1. Unified Log mischa@state.com 2015-05-20
2. This all started about 13 months ago… When I first joined State 2
3. I had read Jay Kreps’ blog post : “The Log: What every software engineer should know about real-time data's unifying abstraction” 3
4. And knew it was the best way for us to move forward, to move faster, to engineer better systems … 4
5. Product Market Fit • Efficiency and speed of iteration • Ability to be nimble • Ability to make changes quick • Ability to test out hypotheses 5
6. Challenges • State is a startup • we burn cash • we have no revenue • pushy product team • super smart engineering team 6
7. Time is of the essence 7
8. Desires • Decouple system architecture into individual standalone components • Enable engineers to have the freedom/flexibility to use the right tools for each and every problem • Framework / Pattern for building new components 8
9. I wanted it to be fun (most importantly) 9 photo by https://www.flickr.com/photos/jdhancock/
10. a short story 10
11. From a monolith … • Single repo codebase • Monolithic deploys requiring full regression testing • Unwieldily Ruby on Rails web application - battered through numerous cycles of product change 11
12. … to a SOA • Multiple daily deploys • Individual, isolated, deployable web services • Engineers can choose the right tools for the tasks at hand • A formula for creating as many Micro-Services as needed 12
13. This was a lot of hard work … initially … 13
14. The State Team you guys ROCK ! 14
15. Me • Mischa Tuffield http://mmt.me.uk/ • State CTO - Since Apr 2014 • 3rd Startup - Garlik, PeerIndex • PhD in CS - Capturing Autobiographical Metadata • Web and Data Geek • I ♥ Semantic Web • TBL is a legend (don’t doubt this) • ex-W3C contributor • Social Web XG Editor • RDF 1.1 Turtle Contributor • I also ♥ Star Wars and Batman • Am more of a Luke person than a Han person 15
16. About State • Opinion Network • You shouldn't need a following to get heard • Exchange opinions with people around the world • Social Network structured like News where people share opinions on topics they care about • Founded by Alex & Mark Asseily (Jawbone & Skype) 16
17. And now for some specifics … 17
18. Our topics define the Data API for all of our Micro-Services 18
19. TL;DR • We created some workflows and infrastructure to allow for data to be persisted into our Unified Log as separate topics - e.g. Users, Opinions, “Well Said”s • We created a framework to allow the data in our Unified Log to be joined together to create new streams • We could move away from treating our database as the canonical source of truth for data - we are undecided • This allows the Engineers to use whatever technology suits the problem at hand, all they have to do is ensure that if their service dies it can recreated itself by replaying all of the data from its topic our Unified Log • We made use of segment.com as our analytics tool, unifying this concept of using an Event Based Unified Log 19
20. Looking at the details 20
21. State’s Unified Log • We have implemented our Log using
 Apache Kafka • Our Unified Log is our Data API for our Micro-Services • We have two types of Kafka topics • Shared Topics - Data API available to all Micro- Services • Internal Topics - not shared, contracted for use by individual Micro-Services only 21
22. The take home message is Decoupling of Services In order to avoid Regressions & Spaghetti Code 22
23. Operation Framework • We have defined a framework (Devops) for writing these Micro-Services. A well understood JSON over HTTP interface • 12 factor, JSON over HTTP 23
24. The key requirement for this work was to continue Product Development We did NOT perform a rewrite of our stack 24
25. A worked example User Search 25
26. Simplified Original Stack 26 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid
27. And then we built our “Op Tailer” 27 • Which reads our Mongo DB “Replica Set Oplog” • It should be noted, that unlike MySQL where the replication data format isn’t an agreed API (see LinkedIn’s papers on their Log) and is susceptible to change. The Mongo Replica Set Oplog is just another Mongo Collection • It could change :)
28. 28 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid OpTailer
29. Kafka REST 29 • Kafka REST if a web service written by the folk at Confluent.io which writes data to a given Kafka topic
30. 30 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid OpTailer User Topic (User Info Data) Kafka REST Unified Log Kafka … …
31. Then we wrote a simple indexer 31 • Which took data from the Kafka topic and pushed it into Elastic Search
32. 32 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid OpTailer User Topic (User Info Data) Kafka REST Unified Log Kafka Search Indexer Elastic Search … …
33. Then we wrote a simple Search Service 33 • Which implements our Micro-Services Framework, based on Dropwizard (from the folk at Yammer)
34. 34 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid OpTailer User Topic (User Info Data) Kafka REST Unified Log Kafka Search Indexer Elastic Search Search Service … …
35. We are moving to V2 of our Search Service 35 • This time we wanted to include the User’s Social Graph (which we call our Connections Graph) • But we had to join the data in our User Kafka topic with our Connections Graph • We used Apache Samza for this Task
36. 36 State API Backend Ruby on Rails Webapp Mongo DB iOS WWW Droid OpTailer User Topic (User Info Data) Kafka REST User Connections (User Social Graph) Unified Log Kafka Search Indexer Samza Elastic Search Search Service User JOIN User Connections … …
37. Segment.com • Buy instead of Build • Event based Analytics • Open-source Client APIs • Write once for the clients • can make use of different services • can be pushed back into product via Webhook Interface, obvs. into the Unified Log 37
38. Gotchas • You need to be super good at Ops to get this stuff working • Schema Evolution is difficult - We are using Apache Avro and Schema Registry from the Confluent folk • Kafka needs to be fault tolerant - it is lower-level than a DB • Must agree upon a Devops Framework for writing these Micro- Services. A well understood JSON over HTTP interface 38
39. THANK YOU to JD Hancock for these amazing stormtrooper photos (what a legend) all photos are shared under CC 2.0 39
40. 40 Thank you for listening Questions ? Dan Harvey will be talking in more detail at the Hadoop User Group mischa@state.com @mischat
