Cast-Free-Arithmetic in Swift v1 with Builds

Have you ever been annoyed by all the casting required to do simple arithmetic between mixed number types in Swift? Many of you who came into Swift after years of Objective-C, myself included, said things like, "Swift is great, but doing simple arithmetic can be quite annoying! So much casting!" On the one hand it brings a higher level of type safety to number types, but on the other it can be an inconvenient amount of extra syntax, especially for simple operations that could otherwise be quite concise. This talk seeks to ease this inconvenience by exploring how best to handle mixed number type operations while contemplating how much type-safety is ok to let go of in the process. Utilizing all the goodies of Swift 2.0 along the way, the talk will also cover protocol extensions, pattern matching, generics, inference, and operator overloading.

Transcript

1. PROPELLER LABS
2. foxinswift.com @RGfox for fox in swift { }
3. Cast-Free Arithmetic in Swift by Rich Fox @RGfox
5. Arithmetic Comparison
6. Arithmetic Comparison Objective-C :
7. Arithmetic Comparison float w = 5; double x = 10; int y = 15; CGFloat z = w + x + y; Objective-C :
8. Arithmetic Comparison float w = 5; double x = 10; int y = 15; CGFloat z = w + x + y; Objective-C : Swift :
9. Arithmetic Comparison float w = 5; double x = 10; int y = 15; CGFloat z = w + x + y; let w:Float = 5 let x:Double = 10 let y:Int = 15 let z:CGFloat = CGFloat(w) + CGFloat(x) + CGFloat(y) Objective-C : Swift :
10. Pre-Swift 2.0
11. Pre-Swift 2.0 • dot syntax for quick conversions.

12. Pre-Swift 2.0 • dot syntax for quick conversions.
 extension Double {
 var c:CGFloat { return CGFloat(self) } //. . . }

 extension Int {
 var c:CGFloat { return CGFloat(self) } //. . . }

 extension Float {
 var c:CGFloat { return CGFloat(self) } //. . . }
 //let y:CGFloat = 1 + x.c
13. Pre-Swift 2.0 • dot syntax for quick conversions.
 • exhaustive implementation, so much repeated code…. extension Double {
 var c:CGFloat { return CGFloat(self) } //. . . }

 extension Int {
 var c:CGFloat { return CGFloat(self) } //. . . }

 extension Float {
 var c:CGFloat { return CGFloat(self) } //. . . }
 //let y:CGFloat = 1 + x.c
14. Protocol Extensions
15. Protocol Extensions • One protocol for all compatible number types.

16. Protocol Extensions • One protocol for all compatible number types.
 • Extend to use a dot syntax for casting

17. Protocol Extensions • One protocol for all compatible number types.
 • Extend to use a dot syntax for casting
 • We also need some pattern matching…

18. But before we do that….
19. How Number Casting Works
20. How Number Casting Works • has initializer for each other compatible type

21. How Number Casting Works • has initializer for each other compatible type
 • i.e. init(_ v: Float ), init(_ v: Double)
22. How Number Casting Works • has initializer for each other compatible type
 • i.e. init(_ v: Float ), init(_ v: Double) • let x: Float = 5.0
23. How Number Casting Works • has initializer for each other compatible type
 • i.e. init(_ v: Float ), init(_ v: Double) • let x: Float = 5.0 • let y = Float(x) OR let y = Float.init(x)
24. Back to Task
25. • Common initializers to define our protocol




 Back to Task
26. • Common initializers to define our protocol




 protocol NumberConvertible {
 init (_ value: Int) init (_ value: Float) init (_ value: Double) init (_ value: CGFloat) }

 Back to Task
27. • Common initializers to define our protocol




 protocol NumberConvertible {
 init (_ value: Int) init (_ value: Float) init (_ value: Double) init (_ value: CGFloat) }

 Back to Task extension CGFloat : NumberConvertible {} extension Double : NumberConvertible {} extension Float : NumberConvertible {} extension Int : NumberConvertible {}
28. • Common initializers to define our protocol




 protocol NumberConvertible {
 init (_ value: Int) init (_ value: Float) init (_ value: Double) init (_ value: CGFloat) }

 z Back to Task extension CGFloat : NumberConvertible {} extension Double : NumberConvertible {} extension Float : NumberConvertible {} extension Int : NumberConvertible {}
29. • Common initializers to define our protocol




