Kubernetes 1.7 Local Persistent Storage Demo
Brief overview of the new 1.7 alpha feature for local persistent storage in Kubernetes.
Michelle Au
June 15, 2017
Transcript
9 slides
-
Google Cloud Platform logo 1.7 Local Persistent Storage 6/15/2017 Michelle
Au Software Engineer, Google Github: @msau42 -
Google Cloud Platform Use Cases • Using local storage subject
to node and storage availability • Data gravity (co-locating data and application) • Distributed datastores and filesystems (Cassandra, GlusterFS, etc) • Large caches Cost • Increase disk utilization in baremetal environments • Reduce operator cost for managing distributed storage systems and supporting infrastructure (networking hardware, etc) Performance • Local SSDs in cloud environments Local Persistent Storage Motivations -
Google Cloud Platform Portability • Need to manually schedule pods
to specific nodes, bypassing scheduler • Paths can change across clusters and different environments Accounting • Keep track of which pods using which paths on which nodes • Manual cleanup when pod is terminated Security • Pod can specify any path • Hostpath often disabled by default through pod security policy Hostpath Volume Issues -
Google Cloud Platform Portability • Use Persistent Volumes abstraction to
separate storage details from pod consumption Accounting • Only one Persistent Volume Claim can be bound to a Persistent Volume • API objects with managed lifecycles Security • Only administrators can create Persistent Volumes Local Persistent Volumes Solution -
Google Cloud Platform New volume type: “local” volume • Can
only be used as a Persistent Volume • Scheduler is aware of volume’s node constraints External static provisioner for local volumes • Run as a DaemonSet on every node • Discovers local volumes mounted under configurable directories • Automatically create, cleanup and destroy local Persistent Volumes 1.7 Alpha Details -
Google Cloud Platform 1. StatefulSet where each instance writes to
a local volume 2. Reader pod that reads from one of the local volumes 3. The pods will always be scheduled to the same node that the volume is on Demo -
Google Cloud Platform • Persistent Volume binding happens before pod
scheduling • Doesn’t consider pod resource and scheduling requirements (ie, CPU, pod affinity, etc) • Cannot specify multiple local volumes in a single pod spec • External provisioner cannot correctly detect volume capacity for new volumes created after provisioner has started 1.7 Limitations -
Google Cloud Platform • Local block devices as a volume
source, and for pod consumption • Local volume health monitoring, taints and tolerations • Inline PV (use local disk as ephemeral storage) • Dynamic provisioning Roadmap -
Google Cloud Platform User guide • https://github.com/kubernetes-incubator/external-storage/tree/master/lo cal-volume Implementation tracker
• https://github.com/kubernetes/kubernetes/issues/43640 Proposal • https://github.com/kubernetes/community/pull/306 Documentation
