2019 DockerCon: Kubernetes and CSI Update

Overview of CSI, what is supported in Kubernetes, and what we plan to add in the future.

Transcript

1. Michelle Au Software Engineer, Google Kubernetes SIG-Storage Kubernetes and Container Storage Interface Update
2. Agenda Background on CSI What’s New in Kubernetes? Future Getting Involved
3. Background
4. What is CSI? Specification for orchestrating control plane operations on file and block storage - https://github.com/container-storage-interface/spec - Create and delete - Attach and detach - Mount and unmount - Snapshot and restore Industry standard supported by multiple container orchestrators - Kubernetes - Mesos - Cloud Foundry
5. Vendor Benefits Write one driver that works across multiple orchestrators Develop outside of Kubernetes core - Independent release cycle - Could be closed source
6. Kubernetes Benefits Vendor code does not need to be imported into core repository Vendor code cannot crash core Kubernetes components Core maintainers don’t need to review vendor code - More time to develop core features!
7. End User Benefits Large ecosystem of CSI drivers available - https://kubernetes-csi.github.io/docs/drivers.html - Over 35! Get bug fixes and new features faster without upgrading your Kubernetes cluster
8. Kubernetes Integration
9. apiVersion: v1 kind: PersistentVolumeClaim metadata: name: my-disk spec: storageClassName: fast-storage accessModes: - ReadWriteOnce resources: requests: storage: 100Gi Kubernetes API apiVersion: storage.k8s.io/v1 kind: StorageClass metadata: name: fast-storage provisioner: csi-driver.example.com parameters: foo1: bar1 foo2: bar2
10. What’s New?
11. Kubernetes 1.13 Basic CSI support is GA - Dynamic provisioning, attaching, mounting - 1.0 spec added, 0.3 spec deprecated Existing alpha features - Snapshots - Raw block - Topology
12. Kubernetes 1.14 Features promoted to beta - Raw block - Topology New alpha features - Resizing - Migration of in-tree plugins
13. Future
14. Kubernetes 1.15 and Beyond New alpha features - Ephemeral volumes - Group snapshots - Application snapshots - Volume cloning - Windows OS
15. Driver Management New challenges: - Versioning - Backwards compatibility - Upgrade/downgrade Kubernetes distros can pre-package/manage qualified drivers
16. Getting Involved
17. Kubernetes SIG-Storage Bi-weekly meetings - https://github.com/kubernetes/community/tree/master/sig-storage Slack - #sig-storage on kubernetes.slack.com Me - Github/Slack: msau42 - Twitter: _msau42_
18. First Time Contributions Improve test coverage - Raw block - Resizing - Snapshots - Topology Fixing bugs - Look for issues with “help wanted” label - https://github.com/kubernetes-csi - https://github.com/kubernetes/kubernetes - Filter by label “sig/storage”
19. Questions?
20. [Extra] Driver Deployment Architecture
21. Deployment Architecture
22. [Extra] Vendor Resources
23. Writing a CSI Plugin Developer docs - https://kubernetes-csi.github.io/docs/ Hostpath sample plugin - https://github.com/kubernetes-csi/csi-driver-host-path - Not for production!
24. CSI Spec Testing Validate that your CSI plugin conforms to the CSI spec - csi-sanity test suite - https://github.com/kubernetes-csi/csi-test/tree/master/pkg/sanity
25. Kubernetes Testing Run Kubernetes E2E tests against any CSI driver - https://github.com/kubernetes/kubernetes/tree/master/test/e2e/ storage/external - Prereq: K8s cluster with CSI driver already installed - Future: CSI driver qualification/conformance
