticServices.put("io.micronaut.inject.BeanDefinitionReference", new
    BeanDefinitionReferenceFactory());
    staticServices.put("io.micronaut.core.beans.BeanIntrospectionReference", new
    BeanIntrospectionReferenceFactory());
    staticServices.put("io.micronaut.inject.BeanConfiguration", new BeanConfigurationFactory());
    staticServices.put("io.micronaut.http.HttpRequestFactory", new HttpRequestFactoryFactory());
    return new SoftServiceLoader.Optimizations(staticServices);
    }
    }
    Micronaut AOT: Code generation
    Copyright © 2022, Oracle and/or its affiliates
    23


    View Slide

23. 
    Optimizing classloading
    
    Performs Class#forName at build time to avoid ClassNotFoundException at run time
    
    Deducing the environment at build time
    
    Performs the “environment deduction” (AWS, Google Cloud, …) at build time instead of run time
    
    Precomputing “expensive operations”
    
    Pre-computes some constants at build-time instead of run time
    
    For example, the mapping between environment variable names and Micronaut properties
    
    (Experimental) Converting logback.xml to Java configuration
    
    Avoids loading the XML parsing library at application startup
    Micronaut AOT Core Optimizations
    Copyright © 2022, Oracle and/or its affiliates
    24


    View Slide

24. 
    Faster startup time
    
    10% faster, sometimes more depending on your context
    
    Smaller native images
    
    By substitution, some classes are not reachable anymore
    
    Results depend on the transitive dependency graph
    
    Improved time to first request
    
    Module specific optimizations can access resources at build time
    Micronaut AOT: what benefits to expect?
    Copyright © 2022, Oracle and/or its affiliates
    25


    View Slide

25. graalvmNative {
    binaries.all {
    // profiling
    buildArgs.add("-H:-DeleteLocalSymbols")
    buildArgs.add("-H:+PreserveFramePointer")
    }
    }
    Micronaut AOT: profiling native applications
    Copyright © 2022, Oracle and/or its affiliates
    26


    View Slide

26. Micronaut AOT: example impact on native
    Copyright © 2022, Oracle and/or its affiliates
    27


    View Slide

27. Micronaut AOT: example impact on native
    Copyright © 2022, Oracle and/or its affiliates
    28


    View Slide

28. 
    Micronaut Serialization
    
    Provides compile-time databinding
    
    Replacement for Jackson Databind
    
    Runtime can use Jackson, BSON or JSON-P
    Impact on image size
    Copyright © 2022, Oracle and/or its affiliates
    29


    View Slide

29. 
    Micronaut AOT supports plugins
    
    Plugins are “source generators” which get access to the application context
    
    Generated code can inject optimizations into Micronaut via dedicated API
    
    Plugins contribute new optimizations
    
    Eg: Micronaut Security can fetch OpenID metadata configuration from remote at build time. Can save up to 1s at
    the first request!
    
    Code generators execute within the context of the target application!
    Micronaut AOT extensibility
    Copyright © 2022, Oracle and/or its affiliates
    30


    View Slide

30. Micronaut AOT extensibility
    Copyright © 2022, Oracle and/or its affiliates
    31
    @Override
    public void generate(@NonNull AOTContext context) {
    context.registerStaticOptimization("KnownMissingTypesOptimizationLoader", ClassUtils.Optimizations.class, body -> {
    List classNames = context.getConfiguration().stringList(OPTION.key());
    body.addStatement("$T knownMissingTypes = new $T()", ParameterizedTypeName.get(Set.class, String.class),
    for (String knownMissingClass : findMissingClasses(classNames)) {
    body.addStatement("knownMissingTypes.add($S)", knownMissingClass);
    }
    body.addStatement("return new $T(knownMissingTypes)", ClassUtils.Optimizations.class);
    });
    }
    private List findMissingClasses(List classNames) {
    List knownMissingClasses = new ArrayList<>();
    ClassLoader cl = this.getClass().getClassLoader();
    for (String name : classNames) {
    try {
    cl.loadClass(name);
    } catch (ClassNotFoundException | NoClassDefFoundError e) {
    knownMissingClasses.add(name);
    }
    }
    return knownMissingClasses;
    }
    This happens in user application
    context


    View Slide

31. 
    Micronaut is a modern framework which uses build-time optimizations
    ●
    Use of annotation processing for generating metadata, avoiding reflection, …
    
    Micronaut AOT complements the approach
    ●
    Not everything can be done by annotation processing
    ●
    Substitution of classes/resources
    ●
    Parsing configuration files
    ●
    Sensitive to the build environment and therefore sensitive to the deployment environment
    Conclusion
    Copyright © 2022, Oracle and/or its affiliates
    32


    View Slide

32. 
    Micronaut Website
    ●
    https://micronaut.io
    
    Micronaut Launch
    ●
    Bootstrap your Micronaut apps: https://micronaut.io/launch
    
    Micronaut AOT
    ●
    Documentation: https://micronaut-projects.github.io/micronaut-aot/latest/
    ●
    Gradle plugin:
    https://micronaut-projects.github.io/micronaut-gradle-plugin/latest/#_micronaut_aot_plugin
    ●
    Maven plugin:
    https://micronaut-projects.github.io/micronaut-maven-plugin/latest/examples/aot.html
    
    GraalVM Community Edition
    ●
    https://www.graalvm.org/
    Links
    Copyright © 2022, Oracle and/or its affiliates
    33


    View Slide

33. Copyright © 2022, Oracle and/or its affiliates
    34
    Thank you!
    Slides coming at @CedricChampeau