 • Looks like something is missing! protocol NumberConvertible {
 init (_ value: Int) init (_ value: Float) init (_ value: Double) init (_ value: CGFloat) }

 z Back to Task extension CGFloat : NumberConvertible {} extension Double : NumberConvertible {} extension Float : NumberConvertible {} extension Int : NumberConvertible {}
31. z Type 'CGFloat' does not conform to protocol 'NumberConvertible'
32. z • CGFloat has no initializer for CGFloat.
 Type 'CGFloat' does not conform to protocol 'NumberConvertible'
33. z • CGFloat has no initializer for CGFloat.
 • Luckily it is trivial to extend one into it. Type 'CGFloat' does not conform to protocol 'NumberConvertible'
34. z • CGFloat has no initializer for CGFloat.
 • Luckily it is trivial to extend one into it. Type 'CGFloat' does not conform to protocol 'NumberConvertible' extension CGFloat{ public init(_ value: CGFloat){ self = value } }
35. Pattern Matching
36. Pattern Matching • Can be used by protocol to figure out it’s type
37. Pattern Matching • Can be used by protocol to figure out it’s type switch self { case let x as CGFloat: print("x is a CGFloat")
 case let x as Float: print("x is a CGFloat")
 case let x as Int: print("x is a CGFloat")
 case let x as Double: print("x is a CGFloat")
 default: print("x is unknown..") }
38. Putting it all together
39. Putting it all together extension NumberConvertible { }
40. Putting it all together extension NumberConvertible { } private func convert<T: NumberConvertible>() -> T { }
41. Putting it all together extension NumberConvertible { } private func convert<T: NumberConvertible>() -> T { } switch self { case let x as CGFloat: return T(x) //T.init(x) case let x as Float: return T(x) case let x as Double: return T(x) case let x as Int: return T(x) default: assert(false, "NumberConvertible convert cast failed!") return T(0) }
42. Putting it all together extension NumberConvertible { } private func convert<T: NumberConvertible>() -> T { } public var c:CGFloat{ return convert() } //... switch self { case let x as CGFloat: return T(x) //T.init(x) case let x as Float: return T(x) case let x as Double: return T(x) case let x as Int: return T(x) default: assert(false, "NumberConvertible convert cast failed!") return T(0) }
44. Castless Conversion
45. Castless Conversion • We can cast without declaring a type




46. Castless Conversion • We can cast without declaring a type



 • let w: Double = 4.4
 let x: Int = 5
 let y: Float = w.convert() + x.convert()
47. Castless Conversion • We can cast without declaring a type



 • Let’s make it easier with operator overloading • let w: Double = 4.4
 let x: Int = 5
 let y: Float = w.convert() + x.convert()
49. Case 1:
50. Case 1: • example test case:
51. Case 1: • example test case: • let x: Int = 5
 let y: CGFloat = 10
 let z: Double = x + y
52. Case 1:
53. Case 1: • Operator overloading

54. Case 1: • Operator overloading
 • Three generics conforming to NumberConvertible

55. Case 1: • Operator overloading
 • Three generics conforming to NumberConvertible
 • Use convert() on lhs and rhs to same type

56. Case 1: • Operator overloading
 • Three generics conforming to NumberConvertible
 • Use convert() on lhs and rhs to same type
 • convert() to infered generic result
57. Case 1: Solution: func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() }
59. Case 2:
60. Case 2: • example test case:


61. Case 2: • example test case:


62. Case 2: • example test case:

 • let x: Int = 5
 let y: CGFloat = 10
 let z: Float = 15
63. Case 2: • example test case:

 • why doesn’t it work? • let x: Int = 5
 let y: CGFloat = 10
 let z: Float = 15 func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() }
65. Which Operator Definition is the Compiler Using?
66. Which Operator Definition is the Compiler Using?
67. + using custom operator
 + using STDLib definition of operator Which Operator Definition is the Compiler Using?
68. •


 (x + y) + z

 (Int + CGFloat) + Float

 Float + Float

 • Double = Float + Float //Can’t return Double

 (uses STDLib version of +) + using custom operator
 + using STDLib definition of operator Which Operator Definition is the Compiler Using?
69. •


 (x + y) + z

 (Int + CGFloat) + Float

 Float + Float

 • Double = Float + Float //Can’t return Double

 (uses STDLib version of +) + using custom operator
 + using STDLib definition of operator Which Operator Definition is the Compiler Using?
70. Compromising with the Compiler
71. Compromising with the Compiler • A Single return type?


72. Compromising with the Compiler • A Single return type?

 public typealias PreferredType = Double public func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: U) -> PreferredType { let v: PreferredType = lhs.convert() let w: PreferredType = rhs.convert() return v+w }
73. Compromising with the Compiler • A Single return type?

