Motorized Butterfly Valves

PROLINE INDUSTRIAL VALVES is Manufacturer and Supplier of Wide Ranges And Various Types of Motorized Butterfly Valves Which Includes Electrical Actuator operated, MOV, On Off Type Actuator Operated, Modulating Type, Proportional Type, Electric Actuator & actuators butterfly valves.

Transcript

2. Types of Industrial Valves industrial valves are mechanical devices that open, close, or partially obstruct passageways to regulate the flow of liquid or gas within a system. With the variety of valve options on the market, finding the one that will provide optimal results in your specific application can be challenging. Having a general understanding of the different valve designs available and how they support specific processing or fluid handling applications is an important first step in the selection process. While they all provide similar functions, industrial valves have evolved into various types with specialized designs and features to meet a number of application-specific requirements. The main types of valves available and their ideal uses are explored below.
3. Balancing Valve Balancing valves are designed to control flow throughout a system by regulating the flow among multiple flow branches. These valves perform several critical functions in HVAC systems and fluid power applications. In commercial heating and cooling systems, for example, balancing valves enable adjustments to GPM under varying loading conditions. They can also be used to balance the load of double-acting cylinders by providing a counterbalancing force.
4. Ball Valve A ball valve is a quarter-turn valve that starts or stops the flow of fluids using a hollow, ball-shaped insert. The valve can be quickly opened or closed with a 90-degree turn of the valve handle. With their relatively simple designs, ball valves are low-maintenance, long-lasting, and exhibit minimal leakage if used properly. These valves are commonly used in fluid, gaseous, and vapor applications that require bubble-tight shut-offs. Although they are mostly used for low- pressure applications, ball valves with metal seats are suitable for high- pressure, high-temperature uses.
5. Butterfly Valve A butterfly valve is a quarter-turn valve with a rotating metal disc that is positioned perpendicular to the stream of fluid when closed. Intermediate rotations of the disc allow for precise regulation of the amount of liquid flowing through a system. They are offered in wafer or lug style variations. Their high accuracy and reliability make them well-suited for a number of industrial applications, including: • Water supply • Wastewater treatment • Fluid-handling power applications • Pharmaceutical, chemical, and food processing services
6. Gate Valve Gate valves are designed primarily for blocking flow rather than regulating it. They contain a plate-like barrier (gate) that can be inserted into the stream of a fluid to block its flow. Gate valves share some operational similarities with globe valves, but they provide less flow restriction when in the fully opened position. Because of this unobstructed flow path, gate valves have significantly reduced head loss when compared with globe valves. However, gate valves are not designed for throttling purposes and may not be capable of producing the positive shut-off that is provided by globe valves. Gate valves are most often used to provide shut-off or isolating capabilities in wastewater plants, power plants, and process plants.
7. Globe Valve A globe valve is a linear motion valve that uses a globe-shaped disc to stop, start, or regulate flow in pipelines. The movable disc, also referred to as a plug, can be closed against a stationary ring seat to constrict flow. To control disc movement, manually operated globe valves rely on hand wheels, while automatic globe valves use actuators and sliding shafts. Globe valves tend to be more leak-proof than other valves and provide a shorter opening-closing time. These general-purpose valves are primarily used for shut-off and regulation in high-temperature applications such as wastewater plants, process plants, and food processing plants.
8. Check Valve Check valves are automatic one-way valves that are designed to allow fluid flow in one direction only. These valves are used in pumps, gas lines, HVAC systems, and other applications requiring one-way fluid movement. Types of check valves include: Lift-type check valve: With lift-type check valves, a ball or piston opens under a specified pressure to allow fluid flow. A decrease in pressure will force the piston or ball into the valve seat, thus closing the valve and preventing backflow.
9. Check Valve Swing check valve: A swing check valve relies on a hinged disc that swings away from the valve seat to permit flow in the forward direction. If the upstream flow stops, the disc returns to the valve seat to prevent backflow. Butterfly check valve: Butterfly check valves consist of two half-circle gates hinged together. Forward flow pushes the gates open, while reverse flow causes them to retract.
10. Motorized Butterfly Valves Pneumatic Control Valve Motorized Ball Valve Pneumatic Actuator Operated Ball Valve
11. ABOUT US Proline Industrial Valves is a biggest manufacturer of high quality Industrial Valves in wide ranges and Electrical & Pneumatic Control Type AUTOMATION Valves. We manufactures product ranges which includes Electrical Actuator Motorized Valves, Pneumatic Control Valves, Electrical Control Valves, Proportionate Modulating Control Valve, 4~20mA input and feedback of 4~20mA Actuator Valves, HVAC Motorized Valves, MOV Ball Valves, MOV Butterfly Valves, Motorized Gate Valves, Motorized Globe Valves, Inching Type Globe Valves, Modulating Type Gate Valves, Modulating Control Valves, Proportionate Valve Positioner, Proportionate Modulating Control Valves, 4~20mA Valve Actuator, 0~10VDC Valve Actuator, Regulating Valves, Actuator Manual Ball Valves, Manual Butterfly Valves, Gear Operated Butterfly Valves, Gate Valves, Globe Valves, Knife Edge Gate Valves, High Performance Butterfly Valves, Centric Design Butterfly Valves, Offset Design Butterfly Valves, Diaphragm Valves, UPVC Ball Valves, UPVC Butterfly Valves, Pneumatic Cylinder Operated
12. Knife Edge Gate Valves, Strainer Swing Check Valves, Water Check Valves, Dual Plate Check Valves, Non Slam Check Valves Disc, Check Valves, Forged Valves, Forged Gate Globe Check Pneumatic Actuator Ball Valves, Pneumatic Actuator Butterfly Valves, Pneumatic Solenoid Valves, Pulse Valves, Diaphragm Solenoid Valves, Y Type Control Valves, Low Pressure Solenoid Valves, Dust Collector Sight Glass Single Window Double Window and many more. Our Products are widely used in manufacturing industries like Refineries, Petrochemicals & Fertilizer Plants, Pharmaceuticals, Oil Exploration, Thermal & Nuclear Plants, Steel Plants, Food & Beverages, Capital Goods Industries, Effluent Treatment & Sewerage Plants, Water Treatment, Cooling Water & Water Supply Plants, Chemical Plants, Agriculture Industries, Rice Mills, OEM Machine Manufacturer Contractor & Consultants, etc. and we sell in cities like Chennai, Bangalore, Hyderabad, Mumbai, Pune, Kolkata, Punjab, Delhi, Chhattisgarh, Rajasthan, Noida and in major industrial belt of India. We have proven track record and reputation for quality and reliability in the Selection, Supply, Delivery, Service and Support of the world’s leading brand names in the Valve Industry. Proline Valves design is appreciated by clients for their attributes which includes its Long Functional Life, Attractive Price, Quick Delivery with multiple product ranges.
13. Our Products motorized upvc butterfly valves USA motorized 3 way ball vales New Zealand motorized control valves Canada motorized ball valves Peru pneumatic control valves Brazil pneumatic actuator ball valves Poland pneumatic actuator butterfly valves Colombia motorized butterfly valves USA
14. Contact Us. Address : 2376/3, Moti Makeriwad, B/h. Mahalaxmi Petrol Pumps, Ahmedabad, Gujarat 380001. Mobile : +91 9825786631 Mail : info@motorizedbutterflyvalves.com
