5分で分かった気になれる Amazon FSx for NetApp ONTAPのSnapshot クラスメソッド株式会社 のんピ 1
2 自己紹介 { "本名": "山本 涼太 (覚えなくていいです)", "部署": "AWS事業本部 コンサルティング部",
"前職": "インフラエンジニア in データセンター", "興味のあること": "面白そうなブログネタ探し", "好きなAWSサービス": [ "AWS Transit Gateway", "AWS Step Functions" "Amazon FSx for NetApp ONTAP" ], "称号" : [ "2023 Japan AWS All Certifications Engineer", "2023 Japan AWS Ambassador", ] }
タイトル 2021/10/5 〇〇部 氏名 みなさん Amazon FSx for NetApp ONTAPのこと
実は気になっていると思います
4 今日伝えたいこと ONTAP の Snapshot はすごいぞ
5 そもそもSnapshotとは ボリュームのある瞬間の状態 = 論理バックアップ
6 ファイルをリストアしたい場合に活躍 ボリュームごとリストア ファイル単位でリストア
7 ブログ読んでください Amazon FSx for NetApp ONTAPのスナップ ショット機能を試してみた ONTAPにおけるSnapshotの操作方法は
8 どうして「ONTAP の Snapshotはすごいぞ」なのか 爆速でSnapshotの取得 / リストアができる
9 ここで疑問 なぜONTAPは 爆速でSnapshotの取得 / リストアできるのか
10 それは WAFL × Point-in-Time方式の恩恵
11 ゑ? WAFL? Point-in-Time? 何それ?
12 WAFLとは Write Anywhere File Layout というONTAPのファイ ルシステム
13 Snapshotと関連のあるWAFLの挙動 データ更新は既存ブロックを上書きせず、 新規ブロックとして追記する 更新時にデータブロックを上書きする方式 更新時にデータブロックの追記をする方式 (更新前のデータブロックは後で消去される )
14 ここで Point-in-Time方式の Snapshotが活きてくる
15 一般的なSnapshotはCopy-on-Write方式 データブロック更新時に Snapshot用の領域に退避する 1度の書き込みで内部的には2回の書 き込み処理が発生 1. 元データをSnapshot領域に退避 2. 元データを上書きする
= パフォーマンスへの影響が大きい
16 ONTAPのSnapshotはPoint-in-Time方式 Snapshot取得時にポインタを保持 • データブロックのコピーは発生しな い • Snapshotで保持しているポインタ に紐づくデータブロックを削除しな い
少ないIOで論理バックアップを実現
17 リストア時の挙動 Snapshot取得で保持している ポインタに貼り直す
18
