1. Scaling Development at State with Docker mischa@state.com 2015-07-08
2. This all started about 15 months ago… When I joined State 2
3. https://state.com/ • Opinion Network • You shouldn't need a following to get heard • Exchange opinions with people around the world • Social Network structured like News where people share opinions on topics they care about • Founded by Alex & Mark Asseily (Jawbone & Skype) 3
4. Product Market Fit • Efficiency and speed of iteration • Ability to be nimble • Ability to make changes quick • Ability to test out hypotheses 4
5. Challenges • State is a startup • we burn cash • we have no revenue • pushy product team • super smart engineering team 5
6. Time is of the essence 6
7. From a monolith … • Single Repository • Multiple languages used JVM (Storm), Node, Ruby, … • Multiple versions of languages for each component Node 6, Node 10, … • SOA without an easy ability to ship individual WS • In-house build and deployment tools • Regression prone massive deploys • Massive Rails App battered through continuous product development 7
8. Motivations • Remove friction, increase productivity, and increase iteration cycles • Enable the team to pick the best tools for the job at hand • Move the engineering towards a true SOA where individual WS could be deployed with ease 8
9. Three Main Issues • As an engineering team we had to decide on how we could start breaking off parts of the Monolith into standalone WS without compromising on our objective of trying to find Product Market Fit • How could we design an infrastructure that would allow developers to pick the best tool for the job at hand • Cost Saving - More QA environment, more powerful infrastructure 9
10. I had read Jay Kreps’ blog post : “The Log: What every software engineer should know about real-time data's unifying abstraction” 10
11. and 11
13. Desires • Decouple system architecture into individual standalone components • Enable engineers to have the freedom/flexibility to use the right tools for each and every problem • Framework / Pattern for building new components 13
14. Some details 14
15. State Docker Infrastructure 15
16. High-level • 2 clusters of CoreOS instances • Datastores cluster (MongoDB, Elastic Search, Kafka, etc) • Uses Docker Host Networking • Uses AWS EC2 Tags for Discovery • 1 container per EC2 instance • Services cluster (15 or so Stateless Services) • Uses etcd + confd for Discovery • Uses HA Proxy to route to Docker Containers 16
17. AWS ELB (SSL) services cluster … AWS instance Container Presence Service etcd HA Proxy + confd AWS instance Container Presence Service HA Proxy + confd AWS instance Container Presence Service HA Proxy + confd datastores cluster Docker Host Networking AWS instance Container AWS instance Container AWS instance Container …
18. Service Cluster Discovery Flow (Not Host Networking) • Docker Assigns Each Container a Port • Every Container has a partner “Presence Service” which find the Port of the service and adds it to ETCD with a 5m TTL and deletes when service is stopped • CONFD generates HA Proxy config (HA Proxy Runs on Every instance [in a Container]) and restarts HA Proxy accordingly • Every HA Proxy (runs in Host Networking) can route to every container • ELBs load balance externals requests to the HA Proxies running on every instance 18
19. HA Proxy 19
20. Service Deployment • We use Fleet as our Scheduler to manage our containers • We have YAML definitions for all of our services • We generate Fleet Units from these, which are made up of explicit Docker Image Tags so we don’t ever use “latest” • We use Fleet Constraints to ensure services are spread across multiple instances 20
21. State Development Workflow 21
22. Developers Push Code • Using git & github • To Branches 22
23. Using Github’s webhooks • We Trigger a build in our Drone Build Server 23
24. Drone runs ours tests • Using Github’s Statuses API reports this back 24
25. Docker Image Creation • When all tests are passing Drone • Creates a new Image • Names the image by using the following convention • “service-name:git-XXXXXX” • Pushes to our Private Registry in AWS on S3 • Docker Hub too flakey • Registry locality • Only depend on AWS 25
26. Final Slide :) • It is stable, it works, it is a bunch of simple bash scripts, it has been in production for 9 months • We open-sourced our Cloud Formation templating scripts (used by some Gov Agency) • https://github.com/State/stacks • We would consider open-sourcing our Fleet Unit YAML templating if people are interested 26
27. THANK YOU for listening And thanks to JD Hancock for these amazing stormtrooper photos all photos are shared under CC 2.0 27
28. Questions? http://twitter.com/mischat 28
