Serverless Architectures on AWS in practice - OSCON 2018

Serverless Architectures on AWS in practice - OSCON 2018

From functions to containers to databases, serverless is a huge paradigm shift. The ability to only pay for what we use and not worry about underlying infrastructure is very tempting to developers and DevOps engineers, and the rate of innovation in this area has been very rapid across all major public cloud providers. Serverless architectures are the natural evolution of microservices design. While Lambda has become synonymous with serverless in AWS, there are several new and upcoming patterns that take serverless architectures to the next level.

Manish Pandit explains how to identify these patterns and put them to use. Using Marqeta’s efforts to move its payments infrastructure to the public cloud as an example, Manish explores the services that Marqeta considered, customized, hacked around, and successfully implemented as a part of this move.


Manish Pandit

July 19, 2018


  1. Serverless Architectures on AWS in practice Manish Pandit 07/19/2018

  2. None
  3. None
  4. None
  5. None
  6. If I had asked people what they wanted, they would

    have said: “faster horses” -Henry Ford
  7. The Journey

  8. About Me Manish Pandit Director of Platform Engineering @marqeta @lobster1234
  9. None
  10. None
  11. None
  12. Why? Scale technology to support the growing business Use public

    cloud capabilities so we can focus on product innovation
  13. Break down the monolith

  14. Shrink the Infrastructure

  15. Cloud-Native-First Mindset ..and many more

  16. Microservices Independent development, deployment, and scaling of functionally isolated services.

  17. Microservices “Loosely coupled, yet highly aligned”

  18. Microservices You can have microservices without containers and serverless! Containers

    and Serverless are the most optimal way to package and deploy microservices.
  19. Abstractions Bare Metal O/S Application Fn Serverless Containers VMs Hardware

  20. Containers Distributed Applications/Services Economics of Scale - Optimal Resource Utilization

    Being lightweight, they’re fast to deploy and run
  21. Serverless Function as a unit of deployment (FaaS) Pay for

    what you use, never for idle resources 100% abstraction from underlying resources
  22. Serverless Components 1. Functions themselves 2. Events that trigger these

    functions, or handlers Event driven programming - Functions are event handlers You only pay when the handler runs
  23. Lambda Amazon’s FaaS Supports Node, Python, Java 8, C#, Go

    Billed as GB-seconds
  24. Lambda Pricing First 1M requests per month are free 400,000

    GB-seconds per month are free START RequestId: 6bd9cf60-7e2b-11e8-9f4a-ebdea81e794d Version: $LATEST END RequestId: 6bd9cf60-7e2b-11e8-9f4a-ebdea81e794d REPORT RequestId: 6bd9cf60-7e2b-11e8-9f4a-ebdea81e794d Duration: 646.26 ms Billed Duration: 700 ms Memory Size: 128 MB Max Memory Used: 31 MB
  25. Use Cases

  26. Consul Backups GET /v1/catalog/service/mqapi PutObject trigger

  27. Database Replication Jobs Get updates PutObject trigger apply

  28. Async Events publish publish trigger trigger Service A Service B

    Service C ECS
  29. File Processing Pipeline Split PGP & Transfer Payment Networks Banks

    trigger trigger N 1 Object + Metadata
  30. Lambda limits Memory : 128-3008 MB with 64 MB increments

    Time : 300 seconds
  31. Batch Jobs

  32. AWS Batch : Managed Compute https://.. Submitter Job Job Job

    Batch Cloudwatch Event
  33. Containers not Serverless Enough? = ECS minus the Cluster

  34. Logging For Lambdas, Cloudwatch logs For ECS, filebeat agent on

    the host For Fargate, LogStashTcpSocketAppender
  35. Monitoring and Alerting

  36. Testing Docker Compose Localstack Use environment variables for configuration (12-Factor

  37. Gotchas.. - Lambda Cold start on both Python and Java

    - Due to VPC and ENI - Be aware of the retries - Async invocation gets two retries - Sync invocation gets no retries - Apply the Principle of Least Privilege to the Lambda and ECS Roles - S3 triggers - source and destination buckets
  38. None
  39. Tips - Declare connection pools outside of the handler’s scope

    - Write tests! - Test locally - the only error you should be expecting is IAM Permissions error. <role> is not authorized to perform: <operation> on resource: <resource> - Do not create Microliths - Set up billing alerts
  40. Tips - Pick the best tool for the job -

    Do not pick the tool and try to fit the job into it - Beware of the shiny object syndrome - Take measured risks - Production is (mostly) unforgiving
  41. None
  42. “You’re free to choose, but you’re not free from the

    consequences of your choice” - Universal Paradox
  43. Fin Manish Pandit Director of Platform Engineering @marqeta @lobster1234