 • Compromises being able to return multiple types. public typealias PreferredType = Double public func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: U) -> PreferredType { let v: PreferredType = lhs.convert() let w: PreferredType = rhs.convert() return v+w }
74. Giving the Compiler More Options
75. • Duplicate operator definition, except now…
 lhs and rhs shall be the same type Giving the Compiler More Options
76. • Duplicate operator definition, except now…
 lhs and rhs shall be the same type Giving the Compiler More Options /// `lhs` and `rhs` are the same type! func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() }
77. • Duplicate operator definition, except now…
 lhs and rhs shall be the same type Giving the Compiler More Options /// `lhs` and `rhs` are the same type! func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } /// The original function `lhs` and `rhs` possibly different func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() }
78. Ambiguous use of operator
79. Ambiguous use of operator • let z: Double = w + x + y
80. Ambiguous use of operator • let z: Double = w + x + y
81. Ambiguous use of operator Only works with five or less operands • let z: Double = w + x + y
82. Ambiguous use of operator Only works with five or less operands • let z: Double = w + x + y
83. Ambiguous use of operator Only works with five or less operands • let z: Double = w + x + y
84. A Simpler Solution
85. • Backtrack, remove the extra overload function




 A Simpler Solution
86. func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } • Backtrack, remove the extra overload function




 A Simpler Solution
87. func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } • Backtrack, remove the extra overload function




 A Simpler Solution
88. func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } • Backtrack, remove the extra overload function




 • And let’s just give the compiler what it wants… A Simpler Solution
89. func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } • Backtrack, remove the extra overload function




 • And let’s just give the compiler what it wants… A Simpler Solution
90. func + <T:NumberConvertible, U:NumberConvertible>(lhs: T, rhs: T) -> U { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } func + <T:NumberConvertible, U:NumberConvertible, V:NumberConvertible>(lhs: T, rhs: U) -> V { let v: Double = lhs.convert() let w: Double = rhs.convert() return (v + w).convert() } • Backtrack, remove the extra overload function




 • And let’s just give the compiler what it wants… A Simpler Solution
91. Optimized Operators
92. Optimized Operators extension NumberConvertible { }
93. Optimized Operators extension NumberConvertible { } private typealias CombineType = (Double,Double) -> Double
94. Optimized Operators extension NumberConvertible { } private typealias CombineType = (Double,Double) -> Double private func operate<T:NumberConvertible,V:NumberConvertible>(b:T, @noescape combine:CombineType) -> V{ }
95. Optimized Operators extension NumberConvertible { } private typealias CombineType = (Double,Double) -> Double private func operate<T:NumberConvertible,V:NumberConvertible>(b:T, @noescape combine:CombineType) -> V{ } let x:Double = self.convert() let y:Double = b.convert() return combine(x,y).convert()
96. Optimized Operators extension NumberConvertible { } public func + <T:NumberConvertible, U:NumberConvertible,V:NumberConvertible>(lhs: T, rhs: U) -> V { return lhs.operate(rhs, combine: + ) } public func - <T:NumberConvertible, U:NumberConvertible,V:NumberConvertible>(lhs: T, rhs: U) -> V { return lhs.operate(rhs, combine: - ) } /// ... other operators ... private typealias CombineType = (Double,Double) -> Double private func operate<T:NumberConvertible,V:NumberConvertible>(b:T, @noescape combine:CombineType) -> V{ } let x:Double = self.convert() let y:Double = b.convert() return combine(x,y).convert()
97. Expression Too Complex
98. Expression Too Complex • Expression was too complex to be solved in reasonable time; consider breaking up the expression into distinct sub-expressions
99. Expression Too Complex Seems to happens more easily when compiler has harder time choosing an operator to use • Expression was too complex to be solved in reasonable time; consider breaking up the expression into distinct sub-expressions
100. Expression Too Complex Seems to happens more easily when compiler has harder time choosing an operator to use
 Many definitions for a single arithmetic operator? • Expression was too complex to be solved in reasonable time; consider breaking up the expression into distinct sub-expressions
101. Expression Too Complex Seems to happens more easily when compiler has harder time choosing an operator to use
 Many definitions for a single arithmetic operator?
 Compiler has too much to do? • Expression was too complex to be solved in reasonable time; consider breaking up the expression into distinct sub-expressions
102. What to do about it?
103. What to do about it? • Rage tweet @clattner_llvm ? #ExpressionTooComplex







104. What to do about it? • Rage tweet @clattner_llvm ? #ExpressionTooComplex






 • Maybe file a radar if it seems not complex…
106. Overall Conclusion
107. Overall Conclusion • We can get castless arithmetic working with constraints
108. Overall Conclusion • We can get castless arithmetic working with constraints • mild inference confusion
109. Overall Conclusion • We can get castless arithmetic working with constraints • mild inference confusion • potential for complex expression error

110. Overall Conclusion • We can get castless arithmetic working with constraints • mild inference confusion • potential for complex expression error
 • Dot property conversions - let z:Int = x.i + y.i
111. Overall Conclusion • We can get castless arithmetic working with constraints • mild inference confusion • potential for complex expression error
 • Dot property conversions - let z:Int = x.i + y.i • add convenience
112. Overall Conclusion • We can get castless arithmetic working with constraints • mild inference confusion • potential for complex expression error
 • Dot property conversions - let z:Int = x.i + y.i • add convenience • doesn't take away type safety
113. Thanks! foxinswift.com @RGfox for fox in swift { } https://github.com/Nadohs/Cast-Free-Arithmetic-in-Swift
